EOA5654AOX
EN
Oven
User Manual

Advertisement

Table of Contents
loading

Related Manuals for Electrolux EOA5654AOX

Summary of Contents for Electrolux EOA5654AOX

  • Page 1 EOA5654AOX Oven User Manual...

  • Page 2: Table Of Contents

    14. ENERGY EFFICIENCY.................. 35 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.

  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

  • Page 4: Safety Instructions

    Always use oven gloves to remove or put in • accessories or ovenware. Before carrying out any maintenance, disconnect the • appliance from the power supply. Ensure that the appliance is switched off before • replacing the lamp to avoid the possibility of electric shock.
  • Page 5 ENGLISH electrical ratings of the mains power • Deactivate the appliance after each supply. use. • Always use a correctly installed • Be careful when you open the shockproof socket. appliance door while the appliance is • Do not use multi-plug adapters and in operation.
  • Page 6 • Do not clean the catalytic enamel (if the appliance is in operation. Heat applicable) with any kind of detergent. and moisture can build up behind a 2.5 Internal lighting closed furniture panel and cause...

  • Page 7: Product Description

    ENGLISH 3. PRODUCT DESCRIPTION 3.1 General overview Control panel Knob for the heating functions Display Control knob (for the temperature) Plus Steam Heating element Lamp Cavity embossment Shelf support, removable Shelf positions 3.2 Accessories • Core temperature sensor To measure how far the food is •...

  • Page 8: Before First Use

    4.2 Display A. Timer / Temperature B. Heat-up and residual heat indicator C. Core temperature sensor (selected models only) D. Door lock (selected models only) E. Hours / minutes F. Demo mode (selected models only) G. Clock functions 5. BEFORE FIRST USE...
  • Page 9 ENGLISH Oven func‐ Application Oven func‐ Application tion tion To bake on up to three This function is de‐ shelf positions at the signed to save energy same time and to dry during cooking. For the Moist Fan food. cooking instructions re‐ Baking Set the temperature 20 fer to "Hints and tips"...

  • Page 10: Fast Heat Up

    6.3 Setting a heating function CAUTION! Do not refill the cavity 1. Turn the knob for the heating embossment with water functions to select a heating function. during cooking or when 2. Turn the control knob to select the the oven is hot.

  • Page 11: Clock Functions

    ENGLISH 7. CLOCK FUNCTIONS 7.1 Clock functions table 2. Press to confirm and set the minutes. Clock func‐ Application The display shows and the set tion hour. "00" flashes. 3. Press to set the current To show or change the minutes.

  • Page 12: Using The Accessories

    7.5 Setting the TIME DELAY 1. Press again and again until function "00" flash in the display. 2. Press to set the seconds 1. Set a heating function. and than the minutes. 2. Press again and again until When the time you set is longer than starts to flash.

  • Page 13: Inserting The Accessories

    ENGLISH the cavity. When the oven calculates the provisional duration time for the first time, the symbol flashes in the display. When the calculation ends, the display shows the duration of the cooking. Calculations run in the background during the cooking and the duration value in the display is updated if necessary.

  • Page 14: Additional Functions

    CAUTION! Do not clean the telescopic runners in the dishwasher. Do not lubricate the telescopic runners. 1. Pull out the right and left hand telescopic runners. Wire shelf and baking tray / deep pan together: °C Push the baking tray / deep pan between the guide bars of the shelf support and the wire shelf on the guide bars above.

  • Page 15: Hints And Tips

    ENGLISH 9.2 Using the Function Lock function operates and you do not change the oven temperature. You can turn on the Function Lock function only when the oven operates. Temperature (°C) Switch-off time When the Function lock is on the temperature and time settings of a 30 - 115 12.5...
  • Page 16 If you cannot find the settings for a Use 150 ml of water. special recipe, look for the similar one. Food Tem‐ Time The oven has a special system which pera‐ (min) circulates the air and constantly recycles ture the steam.

  • Page 17: Baking And Roasting

    ENGLISH Roasting Use the glass baking dish. Food Time (min) Use the second shelf position. Use 200 ml of water. Focaccia 15 - 25 Meat 15 - 25 Food Tempera‐ Time ture (°C) (min) Pasta 15 - 25 Roast beef 50 - 60 Pizza 15 - 25...
  • Page 18 Food Top / Bottom Heat True Fan Cooking Time Com‐ (min) ments Tempera‐ Shelf po‐ Tempera‐ Shelf po‐ ture (°C) sition ture (°C) sition Plum 50 - 60 In a bread cake Small 140 - 150 20 - 30...
  • Page 19 ENGLISH Food Top / Bottom Heat True Fan Cooking Time Com‐ (min) ments Tempera‐ Shelf po‐ Tempera‐ Shelf po‐ ture (°C) sition ture (°C) sition Rich fruit 110 - 120 In a 24 cm cake cake mould Victoria 2 (left and 50 - 60 In a 20 cm sandwich...
  • Page 20 Food Top / Bottom Heat True Fan Cooking Time Com‐ (min) ments Tempera‐ Shelf po‐ Tempera‐ Shelf po‐ ture (°C) sition ture (°C) sition Cannello‐ 180 - 190 180 - 190 25 - 40 In a mould 1) Preheat the oven for 10 minutes.

  • Page 21: Turbo Grilling

    ENGLISH Food Top / Bottom Heat True Fan Cooking Time Com‐ (min) ments Tempera‐ Shelf po‐ Tempera‐ Shelf po‐ ture (°C) sition ture (°C) sition Pheasant 90 - 120 Whole Fish Food Top / Bottom Heat True Fan Cooking Time Com‐...
  • Page 22 Food Tempera‐ Time (min) Food Tempera‐ Time (min) ture (°C) ture (°C) Roast beef 190 - 200 5 - 6 Saddle of 160 - 180 40 - 60 or fillet, rare lamb, 1 - 1.5 Roast beef 180 - 190 6 - 8 or fillet, me‐...
  • Page 23 ENGLISH Food Accessories Temperature Shelf po‐ Time (min) (°C) sition Sweet rolls, 12 baking tray or dripping 20 - 30 pieces Rolls, 9 pieces baking tray or dripping 30 - 40 Pizza, frozen, wire shelf 10 - 15 0.35 kg Swiss roll baking tray or dripping 25 - 35...
  • Page 24 Food Accessories Temperature Shelf po‐ Time (min) (°C) sition Poached vege‐ baking tray or dripping 35 - 45 tables, 0.4 kg Vegetarian pizza pan on wire shelf 25 - 30 omelette Vegetables, baking tray or dripping 25 - 30 mediterrean 0.7 kg...

  • Page 25: Core Temperature Sensor

    ENGLISH Food Temperature (°C) Time (h) Vegetables for sour 60 - 70 5 - 6 Mushrooms 50 - 60 6 - 8 Herbs 40 - 50 2 - 3 Fruit Food Temperature Time (h) Shelf position (°C) 1 position 2 positions Plums 60 - 70 8 - 10...
  • Page 26 Food Function Acces‐ Shelf Tem‐ Time (min) Comments sories posi‐ pera‐ tion ture (°C) Small True Fan Baking 150 - 20 - 35 Put 20 small cake Cooking / tray cakes per one Fan Cook‐ baking tray. Small True Fan...

  • Page 27: Care And Cleaning

    ENGLISH Food Function Acces‐ Shelf Tem‐ Time (min) Comments sories posi‐ pera‐ tion ture (°C) Toast Grilling Wire max. 2 - 3 minutes Preheat the oven 4 - 6 shelf first side; 2 - 3 for 3 minutes. pieces minutes sec‐ ond side Beef bur‐...

  • Page 28: Cleaning Reminder

    1. Put 250 ml of white vinegar into the cavity embossment at the bottom of the oven. Use maximum 6% vinegar without any additives. 2. Let the vinegar dissolve the residual limestone at the ambient temperature for 30 minutes.
  • Page 29 ENGLISH 11.8 Removing and installing door The oven door has three glass panels. You can remove the oven door and the internal glass panels to clean them. Read the whole "Removing and installing door" instruction before you remove the glass panels. The oven door may close if you try to remove the glass panels before you remove...

  • Page 30: Replacing The Lamp

    7. Hold the door trim (B) on the top edge of the door at the two sides and push inwards to release the clip seal. 8. Pull the door trim to the front to remove it. 9. Hold the door glass panels by their top edge and carefully pull them out one by one.

  • Page 31: Troubleshooting

    ENGLISH 12. TROUBLESHOOTING WARNING! Refer to Safety chapters. 12.1 What to do if... Problem Possible cause Remedy You cannot activate or op‐ The oven is not connected Check if the oven is cor‐ erate the oven. to an electrical supply or it rectly connected to the is connected incorrectly.
  • Page 32 Problem Possible cause Remedy The display shows "C2". You want to start the Cat‐ Remove the core tempera‐ alysis or Defrost function, ture sensor plug from the but you did not remove the socket. core temperature sensor plug from the socket.

  • Page 33: Installation

    ENGLISH Problem Possible cause Remedy The appliance is activated The demo mode is activa‐ 1. Deactivate the oven. and does not heat up. The ted. 2. Press and hold the but‐ fan does not operate. The display shows "Demo". 3. The first digit on the display and Demo indi‐...

  • Page 34: Electrical Installation

    13.1 Building In min. 550 min. 560 min. 550 min. 560 13.2 Securing the appliance to 13.3 Electrical installation the cabinet The manufacturer is not responsible if you do not follow the safety precautions from the Safety chapters. This appliance is supplied with a main plug and a main cable.

  • Page 35: Energy Efficiency

    (blue and brown cables). 14. ENERGY EFFICIENCY 14.1 Product Fiche and information according to EU 65-66/2014 Supplier's name Electrolux Model identification EOA5654AOX Energy Efficiency Index 81.2 Energy efficiency class Energy consumption with a standard load, con‐ 0.93 kWh/cycle...

  • Page 36: Environmental Concerns

    Cooking with fan meal warm. The residual heat indicator When possible, use the cooking or temperature appears on the display. functions with fan to save energy. Cooking with the lamp off Residual heat Turn off the lamp during cooking. Turn it If a programme with the Duration or End on only when you need it.
  • Page 37 ENGLISH...
  • Page 38 www.electrolux.com...
  • Page 39 ENGLISH...
  • Page 40 www.electrolux.com/shop...
