Summary of Contents for YOKOGAWA UTAdvanced Series

  • Page 1 User’s Manual UTAdvanced Series Communication Interface (RS-485, Ethernet) User’s Manual IM 05P07A01-01EN IM 05P07A01-01EN 11th Edition...
  • Page 2: Introduction

    Introduction Thank you for purchasing the UTAdvanced Series digital indicating controller (hereinafter referred to as “UTAdvanced”). This manual describes how to use the communication functions (Ethernet and serial communication) of the UTAdvanced. Read this manual thoroughly beforehand to ensure correct use of the UTAdvanced.
  • Page 3: Intended Readers

    ● Under no circumstances may the contents of this manual, in part or in whole, be transcribed or copied without our permission. ● The document concerning TCP/IP software has been created by Yokogawa based on the BSD Networking Software, Release 1 that has been licensed from the University of California.
  • Page 4: Trademarks

    ● Our product names or brand names mentioned in this manual are the trademarks or registered trademarks of Yokogawa Electric Corporation (hereinafter referred to as YOKOGAWA). ● Microsoft, MS-DOS, Windows, Windows XP, and Windows Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
  • Page 5: How To Use This Maunual

    How to Use This Maunual Usage First read through the Operation Guide to understand the basic operation and then read this manual. This user’s manual is organized into Chapters 1 to 13 as shown below. Chapter Title and Description Overview Describes types of communication and communication specifications.
  • Page 6: Table Of Contents

    Contents Introduction ............................i Intended Readers ..........................ii Notice ............................. ii Trademarks ............................. iii Symbols Used in This Manual ......................iii How to Use This Maunual ........................ iv Chapter 1 Overview UTAdvanced Communication ................... 1-1 RS-485 Communication (for UTAdvanced with RS-485 Communication)......1-2 1.2.1 Communication Specifications ....................1-2 Ethernet Communication (for UTAdvanced with Ethernet Communication) .....
  • Page 7 Contents 3.2.6 Commands and Responses ....................3-26  BRD Reading I relays on a bit-by-bit basis ..............3-27  BWR Writing data into I relays on a bit-by-bit basis ............3-27  BRR Reading I relays on a bit-by-bit basis in a random order ........3-28 ...
  • Page 8 Contents Chapter 5 Coordinated Operation Overview .......................... 5-1 Coordinated Items ......................5-2 Starting Coordinated Operation ..................5-4 Chapter 6 Functions and Applications of D Registers (for UT55A/UT52A/UP55A) Overview .......................... 6-1 Conventions Used in D Register Tables ................6-2 Classification of D Registers .................... 6-3 UT55A/UT52A/UP55A D Registers .................. 6-5 6.4.1 Process Monitoring and Program Pattern for UP55A (D2001 to D2300) .......6-5 Process Data Area .........................6-9...
  • Page 9 Contents For Output Ladder Calculation (D7101 to D7200) .............6-120 Status Registers (D7201 to D7300) ...................6-122 Constant Register (D7301 to D7500) ................6-124 Input Range / Scale (D7501 to D7600) (Read only) ............6-124 6.4.10 Input / Output Terminal Status Register (D7601 to D7700) ..........6-126 6.4.11 Program Pattern for UP55A (D8001 to D9000) ..............6-130 Pattern Data Setting (D8001 to D8100) ................6-130 Reading Pattern Data (D8001 to D8100) ................6-131...
  • Page 10 Contents 7.3.3 Input / Output Terminal Status (6305 to 6560) ..............7-26 DI Terminals and DO Terminals (6305 to 6560) ..............7-29 Reading via Communication ..................7-30 GREEN Series Compatible I Relays ................7-31 7.5.1 Compatibility with GREEN Series Controllers ..............7-31 7.5.2 Conventions Used in I Relay Tables ..................7-31 7.5.3 Status (0001 to 0192) ......................7-32...
  • Page 11 Contents System Setting (D6401 to D6500)..................8-89 Free Area (D6501 to D7000) ....................8-89 6.4.7 T Parameter (D6701 to D6800) ....................8-90 T Parameter (D6701 to D6800) ....................8-91 Free Area (D6801 to D7000) ....................8-91 8.4.8 Registers for Ladder Program (D7001 to D7600) ..............8-92 For Input Ladder Calculation (D7001 to D7100) ..............8-98 For Output Ladder Calculation (D7101 to D7200) ...............8-99 Status Registers (D7201 to D7300) ...................8-101...
  • Page 12 Contents Control (Status) Relay (5281 to 5408)..................9-23 Special Relay (5409 to 5536) ....................9-23 Internal Relay (5537 to 5792) ....................9-24 Peer-to-peer Communication Register (6049 to 6304) ............9-24 9.3.3 Input / Output Terminal Status (6305 to 6560) ..............9-25 DI Terminals and DO Terminals (6305 to 6560) ..............9-28 Reading via Communication ..................
  • Page 13 Contents 10.6.9 D Registers Converted for GREEN Series .................10-54 10.6.10 D Registers Differring in Content from GREEN Series ............10-55 Chapter 11 Functions and Applications of I Relays (for UM33A) 11.1 Overview .........................11-1 11.2 Classification of I Relays ....................11-2 11.3 UM33A I Relays .......................11-4 11.3.1 Function Status (4001 to 5024) ....................
  • Page 14 Contents 12.5.1 Compatibility with GREEN Series Controllers ..............12-42 12.5.2 Interpretation of D Register Tables ..................12-42 12.5.3 Process Data and User Area (D0001 to D0100) ..............12-44 12.5.4 Operation Mode and Operation-related Parameters (D0201 to D0300) ......12-45 12.5.5 SP Parameters (D0301 to D0500) ..................12-46 12.5.6 Control Action Parameters (D0901 to D1000) ..............12-47 12.5.7 Common Function Parameters (D1001 to D1100) .............12-48 12.5.8 PV Input, and Limit Control Output Parameters (D1201 to D1300) ........12-49...
  • Page 15 Contents 14.4.5 P Parameter (D4701 to D4800) ..................14-58 P parameter (D4701 to D4770) ..................14-59 P parameter (D4771 to D4800) ..................14-60 14.4.6 10-segment Linearizer Setting Parameter (D4801 to D5000) ..........14-61 10-segment Linearizer Setting (D4801 to D5000) ..............14-63 14.4.7 Setup Parameters (D5001 to D7000) .................14-64 Control Function Setting (D5001 to D5100) ...............14-79 Input Setting (D5101 to D5300)..................14-80 Output Setting (D5301 to D5400) ..................14-83...
  • Page 16 Contents 15.3 UT75A I Relays ......................15-4 15.3.1 Function Status (4001 to 5024) ....................15-4 System Error, Input Error, and Operation Mode (4001 to 4320) ........15-11 Alarm and Alarm Latch (4321 to 4576)................15-12 SP Number, PID Number, Segment Number, and Program Operation Status (4577 to 4704)......................15-13 Key (4705 to 4768) ......................15-13 Display and Program Segment (4769 to 5024) ..............15-14...
  • Page 17 Blank Page...
  • Page 18: Chapter 1 Overview

    Rear Ethernet terminal UT35A/UP55A/ Modbus/TCP Touch panel – communication (E3-terminal area) UP35A: PCL (sequencer) Type 3 = 2 *: GREEN Series controllers are the digital indicating controllers of YOKOGAWA. ► Terminal position: UTAdvanced Operation Guide or User’s Manual IM 05P07A01-01EN...
  • Page 19: Communication (For Utadvanced With Rs-485 Communication)

    Example: For details on wiring, refer to Operation Guide or User’s Manual. RS-485/ RS-232C converter Model: ML2 of YOKOGAWA is recommended. Up to 31 connected slaves with a maximum length of 1200 m RS-485 RS-485 RS-485 RS-485 communication address = 01...
  • Page 20: Ethernet Communication (For Utadvanced With Ethernet Communication)

    Ethernet Communication (for UTAdvanced with Ethernet Communication) The UT55A/UT35A with Ethernet communication can be connected to an IEEE802.3- compliant network (10BASE-T/100BASE-TX) and are capable of exchanging data with host computers, such as personal computers or PLCs (sequencers), using the MODBUS/ TCP protocol.
  • Page 21 VJET* IP address [192.168.1.2] RS-485 communication (Modbus/RTU) RS-485 RS-485 RS-485 communication address = 02 communication address = 03 communication address = 10 *: VJET is the converter of YOKOGAWA. See VJET User’s Manual when using the VJET. IM 05P07A01-01EN...
  • Page 22: Peer-To-Peer Communication (For Utadvanced With Rs-485 Communication)

    1.4 Peer-to-peer Communication (for UTAdvanced with RS-485 Communication) Peer-to-peer communication is a function which can be used in the ladder program of UTAdvanced and which allows sending and receiving data for computation control among devices via communication. Peer-to-peer communication enables up to 32 UTAdvanced controllers to be connected. Of these UTAdvanced controllers, each of the units of address Nos.
  • Page 23: Coordinated Communication (For Utadvanced With Rs-485 Communication)

    Coordinated Communication (for UTAdvanced with RS-485 Communication) Coordinated operation is a function in which a UTAdvanced controller is used as the master controller, and a number of the UTAdvanced controllers are connected to each other as slave controllers and operated according to the operation of the master controller.
  • Page 24: D Registers And I Relays

    D Registers (UT35A-J)”, or “Chapter 14 Functions and Applications of D Registers (UT75A)”in this manual. *1: GREEN Series controllers are the digital indicating controllers of YOKOGAWA. ► UT55A/UT52A/UP55A Details of D registers: Chapter 6 Functions and Applications of D Registers (for UT55A/UT52A/ UP55A) Compatibility with the GREEN Series controllers: 6.6 GREEN Series Compatible D Registers...
  • Page 25 1.6 D registers and I relays I relays I relays are used for ladder program, Modbus communication, PC link communication, and contact input / output function. If communication is newly performed in the UTAdvanced, I relays I4001 to I7072 are used.
  • Page 26: Setting Rs-485 Communication (For Utadvanced With Rs-485 Communication)

    Chapter 2 Setting Communication Functions 2.1 Setting Parameters 2.1.1 Setting RS-485 Communication (for UTAdvanced with RS-485 communication) This section describes the setting parameters and setting ranges of the UTAdvanced for using the communication functions. Set the required parameters referring to the UTAdvanced Operation Guide or User’s Manual. Setting Display Parameter Setting Display UT75A/UT55A/UT35A:/UP55A/PU35A Operation Display >...
  • Page 27 2.1 Setting Parameters 38400 bps can be specified when the UT75A/UT55A/UT35A/UP55A/UP35A suffix code Type 3 = 1 or UT52A/UT32A/UT32A-D/UP32A/UM33A suffix code Type 2 = 1. This parameter may not be displayed depending on the parameter display level (LEVL) setting. UT75A/UT55A/UT52A/UT35A/UT32A/UT32A-D/UP55A/UP35A/UP32A only. UT75A/UT55A/UT52A/UT35A/UT32A/UT32A-D only. UT75A/UP55A only.
  • Page 28: Setting Ethernet Communication (For Utadvanced With Ethernet Communication)

    2.1 Setting Parameters 2.1.2 Setting Ethernet Communication (for UTAdvanced with Ethernet communication) Setting Display Parameter Setting Display Operation Display > PARAMETER and Left arrow keys simultaneously for 3 seconds (to the [CTL] Menu Display) > Right arrow key (to the [ETHR] Menu Display in E3) > SET/ENTER key (The setting parameter is displayed.) (E3 indicating the terminal area is displayed on Group display.) Setting Details...
  • Page 29 2.1 Setting Parameters Description ● High-speed response mode Set the address of the device for which the process data high-speed response function is used. ► Setting details of high-speed response mode: 4.6 Process Data Hight-Speed Response Function ● Baud rate Set the same baud rate as the host computer that the controller is to be connected to. The baud rate unit is bps (bits per second).
  • Page 30: Setting Coordinated Operation

    2.1 Setting Parameters 2.1.3 Setting Coordinated Operation Parameter Setting Display UT75A/UT55A/UT35A/UP55A/UP35A: Operation Display > PARAMETER and Left arrow keys simultaneously for 3 seconds (to the [CTL] Menu Display) > Right arrow key (to the [R485] Menu Display in E3 or E4 ) > SET/ENTER key (The setting parameter is displayed.) *1: Only UT75A/UT55A/UP55A.
  • Page 31: Setting Communication Write Permit

    2.2 Setting Communication Write Permit Writing to registers via all communication protocols can be permitted and prohibited. (When the writing is being prohibited, the response returns as "normal" if the communication is performed, but the writing is not performed.) However, communication using the light-loader (on the front panel) is possible. Writing to registers via communication is possible only when the parameter COM.W (communication write enable/disable) in the KLOC menu is set to OFF (enable).
  • Page 32: Chapter 3 Description Of Rs-485 Communication

    Chapter 3 Description of RS-485 Communication (for UTAdvanced with RS-485 Communication) Modbus Communication 3.1.1 Overview The UTAdvanced can communicate with devices such as PCs, PLCs (sequencer), and touch panels by using Modbus communication. With Modbus communication, these devices can exchange dada with UTAdvanced by reading/writing the internal registers (D registers and I relays) of the UTAdvanced.
  • Page 33 “normal.” However, the data cannot be written to D registers / I relays. For the 2-wire connection of the UTAdvanced series with DAQSTATION series, set the "Command wait time" of the DAQSTATION to 10 ms or more. In case of the 2-wire connection with the MW100 Data acquisition unit via Modbus master function, set the "Gap between messages"...
  • Page 34: Configuration Of Messages

    3.1 Modbus Communication 3.1.2 Configuration of Messages The structure of messages sent to the UTAdvanced from the host computer is as follows: Message start Address No Message end Element Function code Data Error check mark (ADR) mark 2n (variable Number of bytes in RTU mode None None length)
  • Page 35 3.1 Modbus Communication  Specifying D registers / I relays When you use a commercially available SCADA or the like or a user-created communication program, you must be careful when specifying D register / I relay numbers contained in messages because in both cases, you cannot use the original D register / I relay numbers as they are.
  • Page 36 3.1 Modbus Communication  RTU Mode In the RTU mode, error checking is performed by the cyclic redundancy check (CRC-16). Of all message blocks (from communication address through to final data), eight bits (excluding start bit, stop bit and parity bit) are aligned serially, and the remainder (16 bits) when the result is divided by predetermined binary 17 bits becomes the CRC-16.
  • Page 37 3.1 Modbus Communication Showing Results of Error Checking (CRC) of Values 0 to 255 by A001h Number 0000 C0C1 C181 0140 C301 03C0 0280 C241 Result Number C601 06C0 0780 C741 0500 C5C1 C481 0440 Result Number CC01 0CC0 0D80 CD41 0F00 CFC1...
  • Page 38: Configuration Of Responses (Response From Utadvanced)

    3.1 Modbus Communication 3.1.3 Configuration of Responses (response from UTAdvanced) If the instruction message from the host computer is normal and the address is for itself, the UTAdvanced moves to the process execution phase after it judges that the received content is normal.
  • Page 39: Specifying Broadcast

    3.1 Modbus Communication 3.1.4 Specifying Broadcast This function allows multiple instruments specified by respective addresses to receive commands. (1) Broadcast specification is executed with the following addresses specified to the address No. in the command: “00”: All controllers supporting Modbus on network “F9”: All UTAdvanced controllers on network (2) This command functions regardless of communication address.
  • Page 40: Messages And Responses

    3.1 Modbus Communication 3.1.5 Messages and Responses These instruction words are used so that the host computer obtains the D register and I relay information of the UTAdvanced. List of Function Codes Code No. Function Description Up to 256 I relays can be read continuously (I4001 to I7072). Reading of multiple I relays Reading of multiple D Up to 100 D registers can be read continuously (D0001 to D7600*).
  • Page 41: Reading Multiple I Relays

    3.1 Modbus Communication  01 Reading multiple I relays  Function The content of I relays is read continuously for the specified number of relays from the specified I relay No. • The maximum number of relays that can be read at a time is 256. •...
  • Page 42: Reading Multiple D Registers

    3.1 Modbus Communication  03 Reading multiple D registers  Function The content of D registers is read continuously for the specified number of registers from the specified D register No. • The maximum number of registers that can be read at a time is 100. •...
  • Page 43: Writing To An I Relay

    3.1 Modbus Communication  05 Writing to an I relay  Function Data is written to the specified I relay No. • The number of relays that can be written at a time is 1. • For details on the response format at an error, see “● Response in an error state” in “3.1.3 Configuration of Responses (response from UTAdvanced).”...
  • Page 44: Loopback Test

    3.1 Modbus Communication  08 Loopback test  Function This is used to check the communication connection. • For details on the response format at an error, see “● Response in an error state” in “3.1.3 Configuration of Responses (response from UTAdvanced).” •...
  • Page 45: Writing To Multiple I Relays

    3.1 Modbus Communication  15 Writing to multiple I relays  Function Data is written to I relays continuously for the specified number of relays from the specified relay number. • The maximum number of relays that can be written at a time is 256. •...
  • Page 46: Writing To Multiple D Registers

    3.1 Modbus Communication  16 Writing to multiple D registers  Function Data is written to D registers continuously for the specified number of registers from the specified D register No. • The maximum number of registers that can be written at a time is 50. •...
  • Page 47: Random Reading

    3.1 Modbus Communication  66 Random reading  Function The register data of register Nos. specified at random is read. • Register Nos. can be specified from all register areas. • The maximum number of registers that can be set is 100. •...
  • Page 48: Random Writing

    3.1 Modbus Communication  67 Random writing  Function Data is written to the register Nos. specified at random. • Register Nos. can be specified from all register areas. • The maximum number of registers that can be written to at a time is 50. •...
  • Page 49: Specify Monitor

    3.1 Modbus Communication  68 Specify monitor  Function The register No. specified at random can be specified for monitoring. •The maximum number of registers that can be specified for monitoring is 100. • For details on the response format at an error, see “● Response in an error state” in “3.1.3 Configuration of Responses (response from UTAdvanced).”...
  • Page 50: Writing To Multiple D Registers For Program Pattern

    3.1 Modbus Communication  70 Writing to multiple D registers for program pattern  Function Data is written to D registers continuously for the specified number of registers from the specified D register No. Can be specified register areas: D8001 to D9000. •...
  • Page 51: Pc Link Communication

    *2: If the setting of IN (input type) is changed, the parameters related to ranges or scales such as target setpoint etc. will be initialized. Overview of PC Link Communication Connection RS-232C RS-485/ Model: ML2 of YOKOGAWA is recommended. RS-232C RS-485 converter Up to 31 connected slaves with a maximum length of 1200 m...
  • Page 52: Configuration Of Commands

    3.2 PC Link Communication 3.2.2 Configuration of Commands The structure of commands sent to the UTAdvanced from the host computer is as follows: Number of bytes Variable length Element Address Response Command Data to command Checksum ETX No. (ADR) No. (01) waiting time corresponding (1) STX (Start of Text) This indicates the start of the command.
  • Page 53 3.2 PC Link Communication (7) Checksum The ASCII codes of text from the character following STX up to before the checksum are added one byte at a time. The lowermost byte of the addition result is removed, and an ASCII text string of two bytes expressed in Hex is taken to be the checksum. This column is required only when performing PC link communication with a checksum.
  • Page 54: Configuration Of Responses

    3.2 PC Link Communication 3.2.3 Configuration of Responses The UTAdvanced responses to commands sent from a host computer are configured as shown below according to whether execution of operation is normal or ends in error. When data outside the parameter setting range is set, the response is a normal response, but the data is not written.
  • Page 55: Response Error Codes

    3.2 PC Link Communication 3.2.4 Response Error Codes The error code (EC1) and detailed error code (EC2) of the response are as follows. Error Codes (EC1) Error code Meaning Cause • Command does not exist. Command error • Command cannot be executed. Register •...
  • Page 56: Specifying Broadcast

    3.2 PC Link Communication 3.2.5 Specifying Broadcast This function allows multiple UTAdvanced controllers specified by respective addresses to receive writing commands. (1) Broadcast is executed with the address number in the table below specified as the address No. in the command. When GREEN Series device response is UTAdvanced enabled *1 Address No.
  • Page 57: Commands And Responses

    3.2 PC Link Communication 3.2.6 Commands and Responses This item shows lists of commands that can be used in PC link communication. Details are explained in the description for each command. (1) Bit-basis access commands dedicated to I relays Number of bits Command Description handled Bit-basis read...
  • Page 58: Brd Reading I Relays On A Bit-By-Bit Basis

    3.2 PC Link Communication  BRD Reading I relays on a bit-by-bit basis  Function Reads the ON/OFF status of a sequence of contiguous I relays by the specified number of bits, starting at a specified I relay number. • The number of bits to be read at a time is 1 to 256 (decimal). •...
  • Page 59: Brr Reading I Relays On A Bit-By-Bit Basis In A Random Order

    3.2 PC Link Communication  BRR Reading I relays on a bit-by-bit basis in a random order  Function Reads the ON/OFF status of the individual I relays specified in a random order by the specified number of bits. • The number of bits to be read at a time is 1 to 32 (decimal). •...
  • Page 60: Brs Specifying I Relays To Be Monitored On A Bit-By-Bit Basis

    3.2 PC Link Communication  BRS Specifying I relays to be monitored on a bit-by-bit basis  Function Specifies the numbers of I relays to be monitored on a bit-by-bit basis. Note that this command simply specifies I relays. Actual monitoring is performed by the BRM command after the I relay numbers are specified with this command.
  • Page 61: Wrd Reading D Registers And I Relays On A Word-By-Word Basis

    3.2 PC Link Communication  WRD Reading D registers and I relays on a word-by-word basis  Function Reads a sequence of contiguous register information on a word-by-word basis by the specified number of words, starting at the specified register number. • The number of words to be read at a time is 1 to 64 (decimal). •...
  • Page 62: Wrr Reading D Registers And I Relays On A Word-By-Word Basis In Random Order

    3.2 PC Link Communication  WRR Reading D registers and I relays on a word-by-word basis in random order  Function Reads the status of the individual registers, on a word-by-word basis, specified in a random order by the specified number of words. •...
  • Page 63: Wrs Specifying The D Registers And I Relays To Be Monitored On A Word-By-Word Basis

    3.2 PC Link Communication  WRS Specifying the D registers and I relays to be monitored on a word-by-word basis  Function Specifies the numbers of the registers to be monitored on a word-by-word basis. Note that this command simply specifies the registers. Actual monitoring is performed by the WRM command after the register numbers are specified by this command.
  • Page 64: Inf6 Reading The Model, Suffix Code, And Version Information

    3.2 PC Link Communication  INF6 Reading the model, suffix code, and version information  Function Reads the model, version number of the UTAdvanced. • For details on the response format at an error, see “3.2.3 Configuration of Response.”  Command/Response (during normal operation) Number of bytes Command...
  • Page 65 3.2 PC Link Communication  UT55A/UT52A UT55A UT55A Type 3 (Open networks) Model 0: None 1: RS485 communication (Max.38.4 kbps, 2-wire/4-wire) 2: Ethernet communication (with serial gateway function) 3: CC-Link communication (with Modbus master function) 4: PROFIBUS-DP communication (with Modbus master function) 5: DeviceNet communication (with Modbus master function) Type 2 (Functions) 0: None 1: Remote (1 additional aux.
  • Page 66 3.2 PC Link Communication UT32A-D UT32A Type 3 (Open networks) Model 0: None Type 2 (Functions) 0: None 1: RS-485 communication (Max. 38.4 kbps, 2-wire/4-wire) Type 1 (Basic control) D: Dual-loop type UT32A UT32A (Entry model) Type 3 (Open networks) Model 0: None Type 2 (Functions) 0: None 1: RS-485 communication (Max.
  • Page 67 3.2 PC Link Communication  UM33A UM33A Type 3 (Open networks) Model 0: None 3: CC-Link communication (with Modbus master function) Type 2 (Functions) 0: None 1: 1 additional DO (c-contact relay), RS-485 communication (Max.38.4 kbps, 2-wire/4-wire) 2: 1 additional DO (c-contact relay) 3: 6 additional DOs (c-contact relay;...
  • Page 68 3.2 PC Link Communication UT52A Position proportional type and Heating/cooling type (Response is returned as UT551) UT551- Model Type 2 (Functions) Code of UT52A Response code is returned as UT551 0 None Remote (1 additional aux. analog) input, 2 additional DI, and RS485 communication (Max.38.4 kpbs, 2-wire) 4 Remote (1 additional aux.
  • Page 69 3.2 PC Link Communication UP55A (Response is returned as UP550) UP550- Model Type 2 (Functions) Code of UP55A Response code is returned as UP550 None 1 None (when Type 3≠1) Remote (1 additional aux. analog) input, 1 additional DI, and RS-485 1 (when Type 3=1) communication (Max.38.4 kbps, 2-wire/4-wire) None None...
  • Page 70: Inf7 Reading Cpu Maximum Value

    3.2 PC Link Communication UT35A/UT32A V 0 2 . R 3 2 _  Space (blank) UP55A V 0 2 . R 2 7 _  Space (blank) UP35A/UM33A V 0 2 . R 3 2 _  Space (blank)  INF7 Reading CPU maximum value ...
  • Page 71: Communication With Fa-M3

    3.2 PC Link Communication 3.2.7 Communication with FA-M3 Host computers that can use PC link communication protocol can communicate with FA-M3.  Communication with FA-M3 (UT link module) The UTAdvanced can communicate with FA-M3 simply by connecting to the UT link module by PC link communication protocol. Set the communication conditions on the UTAdvanced to the same conditions as those on the UT link module.
  • Page 72: Ladder Communication

    Ladder Communication 3.3.1 Overview By using ladder communication, you can easily perform communication between a PLC (sequencer) and UTAdvanced. This kind of communication allows for the reading/writing of D registers / I relays (internal registers of the UTAdvanced). Hereinafter, PLC (sequencer) is referred to as PLC. ►...
  • Page 73: Configuration Of Commands

    3.3 Ladder Communication 3.3.2 Configuration of Commands Commands sent from a PLC consist of the following elements. Number of bytes Number of BCD digits Element Address Parameter Read/write digit data (0D) (0A) (01) (1) Address No. (01 to 99) The address number is used by the PLC to identify which instrument to communicate with.
  • Page 74: Configuration Of Responses

    3.3 Ladder Communication  Data Forms of Commands The table below shows the data forms of D registers. Data type Data content Data form PV high and low limits, target PV range (EU) data Numerical data not including setpoints, and others the decimal point Bias, deviation alarms, and others PV range span (EUS) data Numeric data not including...
  • Page 75: Communication With Plc

    PLCs that can communicate with UTAdvanced are those capable of using the ladder communication protocol. PLCs that can be connected to a UTAdvanced are listed below. Supplier Product Requirement Remarks Yokogawa Electric With communication module (Note) FA-M3 Corporation (F3RZ91-0F) MELSEC-Q series and others...
  • Page 76: Response Error Codes

    3.3 Ladder Communication  Writing Data Shown below are the configurations of commands and responses when data is written to a UTAdvanced from the PLC.  Command Number of Bytes Number of BCD digits Element Parameter +/– dddd Address digit No.
  • Page 77 Blank Page...
  • Page 78 Chapter 4 Description of Ethernet Communication (Modbus/TCP) (for UTAdvanced with Ethernet Communication) Overview The Modbus/TCP is a communication protocol used for performing communication with a general-purpose PC, PLC (sequencer), touch panel, or other device using TCP/IP protocol via Ethernet or other network. Internal registers on UT75A/UT55A/UT35A/UP55A/UP35A are read and written, and data transactions performed with connected devices via this communication protocol.
  • Page 79 4.1 Overview Network Layers Host computer (such as PC) Application layer Modbus/TCP Transport layer Network layer Data link layer Ethernet Physical layer 10BASE-T/100BASE-TX Overview of Ethernet Communication Connection Device with Ethernet function Distance from hub to Host computer UT75A/UT55A/UT35A/UP55A/UP35A: within 100 m IP address [192.168.1.1] Number of cascade connections on hub: Max.
  • Page 80: Ethernet Communication)

    4.2 TCP/IP-based Communication Modbus/TCP performs transactions by the procedure in the figure below on the TCP/IP socket interface. Ethernet UT75A/UT55A/ UT35A/UP55A/ UP35A with Ethernet communication Initial Startup Initial Startup socket() socket() bind() listen() Connection open connect() accept() Command send() recv() Response recv() send() Connection...
  • Page 81: Configuration Of Network Frames

    Configuration of Network Frames Modbus/TCP frames are configured as follows: MODBUS TCP/IP ADU MBAP Header Function code Data MBAP Header (Modbus Application Protocol Header): Header for identifying that the protocol is Modbus/TCP PDU (Protocol Data Unit): Body of data communication 4.3.1 Configuration of MBAP Header The MBAP header comprises seven bytes as follows: Byte No...
  • Page 82: Communication With Host Computer

    Communication with Host Computer 4.4.1 List of Function Codes These instruction words are used so that the host computer obtains the D register and I relay information of the UT75A/UT55A/UT35A/UP55A/UP35A. List of Function Codes Code No. Function Description Reading of multiple I relays Up to 256 registers can be read continuously (I4001 to I7072).
  • Page 83: Requests And Responses

    4.4 Communication with Host Computer 4.4.3 Requests and Responses 01 Reading multiple I relays   Function The content of I relays is read continuously for the specified number of relays from the specified I relay No. • The maximum number of relays that can be read at a time is 256. •...
  • Page 84: Writing To An I Relay

    4.4 Communication with Host Computer  05 Writing to an I relay  Function Data is written to the specified I relay No. • The number of relays that can be written at a time is 1. • For details on the response format at an error, see “4.4.4 Response Error Codes.” •...
  • Page 85: Loopback Test

    4.4 Communication with Host Computer  08 Loopback test  Function This is used to check the communication connection. • For details on the response format at an error, see “4.4.4 Response Error Codes.” • The “0000” shown below (marked with an asterisk *) is fixed. •...
  • Page 86: Writing To Multiple I Relays

    4.4 Communication with Host Computer  15 Writing to multiple I relays  Function Data is written to I relays continuously for the specified number of relays from the specified I relay No. • The maximum number of relays that can be written at a time is 256. •...
  • Page 87: Writing To Multiple D Registers

    4.4 Communication with Host Computer  16 Writing to multiple D registers  Function Data is written to D registers continuously for the specified number of registers from the specified D register No. • The maximum number of registers that can be written at a time is 50. •...
  • Page 88: Random Reading

    4.4 Communication with Host Computer  66 Random reading  Function The register data of register Nos. specified at random is read. • Register Nos. can be specified from all register areas • The maximum number of registers that can be set is 100. •...
  • Page 89: Specify Monitor

    4.4 Communication with Host Computer  68 Specify monitor  Function The register No. specified at random can be specified for monitoring. • The maximum number of registers that can be specified for monitoring is 100. • For details on the response format at an error, see “4.4.4 Response Error Codes.” ...
  • Page 90: Writing To Multiple D Registers For Program Pattern

    4.4 Communication with Host Computer  70 Writing to multiple D registers for program pattern  Function Data is written to D registers continuously for the specified number of registers from the specified D register No. Can be specified register areas: D8001 to D9000. •...
  • Page 91: Response Error Codes

    4.4 Communication with Host Computer 4.4.4 Response Error Codes  When a response is returned to a request: When the PDU in the request contains an inconsistency, the UT75A/UT55A/UT35A/ UP55A/UP35A does not perform any processing, and returns the following request. Element MBAP Header Number of bytes...
  • Page 92: Ethernet-Serial Gateway Function

    = 02 communication address = 03 communication address = 10 *: VJET is the converter of YOKOGAWA. See the user’s manual for VJET when using it. The UT75A/UT55A/UT35A/UP55A/UP35A operates as a gateway that changes the MODBUS/TCP protocol received via network to the MODBUS/RTU protocol for the serial devices connected to the RS-485 communication interface.
  • Page 93: Wiring For Communication With Serial Devices

    4.5 Ethernet-Serial Gateway Function 4.5.2 Wiring for Communication with Serial Devices For wiring, see the Operation Guide or User’s Manual. A maximum of 31 serial devices are connectable. Set a communication address (02 to 99) different from each other for each device.
  • Page 94: Process Data High-Speed Response Function

    RS-485 communication address = 02 address = 03 address = 04 address = 05 UTAdvanced Series When Process Data High-speed Response Function is Used Response speed : High Host computer (1) The host computer sends the command to read the process data from the serial devices through the UT75A/UT55A/UT35A/UP55A/UP35A.
  • Page 95: How To Set The Function

    4.6 Process Data High-speed Response Function The function can read periodically the process data from a maximum of 8 serial devices, store them in the UT75A/UT55A/UT35A/UP55A/UP35A, and return the response at high speed. However, the function can be used for a maximum of 7 serial devices connected to the RS-485 communication line because the serial communication address “1”...
  • Page 96: Process Data For High-Speed Response

    4.6 Process Data High-speed Response Function 4.6.3 Process Data for High-speed Response The function treats from D2001 to D2025 as process data in D register map, regardless of the kind of the serial devices connected to the RS-485 communication line. The UT75A/UT55A/UT35A/UP55A/UP35A reads this data periodically from the serial devices for which the function is used and returns a response at high speed to the command to read data from multiple registers (function code: 03) in this category from the host computer.
  • Page 97: Ip Access Restriction Function

    4.7 IP Access Restriction Function The UT75A/UT55A/UT35A/UP55A/UP35A has an IP access control function to permit access from registered IP addresses and reject access from unregistered IP addresses. This function is able to prevent unauthorized access and thereby increase security. Ethernet UT75A/UT55A/ UT35A/UP55A/ connect request from UP35A with a device registered with Ethernet...
  • Page 98: Chapter 5 Coordinated Operation

    Chapter 5 Coordinated Operation Overview A system of coordinated operation is configured with a master controller and a number of slave controllers, all of which are UTAdvanced. The slave controllers are set to operate in the same way as the master controller. Therefore you do not have to create a communication program or to use specialized software for coordinated operation.
  • Page 99: Coordinated Items

    Coordinated Items The controllers operate in coordination with respect to the following items.  Target Setpoint When the master is a program controller (UP controller), slave controllers (UT controllers) can be operated in the program operation. • When the master controller is set to PSL=3 (coordinated master station) and the slave controller is set to PSL=4 (coordinated slave station): The master controller sends the target setpoint.
  • Page 100 5.2 Coordinated Items  PID number switching and switching over to the zone PID mode In coordinated operation, the slave controller’s PID number depends on the setting of the parameter ZON of the master and slave controllers. The table below shows the slave controller’s PID number selecting action. Slave controller’s Slave: ZON=2 Slave: ZON=3 PID number Slave: ZON=0...
  • Page 101: Starting Coordinated Operation

    Starting Coordinated Operation After the wiring and setup of communication parameters have been completed, turn off the power once and turn it on again.  Switchover of coordinated operation Set all the slave controllers to REM (remote) mode. Slave controllers do not operate in coordination when they are in LCL (local) mode. (Each slave controller operates independently in LCL mode.)  Switchover of operation mode (RUN/STOP) Switching over the master controller’s operation mode also switches the operation...
  • Page 102: Chapter 6 Functions And Applications Of D Registers (For Ut55A/Ut52A/Up55A)

    Chapter 6 Functions and Applications of D Registers (for UT55A/UT52A/UP55A) Overview This chapter describes the functions and applications of the D registers. D registers are used in Modbus, PC link, ladder, Ethernet communications, or Open Network communication (network profile creating function of LL50A) and are used for storing UTAdvanced parameter data, flag data, process data, and other data and values. The host computer can utilize these data by reading from and writing to the D registers.
  • Page 103 Conventions Used in D Register Tables This section describes the conventions used in the D register map tables. The numerical values arranged vertically in the leftmost column of the table represent (1) D register numbers. 5-digit numbers in the column next to it show (2) reference numbers for Modbus communication.
  • Page 104: Classification Of D Registers

    Classification of D Registers  Classification of D Register Map Tables The table on next page outlines how the D registers are classified by their numbers in the D register map tables. When you newly perform communication with the UTAdvanced, the D registers after D2001 are used.
  • Page 105 6.3 Classification of D Registers Classification of D Registers Register No. Area and data categories Description Reference D0001 to D0049 Process data Sections 6.6.3 D0050 to D0100 User area Sections 6.6.3 D0101 to D0200 Program setting parameter (for UP55A only) Sections 6.6.3 D0201 to D0230 Operation mode parameter...
  • Page 106: Process Monitoring And Program Pattern For Up55A (D2001 To D2300)

    6.4 UT55A/UT52A/UP55A D Registers 6.4.1 Process Monitoring and Program Pattern for UP55A (D2001 to D2300) Process monitoring area Process data D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol AD1.E D2001 42001 07D0 D2051 42051 0802 PV1.E_L1 D2002 42002 07D1 D2052 42052 0803 PV_L1 D2003 42003 07D2 D2053 42053 0804 CSP_L1 D2004 42004 07D3...
  • Page 107 6.4 UT55A/UT52A/UP55A D Registers Process monitoring area Current SP group and PID group D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol SP_L1_* SP_L2_* D2101 42101 0834 D2151 42151 0866 SUB_* D2102 42102 0835 D2152 42152 0867 PIDN_L1_* PIDN_L2_* D2103 42103 0836 D2153 42153 0868 A1_L1_* A1_L2_*...
  • Page 108 6.4 UT55A/UT52A/UP55A D Registers The group number to be displayed varies depending on the currently used SP number selection (D2312) and PID number (D2009, D2025). Either 1 to 8 or R (the currently used group number) is written. However, only 1 to 8 is written in D2101 to D2111 and D2151 to D2161. IM 05P07A01-01EN...
  • Page 109 6.4 UT55A/UT52A/UP55A D Registers Program pattern Local-mode Operation Setting (Menu: LOC) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol LSP_L1 D2201 42201 0898 D2251 42251 08CA LSP_L2 D2202 42202 0899 D2252 42252 08CB L.PID D2203 42203 089A D2253 42253 08CC L.TY1 D2204 42204 089B...
  • Page 110: Process Data Area

    6.4 UT55A/UT52A/UP55A D Registers Process Data Area Some of the D registers represent multiple events such as errors and status depending on combinations of bits in the register. In the following tables, if an event indicated by a specific bit occurs, the state of that bit changes to “1.”...
  • Page 111 6.4 UT55A/UT52A/UP55A D Registers  Bit Configuration of D2008: MOD_L1 (Loop-1 operation mode status) UT55A/UT52A Symbol Event 0: AUTO, 1: MAN R.L_L1 0: Local, 1: Remote 0: Run, 1: Stop CAS_ON 1: CAS AUTO_ON 1: AUTO *2 MAN_ON 1: MAN TRK_ON_L1 1: Output tracking 10 to 13 AT_L1_ON 0: Auto-tuning is OFF, 1: Auto-tuning is ON *1: Effective for the control modes except for cascade control and cascade secondary-loop control.
  • Page 112 6.4 UT55A/UT52A/UP55A D Registers  Bit Configuration of D2011: ALM_L1 (Loop-1 alarm-1 to alarm-8 status) Symbol Event ALM1_L1 ‘1’ when Loop-1 alarm 1 is ON; ‘0’ when OFF ALM2_L1 ‘1’ when Loop-1 alarm 2 is ON; ‘0’ when OFF ALM3_L1 ‘1’ when Loop-1 alarm 3 is ON; ‘0’ when OFF ALM4_L1 ‘1’...
  • Page 113 6.4 UT55A/UT52A/UP55A D Registers  Bit Configuration of D2018: PV2.E_L2 (Loop-2 PV input error status) Symbol Event PVBO_L2 Loop-2 PV input burnout error RSPBO_L2 * Loop-2 RSP input burnout error CRSPBO_L2 * Burnout error when the Loop-2 RSP input is used for control. PVPOVER_L2 Loop-2 PV input over-scale PVMOVER_L2 Loop-2 PV input under-scale 6 to 13 ATERR_L2 Loop-2 auto-tuning timeout error...
  • Page 114 6.4 UT55A/UT52A/UP55A D Registers  Bit Configuration of D2037: ALO_L1 (Loop-1 alarm-1 to alarm-8 output status) Symbol Event Output status where Loop-1 alarm output 1 is assighed. 0: When the alarm is turned off (alarm type: energized), or the alarm is turned on (alarm type: de-energized). (The ALO1_L1 relay contact is open.) 1: When the alarm is turned on (alarm type: energized), or the alarm is turned off (alarm type: de-energized).
  • Page 115 6.4 UT55A/UT52A/UP55A D Registers  Bit Configuration of D2039: PV_EV (PV event status) Symbol Event PV_EV1 0: PV event is OFF PV_EV2 1: PV event is ON PV_EV3 PV_EV4 0: PV event is OFF PV_EV5 1: PV event is ON PV_EV6 PV_EV7 0: PV event is OFF 1: PV event is ON PV_EV8 10 to 15  Bit Configuration of D2040: TIME_EV_1 (Time event status 1)
  • Page 116 6.4 UT55A/UT52A/UP55A D Registers  Bit Configuration of D2050: PV_EV_OUT (PV event output status) PV_EV1_OUT 0: PV event output is OFF PV_EV2_OUT 1: PV event output is ON PV_EV3_OUT 0: PV event output is OFF PV_EV4_OUT 1: PV event output is ON 5 to 7 PV_EV5_OUT 0: PV event output is OFF PV_EV6_OUT 1: PV event output is ON PV_EV7_OUT...
  • Page 117 6.4 UT55A/UT52A/UP55A D Registers  Bit Configuration of D2068: PA.ER (Parameter error status) Symbol Event SYSTEM_ERR System data error CALB_ERR Calibration value error UPARA_ERR User (parameter) default value error SETPA_ERR Setup parameter error OPEPA_ERR Operation parameter error PROG_ERR * Program pattern error FRAM_ERR Faulty FRAM CTLPA_ERR Control parameter error 11 to 15 *: For UP55A only (Option error status)
  • Page 118 6.4 UT55A/UT52A/UP55A D Registers  Bit Configuration of D2072: ALOLA1_L2 (Loop-2 alarm-1 to alarm-8 latch output status) Symbol Event ALO1LA1_L2 Alarm-1 latch-1 output status ALO2LA1_L2 Alarm-2 latch-1 output status ALO3LA1_L2 Alarm-3 latch-1 output status ALO4LA1_L2 Alarm-4 latch-1 output status ALO5LA1_L2 Alarm-5 latch-1 output status ALO6LA1_L2 Alarm-6 latch-1 output status ALO7LA1_L2 Alarm-7 latch-1 output status ALO8LA1_L2 Alarm-8 latch-1 output status 10 to 15...
  • Page 119 6.4 UT55A/UT52A/UP55A D Registers  Bit Configuration of D2076: ALOLA3_L2 (Loop-2 alarm-1 to alarm-8 latch-3 output status) Symbol Event ALO1LA3_L2 Alarm-1 latch-3 output status ALO2LA3_L2 Alarm-2 latch-3 output status ALO3LA3_L2 Alarm-3 latch-3 output status ALO4LA3_L2 Alarm-4 latch-3 output status ALO5LA3_L2 Alarm-5 latch-3 output status ALO6LA3_L2 Alarm-6 latch-3 output status ALO7LA3_L2 Alarm-7 latch-3 output status ALO8LA3_L2 Alarm-8 latch-3 output status...
  • Page 120: Current Sp Group And Pid Group (D2101 To D2200)

    6.4 UT55A/UT52A/UP55A D Registers Current SP Group and PID Group (D2101 to D2200) Register Description Range and meaning of value 0.0 to 100.0% of PV input range (EU) (Setting D2101 SP_L1_* Loop-1 target setpoint range: SPL to SPH) Loop-1 sub-target setpoint (in Two- Set the offset from SP. D2102 SUB_* position two-level control)
  • Page 121 6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value D2130 OLc_L1_* Cooling-side control output low limit 0.0 to 104.9%, (OLc<OHc) Cooling-side ON/OFF control D2131 HYSc_L1_* 0.0 to 100.0% hysteresis Output dead band (in Heating/cooling In Heating/cooling control: -100.0 to 50.0% D2132 DB_L1_* control or Position proportional control)
  • Page 122 6.4 UT55A/UT52A/UP55A D Registers Local-mode Operation Setting for UP55A (D2201 to D2300) Register Description Range and meaning of value D2201 LSP_L1 Loop-1 local target setpoint 0.0 to 100.0% of PV input range (EU) (Setting range: P.RL to P.RH) D2202 LSP_L2 Loop-2 local target setpoint Set a PID group number to use. 1 to 8 D2203 L.PID...
  • Page 123: Up55A (D2301 To D2500)

    6.4 UT55A/UT52A/UP55A D Registers 6.4.2 Loop-1 / Loop-2 Operation Mode Parameter and Loop-1 / Loop-2 Operation Parameter for UP55A (D2301 to D2500) Operation mode parameters Loop-1 / Loop-2 operation mode (Menu: MODE), Loop-1 / Loop-2 Alarm setpoint setting (Menu:AL) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol A1_L1 D2301 42301 08FC D2351 42351 092E A2_L1 D2302 42302 08FD D2352 42352 092F C.A.M A3_L1...
  • Page 124: Free Area (D2401 To D2500)

    6.4 UT55A/UT52A/UP55A D Registers Process monitoring area Free area D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D2401 42401 0960 D2451 42451 0992 D2402 42402 0961 D2452 42452 0993 D2403 42403 0962 D2453 42453 0994 D2404 42404 0963 D2454 42454 0995...
  • Page 125 6.4 UT55A/UT52A/UP55A D Registers Loop-1 / Loop-2 Operation Mode and Loop-1 / Loop-2 Alarm Setpoint Setting for UP55A (D2301 to D2400) Register Description Range and meaning of value 0: AUTO (Automatic mode) 1: MAN (Manual mode) D2301 AUTO/MAN switch Effective for the control modes except for cascade control and cascade secondary-loop control. D2302 0: AUTO (Automatic mode) 1: MAN (Manual mode) D2303 C.A.M...
  • Page 126 6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value Loop-1 communication remote D2331 C.RSP_L1 setpoint 0.0 to 100.0% of PV input range (EU) Loop-2 communication remote D2332 C.RSP_L2 setpoint Loop-1 heating-side control output in D2333 MOUT_L1 0.0 to 105.0% (Standard type: -5.0 to 105.0%) MAN mode Loop-1 cooling-side control output in D2334...
  • Page 127 6.4 UT55A/UT52A/UP55A D Registers 6.4.3 Loop-1 Operation Parameter (D2501 to D3600) Loop-1 operation parameter SP and alarm setpoint setting (Menu: SP) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol SP_L1_1 A8_L1_3 D2501 42501 09C4 D2551 42551 09F6 SUB_1 D2502 42502 09C5 D2552 42552 09F7 PIDN_L1_1 D2503 42503 09C6 D2553 42553 09F8...
  • Page 128: Loop-1 Operation Parameter (D2501 To D3600)

    6.4 UT55A/UT52A/UP55A D Registers Loop-1 operation parameter SP and alarm setpoint setting (Menu: SP) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol SP_L1_6 A8_L1_8 D2601 42601 0A28 D2651 42651 0A5A SUB_6 D2602 42602 0A29 D2652 42652 0A5B PIDN_L1_6 D2603 42603 0A2A D2653 42653 0A5C A1_L1_6...
  • Page 129 6.4 UT55A/UT52A/UP55A D Registers Loop-1 operation parameter SP-related setting (Menu: SPS) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol RMS_L1 D2701 42701 0A8C R/W R/W D2751 42751 0ABE RFL_L1 D2702 42702 0A8D R/W R/W D2752 42752 0ABF RT_L1 D2703 42703 0A8E R/W R/W...
  • Page 130 6.4 UT55A/UT52A/UP55A D Registers Loop-1 operation parameter Alarm function setting (Menu: ALRM) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D2801 42801 0AF0 D2851 42851 0B22 DYN3_L1 AL1.T_L1 D2802 42802 0AF1 D2852 42852 0B23 DYN4_L1 AL1.W_L1 D2803 42803 0AF2 D2853 42853 0B24 DYN5_L1...
  • Page 131 6.4 UT55A/UT52A/UP55A D Registers Loop-1 operation parameter PV-related setting (Menu: PVS) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol BS_L1 R/W R/W D2901 42901 0B54 D2951 42951 0B86 FL_L1 R/W R/W D2902 42902 0B55 D2952 42952 0B87 D2903 42903 0B56 D2953 42953...
  • Page 132 6.4 UT55A/UT52A/UP55A D Registers Loop-1 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D3001 43001 0BB8 P_L1_1 R/W R/W D3051 43051 0BEA P_L1_2 D3002 43002 0BB9 I_L1_1 R/W R/W D3052 43052 0BEB I_L1_2 D3003 43003 0BBA...
  • Page 133 6.4 UT55A/UT52A/UP55A D Registers Loop-1 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol P_L1_3 P_L1_4 D3101 43101 0C1C R/W R/W D3151 43151 0C4E I_L1_3 I_L1_4 D3102 43102 0C1D R/W R/W D3152 43152 0C4F D_L1_3 D_L1_4 D3103...
  • Page 134 6.4 UT55A/UT52A/UP55A D Registers Loop-1 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D3201 43201 0C80 P_L1_5 R/W R/W D3251 43251 0CB2 P_L1_6 I_L1_5 I_L1_6 D3202 43202 0C81 R/W R/W D3252 43252 0CB3 D_L1_5 D_L1_6 D3203...
  • Page 135 6.4 UT55A/UT52A/UP55A D Registers Loop-1 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol P_L1_7 R/W R/W P_L1_8 D3301 43301 0CE4 D3351 43351 0D16 D3302 43302 0CE5 I_L1_7 R/W R/W D3352 43352 0D17 I_L1_8 D_L1_7 R/W R/W D_L1_8...
  • Page 136 6.4 UT55A/UT52A/UP55A D Registers Loop-1 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol P_L1_R R/W R/W D3401 43401 0D48 D3451 43451 0D7A R/W R/W D3402 43402 0D49 I_L1_R D3452 43452 0D7B R/W R/W D3403 43403 0D4A...
  • Page 137 6.4 UT55A/UT52A/UP55A D Registers Loop-1 operation parameter Control action-related setting (Tuning menu: TUNE) (Zone control menu: ZONE) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol SC_L1 RP1_L1 D3501 43501 0DAC R/W R/W D3551 43551 0DDE D3502 43502 0DAD D3552 43552 0DDF RP2_L1 AT.TY_L1 RP3_L1 D3503 43503 0DAE R/W R/W...
  • Page 138 6.4 UT55A/UT52A/UP55A D Registers Loop-1 SP and Alarm Setpoint Setting of Groups 1 to 8 (D2501 to D2700) Register Description Range and meaning of value 0.0 to 100.0% of PV input range (EU) (Setting D2501 SP_L1_1 Target setpoint of group 1 range: SPL to SPH) Sub-target setpoint (in Two-position Set the offset from SP. D2502 SUB_1 two-level control) of group 1...
  • Page 139: Loop-1 Sp-Related Setting (D2701 To D2800)

    6.4 UT55A/UT52A/UP55A D Registers Loop-1 SP-related Setting (D2701 to D2800) Register Description Range and meaning of value 0: RSP (Via remote (aux. analog) input) 1: COM (Via communication) RSP is not displayed if the remote (auxiliary analog) input is not specified. D2701 RMS_L1 Remote input method COM is not displayed if the communication function is not specified.
  • Page 140: Loop-1 Alarm Function Setting (D2801 To D2900)

    6.4 UT55A/UT52A/UP55A D Registers Loop-1 Alarm Function Setting (D2801 to D2900) Register Description Range and meaning of value AL1.T_L1 to AL8.T_L1 D2801 AL1.T_L1 Alarm-1 type 0: Disable D2802 AL1.W_L1 Alarm-1 stand-by action 1: PV high limit 2: PV low limit D2803 AL1.D_L1 Alarm-1 energized/de-energized 3: SP high limit D2804...
  • Page 141: Loop-1 Pv-Related Setting (D2901 To D3000)

    6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value D2841 HY1_L1 Alarm-1 hysteresis D2842 HY2_L1 Alarm-2 hysteresis HY3_L1 D2843 Alarm-3 hysteresis Set a display value of setpoint of hysteresis. D2844 HY4_L1 Alarm-4 hysteresis -19999 to 30000 (Set a value within the input range.) D2845 HY5_L1...
  • Page 142: Loop-1 Pid Setting Of Groups 1 To 8 And R (D3001 To D3500)

    6.4 UT55A/UT52A/UP55A D Registers Loop-1 PID Setting of Groups 1 to 8 and R (D3001 to D3500) Register Description Range and meaning of value 0.0 to 999.9% Proportional band of group 1 When 0.0% is set, it operates as 0.1%. D3001 P_L1_1 Heating-side proportional band (in Heating-side ON/OFF control applies when 0.0% in Heating/cooling control) of group 1 Heating/cooling control Integral time of group 1...
  • Page 143 6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value Proportional band of group 2 D3051 to Heating-side proportional band (in P_L1_2 to POc_L1_2 Same as D3001 to D3022 D3072 Heating/cooling control) of group 2 to Cooling-side preset output of group 2 D3073 to D3100 Proportional band of group 3 D3101 to...
  • Page 144: Loop-1 Control Action-Related Setting (D3501 To D3600)

    6.4 UT55A/UT52A/UP55A D Registers Loop-1 Control Action-related Setting (D3501 to D3600) Register Description Range and meaning of value 0: OFF (Disable) 1: Overshoot suppressing function (normal mode) 2: Hunting suppressing function (stable mode) Enables to answer the wider characteristic changes compared with response mode. 3: Hunting suppressing function (response mode) Enables quick follow-up and short converging time of PV for the changed SP.
  • Page 145 6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value D3551 RP1_L1 Reference point 1 Set reference points at which switching is carried D3552 RP2_L1 Reference point 2 out between groups RP3_L1 D3553 Reference point 3 of PID constants according to the given temperature D3554 RP4_L1 Reference point 4...
  • Page 146 6.4 UT55A/UT52A/UP55A D Registers 6.4.4 Loop-2 Operation Parameter (D3601 to D4700) Loop-2 operation parameter SP and alarm setpoint setting (Menu: SP) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D3601 43601 0E10 SP_L2_1 D3651 43651 0E42 A8_L2_3 D3602 43602 0E11 D3652 43652 0E43 D3603 43603 0E12 PIDN_L2_1 D3653 43653 0E44...
  • Page 147 6.4 UT55A/UT52A/UP55A D Registers Loop-2 operation parameter SP and alarm setpoint setting (Menu: SP) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol SP_L2_6 A8_L2_8 D3701 43701 0E74 D3751 43751 0EA6 D3702 43702 0E75 D3752 43752 0EA7 PIDN_L2_6 D3703 43703 0E76 D3753 43753 0EA8 D3704 43704...
  • Page 148 6.4 UT55A/UT52A/UP55A D Registers Loop-2 operation parameter SP-related setting (Menu: SPS) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D3801 43801 0ED8 RMS_L2 D3851 43851 RFL_L2 D3802 43802 0ED9 D3852 43852 RT_L2 D3803 43803 0EDA D3853 43853 RBS_L2 D3804 43804 0EDB D3854...
  • Page 149 6.4 UT55A/UT52A/UP55A D Registers Loop-2 operation parameter Alarm function setting (Menu: ALRM) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol DYN3_L2 D3901 43901 0F3C AL1.T_L2 R/W R/W D3951 43951 0F6E D3902 43902 0F3D AL1.W_L2 R/W R/W D3952 43952 0F6F DYN4_L2 DYN5_L2 D3903 43903...
  • Page 150 6.4 UT55A/UT52A/UP55A D Registers Loop-2 operation parameter PV-related setting (Menu: PVS) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D4001 44001 0FA0 BS_L2 R/W R/W D4051 44051 0FD2 D4002 44002 0FA1 FL_L2 R/W R/W D4052 44052 0FD3 D4003 44003 0FA2 D4053 44053...
  • Page 151 6.4 UT55A/UT52A/UP55A D Registers Loop-2 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol P_L2_1 P_L2_2 D4101 44101 1004 R/W R/W D4151 44151 1036 D4102 44102 1005 I_L2_1 R/W R/W D4152 44152 1037 I_L2_2 D_L2_1 D_L2_2 D4103...
  • Page 152 6.4 UT55A/UT52A/UP55A D Registers Loop-2 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D4201 44201 1068 P_L2_3 R/W R/W D4251 44251 109A P_L2_4 I_L2_3 I_L2_4 D4202 44202 1069 R/W R/W D4252 44252 109B D_L2_3 D_L2_4 D4203...
  • Page 153 6.4 UT55A/UT52A/UP55A D Registers Loop-2 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol P_L2_5 P_L2_6 D4301 44301 10CC R/W R/W D4351 44351 10FE D4302 44302 10CD I_L2_5 R/W R/W D4352 44352 10FF I_L2_6 D_L2_5 D_L2_6 D4303...
  • Page 154 6.4 UT55A/UT52A/UP55A D Registers Loop-2 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol P_L2_7 P_L2_8 D4401 44401 1130 R/W R/W D4451 44451 1162 I_L2_7 I_L2_8 D4402 44402 1131 R/W R/W D4452 44452 1163 D_L2_7 D_L2_8 D4403...
  • Page 155 6.4 UT55A/UT52A/UP55A D Registers Loop-2 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D4501 44501 1194 P_L2_R R/W R/W D4551 44551 11C6 I_L2_R D4502 44502 1195 R/W R/W D4552 44552 11C7 D_L2_R D4503 44503 1196 R/W R/W...
  • Page 156 6.4 UT55A/UT52A/UP55A D Registers Loop-2 operation parameter Control action-related setting (Tuning menu: TUNE) (Zone control menu: ZONE) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D4601 44601 11F8 SC_L2 R/W R/W D4651 44651 122A D4602 44602 11F9 D4652 44652 122B D4603 44603 11FA AT.TY_L2 R/W R/W D4653 44653 122C...
  • Page 157: Loop-2 Sp And Alarm Setpoint Setting Of Groups 1 To 8 (D3601 To D3800)

    6.4 UT55A/UT52A/UP55A D Registers Loop-2 SP and Alarm Setpoint Setting of Groups 1 to 8 (D3601 to D3800) Register Description Range and meaning of value 0.0 to 100.0% of PV input range (EU) (Setting D3601 SP_L2_1 Target setpoint of group 1 range: SPL to SPH) D3602 Set a PID group number to use. PIDN_L2_1 D3603 PID number selection of group 1...
  • Page 158: Loop-2 Sp-Related Setting (D3801 To D3900)

    6.4 UT55A/UT52A/UP55A D Registers Loop-2 SP-related Setting (D3801 to D3900) Register Description Range and meaning of value 0: RSP (Via remote (aux. analog) input) 1: COM (Via communication) RSP is not displayed if the remote (auxiliary analog) input is not specified. D3801 RMS_L2 Remote input method COM is not displayed if the communication function is not specified.
  • Page 159: Loop-2 Alarm Function Setting (D3901 To D4000)

    6.4 UT55A/UT52A/UP55A D Registers Loop-2 Alarm Function Setting (D3901 to D4000) Register Description Range and meaning of value D3901 AL1.T_L2 Alarm-1 type AL1.T_L1 to AL8.T_L1 00: Disable D3902 AL1.W_L2 Alarm-1 stand-by action 01: PV high limit 02: PV low limit D3903 AL1.D_L2 Alarm-1 energized/de-energized 03: SP high limit D3904...
  • Page 160: Loop-2 Pv-Related Setting (D4001 To D4100)

    6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value D3941 HY1_L2 Alarm-1 hysteresis D3942 HY2_L2 Alarm-2 hysteresis D3943 HY3_L2 Alarm-3 hysteresis Set a display value of setpoint of hysteresis. D3944 HY4_L2 Alarm-4 hysteresis -19999 to 30000 (Set a value within the input range.) D3945 HY5_L2...
  • Page 161 6.4 UT55A/UT52A/UP55A D Registers Loop-2 PID Setting of Groups 1 to 8 and R (D4101 to D4600) Register Description Range and meaning of value 0.0 to 999.9% Proportional band of group 1 When 0.0% is set, it operates as 0.1%. D4101 P_L2_1 Heating-side proportional band (in Heating-side ON/OFF control applies when 0.0% in Heating/cooling control) of group 1 Heating/cooling control Integral time of group 1...
  • Page 162 6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value Proportional band of group 2 D4151 to Heating-side proportional band (in P_L2_2 to POc_L2_2 Same as D4101 to D4122 D4172 Heating/cooling control) of group 2 to Cooling-side preset output of group 2 D4173 to D4200 Proportional band of group 3 D4201 to...
  • Page 163: Loop-2 Control Action-Related Setting (D4601 To D4700)

    6.4 UT55A/UT52A/UP55A D Registers Loop-2 Control Action-related Setting (D4601 to D4700) Register Description Range and meaning of value 0: OFF (Disable) 1: Overshoot suppressing function (normal mode) 2: Hunting suppressing function (stable mode) Enables to answer the wider characteristic changes compared with response mode. 3: Hunting suppressing function (response mode) Enables quick follow-up and short converging time of PV for the changed SP.
  • Page 164: P Parameter (D4701 To D4800)

    6.4 UT55A/UT52A/UP55A D Registers 6.4.5 P Parameter (D4701 to D4800) P parameter P parameter (Menu: PPAR) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol P01D D4701 44701 125C R/W R/W D4751 44751 128E P02D D4702 44702 125D R/W R/W D4752 44752 128F D4703 44703 125E P03D R/W R/W...
  • Page 165: P Parameter (D4701 To D4800)

    6.4 UT55A/UT52A/UP55A D Registers P parameter (D4701 to D4800) Register Description Range and meaning of value P01D D4701 P01 decimal point position P02D D4702 P02 decimal point position P03D D4703 P03 decimal point position 0: No decimal place P04D D4704 P04 decimal point position 1: One decimal place P05D D4705...
  • Page 166: 10-Segment Linearizer Setting Parameter (D4801 To D5000)

    6.4 UT55A/UT52A/UP55A D Registers 6.4.6 10-segment Linearizer Setting Parameter (D4801 to D5000) 10-segment linearizer setting parameter 10-segment inearizer setting (Menu: PYS1, PYS2, PYS3) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol PYS_1 B10_2 D4801 44801 12C0 R/W R/W D4851 44851 12F2 A1_1 A11_2 D4802 44802 12C1 R/W R/W D4852 44852 12F3 B1_1 B11_2 D4803...
  • Page 167 6.4 UT55A/UT52A/UP55A D Registers 10-segment linearizer setting parameter 10-segment linearizer setting (Menu: PYS4) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D4901 44901 1324 PYS_4 R/W R/W D4951 44951 1356 D4902 44902 1325 A1_4 R/W R/W D4952 44952 1357 B1_4 D4903 44903 1326 R/W R/W D4953 44953...
  • Page 168 6.4 UT55A/UT52A/UP55A D Registers 10-segment Linearizer Setting (D4801 to D5000) Register Description Range and meaning of value 0: OFF (Disable) 1: PV (PV analog input) 2: RSP (RSP analog input) 3: AIN2 (AIN2 analog input) 10-segment linearizer selection of D4801 PYS_1 4: AIN4 (AIN4 analog input) group 1...
  • Page 169: Setup Parameters (D5001 To D7000)

    6.4 UT55A/UT52A/UP55A D Registers 6.4.7 Setup Parameters (D5001 to D7000) Setup parameter Control function setting (Menu: CTL) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol CTLM D5001 45001 1388 R/W R/W D5051 45051 13BA D5002 45002 1389 D5052 45052 13BB CNT_L1 D5003 45003 138A R/W R/W D5053 45053...
  • Page 170 6.4 UT55A/UT52A/UP55A D Registers Setup parameter Input setting (PV input setting menu: PV) (RSP input setting menu: RSP) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D5101 45101 13EC R/W R/W D5151 45151 141E UNIT A.BS_E2 D5102 45102 13ED R/W R/W D5152 45152 141F A.FL_E2 D5103 45103 13EE D5153 45153...
  • Page 171 6.4 UT55A/UT52A/UP55A D Registers Setup parameter Input setting (Input range·SP limiter/input switch/input auto-selector setting parameters menu: MPV) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D5201 45201 1450 P.UNI_L1 R/W R/W D5251 45251 1482 P.DP_L1 D5202 45202 1451 R/W R/W D5252 45252 1483 P.RH_L1 D5203 45203 1452 R/W R/W D5253...
  • Page 172 6.4 UT55A/UT52A/UP55A D Registers Setup parameter Output setting (Menu: OUT) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol OT.H D5301 45301 14B4 R/W R/W D5351 45351 14E6 D5302 45302 14B5 OT.C R/W R/W D5352 45352 14E7 D5303 45303 14B6 R/W R/W D5353 45353...
  • Page 173 6.4 UT55A/UT52A/UP55A D Registers Setup parameter Heater break alarm setting (Menu: HBA) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D5401 45401 1518 HB1.S R/W R/W D5451 45451 154A HB2.S D5402 45402 1519 R/W R/W D5452 45452 154B D5403 45403 151A R/W R/W D5453 45453...
  • Page 174 6.4 UT55A/UT52A/UP55A D Registers Setup parameter Communication setting (RS-485 communication setting menu: R485) (Ethernet communication setting menu: ETHR) (Error and version confirmation menu: VER) (CC-Link communication setting menu: CC-L) (DeviceNet communication setting menu: DNET) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol PSL_E1 SM4_E3 D5501 45501 157C D5551 45551 15AE BPS_E1 DG1_E3 D5502 45502 157D D5552 45552 15AF D5503 45503 157E PRI_E1 D5553 45553 15B0...
  • Page 175 6.4 UT55A/UT52A/UP55A D Registers Setup parameter Communication setting (PROFIBUS-DP communication setting menu: PROF) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D5601 45601 15E0 BR_E3-P D5651 45651 1612 D5602 45602 15E1 ADR_E3-P D5652 45652 1613 BPS_E3-P D5603 45603 15E2 D5653 45653 1614 D5604 45604 15E3...
  • Page 176 6.4 UT55A/UT52A/UP55A D Registers Setup parameter Key operation setting (Menu: KEY), Display function setting (Menu: DISP), SELECT Display setting (Menu: CSEL) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol F1-K B.STS D5701 45701 1644 D5751 45751 1676 F2-K CTRS D5702 45702 1645 D5752 45752 1677 Fn-K D.CYC D5703 45703 1646 D5753 45753 1678...
  • Page 177 6.4 UT55A/UT52A/UP55A D Registers Setup parameter Lock setting (Key lock setting menu: KLOC) (Menu lock setting menu: MLOC) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D5801 45801 16A8 U.SP_L1 R/W R/W D5851 45851 16DA DI.SL-L DI.NU-L D5802 45802 16A9 U.SP_L2 R/W R/W D5852 45852 16DB U.OUT_L1 DI.D-L D5803 45803...
  • Page 178 6.4 UT55A/UT52A/UP55A D Registers Setup parameter DI function setting (DI function registration menu: DI.SL) (DI function numbering menu: DI.NU) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol A/M-D D5901 45901 170C D5951 45951 173E PN.B3 R/L_L1-D D5902 45902 170D D5952 45952 173F R/L_L2-D D5903 45903 170E D5953 45953 1740 PT.BC-D S/R-D...
  • Page 179 6.4 UT55A/UT52A/UP55A D Registers Setup parameter DI function setting (Message) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D6001 46001 1770 MSG1 R/W R/W D6051 46051 17A2 MSG3 D6002 46002 1771 MSG1 R/W R/W D6052 46052 17A3 D6003 46003...
  • Page 180 6.4 UT55A/UT52A/UP55A D Registers Setup parameter DI function setting (DI1-DI3 contact type setting menu: DI.D) (DI setting menu (E1 to E4): DI.D) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D6101 46101 17D4 DI1.D R/W R/W D6151 46151 1806 D6102 46102 17D5 DI2.D R/W R/W D6152 46152 1807 D6103 46103 17D6 DI3.D R/W R/W D6153...
  • Page 181 6.4 UT55A/UT52A/UP55A D Registers Setup parameter DO function setting (AL1-AL3 function registration menu: ALM) (DO setting menu (E1 to E4): DO) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D6201 46201 1838 AL1.S R/W R/W D6251 46251 186A AL2.S D6202 46202 1839 R/W R/W D6252 46252 186B AL3.S D6203 46203 183A R/W R/W D6253...
  • Page 182 6.4 UT55A/UT52A/UP55A D Registers Setup parameter I/O display (Menu: I/O) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol KEY-IO D6301 46301 189C D6351 46351 18CE D6302 46302 189D D6352 46352 18CF D6303 46303 189E D6353 46353 18D0 D6304 46304 189F D6354 46354...
  • Page 183 6.4 UT55A/UT52A/UP55A D Registers Setup parameter System setting (Menu: SYS) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D6401 46401 1900 R.MD R/W R/W D6451 46451 1932 D6402 46402 1901 R.TM R/W R/W D6452 46452 1933 D6403 46403 1902 D6453 46453 1934...
  • Page 184: Control Function Setting (D5001 To D5100)

    6.4 UT55A/UT52A/UP55A D Registers Control Function Setting (D5001 to D5100) Register Description Range and meaning of value 1: SGL (Single-loop control) 2: CAS1 (Cascade primary-loop control) 3: CAS2 (Cascade secondary-loop control) *1 4: CAS (Cascade control) 5: BUM (Loop control for backup) *1 6: PVSW (Loop control with PV switching) CTLM D5001...
  • Page 185 6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value D5015 0: TIME (Segment time setting) 1: TM.RT (Segment ramp-rate setting) D5016 SEG.T Segment setting method * Note: A change of setting deletes a program pattern. 0: HH.MM (hour.minute) D5017 Program time unit 1: MM.SS (minute.second)
  • Page 186: Input Setting (D5101 To D5300)

    6.4 UT55A/UT52A/UP55A D Registers Input Setting (D5101 to D5300) Register Description Range and meaning of value 0: OFF (Disable) 1: K1 (-270.0 to 1370.0°C / -450.0 to 2500.0 F) 2: K2 (-270.0 to 1000.0°C / -450.0 to 2300.0 F) 3: K3 (-200.0 to 500.0°C / -200.0 to 1000.0 F) 4: J (-200.0 to 1200.0°C / -300.0 to 2300.0 F) 5: T1 (-270.0 to 400.0°C / -450.0 to 750.0 F) 6: T2 (0.0 to 400.0°C / -200.0 to 750.0 F)
  • Page 187 6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value D5115 A.LC PV analog input low signal cutoff 0.0 to 5.0% D5116 to D5120 40: 0.4-2V (0.400 to 2.000 V) 41: 1-5V (1.000 to 5.000 V) 50: 0-2V (0.000 to 2.000 V) D5121 IN_E1 RSP remote input type...
  • Page 188 6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value D5181 IN_E4 AIN4 aux. analog input type Same as D5121 D5182 UNIT_E4 AIN4 aux. analog input unit Same as D5102 Maximum value of AIN4 aux. analog input D5183 DP_E4 Same as D5103 position D5184...
  • Page 189: Output Setting (D5301 To D5400)

    6.4 UT55A/UT52A/UP55A D Registers Output Setting (D5301 to D5400) Register Description Range and meaning of value 0: OFF 1: OUT terminals (voltage pulse) D5301 OT.H Heating-side control output selection 2: OUT terminals (current) 3: OUT terminals (relay) 4: OUT2 terminals (voltage pulse) 5: OUT2 terminals (current) 6: OUT2 terminals (relay) D5302...
  • Page 190 6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value When RTS=1 (PV1), 2 (SP1), 5 (PV2), 6 (SP2), 8 (TSP1), 12 (TSP2), 16 (PV), 17 (RSP), 18 (AIN2), 19 (AIN4), RTL+1digit to 30000 Decimal point position: RTS=1 (PV1), 2 (SP1), or 8 (TSP1): decimal point position is same as that of PV input.
  • Page 191 6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value Retransmission output type of D5327 O2RS Aame as D5321 OUT2 current output When O2RS=1 (PV1), 2 (SP1), 5 (PV2), 6 (SP2), 8 (TSP1), 12 (TSP2), 16 (PV), 17 (RSP), 18 (AIN2), or 19 (AIN4), O2RL+1digit to 30000 Decimal point position: O2RS=1 (PV1), 2 (SP1), 8 (TSP1): decimal point position...
  • Page 192: Heater Break Alarm Setting (D5401 To D5500)

    6.4 UT55A/UT52A/UP55A D Registers Heater Break Alarm Setting (D5401 to D5500) Register Description Range and meaning of value Heater break alarm-1 function D5401 HB1.S selection 0: Heater current measurement Heater break alarm-2 function 1: Heater break alarm D5402 HB2.S selection Heater break alarm-1 current D5403 setpoint...
  • Page 193: Communication Setting (D5501 To D5700)

    6.4 UT55A/UT52A/UP55A D Registers Communication Setting (D5501 to D5700) Register Description Range and meaning of value 0: PCL (PC link communication) 1: PCLSM (PC link communication (with checksum)) 2: LADR (Ladder communication) 3: CO-M (Coordinated master station) 4: CO-S (Coordinated slave station) D5501 PSL_E1 Protocol selection...
  • Page 194 6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value 4: 9600 (9600 bps) D5542 BPS_E3 Baud rate 5: 19200 (19.2k bps) 6: 38400 (38.4k bps) 0: NONE (None) D5543 PRI_E3 Parity 1: EVEN (Even) 2: ODD (Odd) IP1_E3 D5544 IP address 1 0 to 255...
  • Page 195 6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value 0: 125K (125k bps) Baud rate D5591 BR_E3-D *1 1: 250K (250k bps) (for DeviceNet communication) 2: 500K (500k bps) Address D5592 ADR_E3-D *1 0 to 63 (for DeviceNet communication) Baud rate D5593 BPS_E3-D *1 Same as D5583...
  • Page 196: Key Operation Setting, Display Function Setting, And Select Display Setting (D5701 To D5800)

    6.4 UT55A/UT52A/UP55A D Registers Key Operation Setting, Display Function Setting, and SELECT Display Setting (D5701 to D5800) Register Description Range and meaning of value 0: OFF (Disable) 1: A/M (AUTO/MAN switch) 2: C/A/M (CAS/AUTO/MAN switch) 3: R/L1 (REM/LCL switch) D5701 User function key-1 action setting 4: R/L2 (Loop-2 REM/LCL switch) 5: S/R (STOP/RUN switch)
  • Page 197 6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value 0: Fixed in white 1: Fixed in red 2: Link to alarm 1 (Alarm OFF: white, Alarm ON: red) 3: Link to alarm 1 (Alarm OFF: red, Alarm ON: white) 4: Link to alarm 1 or 2 (Alarm OFF: white, Alarm ON: red) 5: Link to alarm 1 or 2 (Alarm OFF: red, Alarm ON: white) D5713...
  • Page 198 6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value Setting range: 4001 to 6304 D5723 EV1_L1 Loop-1 EV1 display condition registration OFF: Disable 4321: Link to alarm 1 (Lit when the alarm occurs) 4322: Link to alarm 2 (Lit when the alarm occurs) 4323: Link to alarm 3 (Lit when the alarm occurs) D5724 EV2_L1...
  • Page 199 6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value D5739 PV.D PV display area ON/OFF 0: OFF (Nondisplay) D5740 SP.D Setpoint display area ON/OFF 1: ON (Display) STS.D D5741 Status display area ON/OFF D5742 Scroll speed (Slow) 1 to 8 (Quick) 0: OFF (Nondisplay) D5743 GUID...
  • Page 200 6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value D5757 to D5760 Register the operation parameter (except the Operation D5761 SELECT Display-1 registration Mode) that is frequently modified to display it in the Operation Display. D5762 SELECT Display-2 registration (Register the register number of the parameter) UT55A/UT52A D5763...
  • Page 201: Lock Setting (Key Lock/Menu Lock) (D5801 To D5900)

    6.4 UT55A/UT52A/UP55A D Registers Lock Setting (Key Lock/Menu Lock) (D5801 to D5900) Register Description Range and meaning of value U.SP_L1 D5801 Loop-1 SP Display lock D5802 U.SP_L2 Loop-2 SP Display lock D5803 U.OUT_L1 Loop-1 OUT Display lock D5804 U.OUT_L2 Loop-2 OUT Display lock D5805 U.HCO Heating/cooling OUT Display lock...
  • Page 202 6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value [DI.D] menu lock D5853 DI.D-L D5854 DI.D_E1-L [DI.D] menu lock (E1-terminal area) D5855 DI.D_E2-L [DI.D] menu lock (E2-terminal area) D5856 DI.D_E3-L [DI.D] menu lock (E3-terminal area) [DI.D] menu lock (E4-terminal area) D5857 DI.D_E4-L [ALM] menu lock...
  • Page 203: Di Function Setting (D5901 To D6200)

    6.4 UT55A/UT52A/UP55A D Registers DI Function Setting (D5901 to D6200) Register Description Range and meaning of value AUTO/MAN switch D5901 A/M-D R/L_L1-D *1 REMOTE/LOCAL switch D5902 REMOTE/LOCAL switch D5903 R/L_L2-D *1 STOP/RUN switch D5904 S/R-D Switch to CAS D5905 CAS-D Switch to AUTO D5906 AUTO-D MAN-D...
  • Page 204 6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value Set an I relay number of contact input. SP.B0 D5942 Bit-0 of SP number 0: OFF (Disable) Standard terminals DI1: 5025, DI2: 5026, DI3: 5027 E1-terminal area D5943 SP.B1 Bit-1 of SP number DI11: 5041, DI12: 5042, DI13: 5043, DI14: 5044, DI15: 5045, DI16: 5046...
  • Page 205: Do Function Setting (D6201 To D6300)

    6.4 UT55A/UT52A/UP55A D Registers DO Function Setting (D6201 to D6300) Register Description Range and meaning of value D6021 MSG2 D6022 MSG2 D6023 MSG2 20-digit value of alphanumeric characters can be D6024 MSG2 set. Arrangement: D6025 MSG2 D6021, D6022, D6023, D6024, D6025, D6026, D6026 MSG2 Messege-2 *2...
  • Page 206 6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value DI1.D_E3 DI31 contact type D6161 0: The assigned function is enabled when the contact is DI2.D_E3 DI32 contact type D6162 closed. DI3.D_E3 DI33 contact type D6163 1: The assigned function is enabled when the contact is DI4.D_E3 DI34 contact type D6164...
  • Page 207 6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value Set an I relay number (Setting range: 4001 to 6000, UP55A: 4001 to 6304). Ex.) Set the number 4353 for AL1.S to use the alarm 1. UT55A/UT52A 0: OFF (No function) D6201 AL1.S AL1 function selection...
  • Page 208 6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value D6206 AL1.D AL1 contact type 0: When the event of assigned function occurs, the contact is closed. D6207 AL2.D AL2 contact type 1: When the event of assigned function occurs, the D6208 AL3.D AL3 contact type...
  • Page 209: I/O Display (D6301 To D6400)

    6.4 UT55A/UT52A/UP55A D Registers I/O Display (D6301 to D6400)  Bit Configuration of D6301: KEY-IO*1 (Key status) Symbol Event PARA_KEY PARAMETER (PARA) key (0: OFF 1: ON) DISP_KEY DISPLAY (DISP) key (0: OFF 1: ON) RIGHT_KEY RIGHT key (0: OFF 1: ON) DOWN_KEY DOWN key (0: OFF 1: ON) SET_KEY...
  • Page 210: System Setting (D6401 To D6500)

    6.4 UT55A/UT52A/UP55A D Registers System Setting (D6401 to D6500) Register Description Range and meaning of value Set how the controller should recover from a power failure of 5 seconds or more. UT55A/UT52A 0: CONT (Continue action set before power failure.) 1: MAN (Start from MAN.) 2: AUTO (Start from AUTO.) R.MD...
  • Page 211: T Parameter (D6701 To D6800)

    6.4 UT55A/UT52A/UP55A D Registers 6.4.8 T Parameter (D6701 to D6800) T Parameter T Parameter D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D6701 46701 1A2C R/W R/W D6751 46751 1A5E D6702 46702 1A2D R/W R/W D6752 46752 1A5F D6703 46703 1A2E R/W R/W D6753 46753 1A60...
  • Page 212: T Parameter (D6701 To D6800)

    6.4 UT55A/UT52A/UP55A D Registers T Parameter (D6701 to D6800) Register Description Range and meaning of value This is used to display the value of the ladder of D6701 T1 register the timer or counter. D6702 T2 register D6703 T3 register 0 to 65535 D6704 T4 register D6705 T5 register...
  • Page 213 6.4 UT55A/UT52A/UP55A D Registers 6.4.9 Registers for Ladder Program (D7001 to D7600) Registers for ladder program For input ladder calculation D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D7001 47001 1B58 X_PV D7051 47051 1B8A PVIN_CTL D7002 47002 1B59 X_RSP D7052 47052 1B8B PVIN1_CTL D7003...
  • Page 214: Registers For Ladder Program (D7001 To D7600)

    6.4 UT55A/UT52A/UP55A D Registers Registers for ladder program For output ladder calculation D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D7101 47101 1BBC OUT_CTL D7151 47151 1BEE Y_OUT D7102 47102 1BBD OUT2_CTL D7152 47152 1BEF Y_OUT2 D7103 47103 1BBE...
  • Page 215 6.4 UT55A/UT52A/UP55A D Registers Registers for ladder program Status register D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D7201 47201 1C20 M1_16 R/W R/W D7251 47251 1C52 D7202 47202 1C21 M17_32 R/W R/W D7252 47252 1C53 D7203 47203 1C22...
  • Page 216 6.4 UT55A/UT52A/UP55A D Registers Registers for ladder program Constant register D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D7301 47301 1C84 R/W R/W D7351 47351 1CB6 D7302 47302 1C85 R/W R/W D7352 47352 1CB7 D7303 47303 1C86 R/W R/W D7353...
  • Page 217 6.4 UT55A/UT52A/UP55A D Registers Registers for ladder program Constant register D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D7401 47401 1CE8 D7451 47451 1D1A D7402 47402 1CE9 D7452 47452 1D1B D7403 47403 1CEA D7453 47453 1D1C D7404 47404 1CEB...
  • Page 218 6.4 UT55A/UT52A/UP55A D Registers Registers for ladder program Input range / scale D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D7501 47501 1D4C DP_R D7551 47551 1D7E D7502 47502 1D4D RH_R D7552 47552 1D7F D7503 47503 1D4E RL_R D7553...
  • Page 219: For Input Ladder Calculation (D7001 To D7100)

    6.4 UT55A/UT52A/UP55A D Registers For Input Ladder Calculation (D7001 to D7100)  D7001 to D7010 Register Description Range and meaning of value D7001 X_PV PV analog input -5.0 to 105.0% D7002 X_RSP RSP analog input -5.0 to 105.0% D7003 X_AIN2 AIN2 aux.
  • Page 220 6.4 UT55A/UT52A/UP55A D Registers  Bit Configuration of D7015: X400_E4 (DI41-DI46 status: E4-terminal area) Symbol Event X_DI41 DI41 status (0: OFF 1: ON) X_DI42 DI42 status (0: OFF 1: ON) X_DI43 DI43 status (0: OFF 1: ON) X_DI44 DI44 status (0: OFF 1: ON) X_DI45 DI45 status (0: OFF 1: ON) X_DI46 DI46 status...
  • Page 221: For Output Ladder Calculation (D7101 To D7200)

    6.4 UT55A/UT52A/UP55A D Registers For Output Ladder Calculation (D7101 to D7200)  D7101 to D7110 Register Description Range and meaning of value D7101 OUT_CTL Control OUT output -5.0 to 105.0% of control OUT output range D7102 OUT2_CTL Control OUT2 output -5.0 to 105.0% of control OUT2 output range D7103 RET_CTL...
  • Page 222 6.4 UT55A/UT52A/UP55A D Registers  Bit Configuration of D7115: DO40_E4 (Control DO41-DO45 status: E4-terminal area) Symbol Event DO41_CTL Control DO41 status (0: OFF 1: ON) DO42_CTL Control DO42 status (0: OFF 1: ON) DO43_CTL Control DO43 status (0: OFF 1: ON) DO44_CTL Control DO44 status (0: OFF 1: ON) DO45_CTL Control DO45 status (0: OFF...
  • Page 223: Status Registers (D7201 To D7300)

    6.4 UT55A/UT52A/UP55A D Registers  Bit Configuration of D7164: Y300_E3 (DO31-DO35 status: E3-terminal area) Symbol Event Y_DO31 DO31 status (0: OFF 1: ON) Y_DO32 DO32 status (0: OFF 1: ON) Y_DO33 DO33 status (0: OFF 1: ON) Y_DO34 DO34 status (0: OFF 1: ON) Y_DO35 DO35 status (0: OFF 1: ON) 5 to 15  Bit Configuration of D7165: Y400_E4 (DO41-DO45 status: E4-terminal area)
  • Page 224 6.4 UT55A/UT52A/UP55A D Registers  Bit Configuration of D7213 to D7218: M33_48_B to M113_128_B (Status register (M33_B-M48_B to M113_B-M128_B, Holding type) Symbol Event M33_B M49_B M65_B M81_B M97_B M113_B Internal relay (Holding type) * (0: OFF 1: ON) M34_B M50_B M66_B M82_B M98_B M114_B Internal relay (Holding type) * (0: OFF 1: ON) M35_B M51_B M67_B M83_B M99_B...
  • Page 225: Constant Register (D7301 To D7500)

    6.4 UT55A/UT52A/UP55A D Registers Constant Register (D7301 to D7500) Register Description Range and meaning of value D7301 K01 data register to K30 data K01 to K20: -32768 to 32767 K01 to K30 register K21 to K30: 0 to 65535 D7330 D7331 to D7409 D7410 Constant -1...
  • Page 226 6.4 UT55A/UT52A/UP55A D Registers Register Description Range and meaning of value Maximum value of AIN4 aux. analog input D7525 DP_E4_R Same as D5183 (DP_E4) position Maximum value of AIN4 aux. analog input D7526 RH_E4_R Same as D5184 (RH_E4) range Minimum value of AIN4 aux. analog input D7527 RL_E4_R Same as D5185 (RL_E4)
  • Page 227: Input / Output Terminal Status Register (D7601 To D7700)

    6.4 UT55A/UT52A/UP55A D Registers 6.4.10 Input / Output Terminal Status Register (D7601 to D7700) Terminal status registers Input / output terminal status register D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D7601 47601 1DB0 D7651 47651 1DE2 D7602 47602...
  • Page 228 6.4 UT55A/UT52A/UP55A D Registers  Bit Configuration of D7601: DI (DI1-DI3 terminal status: equipped as standard) Symbol Event DI1 terminal status (0: OFF 1: ON) DI2 terminal status (0: OFF 1: ON) DI3 terminal status (0: OFF 1: ON) 3 to 15  Bit Configuration of D7602: DI_E1 (DI11-DI16 terminal status: E1-terminal area) Symbol Event DI11 DI11 terminal status (0: OFF 1: ON) DI12 DI12 terminal status...
  • Page 229 6.4 UT55A/UT52A/UP55A D Registers  Bit Configuration of D7612: OUT_DO_E1 (DO11-DO15 terminal status: E1- terminal area) Symbol Event OUT_DO11 DO11 terminal status (0: OFF 1: ON) OUT_DO12 DO12 terminal status (0: OFF 1: ON) OUT_DO13 DO13 terminal status (0: OFF 1: ON) OUT_DO14 DO14 terminal status (0: OFF 1: ON) OUT_DO15 DO15 terminal status (0: OFF...
  • Page 230 6.4 UT55A/UT52A/UP55A D Registers  D7616 to D7700 Register Description Range and meaning of value D7616 to D7620 D7621 OUT_OUT OUT terminal -1500 to 31500 UT55A/UP55A Cooling-side control output: OUT2 terminal (Relay) Heater break alarm: HAL1 terminal 0: OFF D7622 OUT_OUT2H Position proportional control output: 30000: ON...
  • Page 231: Program Pattern For Up55A (D8001 To D9000)

    6.4 UT55A/UT52A/UP55A D Registers 6.4.11 Program Pattern for UP55A (D8001 to D9000) Pattern Data Setting (D8001 to D8100) Register Ref. Register H No. Description Range and meaning of value symbol 0: Not select program pattern D8001 48001 1F40 PTNO._C R/W Program pattern number selection 1 to 30 (1 to 99) D8002 48002 1F41 SEGNO._C...
  • Page 232: Reading Pattern Data (D8001 To D8100)

    6.4 UT55A/UT52A/UP55A D Registers Reading Pattern Data (D8001 to D8100)  Modbus communication The example for the communication command is Modbus/RTU. For easy understanding, space is added but it is not present in the actual command. The device address is “1.”  Reading start segment data Example: Reading start target setpoint (SSP_L1) for pattern 2 (1) Write pattern number “2”...
  • Page 233: Writing Pattern Data (D8001 To D8100)

    6.4 UT55A/UT52A/UP55A D Registers Writing Pattern Data (D8001 to D8100)  Modbus communication The example for the communication command is Modbus/RTU. For easy understanding, space is added but it is not present in the actual command. The device address is “1.”  Writing start segment data Example: Writing “2” to start code (STC) for pattern 2 (1) Write pattern number “2”...
  • Page 234: Segment Data Setting (D8101 To D8200)

    6.4 UT55A/UT52A/UP55A D Registers Segment Data Setting (D8101 to D8200) Register Ref. Register H No. Description Range and meaning of value symbol 0: Not select program pattern D8101 48101 1FA4 PTNO._C R/W Program pattern number selection 1 to 30 D8102 48102 1FA5 SEGNO._C R/W Segment number designation...
  • Page 235 6.4 UT55A/UT52A/UP55A D Registers Register Ref. Register H No. Description Range and meaning of value symbol OFF: Disable (Energized) 1: PV high limit, 02: PV low limit, 3: SP high limit, 04: SP low limit, 5: Deviation high limit, 6: Deviation low limit, 7: Deviation high and low limits, 8: Deviation within high and low limits, 9: Target SP high limit,...
  • Page 236 6.4 UT55A/UT52A/UP55A D Registers Register Ref. Register H No. Description Range and meaning of value symbol D8128 48128 1FBF TME2 R/W Start condition of time event 2 D8129 48129 1FC0 T.ON2 R/W On time of time event 2 D8130 48130 1FC1 T.OF2 R/W Off time of time event 2...
  • Page 237: Reading Segment Data (D8101 To D8200)

    6.4 UT55A/UT52A/UP55A D Registers Reading Segment Data (D8101 to D8200)  Modbus communication The example for the communication command is Modbus/RTU. For easy understanding, space is added but it is not present in the actual command. The device address is “1.” Example: Reading final target setpoint (TSP_L1) of segment 5 for pattern 3 (1) Write pattern number “3”...
  • Page 238: Writing Segment Data (D8101 To D8200)

    6.4 UT55A/UT52A/UP55A D Registers Writing Segment Data (D8101 to D8200)  Modbus communication The example for the communication command is Modbus/RTU. For easy understanding, space is added but it is not present in the actual command. The device address is “1.” Example: Writing final target setpoint (TSP_L1) of segment 5 for pattern 3 (1) Write pattern number “3”...
  • Page 239: Loop-1 Final Target Setpoint Setting For Batch Writing (D8201 To D8400)

    6.4 UT55A/UT52A/UP55A D Registers Loop-1 Final Target Setpoint Setting for Batch Writing (D8201 to D8400) Register Ref. Register H No. Description Range and meaning of value symbol Program pattern number 0: Not select program pattern D8201 48201 2008 PTNO._C selection 1 to 30 D8202 48202...
  • Page 240 6.4 UT55A/UT52A/UP55A D Registers Register Ref. Register H No. Description Range and meaning of value symbol Program pattern number 0: Not select program pattern D8301 48301 206C PTNO._C selection 1 to 30 D8302 48302 206D TSP_L1_S50 R/W Segment-50 final target setpoint D8303 48303 206E...
  • Page 241: Final Target Setpoint Of Program Pattern-2 Retransmission For Batch Writing (D8401 To D8600)

    6.4 UT55A/UT52A/UP55A D Registers Final Target Setpoint of Program Pattern-2 Retransmission for Batch Writing (D8401 to D8600) Register Ref. Register H No. Description Range and meaning of value symbol Program pattern number 0: Not select program pattern D8401 48401 20D0 PTNO._C selection 1 to 30 D8402 48402 20D1 0.0 to 100.0% of PV input range (EU) D8403 48403 20D2...
  • Page 242 6.4 UT55A/UT52A/UP55A D Registers Register Ref. Register H No. Description Range and meaning of value symbol Program pattern number 0: Not select program pattern D8501 48501 2134 PTNO._C selection 1 to 30 D8502 48502 2135 TSP_L2_S50 R/W Segment-50 final target setpoint D8503 48503 2136...
  • Page 243: Segment Time Setting For Batch Writing (D8601 To D8800)

    6.4 UT55A/UT52A/UP55A D Registers Segment Time Setting for Batch Writing (D8601 to D8800) Register Ref. Register H No. Description Range and meaning of value symbol Program pattern number 0: Not select program pattern D8601 48601 2198 PTNO._C selection 1 to 30 D8602 48602 2199...
  • Page 244 6.4 UT55A/UT52A/UP55A D Registers Register Ref. Register H No. Description Range and meaning of value symbol Program pattern number 0: Not select program pattern D8701 48701 21FC PTNO._C selection 1 to 30 D8702 48702 21FD R/W Segment-50 segment time setting D8703 48703 21FE...
  • Page 245: Segment Ramp-Rate Setting For Batch Writing (D8801 To D9000)

    6.4 UT55A/UT52A/UP55A D Registers Segment Ramp-Rate Setting for Batch Writing (D8801 to D9000) Register Ref. Register H No. Description Range and meaning of value symbol 0: Not select program pattern D8801 48801 2260 PTNO._C R/W Program pattern number selection 1 to 30 D8802 48802 2261...
  • Page 246 6.4 UT55A/UT52A/UP55A D Registers Register Ref. Register H No. Description Range and meaning of value symbol 0: Not select program pattern D8901 48901 22C4 PTNO._C R/W Program pattern number selection 1 to 30 D8902 48902 22C5 R/W Segment-50 segment ramp-rate setting D8903 48903 22C6...
  • Page 247: Reading Data (Multiple Segment Data) (D8201 To D8953)

    6.4 UT55A/UT52A/UP55A D Registers Reading Data (Multiple Segment Data) (D8201 to D8953)  Modbus communication The example for the communication command is Modbus/RTU. For easy understanding, space is added but it is not present in the actual command. The device address is “1.” Example: Batch reading SSP_L1 and target setpoints in segments 1 to 5 (TSP_L1_S1 to TSP_L1_S5) for pattern 3 (1) Write pattern number “3”...
  • Page 248: Writing Data (Multiple Segment Data) (D8201 To D8953)

    6.4 UT55A/UT52A/UP55A D Registers Writing Data (Multiple Segment Data) (D8201 to D8953)  Modbus communication The example for the communication command is Modbus/RTU. For easy understanding, space is added but it is not present in the actual command. The device address is “1.” Example: Batch writing SSP_L1 and target setpoints in segments 1 to 5 (TSP_L1_S1 to TSP_L1_S5) for pattern 3 (1) Write to 52 registers continuously: pattern number “3”...
  • Page 249: Used Pattern Numbers And The Number Of Remaining Unused Segments (D8961 To D8963)

    6.4 UT55A/UT52A/UP55A D Registers Used Pattern Numbers and the Number of Remaining Unused Segments (D8961 to D8963) Register Ref. Register H No. Description Range and meaning of value symbol Used program pattern D8961 48961 2300 PTN_USE1 R/W See below numbers (Patterns 1 to 16) Used program pattern See below D8962 48962 2301 PTN_USE2 R/W numbers (Patterns 17 to 32) Program pattern 31 and 32 (UP55A with option code /AP)
  • Page 250 6.4 UT55A/UT52A/UP55A D Registers  Bit Configuration of D8965: PTN_USE3 (Used program pattern numbers (Patterns 33 to 48)) Symbol Event PT33_USE Used pattern 33 PT34_USE Used pattern 34 PT35_USE Used pattern 35 PT36_USE Used pattern 36 PT37_USE Used pattern 37 PT38_USE Used pattern 38 PT39_USE Used pattern 39 PT40_USE Used pattern 40 PT41_USE Used pattern 41 PT42_USE Used pattern 42...
  • Page 251 6.4 UT55A/UT52A/UP55A D Registers  Bit Configuration of D8968: PTN_USE6 (Used program pattern numbers (Patterns 81 to 96)) Symbol Event PT81_USE Used pattern 81 PT82_USE Used pattern 82 PT83_USE Used pattern 83 PT84_USE Used pattern 84 PT85_USE Used pattern 85 PT86_USE Used pattern 86 PT87_USE Used pattern 87 PT88_USE Used pattern 88 PT89_USE Used pattern 89 PT90_USE Used pattern 90...
  • Page 252: Check The Number Of Segments, Copy And Clear Of Program Pattern (D8971 To D8993)

    6.4 UT55A/UT52A/UP55A D Registers Check the Number of Segments, Copy and Clear of Program Pattern (D8971 to D8993) Register Ref. Register H No. Description Range and meaning of value symbol Pattern number designation for 0: not select program pattern D8971 48971 230A PTN.S comfirming number of segments 1 to 30 The number of the segment is displayed when the program pattern number is specified Number of segments within a D8972...
  • Page 253: Error Information

    6.4 UT55A/UT52A/UP55A D Registers  PC link communication The example for the communication command is a PC link without a checksum. The device address is “1.”  How to check the number of segments used in one pattern Example: Checking segment numbers used in pattern 3 (1) Write pattern number “3” to D8971 (PTN.S). (2) Read from D8972 (USE.S).
  • Page 254: Writing Via Communication

    Writing via Communication  Setting Target Setpoint In LCL (local) mode (1) Set the Loop-1 and Loop-2 target setpoints of groups 1 to 8 parameters (SP_L1_1 to SP_L1_8 or SP_L2_1 to SP_L2_8). (2) Write the setpoint (1 to 8) in the SPNO. (SP number selection) (depends on the setup parameter SPGR.
  • Page 255 6.5 Writing via Communication  Setting PID Number (D2503: PIDN_L1_1 to D2643: PIDN_L1_8, D3603: PIDN_L2_1 to D3743: PIDN_L2_8) PID number can be selected via communication only when the zone PID selection parameter (ZON) is set to 1, 2, or 4. D2503 to D2643 = 1 to 8, D3603 to D3743 = 1 to 8 (depends on the setup parameter SPGR.
  • Page 256: Green Series Compatible D Registers

    GREEN Series Compatible D Registers 6.6.1 Compatibility with GREEN Series Controllers The D register map configuration of the UTAdvanced is the same as that of the GREEN Series (UT500 Series/UP550) controllers that perform access in the 2-byte integer data format. When GREEN Series devices are replaced with the UTAdvanced, communication programs created in the GREEN Series controllers can be used by just carrying out wiring.
  • Page 257 6.6 GREEN Series Compatible D Registers  D register symbols • With regards to some D register symbols, the loop number, terminal area, and group number are indicated by adding the underline (_) to the end of the parameter symbols. If both the loop number and group number are added to the parameter symbols, they are added in the order of _loop number and _group number.
  • Page 258: Process Data And User Area (D0001 To D0100)

    6.6 GREEN Series Compatible D Registers 6.6.3 Process Data and User Area (D0001 to D0100) Configuration map for GREEN Series Process data User area Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0001 40001 0000 ADERROR AD1.E_G D0051 40051 0032 USER USER1...
  • Page 259 6.6 GREEN Series Compatible D Registers Configuration map for GREEN Series Program setting parameters Process data User area Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0101 40101 0064 LSP1 (Note) LSP1_L1 (D2201) R/W D0151 40151 0096 D0102 40102 0065 LSP2 (Note) LSP2_L2 (D2202) R/W D0152 40152 0097...
  • Page 260: Operation Mode And Operation-Related Parameters (D0201 To D0300)

    6.6 GREEN Series Compatible D Registers 6.6.4 Operation Mode and Operation-related Parameters (D0201 to D0300) Configuration map for GREEN Series Operation mode / Operation-related parameters Register Register Register D-Reg Ref. Register symbol D-Reg Ref. H No. symbol for H No. symbol for symbol for for UTAdvanced GREEN GREEN UTAdvanced D0201 40201 00C8 A/M1 (Note 1) A.M (D2301) R/W D0251 40251 00FA ORH.1 D0202 40202 00C9 D0252 40252 00FB ORL.1...
  • Page 261: Loop-1 Pid Parameters (D0301 To D0500)

    6.6 GREEN Series Compatible D Registers 6.6.5 Loop-1 PID Parameters (D0301 to D0500) Configuration map for GREEN Series Loop-1 SP / AL / PID parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0301 40301 012C 1.SP (Note 1) SP_L1_1 (D2501) R/W D0351 40351 015E 3.SP (Note 1) SP_L1_3 (D2541) R/W A1_L1_1 (D2504) R/W D0352 40352 015F 3.A1 (Note 1) A1_L1_3 (D2544) R/W D0302 40302 012D 1.A1 (Note 1)
  • Page 262 6.6 GREEN Series Compatible D Registers Configuration map for GREEN Series Loop-1 SP / AL / PID parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0401 40401 0190 5.SP (Note 1) SP_L1_5 (D2581) R/W D0451 40451 01C2 7.SP (Note 1) SP_L1_7 (D2621) R/W D0402 40402 0191 5.A1 (Note 1) A1_L1_5 (D2584) R/W D0452 40452 01C3 7.A1 (Note 1) A1_L1_7 (D2624) R/W...
  • Page 263: Loop-2 Pid Parameters (D0501 To D0700)

    6.6 GREEN Series Compatible D Registers 6.6.6 Loop-2 PID Parameters (D0501 to D0700) Configuration map for GREEN Series Loop-2 SP / AL / PID parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0501 40501 01F4 1.SP (Note 1) SP_L2_1 (D3601) R/W D0551 40551 0226 3.SP (Note 1) SP_L2_3 (D3641) R/W A1_L2_1 (D3604) R/W D0552 40552 0227 3.A1 (Note 1) A1_L2_3 (D3644) R/W D0502 40502 01F5 1.A1 (Note 1)
  • Page 264 6.6 GREEN Series Compatible D Registers Configuration map for GREEN Series Loop-2 SP / AL / PID parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0601 40601 0258 5.SP (Note 1) SP_L2_5 (D3681) R/W D0651 40651 028A 7.SP (Note 1) SP_L2_7 (D3721) R/W D0602 40602 0259 5.A1 (Note 1) A1_L2_5 (D3684) R/W D0652 40652 028B 7.A1 (Note 1) A1_L2_7 (D3724) R/W...
  • Page 265: User Parameters And 10-Segment Linearizer Parameters (D0701 To D0800)

    6.6 GREEN Series Compatible D Registers 6.6.7 User Parameters and 10-segment Linearizer Parameters (D0701 to D0800) Configuration map for GREEN Series User parameters / 10-segment linearizer parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced A1_2 (D4832) D0701 40701 02BC U1 Depends on the conditions (Note1) R/W D0751 40751 02EE 2.A1 D0702 40702 02BD U2 Depends on the conditions (Note1) R/W D0752 40752 02EF 2.B1...
  • Page 266: Message (D0801 To D0900)

    6.6 GREEN Series Compatible D Registers 6.6.8 Message (D0801 to D0900) Configuration map for GREEN Series Message Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0801 40801 0320 MG10 (Note 1) D0851 40851 0352 D0802 40802 0321 MG11 (Note 1) D0852 40852 0353...
  • Page 267: Control Action Parameters (D0901 To D1000)

    6.6 GREEN Series Compatible D Registers 6.6.9 Control Action Parameters (D0901 to D1000) Configuration map for GREEN Series Control action parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0901 40901 0384 RMS.1 (Note 1) RMS_L1 (D2701) R/W D0951 40951 03B6 D0902 40902 0385 SPT.1 SPT_L1 (D2710) R/W D0952 40952 03B7...
  • Page 268: Common Function Parameters (D1001 To D1100)

    6.6 GREEN Series Compatible D Registers 6.6.10 Common Function Parameters (D1001 to D1100) Configuration map for GREEN Series Common function parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D1001 41001 03E8 A.BS1 A.BS (D5112) R/W D1051 41051 041A D1002 41002 03E9 A.FL1...
  • Page 269: Display And Input / Output Parameters (D1101 To D1200)

    6.6 GREEN Series Compatible D Registers 6.6.11 Display and Input / Output Parameters (D1101 to D1200) Configuration map for GREEN Series Display and input / Output parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced R/W D1151 41151 047E ADV (Note 2) D1101 41101 044C C.S1 047F A/M.1 (Note 2) D1102 41102 044D C.S2...
  • Page 270: Control Mode, Pv Input, And Control Output Parameters (D1201 To D1300)

    6.6 GREEN Series Compatible D Registers 6.6.12 Control Mode, PV Input, and Control Output Parameters (D1201 to D1300) Configuration map for GREEN Series Control mmode, PV input, and Control output parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D1201 41201 04B0 IN1 IN (D5101) R/W D1251 41251 04E2 DLN1 Depends on the conditions (Note3) R/W D1202 41202 04B1 UNI1...
  • Page 271: D Registers Converted For Green Series

    6.6 GREEN Series Compatible D Registers 6.6.13 D Registers Converted for GREEN Series  Bit Configuration of D0001: AD1.E_G (A/D converter error status for GREEN Series) Symbol Event GREEN Series UTAdvanced AD1ERR.st ADERR (I4065) PV input A/D converter error AD3ERR.st ADERR_E1 (I4066) RSP input (E1-terminal area) A/D converter error AD1BO.st ADBO (I4073) PV input burnout error AD3BO.st ADBO_E1 (I4074)
  • Page 272 6.6 GREEN Series Compatible D Registers  Bit Configuration of D0008: MOD_L1_G (Loop-1 operation mode status for GREEN Series) UT55A/UT52A Symbol Event GREEN Series UTAdvanced A/M1.st A.M (I4193) 0: AUTO, 1: MAN R/L1.st R.L_L1 (I4194) 0: Local, 1: Remote R/S1.st S.R (I4195) 0: Run, 1: Stop CAS.st CAS_ON (I4197) 1: CAS AUT.st AUTO_ON (I4198) 1: AUTO *2...
  • Page 273 6.6 GREEN Series Compatible D Registers  Bit Configuration of D0018: PV1.E_L2_G (Loop-2 PV input error status for GREEN Series) UT55A/UT52A Symbol Event GREEN Series UTAdvanced PV2ADC.st (Not used) PV2BO.st PVBO_L2 (I4113) Loop-2 PV input burnout error RJC2ERR.st (Not used) PV2+over.st PVPOV_L2 (I4117) Loop-2 PV input over-scale PV2-over.st PVMOV_L2 (I4118) Loop-2 PV input under-scale 6 to 7 RSP2ADC.st (Not used)
  • Page 274 6.6 GREEN Series Compatible D Registers  Bit Configuration of D0035: PA.ER_G (Parameter error status for GREEN Series) Symbol Event GREEN Series UTAdvanced CALB.E.st CALB_ERR (I4002) Calibration value error 1 to 3 UTMD.st SETPA_ERR (I4005) Setup parameter error RANGE.st SETPA_ERR (I4005) Setup parameter error SETUP.st SETPA_ERR (I4005) Setup parameter error PARA.E.st OPEPA_ERR (I4006) Operation parameter error MODE.E.st...
  • Page 275 6.6 GREEN Series Compatible D Registers  D0231: A1_G (Alarm-1 setpoint for GREEN Series) (For UT400 Series) Symbol Register Event GREEN Series UTAdvanced D0231 A1_G -19999 to 30000 (Set a value within the input range.) Write: The value written in A1_G will be written in the register of A1_L1_1 to A1_L1_4. A1_L1_1 (D2504) A1_L1_2 (D2524) A1_L1_3 (D2544)
  • Page 276: D Registers Differring In Content From Green Series

    6.6 GREEN Series Compatible D Registers 6.6.14 D Registers Differring in Content from GREEN Series  Bit Configuration of D0033: DI00 (DI1 to DI3 terminal status) Symbol Event GREEN Series UTAdvanced DI1.st 0: OFF 1: ON DI2.st 0: OFF 1: ON DI3.st 0: OFF 1: ON DI4.st (Not used) DI5.st (Not used) DI6.st (Not used)
  • Page 277 6.6 GREEN Series Compatible D Registers  D0302 to D0480: A1_L1_1 to A4_L1_8 (Loop-1 Alarm-1 setpoint to Alarm-8 setpoint of Groups 1 to 4) (For UT500 Series) When the Loop-1 Alarm-1 setpoint to Alarm-4 setpoint (D0915: AL1.1, D0916: AL2.1, D0917: AL3.1, D0918: AL4.1) are the following values (Deviation low limit alarm), the sign of the alarm setpoint is reversed and is set to UTAdvanced.
  • Page 278 6.6 GREEN Series Compatible D Registers Loop-1 Alarm-1 setpoint to Alarm-8 setpoint of Groups 4 When D0918 (AL4.1) = 4, 6, 14, 16, 34, 44, 36, 46 Symbol Event GREEN Series UTAdvanced D0305 1.A4 A4_L1_1 (D2507) D0330 2.A4 A4_L1_2 (D2527) D0355 3.A4 A4_L1_3 (D2547)
  • Page 279 6.6 GREEN Series Compatible D Registers Loop-2 Alarm-1 setpoint to Alarm-8 setpoint of Groups 3 When D0957 (AL3.2) = 4, 6, 14, 16, 34, 44, 36, 46 Symbol Event GREEN Series UTAdvanced D0504 1.A3 A3_L2_1 (D3606) D0529 2.A3 A3_L2_2 (D3626) D0554 3.A3 A3_L2_3 (D3646)
  • Page 280 6.6 GREEN Series Compatible D Registers GREEN Series Register Description Range and meaning of value OFF (0), 1 to 20, 25 to 31, 33 to 38, 43 to 48 1: PV high limit (energized, no stand-by action) 2: PV low limit (energized, no stand-by action) 3: Deviation high limit (energized, no stand-by action) D0915 AL1.1...
  • Page 281 6.6 GREEN Series Compatible D Registers  D0955 to D0958: Loop-2 alarm-1 type to alarm-4 type UTAdvanced Register Description Range and meaning of value 00: Disable 01: PV high limit 02: PV low limit 03: SP high limit D0955 AL1.T_L2 Loop-2 alarm-1 type 04: SP low limit 05: Deviation high limit 06: Deviation low limit 07: Deviation high and low limits 08: Deviation within high and low limits...
  • Page 282 6.6 GREEN Series Compatible D Registers  D1266: Initialization to factory default value UTAdvanced Register Description Range and meaning of value -12345: Initialization, automatically returned to "0" after D1266 F.DEF Initialization to factory default value initialization. GREEN Series Register Description Range and meaning of value 0: OFF D1266 Parameter initialization 1: ON (Initialize parameters)
  • Page 283: D Registers Differring Depending On Conditions

    6.6 GREEN Series Compatible D Registers 6.6.15 D Registers Differring Depending on Conditions  D registers differring depending on the setting of the control type (CNT_L1) Example: When CNT_L1 = 0, 1, 2, 5, 6, or 7, D0310 is D3005 (OL_L1_1) data. When CNT_L1 = 3 or 4, D0310 is D3016 (OHc_L1_1) data. ONOF ONOF2 2P2L...
  • Page 284 6.6 GREEN Series Compatible D Registers  D registers differring depending on the model Example: For UT55A, D1247 is PSL_E4. For UT52A, D1247 is PSL_E1. For UP55A, D1247 is PSL_E3. Register Name of UT55A UT52A UP55A GREEN D1247 PSL1 D5531 (PSL_E4) D5501 (PSL_E1) D5521 (PSL_E3) D1248...
  • Page 285 Blank Page...
  • Page 286: Chapter 7 Functions And Applications Of I Relays (For Ut55A/Ut52A/Up55A)

    Chapter 7 Functions and Applications of I Relays (for UT55A/UT52A/UP55A) Overview This chapter describes the functions and applications of the I relays. I relays are used in ladder program, Modbus communication, PC link communication, and contact input / output functions. I relays contain status information of errors, operation, and alarms. Contents of I relays can be read only by means of communication using a host computer.
  • Page 287: Classification Of I Relays

    Classification of I Relays I relays are classified as shown below. Classification of I Relay Map Area and data I relay No. Description categories Each bit information is the same as that of 1 to 192 Status D register. 193 to 576 Free area GREEN series SP number, PID number,...
  • Page 288 7.2 Classification of I Relays Area and data I relay No. Description categories Each bit information is the same as that of 6305 to 6432 DI terminal D register. Input / Output Each bit information is the same as that of 6433 to 6560 terminal status DO terminal...
  • Page 289: Ut55A/Ut52A/Up55A I Relays

    7.3 UT55A/UT52A/UP55A I Relays 7.3.1 Function Status (4001 to 5024) Note When specifying an I relay number for communication, begin the number with the character “I.” Example: Set “I4065” to specify the ADERR (I relay No.: 4065). IM 05P07A01-01EN...
  • Page 290 7.3 UT55A/UT52A/UP55A I Relays System error Input error I relay symbol I relay symbol UT55A/UT52A UP55A UT55A/UT52A UP55A SYSTEM_ERR 4001 4065 ADERR CALB_ERR 4066 4002 ADERR_E1 UPARA_ERR 4003 4067 ADERR_E2 4004 4068 4005 SETPA_ERR 4069 ADERR_E4 OPEPA_ERR 4006 4070 RJCERR PROG_ERR 4007 4071...
  • Page 291 7.3 UT55A/UT52A/UP55A I Relays Operation mode Operation mode Operation mode I relay symbol I relay symbol I relay symbol UT55A/UT52A UP55A UT55A/UT52A UP55A UT55A/UT52A UP55A 4129 4193 A.M 4257 WTEND1 4130 4194 R.L_L1 4258 WTEND3 4131 4195 S.R 4259 WTEND5 4132 4196 4260...
  • Page 292 7.3 UT55A/UT52A/UP55A I Relays Alarm Alarm latch Alarm latch I relay symbol I relay symbol I relay symbol UT55A/UT52A UP55A UT55A/UT52A UP55A UT55A/UT52A UP55A 4321 ALM1_L1 4385 ALO1LA1_L1 4449 ALO1LA3_L1 4322 ALM2_L1 4386 ALO2LA1_L1 4450 ALO2LA3_L1 4323 ALM3_L1 4387 ALO3LA1_L1 4451 ALO3LA3_L1 4324 4388...
  • Page 293 7.3 UT55A/UT52A/UP55A I Relays Alarm latch and Heater break alarm SP number and PID number Pattern number and Segment number I relay symbol I relay symbol I relay symbol UT55A/UT52A UP55A UT55A/UT52A UP55A UT55A/UT52A UP55A 4513 ALOLA_RLS 4577 CSPN.B0 4641 PTNO.B0 4514 ALM_WAIT 4578 CSPN.B1 4642 PTNO.B1 4579 CSPN.B2 4643 PTNO.B2 4515 4580 CSPN.B3...
  • Page 294 7.3 UT55A/UT52A/UP55A I Relays Display, PV event status and Time event status I relay symbol I relay symbol UT55A/UT52A UP55A UT55A/UT52A UP55A PARA_KEY MG1.B 4705 4769 DISP_KEY MG2.B 4706 4770 RIGHT_KEY MG3.B 4707 4771 DOWN_KEY 4708 4772 4709 SET_KEY 4773 MG4.B UP_KEY 4710 4774 LEFT_KEY 4711 4775 F2_KEY 4712 4776...
  • Page 295 7.3 UT55A/UT52A/UP55A I Relays Pattern number status and Segment number status Pattern number status and Segment number status Pattern number status and Segment number status I relay symbol I relay symbol I relay symbol UT55A/UT52A UP55A UT55A/UT52A UP55A UT55A/UT52A UP55A 4833 TIME_EV9 4897 SEG1 4961 SEG65 4834 TIME_EV10 4898 SEG2 4962 SEG66 4835 TIME_EV11 4899 SEG3 4963 SEG67 4836 4900 SEG4 4964 SEG68...
  • Page 296: System Error, Input Error, And Operation Mode (4001 To 4320)

    7.3 UT55A/UT52A/UP55A I Relays System Error, Input Error, and Operation Mode (4001 to 4320) UT55A/UT52A I relay No. Symbol Event SYSTEM_ERR to 4001 to 4016 Parameter error status (Same as D2068) CTLPA_ERR LAD_ERR to 4017 to 4032 Ladder error status (Same as D2012) LD200_OVER E1_ERR to 4033 to 4048...
  • Page 297: Alarm, Alarm Latch, And Heater Break Alarm (4321 To 4576)

    7.3 UT55A/UT52A/UP55A I Relays Alarm, Alarm Latch, and Heater Break Alarm (4321 to 4576) I relay No. Symbol Event 4321 to 4336 ALM1_L1~ALM8_L1 Loop-1 alarm-1 to alarm-8 status (Same as D2011) 4337 to 4352 ALM1_L2~ALM8_L2 Loop-2 alarm-1 to alarm-8 status (Same as D2013) 4353 to 4368 ALO1_L1 to ALO8_L1 Loop-1 alarm-1 to alarm-8 output status (Same as D2037)
  • Page 298: Sp Number, Pid Number, Pattern Number And Segment Number (4577 To 4704)

    7.3 UT55A/UT52A/UP55A I Relays SP Number, PID Number, Pattern Number and Segment Number (4577 to 4704) UT55A/UT52A I relay No. Symbol Event CSPN.B0 to 4577 to 4592 *1 SP number (Same as D2312) CSPN.B3 4593 to 4608 PIDN.B0_L1 to 4609 to 4624 *1 Loop-1 PID number (Same as D2009) PIDN.B3_L1 PIDN.B0_L2 to 4625 to 4640 *1 Loop-2 PID number (Same as D2025) PIDN.B3_L2...
  • Page 299: Display, Pv Event Status And Time Event Status (4769 To 5024)

    7.3 UT55A/UT52A/UP55A I Relays Display, PV Event Status and Time Event Status (4769 to 5024) UT55A/UT52A I relay No. Symbol Event 4769 to 4773 MG1.B to MG4.B Message display interruption status (Same as D2066) 4779 PVRW_L1 Loop-1 PV red/white switch 0: White color 1: Red color 4780 PVRW_L2...
  • Page 300: Status For Ladder Program (5025 To 5664)

    7.3 UT55A/UT52A/UP55A I Relays 7.3.2 Status for Ladder Program (5025 to 5664) Note When specifying an I relay number for communication, begin the number with the character “I.” Example: Set “I5025” to specify the X_DI1 (I relay No.: 5025). 7-15 IM 05P07A01-01EN...
  • Page 301 7.3 UT55A/UT52A/UP55A I Relays Input (status) relay Input (status) relay I relay symbol I relay symbol UT55A/UT52A UP55A UT55A/UT52A UP55A X_DI41 5025 X_DI1 5089 X_DI2 5090 X_DI42 5026 X_DI3 5091 X_DI43 5027 X_DI44 5028 5092 5093 X_DI45 5029 5094 X_DI46 5030 5095 5031...
  • Page 302 7.3 UT55A/UT52A/UP55A I Relays Output (status) relay Output (status) relay I relay symbol I relay symbol UT55A/UT52A UP55A UT55A/UT52A UP55A 5153 Y_AL1 5217 Y_DO41 5154 Y_AL2 5218 Y_DO42 5155 Y_AL3 5219 Y_DO43 Y_DO44 5156 5220 5157 5221 Y_DO45 5158 5222 5159 5223 5160...
  • Page 303 7.3 UT55A/UT52A/UP55A I Relays Control (status) relay Control (status) relay I relay symbol I relay symbol UT55A/UT52A UP55A UT55A/UT52A UP55A 5281 AL1_CTL 5345 DO41_CTL 5282 AL2_CTL 5346 DO42_CTL 5283 AL3_CTL 5347 DO43_CTL 5284 5348 DO44_CTL 5285 5349 DO45_CTL 5286 5350 5287 5351 5288...
  • Page 304 7.3 UT55A/UT52A/UP55A I Relays Special relay Free area I relay symbol I relay symbol UT55A/UT52A UP55A UT55A/UT52A UP55A 5409 TIM1 5473 5410 TIM2 5474 5411 TIM3 5475 5412 TIM4 5476 5413 5477 5414 5478 5415 5479 5416 5480 5417 5481 5418 5482 5419...
  • Page 305 7.3 UT55A/UT52A/UP55A I Relays Internal relay Internal relay I relay symbol I relay symbol 5537 5601 5538 5602 5539 5603 5540 5604 5541 5605 5542 5606 5543 5607 5544 5608 5545 5609 5546 5610 5547 5611 5548 5612 5549 5613 5550 5614 5551...
  • Page 306 7.3 UT55A/UT52A/UP55A I Relays Internal relay Internal relay I relay symbol I relay symbol UT55A/UT52A UP55A UT55A/UT52A UP55A 5665 M01_B 5729 M65_B 5666 M02_B 5730 M66_B 5667 M03_B 5731 M67_B 5668 M04_B 5732 M68_B 5669 M05_B 5733 M69_B 5670 M06_B 5734 M70_B 5671...
  • Page 307 7.3 UT55A/UT52A/UP55A I Relays Peer-to-peer communication register Peer-to-peer communication register I relay symbol I relay symbol UT55A/UT52A UP55A UT55A/UT52A UP55A 6049 CF01 6113 CI01 6050 CF02 6114 CI02 6051 CF03 6115 CI03 6052 CF04 6116 CI04 6053 6117 CI05 6054 6118 CI06 6055 6119 CI07 6056 6120...
  • Page 308 7.3 UT55A/UT52A/UP55A I Relays Peer-to-peer communication register Free area I relay symbol I relay symbol UT55A/UT52A UP55A UT55A/UT52A UP55A 6177 CO01 6241 6178 CO02 6242 6179 CO03 6243 6180 CO04 6244 6181 CO05 6245 6182 CO06 6246 6183 CO07 6247 6184 CO08 6248 6185 CO09...
  • Page 309: Input (Status) Relay And Output (Status) Relay (5025 To 5280)

    7.3 UT55A/UT52A/UP55A I Relays Input (Status) Relay and Output (Status) Relay (5025 to 5280) I relay No. Symbol Description 5025 to 5040 X_DI1 to X_DI3 DI1-DI3 status (Same as D7011) 5041 to 5056 X_DI11 to X_DI16 DI11-DI16 status (Same as D7012) 5057 to 5072 X_DI21 to X_DI26 DI21-DI26 status (Same as D7013) 5073 to 5088...
  • Page 310: Internal Relay (5537 To 5792)

    7.3 UT55A/UT52A/UP55A I Relays Internal Relay (5537 to 5792) I relay No. Symbol Description You can read/write data from/to the area via communication. (Same as D7201 to D7208) 5537 to 5664 M01 to M128 That is, you can use the area freely without affecting the control function of the UTAdvanced You can read/write data from/to the area via communication.
  • Page 311: Input / Output Terminal Status (6305 To 6560)

    7.3 UT55A/UT52A/UP55A I Relays 7.3.3 Input / Output Terminal Status (6305 to 6560) Note When specifying an I relay number for communication, begin the number with the character “I.” Example: Set “I6305” to specify the DI1 (I relay No.: 6305). 7-26 IM 05P07A01-01EN...
  • Page 312 7.3 UT55A/UT52A/UP55A I Relays DI terminals DI terminals I relay symbol I relay symbol UT55A/UT52A UP55A UT55A/UT52A UP55A 6305 6369 DI41 6306 6370 DI42 6307 6371 DI43 6308 6372 DI44 6309 6373 DI45 6310 6374 DI46 6311 6375 6312 6376 6313 6377 6314...
  • Page 313 7.3 UT55A/UT52A/UP55A I Relays DO terminals DO terminals I relay symbol I relay symbol UT55A/UT52A UP55A UT55A/UT52A UP55A 6433 OUT_AL1 6497 OUT_DO41 6434 OUT_AL2 6498 OUT_DO42 6435 OUT_AL3 6499 OUT_DO43 6436 6500 OUT_DO44 6437 6501 OUT_DO45 6438 6502 6439 6503 6440 6504 6441...
  • Page 314: Di Terminals And Do Terminals (6305 To 6560)

    7.3 UT55A/UT52A/UP55A I Relays DI Terminals and DO Terminals (6305 to 6560) I relay No. Symbol Description 6305 to 6320 DI1 to DI3 DI1-DI3 status (Same as D7601) 6321 to 6336 DI11 to DI16 DI11-DI16 status (Same as D7602) 6337 to 6352 DI21 to DI26 DI21-DI26 status (Same as D7603) 6353 to 6368...
  • Page 315: Reading Via Communication

    Reading via Communication  When reading the alarm status Read I relay numbers 4321 to 4336 for Loop-1 alarm-1 to alarm-8 status. I relay No. Symbol Event 4321 to 4336 ALM1_L1~ALM8_L1 Loop-1 alarm-1 to alarm-8 status (Same as D2011) * 4337 to 4352 ALM1_L2~ALM8_L2 Loop-2 alarm-1 to alarm-8 status (Same as D2013)
  • Page 316: Green Series Compatible I Relays

    GREEN Series Compatible I Relays 7.5.1 Compatibility with GREEN Series Controllers The map configuration from 1 to 2048 of the I relay map is the same as that of the GREEN Series (UT500 Series/UP550) controllers. If existing programs created in the GREEN Series controllers are used, communication is performed using the area from 0001 to 2048.
  • Page 317: Status (0001 To 0192)

    7.5 I Relays Corresponding to GREEN Series 7.5.3 Status (0001 to 0192) UT55A/UT52A Status I relay symbol I relay symbol I relay symbol GREEN UTAdvanced GREEN UTAdvanced GREEN UTAdvanced AD1 ERR ADERR (4065) A/M1 A.M (4193) R/L1 R.L_L1 (4194) AD3 ERR ADERR_E1 (4066) R/S1 S.R (4193)
  • Page 318 7.5 I Relays Corresponding to GREEN Series *1: Effective for the control modes except for cascade control and cascade secondary-loop control. *2: Effective for cascade control mode and cascade secondary-loop control mode. I relay No. Symbol Description ADERR to 1 to 16 A/D converter error status for GREEN Series (Same as D0001) VALVBO PVBO_L1 to...
  • Page 319 7.5 I Relays Corresponding to GREEN Series UP55A Status I relay symbol I relay symbol I relay symbol GREEN UTAdvanced GREEN UTAdvanced GREEN UTAdvanced AD1ERR ADERR (4065) A/M1 A.M_L1 (4177) 129 TIME1 TIME_EV1 (4817) 130 TIME2 TIME_EV2 (4818) AD3ERR ADERR_E1 (4066) 131 TIME3 TIME_EV3 (4819) AD1BO...
  • Page 320 7.5 I Relays Corresponding to GREEN Series *1: Effective for the control modes except for cascade control and cascade secondary-loop control. *2: Effective for cascade control mode and cascade secondary-loop control mode. I relay No. Symbol Description ADERR to 1 to 16 A/D converter error status for GREEN Series (Same as D0001) VALVBO PVBO_L1 to...
  • Page 321: Sp Number, Pid Number, And Status (0577 To 0720)

    7.5 I Relays Corresponding to GREEN Series 7.5.4 SP Number, PID Number, and Status (0577 to 0720) UT55A/UP55A SP number, PID number, and status I relay symbol I relay symbol GREEN UTAdvanced GREEN UTAdvanced 577 CSPNO.0 CSPN.B0 (4577) 578 CSPNO.1 CSPN.B1 (4578) 579 CSPNO.2 CSPN.B2 (4579) 580 CSPNO.3 CSPN.B3 (4580) 593 PIDNO1.0 PIDN.B0_L1 (4609) 594 PIDNO1.1 PIDN.B1_L1 (4610) 595 PIDNO1.2...
  • Page 322 7.5 I Relays Corresponding to GREEN Series I relay No. Symbol Description CSPN.B0 to 577 to 592 SPnumber (Same as 2010) CSPN.B3 PIDN.B0_L1 to 593 to 608 Loop-1 PID number (Same as 2009) PIDN.B3_L1 PIDN.B0_L2 to 609 to 624 Loop-2 PID number (Same as 2025) PIDN.B3_L2 625 to 656 INV_DI1...
  • Page 323 7.5 I Relays Corresponding to GREEN Series UP55A SP number, PID number, and status I relay symbol I relay symbol I relay symbol GREEN UTAdvanced GREEN UTAdvanced GREEN UTAdvanced 705 PVE01 641 SEGNO.0 SEGNO.B0 (4657) PV_EV1_OUT (4801) 706 PVE02 642 SEGNO.1 SEGNO.B1 (4658) PV_EV2_OUT (4802) 707 PVE03 PV_EV3_OUT (4803) 643 SEGNO.2...
  • Page 324: User Area (0721 To 2048)

    7.5 I Relays Corresponding to GREEN Series I relay No. Symbol Description 577 to 592 PIDN.B0_L1 to 593 to 608 Loop-1 PID number (Same as 2009) PIDN.B3_L1 PIDN.B0_L2 to 609 to 624 Loop-2 PID number (Same as 2025) PIDN.B3_L2 PTNO.B0 to 625 to 640 Pattern number (Same as D2015) PTNO.B4...
  • Page 325 Blank Page...
  • Page 326: Chapter 8 Functions And Applications Of D Registers

    Chapter 8 Functions and Applications of D Registers (for UT35A/UT32A/UT32A-D/UP35A/UP32A) Overview This chapter describes the functions and applications of the D registers. D registers are used in Modbus, PC link, ladder, Ethernet communications, or Open Network communication (network profile creating function of LL50A) and are used for storing UTAdvanced parameter data, flag data, process data, and other data and values. The host computer can utilize these data by reading from and writing to the D registers.
  • Page 327: Conventions Used In D Register Tables

    Conventions Used in D Register Tables This section describes the conventions used in the D register map tables. The numerical values arranged vertically in the leftmost column of the table represent (1) D register numbers. 5-digit numbers in the column next to it show (2) reference numbers for Modbus communication.
  • Page 328: Classification Of D Registers

    Classification of D Registers  Classification of D Register Map Tables The table on next page outlines how the D registers are classified by their numbers in the D register map tables. When you newly perform communication with the UTAdvanced, the D registers after D2001 are used.
  • Page 329 8.3 Classification of D Registers Classification of D Registers Register No. Area and data categories Description Reference D0001 to D0049 Process data Sections 8.6.3 D0050 to D0100 User area Sections 8.6.3 D0101 to D0200 Program setting parameter (for UP35A only) Sections 8.6.3 D0201 to D0230 Operation mode parameter...
  • Page 330 8.3 Classification of D Registers Note 1: Data in the process values, operation parameters, and setup parameters is stored in the format (data excluding the decimal point of PV input range, PV input range span, %, or ABS) described in “Lists of Operation Parameters” and “Lists of Setup Parameters” in the UTAdvanced Operation Guide or User’s Manual.
  • Page 331: Ut35A/Ut32A/Ut32A-D/Up35A/Up32A

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers 8.4.1 Process Monitoring and Program Pattern for UP35A (D2001 to D2300) Process monitoring area Process data D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol AD1.E D2001 42001 07D0 D2051 42051 0802 D2002 42002 07D1 PV1.E_L1 D2052 42052 0803 D2003 42003 07D2 PV_L1 D2053 42053 0804 D2004 42004 07D3 CSP_L1 D2054 42054 0805 D2005 42005 07D4 OUT_L1...
  • Page 332 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Process monitoring area Current SP group and PID group D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D2101 42101 0834 SP_L1_* R/W R/W D2151 42151 0866 D2102 42102 0835 SUB_* R/W R/W D2152 42152 0867 D2103 42103 0836 PIDN_L1_* R/W R/W D2153 42153 0868 D2104 42104 0837...
  • Page 333 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers The group number to be displayed varies depending on the currently used SP number selection (D2312) and PID number (D2009). Either 1 to 4 or R (the currently used group number) is written. However, only 1 to 4 is written in D2101 to D2107. IM 05P07A01-01EN...
  • Page 334 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Program pattern Local-mode Operation Setting (Menu: LOC) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol LSP_L1 D2201 42201 0898 R/W R/W D2251 42251 08CA D2202 42202 0899 D2252 42252 08CB L.PID D2203 42203 089A R/W R/W D2253 42253 08CC L.TY1 D2204 42204 089B R/W R/W D2254 42254 08CD...
  • Page 335: Process Data Area

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Process Data Area Some of the D registers represent multiple events such as errors and status depending on combinations of bits in the register. In the following tables, if an event indicated by a specific bit occurs, the state of that bit changes to “1.”...
  • Page 336 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers UP35A/UP32A Symbol Event 0: AUTO, 1: MAN 1 to 3 RST_ON 1: Program reset PRG_ON 1: Program operation LOC_ON 1: Local operation ADV_ON 1: Advance of segment HOLD_ON 1: Pause WAITF 1: Wait AT_L1_ON 0: Auto-tuning is OFF, 1: Auto-tuning is ON  Bit Configuration of D2009: PID_L1 (Current PID number) Symbol Event...
  • Page 337 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers  Bit Configuration of D2013: ALM_L2 (Loop-2 alarm-1 to alarm-4 status) Symbol Event ALM1_L2 ‘1’ when Alarm 1 is ON; ‘0’ when OFF ALM2_L2 ‘1’ when Alarm 2 is ON; ‘0’ when OFF ALM3_L2 ‘1’ when Alarm 3 is ON; ‘0’ when OFF ALM4_L2 ‘1’ when Alarm 4 is ON; ‘0’ when OFF 5 to 15 ...
  • Page 338 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers  Bit Configuration of D2025: PID_L2(Loop-2 current PID number) Symbol Event PIDN.B0_L2 Bit-0 of the PID number PIDN.B1_L2 Bit-1 of the PID number PIDN.B2_L2 Bit-2 of the PID number 3 to 15  D2033 to D2036 Register Description Range and meaning of value D2033 TSP_L1 Final target setpoint 0.0 to 100.0% of PV input range (EU) (Setting...
  • Page 339 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers  Bit Configuration of D2040: TIME_EV_1 (Time event status 1) Symbol Event TIME_EV1 0: Time event is OFF TIME_EV2 1: Time event is ON TIME_EV3 0: Time event is OFF TIME_EV4 1: Time event is ON 5 to 15  D2044 to D2049 Register Description Range and meaning of value Number of segments contained in the selected D2044...
  • Page 340 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers  Bit Configuration of D2066: DIMG (Message display interruption status) Symbol Event MG1.B Message display interruption 1 (1: displayed, 0: not displayed) MG2.B Message display interruption 2 (1: displayed, 0: not displayed) MG3.B Message display interruption 3 (1: displayed, 0: not displayed) MG4.B Message display interruption 4 (1: displayed, 0: not displayed) 5 to 15  Bit Configuration of D2068: PA.ER (Parameter error status) Symbol...
  • Page 341 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers  Bit Configuration of D2072: ALOLA1_L2 (Loop-2 alarm-1 to alarm-4 latch output status); UT32A-D Symbol Event ALO1LA1_L2 Alarm-1 latch-1 output status ALO2LA1_L2 Alarm-2 latch-1 output status ALO3LA1_L2 Alarm-3 latch-1 output status ALO4LA1_L2 Alarm-4 latch-1 output status 5 to 15  Bit Configuration of D2073: ALOLA2_L1 (Alarm-1 to alarm-4 latch-2 output status) Symbol Event ALO1LA2_L1 Alarm-1 latch-2 output status ALO2LA2_L1 Alarm-2 latch-2 output status ALO3LA2_L1 *...
  • Page 342 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers  Bit Configuration of D2077: ALOLA4_L1 (Alarm-1 to alarm-4 latch-4 output status) Symbol Event ALO1LA4_L1 Alarm-1 latch-4 output status ALO2LA4_L1 Alarm-2 latch-4 output status ALO3LA4_L1 * Alarm-3 latch-4 output status ALO4LA4_L1 * Alarm-4 latch-4 output status 5 to 15 *: For UT35A/UT32A only  Bit Configuration of D2078: ALOLA4_L1 (Loop-2 alarm-1 to alarm-4 latch-4 output status); UT32A-D Symbol Event ALO1LA4_L2...
  • Page 343: Current Sp Group And Pid Group (D2101 To D2200)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Current SP Group and PID Group (D2101 to D2200) Register Description Range and meaning of value 0.0 to 100.0% of PV input range (EU) (Setting D2101 SP_L1_* Target setpoint range: SPL to SPH) Sub-target setpoint (in Two-position Set the offset from SP. D2102 SUB_* two-level control) -100.0 to 100.0% of PV input range span (EUS) Set a PID group number to use.
  • Page 344: Local-Mode Operation Setting For Up35A (D2201 To D2300)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Register Description Range and meaning of value In STOP mode, fixed control output can be Preset output generated. In Position proportional control, Valve PO_L1_* D2133 Heating-side preset output (in Heating/ opening can be set cooling control) -5.0 to 105.0% In STOP mode, fixed sub-control output can be Sub-preset output (in Two-position...
  • Page 345: Loop-1/Loop-2 Operation Mode Parameter And Operation Parameter For Up35A

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers 8.4.2 Loop-1/Loop-2 Operation Mode Parameter and Operation Parameter for UP35A (D2301 to D2500) Operation mode parameters Operation mode (Menu: MODE), Alarm setpoint setting (Menu:AL) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol A1_L1 D2301 42301 08FC A.M R/W R/W R/W D2351 42351 092E R/W R/W A2_L1 D2302 42302 08FD D2352 42352 092F R/W R/W D2303 42303 08FE...
  • Page 346: Operation Mode And Alarm Setpoint Setting For Up35A (D2301 To D2400)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Operation Mode and Alarm Setpoint Setting for UP35A (D2301 to D2400) Register Description Range and meaning of value D2301 A.M_L1 AUTO/MAN switch 0: AUTO (Automatic mode) 1: MAN (Manual mode) D2302 A.M_L2 Loop-2 AUTO/MAN switch D2303 0: RUN (Run mode) 1: STOP (Stop mode) D2304 S.R_L1...
  • Page 347: Free Area (D2401 To D2500)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Register Description Range and meaning of value 1 to 20 (40 when the option “/AP” is specified.) The setting value returns to “1” when the program D2343 Start-of-program segment number operation (PROG) changes into RESET, LOCAL, or REM.
  • Page 348: Operation Parameter (D2501 To D4700)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers 8.4.3 Operation Parameter (D2501 to D4700) Operation parameter SP and alarm setpoint setting (Menu: SP) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol SP_L1_1 R/W R/W R/W D2501 42501 09C4 D2551 42551 09F6 SUB_1 R/W R/W D2502 42502 09C5 D2552 42552 09F7 PIDN_L1_1 R/W R/W R/W D2503 42503 09C6 D2553 42553 09F8...
  • Page 349 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Operation parameter SP-related setting (Menu: SPS) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D2701 42701 0A8C D2751 42751 0ABE D2702 42702 0A8D D2752 42752 0ABF RT_L1 D2703 42703 0A8E R/W R/W R/W D2753 42753 0AC0 RBS_L1 D2704 42704 0A8F R/W R/W R/W...
  • Page 350 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Operation parameter Alarm function setting (Menu: ALRM) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D2801 42801 0AF0 AL1.T_L1 R/W R/W R/W R/W R/W D2851 42851 0B22 DYN3_L1 R/W R/W R/W D2802 42802 0AF1 AL1.W_L1 R/W R/W R/W R/W R/W D2852 42852 0B23 DYN4_L1 R/W R/W R/W D2803 42803 0AF2 AL1.D_L1...
  • Page 351 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Operation parameter PV-related setting (Menu: PVS) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol BS_L1 R/W R/W R/W R/W R/W D2951 42951 0B86 D2901 42901 0B54 FL_L1 R/W R/W R/W R/W R/W D2952 42952 0B87 D2902 42902 0B55 D2903 42903 0B56 D2953 42953 0B88...
  • Page 352 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D3001 43001 0BB8 P_L1_1 R/W R/W R/W R/W R/W D3051 43051 0BEA P_L1_2 R/W R/W R/W R/W R/W D3002 43002 0BB9 I_L1_1 R/W R/W R/W R/W R/W D3052 43052 0BEB I_L1_2...
  • Page 353 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol P_L1_3 P_L1_4 D3101 43101 0C1C R/W R/W R/W R/W R/W D3151 43151 0C4E R/W R/W R/W R/W R/W I_L1_3 I_L1_4 D3102 43102 0C1D R/W R/W R/W R/W R/W D3152 43152 0C4F R/W R/W R/W R/W R/W D_L1_3...
  • Page 354 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D3401 43401 0D48 P_L1_R R/W R/W R/W R/W R/W D3451 43451 0D7A D3402 43402 0D49 I_L1_R R/W R/W R/W R/W R/W D3452 43452 0D7B D3403 43403 0D4A D_L1_R R/W R/W R/W R/W R/W D3453 43453 0D7C...
  • Page 355 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Operation parameter Control action-related setting (Tuning menu: TUNE) (Zone control menu: ZONE) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol SC_L1 RP1_L1 R/W R/W R/W R/W R/W D3501 43501 0DAC R/W R/W R/W R/W R/W D3551 43551 0DDE D3502 43502 0DAD D3552 43552 0DDF RP2_L1 R/W R/W R/W R/W R/W...
  • Page 356: Sp And Alarm Setpoint Setting Of Groups 1 To 4 (D2501 To D2700)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers SP and Alarm Setpoint Setting of Groups 1 to 4 (D2501 to D2700) Register Description Range and meaning of value 0.0 to 100.0% of PV input range (EU) (Setting D2501 SP_L1_1 Target setpoint of group 1 range: SPL to SPH) Sub-target setpoint (in Two-position Set the offset from SP. D2502 SUB_1 two-level control) of group 1...
  • Page 357: Alarm Function Setting (D2801 To D2900)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Alarm Function Setting (D2801 to D2900) Register Description Range and meaning of value AL1.T_L1 to AL8.T_L1 D2801 AL1.T_L1 Alarm-1 type 0: Disable 1: PV high limit 2: PV low limit D2802 AL1.W_L1 Alarm-1 stand-by action 3: SP high limit 4: SP low limit 5: Deviation high limit D2803...
  • Page 358: Pv-Related Setting (D2901 To D3000)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Register Description Range and meaning of value D2841 HY1_L1 Alarm-1 hysteresis Set a display value of setpoint of hysteresis. D2842 HY2_L1 Alarm-2 hysteresis -19999 to 30000 (Set a value within the input range.) D2843 HY3_L1 Alarm-3 hysteresis Decimal point position depends on the input type.
  • Page 359: Pid Setting Of Groups 1 To 4 And R (D3001 To D3500)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers PID Setting of Groups 1 to 4 and R (D3001 to D3500) Register Description Range and meaning of value 0.0 to 999.9% Proportional band of group 1 When 0.0% is set, it operates as 0.1%. D3001 P_L1_1 Heating-side proportional band (in Heating-side ON/OFF control applies when 0.0% in Heating/cooling control) of group 1 Heating/cooling control Integral time of group 1...
  • Page 360 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Register Description Range and meaning of value Proportional band of group 2 D3051 to Heating-side proportional band (in P_L1_2 to POc_L1_2 Same as D3001 to D3022 D3072 Heating/cooling control) of group 2 to Cooling-side preset output of group 2 D3073 to D3100 Proportional band of group 3 D3101 to...
  • Page 361: Control Action-Related Setting (D3501 To D3600)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Control Action-related Setting (D3501 to D3600) Register Description Range and meaning of value 0: OFF (Disable) 1: Overshoot suppressing function (normal mode) 2: Hunting suppressing function (stable mode) Enables to answer the wider characteristic changes compared with response mode. 3: Hunting suppressing function (response mode) Enables quick follow-up and short converging time of PV for the changed SP.
  • Page 362: Free Area (D3601 To D4700)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Register Description Range and meaning of value Set reference points at which switching is carried D3551 RP1_L1 Reference point 1 out between groups of PID constants according to the given temperature D3552 RP2_L1 Reference point 2 zone.
  • Page 363: Loop-2 Operation Parameter (D3601 To D4700)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers 8.4.4 Loop-2 Operation Parameter (D3601 to D4700) Loop-2 operation parameter SP and alarm setpoint setting (Menu: SP) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol SP_L1_1 D3601 43601 0E10 D3651 43651 0E42 SUB_1 D3602 43602 0E11 D3652 43652 0E43 PIDN_L1_1 D3603 43603 0E12 D3653 43653 0E44 A1_L1_1 D3604 43604 0E13...
  • Page 364 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Loop-2 operation parameter SP-related setting (Menu: SPS) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D3801 43801 0ED8 D3851 43851 0F0A D3802 43802 0ED9 D3852 43852 0F0B RT_L2 D3803 43803 0EDA D3853 43853 0F0C RBS_L2 D3804 43804 0EDB D3854 43854 0F0D UPR_L2...
  • Page 365 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Loop-2 operation parameter Alarm function setting (Menu: ALRM) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D3901 43901 0F3C AL1.T_L2 D3951 43951 0F6E DYN3_L2 D3902 43902 0F3D AL1.W_L2 D3952 43952 0F6F DYN4_L2 D3903 43903 0F3E AL1.D_L2 D3953 43953 0F70 D3904 43904 0F3F AL1.L_L2 D3954 43954 0F71...
  • Page 366 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Loop-2 operation parameter PV-related setting (Menu: PVS) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol BS_L2 D4001 44001 0FA0 D4051 44051 0FD2 FL_L2 D4002 44002 0FA1 D4052 44052 0FD3 D4003 44003 0FA2 D4053 44053 0FD4 D4004 44004 0FA3 D4054 44054 0FD5 D4005 44005 0FA4...
  • Page 367 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Loop-2 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol P_L2_1 P_L2_2 D4101 44101 1004 D4151 44151 1036 D4102 44102 1005 I_L2_1 D4152 44152 1037 I_L2_2 D_L2_1 D_L2_2 D4103 44103 1006 D4153 44153 1038 D4104 44104 1007 OH_L2_1...
  • Page 368 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Loop-2 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D4201 44201 1068 P_L2_3 D4251 44251 109A P_L2_4 I_L2_3 I_L2_4 D4202 44202 1069 D4252 44252 109B D_L2_3 D_L2_4 D4203 44203 106A D4253 44253 109C OH_L2_3 OH_L2_4...
  • Page 369 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Loop-2 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D4501 44501 1194 P_L2_R D4551 44551 11C6 D4502 44502 1195 I_L2_R D4552 44552 11C7 D4503 44503 1196 D_L2_R D4553 44553 11C8 D4504 44504 1197 OH_L2_R D4554 44554 11C9...
  • Page 370 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Loop-2 operation parameter Control action-related setting (Tuning menu: TUNE) (Zone control menu: ZONE) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D4601 44601 11F8 SC_L2 D4651 44651 122A D4602 44602 11F9 D4652 44652 122B D4603 44603 11FA AT.TY_L2 D4653 44653 122C RP1_L2 D4604 44604 11FB AT.OH_L2...
  • Page 371: Loop-2 Sp And Alarm Setpoint Setting Of Groups 1 To 4 (D3601 To D3700)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Loop-2 SP and Alarm Setpoint Setting of Groups 1 to 4 (D3601 to D3700) Register Description Range and meaning of value 0.0 to 100.0% of PV input range (EU) (Setting D3501 SP_L2_1 Target setpoint of group 1 range: SPL to SPH) Sub-target setpoint (in Two-position Set the offset from SP. D3502 SUB_1 two-level control) of group 1...
  • Page 372: Loop-2 Alarm Function Setting (D3901 To D4000)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Loop-2 Alarm Function Setting (D3901 to D4000) Register Description Range and meaning of value AL1.T_L1 to AL8.T_L1 D3901 AL1.T_L2 Alarm-1 type 0: Disable 1: PV high limit 2: PV low limit D3902 AL1.W_L2 Alarm-1 stand-by action 3: SP high limit 4: SP low limit 5: Deviation high limit D3903...
  • Page 373: Loop-2 Pv-Related Setting (D4001 To D4100)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Register Description Range and meaning of value D3941 HY1_L2 Alarm-1 hysteresis Set a display value of setpoint of hysteresis. D3942 HY2_L2 Alarm-2 hysteresis -19999 to 30000 (Set a value within the input range.) HY3_L2 D3943 Alarm-3 hysteresis Decimal point position depends on the input type.
  • Page 374: Loop-2 Pid Setting Of Groups 1 To 4 And R (D4101 To D4600)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Loop-2 PID Setting of Groups 1 to 4 and R (D4101 to D4600) Register Description Range and meaning of value 0.0 to 999.9% D4101 P_L2_1 Proportional band of group 1 When 0.0% is set, it operates as 0.1%. 0: OFF (Disable) D4102 I_L2_1 Integral time of group 1 1 to 6000 s 0: OFF (Disable) D_L2_1...
  • Page 375: Control Action-Related Setting (D4601 To D4700)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Control Action-related Setting (D4601 to D4700) Register Description Range and meaning of value 0: OFF (Disable) 1: Overshoot suppressing function (normal mode) 2: Hunting suppressing function (stable mode) Enables to answer the wider characteristic changes compared with response mode. 3: Hunting suppressing function (response mode) Enables quick follow-up and short converging time of PV for the changed SP.
  • Page 376 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Register Description Range and meaning of value Set reference points at which switching is carried D4653 RP1_L2 Reference point 1 out between groups of PID constants according to the given temperature D4654 RP2_L2 Reference point 2 zone.
  • Page 377: P Parameter (D4701 To D4800)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers 8.4.5 P Parameter (D4701 to D4800) P parameter P parameter (Menu: PPAR) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D4701 44701 125C P01D R/W R/W R/W R/W R/W D4751 44751 128E D4702 44702 125D P02D R/W R/W R/W R/W R/W D4752 44752 128F D4703 44703 125E P03D R/W R/W R/W R/W R/W D4753 44753 1290 D4704 44704 125F P04D...
  • Page 378: P Parameter (D4701 To D4800)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers P parameter (D4701 to D4800) Register Description Range and meaning of value P01D D4701 P01 decimal point position P02D D4702 P02 decimal point position P03D D4703 P03 decimal point position 0: No decimal place P04D D4704 P04 decimal point position 1: One decimal place P05D D4705...
  • Page 379: Setup Parameters (D5001 To D7000)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers 8.4.6 Setup Parameters (D5001 to D7000) Setup parameter Control function setting (Menu: CTL) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D5001 45001 1388 D5051 45051 13BA D5002 45002 1389 D5052 45052 13BB CNT_L1 D5003 45003 138A R/W R/W R/W R/W R/W D5053 45053 13BC CNT_L2 D5004 45004 138B D5054 45054 13BD...
  • Page 380 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Setup parameter Input setting (PV input setting menu: PV) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D5101 45101 13EC R/W R/W R/W R/W R/W D5151 45151 141E UNIT D5102 45102 13ED R/W R/W R/W R/W R/W D5152 45152 141F D5103 45103 13EE DP D5153 45153 1420 D5104 45104 13EF...
  • Page 381 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Setup parameter Input setting (Input range·SP limiter setting parameters menu: MPV) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D5201 45201 1450 P.UNI_L1 R/W R/W R/W R/W R/W D5251 45251 1482 P.DP_L1 D5202 45202 1451 R/W R/W R/W R/W R/W D5252 45252 1483 P.RH_L1 D5203 45203 1452 R/W R/W R/W R/W R/W D5253 45253 1484...
  • Page 382 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Setup parameter Output setting (Menu: OUT) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D5301 45301 14B4 OT.H MAN.T R/W R/W R/W R/W R/W D5351 45351 14E6 R/W R/W R/W R/W R/W D5302 45302 14B5 OT.C R/W R/W R/W R/W D5352 45352 14E7 D5303 45303 14B6...
  • Page 383 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Setup parameter Heater break alarm setting (Menu: HBA) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D5401 45401 1518 HB1.S R/W R/W R/W R/W R/W D5451 45451 154A HB2.S D5402 45402 1519 R/W R/W R/W R/W R/W D5452 45452 154B D5403 45403 151A R/W R/W R/W R/W R/W D5453 45453 154C D5404 45404 151B...
  • Page 384 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Setup parameter Communication setting (RS-485 communication setting menu: R485) (Ethernet communication setting menu: ETHR) (Error and version confirmation menu: VER) (CC-Link communication setting menu: CC-L) (DeviceNet communication setting menu: DNET) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D5501 45501 157C PSL_E1 R/W R/W D5551 45551 15AE SM4_E3 D5502 45502 157D BPS_E1 R/W R/W D5552 45552 15AF DG1_E3 D5503 45503 157E PRI_E1 R/W R/W...
  • Page 385 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Setup parameter Communication setting (PROFIBUS-DP communication setting menu: PROF) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D5601 45601 15E0 BR_E3-P D5651 45651 1612 D5602 45602 15E1 ADR_E3-P *1 R/W D5652 45652 1613 BPS_E3-P D5603 45603 15E2 *1 R/W D5653 45653 1614 D5604 45604 15E3 FILE_E3-P...
  • Page 386 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Setup parameter Key operation setting (Menu: KEY), Display function setting (Menu: DISP), SELECT Display setting (Menu: CSEL) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol F1-K B.STS D5701 45701 1644 D5751 45751 1676 R/W R/W F2-K D5702 45702 1645 D5752 45752 1677 Fn-K D.CYC D5703 45703 1646 R/W R/W R/W D5753 45753 1678 R/W R/W...
  • Page 387 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Setup parameter Lock setting (Key lock setting menu: KLOC) (Menu lock setting menu: MLOC) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D5801 45801 16A8 U.SP_L1 R/W R/W R/W R/W R/W D5851 45851 16DA DI.SL-L R/W R/W R/W R/W R/W DI.NU-L D5802 45802 16A9 U.SP_L2 D5852 45852 16DB R/W R/W R/W R/W R/W...
  • Page 388 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Setup parameter DI function setting (DI function registration menu: DI.SL) (DI function numbering menu: DI.NU) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol A/M-D D5901 45901 170C R/W R/W R/W D5951 45951 173E D5902 45902 170D R/L_L1-D *1 R/W R/W R/W D5952 45952 173F D5903 45903 170E D5953 45953 1740 PT.BC-D R/W R/W...
  • Page 389 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Setup parameter DI function setting (Message) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D6001 46001 1770 MSG1 R/W R/W R/W R/W R/W D6051 46051 17A2 MSG3 R/W R/W R/W R/W R/W D6002 46002 1771 MSG1 R/W R/W R/W R/W R/W D6052 46052 17A3 D6003 46003 1772 MSG1...
  • Page 390 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Setup parameter DI function setting (DI1-DI2 contact type setting menu: DI.D) (DI setting menu (E1, E4): DI.D) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D6101 46101 17D4 DI1.D R/W R/W R/W R/W R/W D6151 46151 1806 D6102 46102 17D5 DI2.D R/W R/W R/W R/W R/W D6152 46152 1807 D6103 46103 17D6 DI3.D R/W R/W R/W D6153 46153 1808...
  • Page 391 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Setup parameter DO function setting (AL1-AL3 function registration menu: ALM) (DO setting menu (E1 to E4): DO) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D6201 46201 1838 AL1.S R/W R/W R/W R/W R/W D6251 46251 186A AL2.S D6202 46202 1839 R/W R/W R/W R/W R/W D6252 46252 186B AL3.S D6203 46203 183A R/W R/W R/W R/W R/W D6253 46253 186C...
  • Page 392 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Setup parameter I/O display (Menu: I/O) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol KEY-IO D6301 46301 189C D6351 46351 18CE D6302 46302 189D D6352 46352 18CF D6303 46303 189E D6353 46353 18D0 D6304 46304 189F D6354 46354 18D1 D6305 46305 18A0 D6355 46355 18D2...
  • Page 393 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Setup parameter System setting (Menu: SYS) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D6401 46401 1900 R.MD R/W R/W R/W R/W R/W D6451 46451 1932 D6402 46402 1901 R.TM R/W R/W R/W R/W R/W D6452 46452 1933 D6403 46403 1902 D6453 46453 1934 D6404 46404 1903...
  • Page 394: Control Function Setting (D5001 To D5100)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Control Function Setting (D5001 to D5100) Register Description Range and meaning of value D5001 to D5002 0: PID (PID control) 1: ONOF (ON/OFF control (1 point of hysteresis)) 2: ONOF2 (ON/OFF control (2 points of hysteresis)) D5003 CNT_L1 Control type...
  • Page 395: Input Setting (D5101 To D5300)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Register Description Range and meaning of value If set to “SP group number selection,” allows PID constants to be selected for each SP group. If set to “Zone PID selection,” automatically selects PID constants according to the range set in the Reference point.
  • Page 396 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Register Description Range and meaning of value D5107 Maximum value of PV input scale -19999 to 30000, (SL<SH), | SH - SL | ≤ 30000 D5108 Minimum value of PV input scale 0: OFF (Disable) D5109 PV input burnout action 1: UP (Upscale) 2: DOWN (Downscale)
  • Page 397: Output Setting (D5301 To D5400)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Output Setting (D5301 to D5400) Register Description Range and meaning of value 0: OFF 1: OUT terminals (voltage pulse) D5301 OT.H Heating-side control output selection 2: OUT terminals (current) 3: OUT terminals (relay) 6: OUT2 terminals (relay) 7: RET/OUT2 terminals (voltage pulse) 8: RET/OUT2 terminals (current) When the UTAdvanced parameter is set by key stroke,...
  • Page 398 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Register Description Range and meaning of value When RTS=1 (PV1), 2 (SP1), 8 (TSP1), or 16 (PV), RTL+1digit to 30000 Decimal point position: Maximum value of retransmission D5322 RTS=1 (PV1), 2 (SP1), or 8 (TSP1): decimal point position output scale of RET is same as that of PV input.
  • Page 399: Heater Break Alarm Setting (D5401 To D5500)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Heater Break Alarm Setting (D5401 to D5500) Register Description Range and meaning of value Heater break alarm-1 function D5401 HB1.S 0: Heater current measurement selection 1: Heater break alarm (Heating-side) Heater break alarm-2 function 2: Cooling-side heater break alarm D5402 HB2.S selection...
  • Page 400: Communication Setting (D5501 To D5700)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Communication Setting (D5501 to D5700) Register Description Range and meaning of value 0: PCL (PC link communication) 1: PCLSM (PC link communication (with checksum)) 2: LADR (Ladder communication) 3: CO-M (Coordinated master station) 4: CO-S (Coordinated slave station) 7: MBASC (Modbus (ASCII)) D5501 PSL_E1...
  • Page 401 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Register Description Range and meaning of value SM1_E3 D5548 Subnet mask 1 0 to 255 SM2_E3 D5549 Subnet mask 2 SM3_E3 D5550 Subnet mask 3 Address : D5546.D5547.D5548.D5549 SM4_E3 D5551 Subnet mask 4 DG1_E3 D5552 Default gateway 1 0 to 255 DG2_E3 D5553...
  • Page 402 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Register Description Range and meaning of value 0: 9.6K (9.6k bps) 1: .2K (19.2k bps) 2: 93.75K (93.75k bps) 3: 187.5K (187.5k bps) 4: 0.5M (0.5M bps) Baud rate D5601 BR_E3-P 5: 1.5M (1.5M bps) (for PROFIBUS-DP communication) 6: 3M (3M bps) 7: 6M (6M bps) 8: 12M (12M bps)
  • Page 403: Key Operation Setting, Display Function Setting, And Select Display Setting

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Key Operation Setting, Display Function Setting, and SELECT Display Setting (D5701 to D5800) Register Description Range and meaning of value 0: OFF (Disable) 1: A/M (AUTO/MAN switch) 3: R/L1 (REM/LCL switch) D5701 User function key-1 action setting 5: S/R (STOP/RUN switch) 7: AUTO (Switch to AUTO) 8: MAN (Switch to MAN)
  • Page 404 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Register Description Range and meaning of value 0: Disable 1: OUT, Heating-side OUT, Internal value in Position proportional control 2: Cooling-side OUT 3: PV 4: SP D5719 BAR1 Bar-graph display registration 5: Deviation 6 to 16: Disable 17: Feedback input (valve opening) 18: PV terminals analog input 19 to 22: Disable...
  • Page 405 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Register Description Range and meaning of value 0: SP1 (SP Display) 2: OUT1 (OUT Display) 4: HCO (Heating/cooling OUT Display) 5: VP (Valve Position Display) 6: MV (Position Proportional Computation Output Display) 8: PID1 (PID Number Display) 10: HC1 (Heater Break Alarm-1 Current Display) 11: HC2 (Heater Break Alarm-2 Current Display) 14: PV (PV Analog Input Display)
  • Page 406 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Register Description Range and meaning of value CS10 D5770 SELECT parameter-10 registration Register the parameter that is frequently modified in CS11 D5771 SELECT parameter-11 registration the Operation Parameter Setting Display. CS12 D5772 SELECT parameter-12 registration (Register the register number of the parameter) CS13 D5773 SELECT parameter-13 registration...
  • Page 407: Lock Setting (Key Lock/Menu Lock) (D5801 To D5900)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Lock Setting (Key Lock/Menu Lock) (D5801 to D5900) Register Description Range and meaning of value D5801 U.SP_L1 SP Display lock D5802 U.OUT_L1 D5803 OUT Display lock D5804 U.HCO D5805 Heating/cooling OUT Display lock D5806 U.VP Valve Position Display lock Position Proportional Computation Output U.MV D5807...
  • Page 408 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Register Description Range and meaning of value [DI.D] menu lock (E4-terminal area) D5857 DI.D_E4-L [ALM] menu lock D5858 ALM-L 0: OFF (Display) D5859 DO_E1-L [DO] menu lock (E1-terminal area) 1: ON (Nondisplay) D5860 to D5861 DO_E4-L D5862 [DO] menu lock (E4-terminal area) D5863...
  • Page 409: Di Function Setting (D5901 To D6200)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers DI Function Setting (D5901 to D6200) Register Description Range and meaning of value AUTO/MAN switch D5901 A/M-D R/L_L1-D *1 REMOTE/LOCAL switch D5902 D5903 STOP/RUN switch D5904 S/R-D D5905 Switch to AUTO D5906 AUTO-D MAN-D Switch to MAN D5907 Switch to REMOTE D5908...
  • Page 410 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Register Description Range and meaning of value D5947 PN.BC Bit changing method of PID number Same as D5941 D5948 PN.B0 Bit-0 of PID number D5949 PN.B1 Bit-1 of PID number Same as D5942 D5950 PN.B2 Bit-2 of PID number D5951 to D5952 Bit changing method of program pattern D5953...
  • Page 411 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Register Description Range and meaning of value D6041 MSG3 D6042 MSG3 D6043 MSG3 20-digit value of alphanumeric characters can be D6044 MSG3 set. Arrangement: D6045 MSG3 D6041, D6042, D6043, D6044, D6045, D6046, D6046 MSG3 Message-3 *2 D6047, D6048, D6049, D6050, D6051 D6047 MSG3...
  • Page 412: Do Function Setting (D6201 To D6300)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers DO Function Setting (D6201 to D6300) Register Description Range and meaning of value Set an I relay number (Setting range: 4001 to 6000, UP35A: 4001 to 6304). D6201 AL1.S AL1 function selection Ex.) Set the number 4353 for AL1.S to use the alarm 1. 0: OFF (No function) UT35A/UT32A D6202...
  • Page 413: I/O Display (D6301 To D6400)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Register Description Range and meaning of value DO1.D_E4 DO41 contact type D6286 DO42 contact type D6287 DO2.D_E4 DO43 contact type D6288 DO3.D_E4 Same as D6206 DO44 contact type D6289 DO4.D_E4 DO45 contact type D6290 DO5.D_E4 D6291 to D6300 I/O Display (D6301 to D6400)  Bit Configuration of D6301: KEY-IO*1 (Key status) Symbol...
  • Page 414 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers System Setting (D6401 to D6500) Register Description Range and meaning of value Set how the controller should recover from a power failure of 5 seconds or more. UT35A/UT32A 0: CONT (Continue action set before power failure.) 1: MAN (Start from MAN.) D6401 R.MD...
  • Page 415: Parameter (D6701 To D6800)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers 6.4.7 T Parameter (D6701 to D6800) T Parameter T Parameter D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D6701 46701 1A2C T01 R/W R/W R/W R/W R/W D6751 46751 1A5E D6702 46702 1A2D T02 R/W R/W R/W R/W R/W D6752 46752 1A5F D6703 46703 1A2E T03 R/W R/W R/W R/W R/W D6753 46753 1A60 D6704 46704 1A2F T04...
  • Page 416 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers T Parameter (D6701 to D6800) Register Description Range and meaning of value This is used to display the value of the ladder of D6701 T1 register the timer or counter. D6702 T2 register D6703 T3 register 0 to 65535 D6704 T4 register D6705 T5 register...
  • Page 417: Registers For Ladder Program (D7001 To D7600)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers 8.4.8 Registers for Ladder Program (D7001 to D7600) Registers for ladder program For input ladder calculation D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D7001 47001 1B58 X_PV D7051 47051 1B8A PVIN_CTL R * R * D7002 47002 1B59 X_PV2 D7052 47052 1B8B D7003 47003 1B5A D7053 47053 1B8C...
  • Page 418 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Registers for ladder program For output ladder calculation D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D7101 47101 1BBC OUT_CTL D7151 47151 1BEE Y_OUT R * R * R * R * R * D7102 47102 1BBD D7152 47152 1BEF D7103 47103 1BBE RET_CTL...
  • Page 419 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Registers for ladder program Status register D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D7201 47201 1C20 M1_16 R/W R/W R/W R/W R/W D7251 47251 1C52 D7202 47202 1C21 M17_32 R/W R/W R/W R/W R/W D7252 47252 1C53 D7203 47203 1C22 M33_48 R/W R/W R/W R/W R/W D7253 47253 1C54 D7204 47204 1C23 M49_64...
  • Page 420 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Registers for ladder program Constant register D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D7301 47301 1C84 K01 R/W R/W R/W R/W R/W D7351 47351 1CB6 D7302 47302 1C85 K02 R/W R/W R/W R/W R/W D7352 47352 1CB7 D7303 47303 1C86 K03 R/W R/W R/W R/W R/W D7353 47353 1CB8 D7304 47304 1C87 K04...
  • Page 421 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Registers for ladder program Constant register D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D7401 47401 1CE8 D7451 47451 1D1A D7402 47402 1CE9 D7452 47452 1D1B D7403 47403 1CEA D7453 47453 1D1C D7404 47404 1CEB D7454 47454 1D1D D7405 47405 1CEC...
  • Page 422 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Registers for ladder program Input range / scale D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D7501 47501 1D4C DP_R D7551 47551 1D7E D7502 47502 1D4D RH_R D7552 47552 1D7F D7503 47503 1D4E RL_R D7553 47553 1D80 D7504 47504 1D4F D7554 47554 1D81...
  • Page 423: For Input Ladder Calculation (D7001 To D7100)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers For Input Ladder Calculation (D7001 to D7100)  D7001 to D7010 Register Description Range and meaning of value D7001 X_PV PV analog input -5.0 to 105.0% D7002 X_PV2 PV2 analog input -5.0 to 105.0% D7003 to D7010  Bit Configuration of D7011: X000 (DI1-DI2 status: equipped as standard) Symbol Event...
  • Page 424: For Output Ladder Calculation (D7101 To D7200)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers For Output Ladder Calculation (D7101 to D7200)  D7101 to D7110 Register Description Range and meaning of value D7101 OUT_CTL Control OUT output -5.0 to 105.0% of control OUT output range D7102 D7103 RET_CTL Control RET output -5.0 to 105.0% of control ERT output range D7104 OUT2R_CTL...
  • Page 425 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers  Bit Configuration of D7161: Y000 (AL1-AL3 status: equipped as standard) Symbol Event Y_AL1 AL1 status (0: OFF 1: ON) Y_AL2 AL2 status (0: OFF 1: ON) Y_AL3 AL3 status (0: OFF 1: ON) 3 to 15  Bit Configuration of D7162: Y100_E1 (DO11-DO15 status: E1-terminal area) Symbol Event Y_DO11 DO11 status (0: OFF 1: ON) Y_DO12 DO12 status (0: OFF...
  • Page 426: Status Registers (D7201 To D7300)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Status Registers (D7201 to D7300)  Bit Configuration of D7201 to D7208: M1_16 to M113_128 (Status register (M1-M16 to M113-M128, Non-holding type) Symbol Event M113 Internal relay (Non-holding type) (0: OFF 1: ON) M114 Internal relay (Non-holding type) (0: OFF 1: ON) M115 Internal relay (Non-holding type) (0: OFF 1: ON) M100 M116...
  • Page 427 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers  Bit Configuration of D7213 to D7218: M33_48_B to M113_128_B (Status register (M33_B-M48_B to M113_B-M128_B, Holding type) Symbol Event M33_B M49_B M65_B M81_B M97_B M113_B Internal relay (Holding type) * (0: OFF 1: ON) M34_B M50_B M66_B M82_B M98_B M114_B Internal relay (Holding type) * (0: OFF 1: ON) M35_B M51_B M67_B M83_B M99_B...
  • Page 428: Constant Register (D7301 To D7500)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Constant Register (D7301 to D7500) Register Description Range and meaning of value D7301 K01 data register to K30 data K01 to K20: -32768 to 32767 K01 to K30 register K21 to K30: 0 to 65535 D7330 D7331 to D7409 D7410 Constant -1...
  • Page 429: Input / Output Terminal Status Register (D7601 To D7700)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers 8.4.9 Input / Output Terminal Status Register (D7601 to D7700) Terminal status registers Input / output terminal status register D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol D7601 47601 1DB0 DI D7651 47651 1DE2 D7602 47602 1DB1 DI_E1 D7652 47652 1DE3 D7603 47603 1DB2...
  • Page 430 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers  Bit Configuration of D7601: DI (DI1-DI2 terminal status: equipped as standard) Symbol Event DI1 terminal status (0: OFF 1: ON) DI2 terminal status (0: OFF 1: ON) DI3 * DI3 terminal status (0: OFF 1: ON) 3 to 15 *: Only for UP35A.  Bit Configuration of D7602: DI_E1 (DI11-DI15 terminal status: E1-terminal area) Symbol Event DI11 DI11 terminal status (0: OFF...
  • Page 431 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers  D7616 to D7700 Register Description Range and meaning of value D7616 to D7620 D7621 OUT_OUT OUT terminal -1500 to 31500 UT35A Heater break alarm: HAL1 terminal Position proportional control output: VALV (HIGH) terminal UT32A/UT32A-D D7622 OUT_OUT2H Heater break alarm: HAL1 terminal UP35A/UP32A...
  • Page 432: Program Pattern For Up35A/Up32A (D8001 To D9000)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers 8.4.8 Program Pattern for UP35A/UP32A (D8001 to D9000) Pattern Data Setting (D8001 to D8100) Register Ref. Register H No. Description Range and meaning of value symbol 0: Not select program pattern D8001 48001 1F40 PTNO._C R/W Program pattern number selection 1 to 2 (4 when the option “/AP” is specified.) (1 to 20.
  • Page 433: Reading Pattern Data (D8001 To D8100)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Reading Pattern Data (D8001 to D8100)  Modbus communication The example for the communication command is Modbus/RTU. For easy understanding, space is added but it is not present in the actual command. The device address is “1.”  Reading start segment data Example: Reading start target setpoint (SSP_L1) for pattern 2 (1) Write pattern number “2”...
  • Page 434: Writing Pattern Data (D8001 To D8100)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Writing Pattern Data (D8001 to D8100)  Modbus communication The example for the communication command is Modbus/RTU. For easy understanding, space is added but it is not present in the actual command. The device address is “1.”  Writing start segment data Example: Writing “2” to start code (STC) for pattern 2 (1) Write pattern number “2”...
  • Page 435: Segment Data Setting (D8101 To D8200)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Segment Data Setting (D8101 to D8200) Register Ref. Register H No. Description Range and meaning of value symbol 0: Not select program pattern D8101 48101 1FA4 PTNO._C R/W Program pattern number selection 1 to 2 (4 when the option “/AP” is specified.) (1 to 20.
  • Page 436 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Register Ref. Register H No. Description Range and meaning of value symbol OFF: Disable (Energized) 1: PV high limit, 02: PV low limit, 3: SP high limit, 04: SP low limit, 5: Deviation high limit, 6: Deviation low limit, 7: Deviation high and low limits, 8: Deviation within high and low limits, 9: Target SP high limit,...
  • Page 437: Reading Segment Data (D8101 To D8200)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Reading Segment Data (D8101 to D8200)  Modbus communication The example for the communication command is Modbus/RTU. For easy understanding, space is added but it is not present in the actual command. The device address is “1.” Example: Reading final target setpoint (TSP_L1) of segment 5 for pattern 1 (1) Write pattern number “1”...
  • Page 438: Writing Segment Data (D8101 To D8200)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Writing Segment Data (D8101 to D8200)  Modbus communication The example for the communication command is Modbus/RTU. For easy understanding, space is added but it is not present in the actual command. The device address is “1.” Example: Writing final target setpoint (TSP_L1) of segment 5 for pattern 1 (1) Write pattern number “1”...
  • Page 439: Final Target Setpoint Setting For Batch Writing (D8201 To D8300)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Final Target Setpoint Setting for Batch Writing (D8201 to D8300) Register Ref. Register H No. Description Range and meaning of value symbol Program pattern number 0: Not select program pattern D8201 48201 2008 PTNO._C selection 1 to 2 (4 when the option “/AP” is specified.) D8202 48202 2009...
  • Page 440: Segment Time Setting For Batch Writing (D8601 To D8700)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Segment Time Setting for Batch Writing (D8601 to D8700) Register Ref. Register H No. Description Range and meaning of value symbol Program pattern number 0: Not select program pattern D8601 48601 2198 PTNO._C selection 1 to 2 (4 when the option “/AP” is specified.) D8602 48602 2199...
  • Page 441: Segment Ramp-Rate Setting For Batch Writing (D8801 To D9000)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Segment Ramp-Rate Setting for Batch Writing (D8801 to D9000) Register Ref. Register H No. Description Range and meaning of value symbol 0: Not select program pattern D8801 48801 2260 PTNO._C R/W Program pattern number selection 1 to 2 (4 when the option “/AP” is specified.) D8802 48802...
  • Page 442: Reading Data (Multiple Segment Data) (D8201 To D8953)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Reading Data (Multiple Segment Data) (D8201 to D8953)  Modbus communication The example for the communication command is Modbus/RTU. For easy understanding, space is added but it is not present in the actual command. The device address is “1.” Example: Batch reading SSP_L1 and target setpoints in segments 1 to 5 (TSP_L1_S1 to TSP_L1_S5) for pattern 1 (1) Write pattern number “1”...
  • Page 443: Writing Data (Multiple Segment Data) (D8201 To D8953)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Writing Data (Multiple Segment Data) (D8201 to D8953)  Modbus communication The example for the communication command is Modbus/RTU. For easy understanding, space is added but it is not present in the actual command. The device address is “1.” Example: Batch writing SSP_L1 and target setpoints in segments 1 to 20 (TSP_L1_S1 to TSP_L1_S20) for pattern 1 (1) Write to 23 registers continuously: pattern number “1”...
  • Page 444: Used Pattern Numbers And The Number Of Remaining Unused Segments (D8961 To D8963)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Used Pattern Numbers and the Number of Remaining Unused Segments (D8961 to D8963) Register Ref. Register H No. Description Range and meaning of value symbol Used program pattern numbers D8961 48961 2300 PTN_USE1 See below (Patterns 1 to 4) D8962 Number of remaining unused 0 to 20 (40 when the option “/AP” is D8963 48963 2302...
  • Page 445: Check The Number Of Segments, Copy And Clear Of Program Pattern (D8971 To D8993)

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Check the Number of Segments, Copy and Clear of Program Pattern (D8971 to D8993) Register Ref. Register H No. Description Range and meaning of value symbol Pattern number designation for 0: not select program pattern D8971 48971 230A PTN.S comfirming number of segments 1 to 2 (4 when the option “/AP” is specified.) The number of the segment is displayed when the program pattern number is specified Number of segments within a...
  • Page 446 8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers  PC link communication The example for the communication command is a PC link without a checksum. The device address is “1.”  How to check the number of segments used in one pattern Example: Checking segment numbers used in pattern 1 (1) Write pattern number “1” to D8971 (PTN.S). (2) Read from D8972 (USE.S).
  • Page 447: Error Information

    8.4 UT35A/UT32A/UT32A-D/UP35A/UP32A D Registers Error Information The following table shows the Error Information for the register symbol "PTN.ERR". Error code Error information Cause of error No error Normal end Deleting or copying of the program pattern, or inserting Pattern creation or editing is disable during or deleting of the segment was excuted during program program operation.
  • Page 448: Writing Via Communication

    Writing via Communication  Setting Target Setpoint In LCL (local) mode (1) Set the target setpoints of groups 1 to parameters (SP_L1_1 to SP_L1_4). (2) Write the setpoint (1 to 4) in the SPNO. (SP number selection) (depends on the setup parameter SPGR.
  • Page 449: Green Series Compatible D Registers

    GREEN Series Compatible D Registers 8.6.1 Compatibility with GREEN Series Controllers The D register map configuration of the UTAdvanced is the same as that of the GREEN Series (UT300 Series) controllers that perform access in the 2-byte integer data format. When GREEN Series devices are replaced with the UTAdvanced, communication programs created in the GREEN Series controllers can be used by just carrying out wiring.
  • Page 450 8.6 GREEN Series Compatible D Registers  D register symbols • With regards to some D register symbols, the loop number, terminal area, and group number are indicated by adding the underline (_) to the end of the parameter symbols. If both the loop number and group number are added to the parameter symbols, they are added in the order of _loop number and _group number.
  • Page 451: Process Data And User Area (D0001 To D0100)

    8.6 GREEN Series Compatible D Registers 8.6.3 Process Data and User Area (D0001 to D0100) Configuration map for GREEN Series Process data User area Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0001 40001 0000 ADERROR AD1.E_G D0051 40051 0032 USER USER1...
  • Page 452 8.6 GREEN Series Compatible D Registers Configuration map for GREEN Series Can not be used Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0151 40151 0096 1.SP7 D0101 40101 0064 D0152 40152 0097 1.TM7 D0102 40102 0065 D0153 40153 0098 1.SP8...
  • Page 453: Operation Mode And Operation-Related Parameters (D0201 To D0300)

    8.6 GREEN Series Compatible D Registers 8.6.4 Operation Mode and Operation-related Parameters (D0201 to D0300) Configuration map for GREEN Series Operation mode / Operation-related parameters Register Register Register D-Reg Ref. Register symbol D-Reg Ref. H No. symbol for H No. symbol for symbol for for UTAdvanced GREEN GREEN UTAdvanced D0201 40201 00C8 A/M (Note 2) A.M (D2301) R/W D0251 40251 00FA ORH D0202 40202 00C9...
  • Page 454: Pid Parameters (D0301 To D0500)

    8.6 GREEN Series Compatible D Registers 8.6.5 PID Parameters (D0301 to D0500) Configuration map for GREEN Series SP / AL / PID parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0301 40301 012C 1.SP (Note 1) SP_L1_1 (D2501) R/W D0351 40351 015E 3.SP (Note 1) SP_L1_3 (D2541) R/W D0302 40302 012D D0352 40352 015F D0303 40303 012E...
  • Page 455 8.6 GREEN Series Compatible D Registers Configuration map for GREEN Series SP / AL / PID parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0401 40401 0190 D0451 40451 01C2 D0402 40402 0191 D0452 40452 01C3 D0403 40403 0192 D0453 40453 01C4...
  • Page 456: Control Action Parameters (D0901 To D1000)

    8.6 GREEN Series Compatible D Registers 8.6.6 Control Action Parameters (D0901 to D1000) Configuration map for GREEN Series Control action parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0901 40901 0384 D0951 40951 03B6 D0902 40902 0385 D0952 40952 03B7 D0903 40903 0386...
  • Page 457: Common Function Parameters (D1001 To D1100)

    8.6 GREEN Series Compatible D Registers 8.6.7 Common Function Parameters (D1001 to D1100) Configuration map for GREEN Series Common function parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D1001 41001 03E8 D1051 41051 041A D1002 41002 03E9 D1052 41052 041B D1003 41003 03EA...
  • Page 458: Display And Input / Output Parameters (D1101 To D1200)

    8.6 GREEN Series Compatible D Registers 8.6.8 Display and Input / Output Parameters (D1101 to D1200) Configuration map for GREEN Series Display and input / Output parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D1101 41101 044C C.S1 R/W D1151 41151 047E D1102 41102 044D C.S2 R/W D1152 41152...
  • Page 459: Control Mode, Pv Input, And Control Output Parameters (D1201 To D1300)

    8.6 GREEN Series Compatible D Registers 8.6.9 Control Mode, PV Input, and Control Output Parameters (D1201 to D1300) Configuration map for GREEN Series Control mmode, PV input, and Control output parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D1201 41201 04B0 IN IN (D5101) R/W D1251 41251 04E2 DLN Depends on the conditions D1202 41202 04B1 UNI...
  • Page 460: Registers Converted For Green Series

    8.6 GREEN Series Compatible D Registers 8.6.10 D Registers Converted for GREEN Series  Bit Configuration of D0001: AD1.E_G (A/D converter error status for GREEN Series) Symbol Event GREEN Series UTAdvanced ADERR.st ADERR (I4065) PV input A/D converter error 1 to 15  Bit Configuration of D0002: PV1.E_L1_G (PV input error status for GREEN Series) Symbol Event GREEN Series UTAdvanced PVBO.st PVBO_L1 (I4097) PV input burnout error RJCERR.st RJCERR (I4070)
  • Page 461 8.6 GREEN Series Compatible D Registers  Bit Configuration of D0035: PA.ER_G (Parameter error status for GREEN Series) Symbol Event GREEN Series UTAdvanced CALB.E.st CALB_ERR (I4002) Calibration value error 1 to 5 SETUP.st SETPA_ERR (I4005) Setup parameter error PARA.E.st OPEPA_ERR (I4006) Operation parameter error MODE.E.st CTLPA_ERR (I4011) Control parameter error 10 to 11 EEP.E.st FRAM_ERR (I4009) Faulty FRAM...
  • Page 462 8.6 GREEN Series Compatible D Registers  D0254: OH_G (Control output high limit for GREEN Series) Symbol Register Event GREEN Series UTAdvanced D0254 OH_G -4.9 to 105.0%, (OL<OH) In Heating/cooling control: 0.1 to 105.0% (OL<OH) Write: The value written in OH_G will be written in the register of OH_L1_1 to OH_L1_4 and OH_L1_R.
  • Page 463 8.6 GREEN Series Compatible D Registers  D0257: DR_G (Direct/reverse action switch for GREEN Series) Symbol Register Event GREEN Series UTAdvanced D0257 DR_G 0: RVS: Reverse action 1: DIR: Direct action Write: The value written in DR_G will be written in the register of DR_L1_1 to DR_L1_4 and DR_L1_R.
  • Page 464: Registers Differring In Content From Green Series

    8.6 GREEN Series Compatible D Registers 8.6.11 D Registers Differring in Content from GREEN Series  D0028, D0029: Heter break alarm-1 current valuedisplay, Heter break alarm-2 current valuedisplay D0258, D0259: Heater break alarm-1 current setpoint, Heater break alarm-2 current setpoint UTAdvanced Register Description Range and meaning of value D0028 Heter break alarm-1 current value display...
  • Page 465 8.6 GREEN Series Compatible D Registers  D0915 to D0917: Alarm-1 type to alarm-4 type UTAdvanced Register Description Range and meaning of value 0: Disable 01: PV high limit 02: PV low limit 03: SP high limit D0915 AL1.T_L1 Alarm-1 type 04: SP low limit 05: Deviation high limit 06: Deviation low limit 07: Deviation high and low limits 08: Deviation within high and low limits...
  • Page 466: Registers Differring Depending On Conditions

    8.6 GREEN Series Compatible D Registers  D1240: Control output cycle time Heating-side control output cycle time (in Heating/cooling control) D1241: Cooling-side control output cycle time UTAdvanced Register Description Range and meaning of value Control output cycle time D1240 Heating-side control output cycle time (in 0.5 to 1000.0 s Heating/cooling control) D1241 Cooling-side control output cycle time GREEN Series...
  • Page 467 Blank Page...
  • Page 468: Overview

    Chapter 9 Functions and Applications of I Relays (for UT35A/UT32A/UT32A-D/UP35A/UP32A) Overview This chapter describes the functions and applications of the I relays. I relays are used in ladder program, Modbus communication, PC link communication, and contact input / output functions. I relays contain status information of errors, operation, and alarms. Contents of I relays can be read only by means of communication using a host computer.
  • Page 469: Classification Of I Relays

    Classification of I Relays I relays are classified as shown below. Classification of I Relay Map Area and data I relay No. Description categories Each bit information is the same as that of 1 to 192 Status D register. 193 to576 Free area GREEN series SP number, PID number,...
  • Page 470 9.2 Classification of I Relays Area and data I relay No. Description categories Each bit information is the same as that of 6305 to 6432 DI terminal D register. Input / Output Each bit information is the same as that of 6433 to 6560 terminal status DO terminal...
  • Page 471: Ut35A/Ut32A/Ut32A-D/Up35A/Up32A I Relays

    9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays 9.3.1 Function Status (4001 to 5024) Note When specifying an I relay number for communication, begin the number with the character “I.” Example: Set “I4065” to specify the ADERR (I relay No.: 4065). IM 05P07A01-01EN...
  • Page 472 9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays System error Input error I relay symbol I relay symbol UT35A/UT32A UP35A UT35A/UT32A UP35A 4001 SYSTEM_ERR 4065 ADERR 4002 CALB_ERR 4066 4003 UPARA_ERR 4067 4068 4004 4005 SETPA_ERR 4069 4006 OPEPA_ERR 4070 RJCERR 4007 PROG_ERR 4071 4072 4008 4009 FRAM_ERR 4073 ADBO 4074 4010...
  • Page 473 9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays Operation mode Operation mode Operation mode I relay symbol I relay symbol UT35A/UT32A/ UP35A/ I relay symbol UT35A/UT32A/ UP35A/ UT35A/UT32A/ UP35A/ UT32A-D UP32A UT32A-D UP32A UT32A-D UP32A 4129 4193 A.M 4257 WTEND1 4130 4194 R.L_L1 4258 WTEND3 4131 4195 S.R 4259 WTEND5 4132 4196...
  • Page 474 9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays Alarm Alarm latch Alarm latch I relay symbol UT35A/UT32A/ UP35A/ I relay symbol UT35A/UT32A/ UP35A/ I relay symbol UT35A/UT32A/ UP35A/ UT32A-D UP32A UT32A-D UP32A UT32A-D UP32A 4321 ALM1_L1 4385 ALO1LA1_L1 4449 ALO1LA3_L1 4322 ALM2_L1 4386 ALO2LA1_L1 4450 ALO2LA3_L1 4323 ALM3_L1 4387 ALO3LA1_L1 4451 ALO3LA3_L1 4324...
  • Page 475 9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays Alarm latch and Heater break alarm SP number and PID number Pattern number and Segment number I relay symbol UT35A/UT32A/ UP35A/ I relay symbol UT35A/UT32A/ UP35A/ I relay symbol UT35A/UT32A/ UP35A/ UT32A-D UP32A UT32A-D UP32A UT32A-D UP32A 4513 ALOLA_RLS 4577 CSPN.B0 4641 PTNO.B0 4514 ALM_WAIT 4578 CSPN.B1 4642 PTNO.B1 4515 4579 CSPN.B2...
  • Page 476 9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays Display, PV event status and Time event status I relay symbol UT35A/UT32A/ UP35A/ I relay symbol UT35A/UT32A/ UP35A/ UT32A-D UP32A UT32A-D UP32A 4705 PARA_KEY 4769 MG1.B 4706 DISP_KEY 4770 MG2.B 4707 RIGHT_KEY 4771 MG3.B 4708 DOWN_KEY 4772 4709 SET_KEY 4773 MG4.B 4710 UP_KEY 4774 4711 LEFT_KEY 4775 4712 F2_KEY...
  • Page 477 9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays Pattern number status and Segment number status Pattern number status and Segment number status Pattern number status and Segment number status I relay symbol UT35A/UT32A/ UP35A/ I relay symbol UT35A/UT32A/ UP35A/ I relay symbol UT35A/UT32A/ UP35A/ UT32A-D UP32A UT32A-D UP32A UT32A-D UP32A 4833 4897 SEG1 4961 4834 4898 SEG2 4962 4835 4899 SEG3 4963 4836 4900 SEG4 4964 4837 4901 SEG5...
  • Page 478: System Error, Input Error, And Operation Mode (4001 To 4320)

    9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays System Error, Input Error, and Operation Mode (4001 to 4320) UT35A/UT32A I relay No. Symbol Event SYSTEM_ERR to 4001 to 4016 Parameter error status (Same as D2068) CTLPA_ERR LAD_ERR to 4017 to 4032 Ladder error status (Same as D2012) LD200_OVER E1_ERR to 4033 to 4048...
  • Page 479: Alarm, Alarm Latch And Heater Break Alarm (4321 To 4576)

    9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays Alarm, Alarm Latch and Heater Break Alarm (4321 to 4576) UT35A/UT32A/UT32A-D I relay No. Symbol Event 4321 to 4336 ALM1_L1 to ALM4_L1 Alarm-1 to alarm-4 status (Same as D2011) 4337 to 4352 ALM1_L2 to ALM4_L2 Loop-2 alarm-1 to alarm-4 status (Same as D2013) 4353 to 4368 ALO1_L1 to ALO4_L1 Alarm-1 to alarm-4 output status (Same as D2037)
  • Page 480: Key (4705 To 4768)

    9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays UP35A/UP32A I relay No. Symbol Event 4577 to 4608 PIDN.B0_L1 to 4609 to 4624 *1 PID number (Same as D2009) PIDN.B3_L1 4625 to 4640 4641 to 4656 PTNO.B0 to PTNO.B2 Pattern number (Same as D2015) SEGNO.B0 to SEGNO. 4657 to 4672 Segment number (Same as D2016) 4673 RAMP_UP_L...
  • Page 481: Status For Ladder Program (5025 To 5664)

    9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays 9.3.2 Status for Ladder Program (5025 to 5664) Note When specifying an I relay number for communication, begin the number with the character “I.” Example: Set “I5025” to specify the X_DI1 (I relay No.: 5025). 9-14 IM 05P07A01-01EN...
  • Page 482 9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays Input (status) relay Input (status) relay I relay symbol UT35A/UT32A/ UP35A/ I relay symbol UT35A/UT32A/ UP35A/ UT32A-D UP32A UT32A-D UP32A 5025 X_DI1 5089 X_DI41 5026 X_DI2 5090 X_DI42 5027 X_DI3 5091 X_DI43 5028 5092 X_DI44 5029 5093 X_DI45 5030 5094 5031 5095...
  • Page 483 9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays Output (status) relay Output (status) relay I relay symbol I relay symbol UT35A/UT32A/ UP35A/ UT35A/UT32A/ UP35A/ UT32A-D UP32A UT32A-D UP32A 5153 Y_AL1 5217 Y_DO41 5154 Y_AL2 5218 Y_DO42 5155 Y_AL3 5219 Y_DO43 5156 5220 Y_DO44 5157 5221 Y_DO45 5158 5222 5159 5223...
  • Page 484 9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays Control (status) relay Control (status) relay I relay symbol UT35A/UT32A/ UP35A/ I relay symbol UT35A/UT32A/ UP35A/ UT32A-D UP32A UT32A-D UP32A 5281 AL1_CTL 5345 DO41_CTL 5282 AL2_CTL 5346 DO42_CTL 5283 AL3_CTL 5347 DO43_CTL 5284 5348 DO44_CTL 5285 5349 DO45_CTL 5286 5350 5287 5351...
  • Page 485 9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays Special relay Free area I relay symbol I relay symbol UT35A/UT32A/ UP35A/ UT35A/UT32A/ UP35A/ UT32A-D UP32A UT32A-D UP32A 5409 TIM1 5473 5410 TIM2 5474 5411 TIM3 5475 5412 TIM4 5476 5413 5477 5414 5478 5415 5479 5416 5480 5417 5481 5418 5482...
  • Page 486 9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays Internal relay Internal relay I relay symbol UT35A/UT32A/ UP35A/ I relay symbol UT35A/UT32A/ UP35A/ UT32A-D UP32A UT32A-D UP32A 5537 5601 5538 5602 5539 5603 5540 5604 5541 5605 5542 5606 5543 5607 5544 5608 5545 5609 5546 5610 5547 5611 5548 5612...
  • Page 487 9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays Internal relay Internal relay I relay symbol I relay symbol UT35A/UT32A/ UP35A/ UT35A/UT32A/ UP35A/ UT32A-D UP32A UT32A-D UP32A 5665 M01_B 5729 M65_B 5666 5730 M66_B M02_B 5667 5731 M67_B M03_B 5668 M04_B 5732 M68_B 5669 5733 M69_B M05_B 5670 M06_B 5734 M70_B...
  • Page 488 9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays Peer-to-peer communication register Peer-to-peer communication register I relay symbol UT35A/UT32A/ UP35A/ I relay symbol UT35A/UT32A/ UP35A/ UT32A-D UP32A UT32A-D UP32A CI01 6049 CF01 6113 6050 CF02 6114 CI02 CI03 6051 CF03 6115 6052 CF04 6116 CI04 CI05 6053 6117 6054 6118 CI06 CI07 6055 6119 6056...
  • Page 489 9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays Peer-to-peer communication register Free area I relay symbol I relay symbol UT35A/UT32A/ UP35A/ UT35A/UT32A/ UP35A/ UT32A-D UP32A UT32A-D UP32A 6177 CO01 6241 CO02 6178 6242 6179 CO03 6243 6180 CO04 6244 CO05 6181 6245 6182 CO06 6246 CO07 6183 6247 6184 CO08 6248 CO09...
  • Page 490: Input (Status) Relay And Output (Status) Relay (5025 To 5280)

    9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays Input (Status) Relay and Output (Status) Relay (5025 to 5280) I relay No. Symbol Description 5025 to 5040 X_DI1 to X_DI2 * DI1-DI2 status (Same as D7011) * 5041 to 5056 X_DI11 to X_DI15 DI11-DI15 status (Same as D7012) 5057 to 5072 5073 to 5088 5089 to 5104...
  • Page 491: Internal Relay (5537 To 5792)

    9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays Internal Relay (5537 to 5792) I relay No. Symbol Description You can read/write data from/to the area via communication. (Same as D7201 to D7208) 5537 to 5664 M01 to M128 That is, you can use the area freely without affecting the control function of the UTAdvanced You can read/write data from/to the area via communication.
  • Page 492 9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays 9.3.3 Input / Output Terminal Status (6305 to 6560) Note When specifying an I relay number for communication, begin the number with the character “I.” Example: Set “I6305” to specify the DI1 (I relay No.: 6305). 9-25 IM 05P07A01-01EN...
  • Page 493 9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays DI terminals DI terminals I relay symbol I relay symbol UT35A/UT32A/ UP35A/ UT35A/UT32A/ UP35A/ UT32A-D UP32A UT32A-D UP32A 6305 6369 DI41 6306 6370 DI42 6307 6371 DI43 6308 6372 DI44 6309 6373 DI45 6310 6374 6311 6375 6312 6376 6313 6377 6314...
  • Page 494 9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays DO terminals DO terminals I relay symbol UT35A/UT32A/ UP35A/ I relay symbol UT35A/UT32A/ UP35A/ UT32A-D UP32A UT32A-D UP32A OUT_DO41 6433 OUT_AL1 6497 6434 OUT_AL2 6498 OUT_DO42 OUT_DO43 6435 OUT_AL3 6499 6436 6500 OUT_DO44 OUT_DO45 6437 6501 6438 6502 6439 6503 6440 6504...
  • Page 495: Di Terminals And Do Terminals (6305 To 6560)

    9.3 UT35A/UT32A/UT32A-D/UP35A/UP32A I Relays DI Terminals and DO Terminals (6305 to 6560) I relay No. Symbol Description 6305 to 6320 DI1 to DI2 * DI1-DI2 status (Same as D7601) * 6321 to 6336 DI11 to DI15 DI11-DI15 status (Same as D7602) 6337 to 6352 6353 to 6368 6369 to 6384 DI41 to DI45...
  • Page 496: Reading Via Communication

    Reading via Communication  When reading the alarm status Read I relay numbers 4321 to 4336 for alarm-1 to alarm-4 status. I relay No. Symbol Event 4321 to 4336 ALM1_L1~ALM4_L1 Alarm-1 to alarm-4 status (Same as D2011) * • • •...
  • Page 497 GREEN Series Compatible I Relays 9.5.1 Compatibility with GREEN Series Controllers The map configuration from 1 to 2048 of the I relay map is the same as that of the GREEN Series (UT300 Series) controllers. If existing programs created in the GREEN Series controllers are used, communication is performed using the area from 0001 to 0784.
  • Page 498 9.5 I Relays Corresponding to GREEN Series 9.5.3 Status (0001 to 0192) UT35A/UT32A Status I relay symbol I relay symbol I relay symbol GREEN UTAdvanced GREEN UTAdvanced GREEN UTAdvanced ADERROR ADERR (4065) AUT/MAN A.M (4193) S.R (4193) AT_L1_ON (4207) PVBO PVBO_L1 (4097) RJCERR RJCERR (4070)
  • Page 499 9.5 I Relays Corresponding to GREEN Series I relay No. Symbol Description 1 to 16 ADERR A/D converter error status for GREEN Series (Same as 0001) PVBO_L1 to PV input error status for GREEN Series 17 to 32 ATERR_L1 (Same as 0002) 33 to 48 CALB_ERR to 49 to 64...
  • Page 500 9.5 I Relays Corresponding to GREEN Series UP35A Status I relay symbol I relay symbol I relay symbol GREEN UTAdvanced GREEN UTAdvanced GREEN UTAdvanced ADERROR ADERR (4065) 129 TIME1 TIME_EV1 (4817) RESET RST_ON (4181) PROG1 PT1 (4849) PROG2 PT2 (4850) HOLD HOLD_ON (4189) WAIT...
  • Page 501: User Area (0721 To 784)

    9.5 I Relays Corresponding to GREEN Series I relay No. Symbol Description ADERR to 1 to 16 A/D converter error status for GREEN Series (Same as D0001) VALVBO PVBO_L1 to PV input error status for GREEN Series 17 to 32 ATERR_L1 (Same as D0002) 33 to 48...
  • Page 502: Overview

    Chapter 10 Functions and Applications of D Registers (for UM33A) 10.1 Overview This chapter describes the functions and applications of the D registers. D registers are used in Modbus, PC link, ladder, Ethernet communications, or Open Network communication (network profile creating function of LL50A) and are used for storing UTAdvanced parameter data, flag data, process data, and other data and values.
  • Page 503 10.2 Conventions Used in D Register Tables This section describes the conventions used in the D register map tables. The numerical values arranged vertically in the leftmost column of the table represent (1) D register numbers. 5-digit numbers in the column next to it show (2) reference numbers for Modbus communication.
  • Page 504 10.3 Classification of D Registers  Classification of D Register Map Tables The table on next page outlines how the D registers are classified by their numbers in the D register map tables. When you newly perform communication with the UTAdvanced, the D registers after D2001 are used.
  • Page 505 10.3 Classification of D Registers Classification of D Registers Register No. Area and data categories Description Reference D0001 to D0049 Process data Sections 10.6.3 D0050 to D0100 User area Sections 10.6.3 D0101 to D0200 Cannot be used D0201 to D0300 Operation-related parameter Sections 10.6.4 Configuration map for GREEN Series...
  • Page 506: Um33A D Registers

    10.4 UM33A D Registers 10.4.1 Process Monitoring (D2001 to D2300) Process monitoring area Process data D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UM33A UM33A AD1.E D2001 42001 07D0 D2051 42051 0802 PV1.E_L1 D2002 42002 07D1 D2052 42052 0803 D2003 PV_L1 42003 07D2 D2053 42053 0804...
  • Page 507 10.4 UM33A D Registers Process Data Area Some of the D registers represent multiple events such as errors and status depending on combinations of bits in the register. In the following tables, if an event indicated by a specific bit occurs, the state of that bit changes to “1.”...
  • Page 508 10.4 UM33A D Registers  Bit Configuration of D2037: ALO_L1 (Alarm-1 to alarm-8 output status) Symbol Event Output status where Alarm output 1 is assighed. 0: When the alarm is turned off (alarm type: energized), or the alarm is turned on (alarm type: de-energized). (The ALO1_L1 relay contact is open.) 1: When the alarm is turned on (alarm type: energized), or the alarm is turned off (alarm type: de-energized).
  • Page 509 10.4 UM33A D Registers  Bit Configuration of D2071: ALOLA1_L1 (Alarm-1 to alarm-8 latch output status) Symbol Event ALO1LA1_L1 Alarm-1 latch-1 output status ALO2LA1_L1 Alarm-2 latch-1 output status ALO3LA1_L1 Alarm-3 latch-1 output status ALO4LA1_L1 Alarm-4 latch-1 output status ALO5LA1_L1 Alarm-5 latch-1 output status ALO6LA1_L1 Alarm-6 latch-1 output status ALO7LA1_L1 Alarm-7 latch-1 output status ALO8LA1_L1 Alarm-8 latch-1 output status 10 to 15...
  • Page 510: Free Area (D2101 To D2300)

    10.4 UM33A D Registers Free Area (D2101 to D2300) Register Description Range and meaning of value D2101 to D2300 Free area 10-9 IM 05P07A01-01EN...
  • Page 511 10.4 UM33A D Registers 10.4.2 Operation Parameter (D2301 to D3000) Operation parameters Alarm setpoint setting (Menu: AL) D-Reg Ref. D-Reg Ref. H No. Register Symbol H No. Register Symbol UM33A UM33A A1_L1 D2301 42301 08FC D2351 42351 092E A2_L1 D2302 42302 08FD D2352 42352 092F A3_L1 D2303 42303 08FE D2353...
  • Page 512 10.4 UM33A D Registers Operation parameter Alarm function setting (Menu: ALRM) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UM33A UM33A D2801 42801 0AF0 AL1.T_L1 D2851 42851 0B22 DYN3_L1 D2802 42802 0AF1 AL1.W_L1 D2852 42852 0B23 DYN4_L1 D2803 42803 0AF2 AL1.D_L1 D2853 42853...
  • Page 513 10.4 UM33A D Registers Operation parameter PV-related setting (Menu: PVS) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UM33A UM33A BS_L1 D2901 42901 0B54 D2951 42951 0B86 FL_L1 D2902 42902 0B55 D2952 42952 0B87 D2903 42903 0B56 D2953 42953 0B88 D2904 42904...
  • Page 514 10.4 UM33A D Registers Alarm Setpoint Setting (D2301 to D2400) Register Description Range and meaning of value D2301 to D2350 A1_L1 D2351 Alarm-1 setpoint A2_L1 D2352 Alarm-2 setpoint Set a display value of setpoint of PV alarm or A3_L1 D2353 Alarm-3 setpoint velocity alarm.
  • Page 515 10.4 UM33A D Registers Alarm Function Setting (D2801 to D2900) Register Description Range and meaning of value D2801 AL1.T_L1 Alarm-1 type D2802 AL1.W_L1 Alarm-1 stand-by action D2803 AL1.D_L1 Alarm-1 energized/de-energized D2804 AL1.L_L1 Alarm-1 latch D2805 AL2.T_L1 Alarm-2 type D2806 AL2.W_L1 Alarm-2 stand-by action D2807 AL2.D_L1...
  • Page 516 10.4 UM33A D Registers Register Description Range and meaning of value D2841 HY1_L1 Alarm-1 hysteresis D2842 HY2_L1 Alarm-2 hysteresis D2843 HY3_L1 Alarm-3 hysteresis Set a display value of setpoint of hysteresis. D2844 HY4_L1 Alarm-4 hysteresis -19999 to 30000 (Set a value within the input range.) D2845 HY5_L1...
  • Page 517 10.4 UM33A D Registers 10.4.3 10-segment Linearizer Setting Parameter (D4801 to D4900) 10-segment linearizer setting parameter 10-segment inearizer setting (Menu: PYS1, PYS2) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UM33A UM33A B10_2 D4801 44801 12C0 D4851 44851 12F2 A1_1 A11_2 D4802 44802 12C1 D4852 44852 12F3 D4803 44803 12C2 B1_1 D4853 44853...
  • Page 518: Free Area (D4901 To D5000)

    10.4 UM33A D Registers 10-segment Linearizer Setting (D4801 to D4900) Register Description Range and meaning of value D4801 D4802 A1_1 10-segment linearizer input 1 of group 1 D4803 B1_1 10-segment linearizer output 1 of group 1 D4804 A2_1 10-segment linearizer input 2 of group 1 D4805 B2_1 10-segment linearizer output 2 of group 1...
  • Page 519: Setup Parameters (D5001 To D6500)

    10.4 UM33A D Registers 10.4.4 Setup Parameters (D5001 to D6500) Setup parameter Control function setting (Menu: CTL) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UM33A UM33A D5001 45001 1388 D5051 45051 13BA D5002 45002 1389 D5052 45052 13BB D5003 45003 138A D5053 45053 13BC D5004 45004...
  • Page 520 10.4 UM33A D Registers Setup parameter Input setting (PV input setting menu: PV) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UM33A UM33A D5101 45101 13EC D5151 45151 141E D5102 45102 13ED UNIT D5152 45152 141F D5103 45103 13EE D5153 45153 1420 D5104 45104 13EF...
  • Page 521 10.4 UM33A D Registers Setup parameter Input setting (Input range·SP limiter setting parameters menu: MPV) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UM33A UM33A P.UNI_L1 D5201 45201 1450 D5251 45251 1482 P.DP_L1 D5202 45202 1451 D5252 45252 1483 P.RH_L1 D5203 45203 1452 D5253 45253 1484 D5204...
  • Page 522 10.4 UM33A D Registers Setup parameter Output setting (Menu: OUT) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UM33A UM33A D5301 45301 14B4 D5351 45351 14E6 D5302 45302 14B5 D5352 45352 14E7 D5303 45303 14B6 D5353 45353 14E8 D5304 45304 14B7 D5354...
  • Page 523 10.4 UM33A D Registers Setup parameter Communication setting (RS-485 communication setting menu: R485) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UM33A UM33A PSL_E1 D5501 45501 157C D5551 45551 15AE BPS_E1 D5502 45502 157D D5552 45552 15AF PRI_E1 D5503 45503 157E D5553 45553 15B0 D5504...
  • Page 524 10.4 UM33A D Registers Setup parameter Communication setting (CC-Link communication setting menu: CC-L) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UM33A UM33A D5601 45601 15E0 D5651 45651 1612 D5602 45602 15E1 D5652 45652 1613 D5603 45603 15E2 D5653 45653 1614 D5604 45604 15E3 D5654...
  • Page 525 10.4 UM33A D Registers Setup parameter Key operation setting (Menu: KEY), Display function setting (Menu: DISP), SELECT Display setting (Menu: CSEL) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UM33A UM33A B.STS D5701 45701 1644 D5751 45751 1676 D5702 45702 1645 D5752 45752 1677 Fn-K D.CYC D5703 45703 1646 D5753 45753 1678 D5704...
  • Page 526 10.4 UM33A D Registers Setup parameter Lock setting (Key lock setting menu: KLOC) (Menu lock setting menu: MLOC) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UM33A UM33A DI.SL-L D5801 45801 16A8 D5851 45851 16DA D5802 45802 16A9 D5852 45852 16DB DI.D-L D5803 45803 16AA D5853 45853 16DC D5804 45804...
  • Page 527 10.4 UM33A D Registers Setup parameter DI function setting (DI function registration menu: DI.SL) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UM33A UM33A D5901 45901 170C D5951 45951 173E D5902 45902 170D D5952 45952 173F D5903 45903 170E D5953 45953 1740 D5904 45904 170F D5954...
  • Page 528 10.4 UM33A D Registers Setup parameter DI function setting (Message) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UM33A UM33A D6001 46001 1770 MSG1 D6051 46051 17A2 MSG3 D6002 46002 1771 MSG1 D6052 46052 17A3 D6003 46003 1772 MSG1...
  • Page 529 10.4 UM33A D Registers Setup parameter DI function setting (DI1-DI2 contact type setting menu: DI.D) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UM33A UM33A DI1.D D6101 46101 17D4 D6151 46151 1806 D6102 46102 17D5 DI2.D D6152 46152 1807 D6103 46103 17D6 D6153 46153 1808 D6104 46104...
  • Page 530 10.4 UM33A D Registers Setup parameter DO function setting (AL1-AL4 function registration menu: ALM) (DO setting menu (E1): DO) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UM33A UM33A D6201 46201 1838 D6251 46251 186A D6202 46202 1839 D6252 46252 186B D6203 46203 183A D6253 46253 186C D6204 46204 183B D6254...
  • Page 531 10.4 UM33A D Registers Setup parameter I/O display (Menu: I/O) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UM33A UM33A KEY-IO D6301 46301 189C D6351 46351 18CE D6302 46302 189D D6352 46352 18CF D6303 46303 189E D6353 46353 18D0 D6304 46304 189F...
  • Page 532 10.4 UM33A D Registers Setup parameter System setting (Menu: SYS) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UM33A UM33A D6401 46401 1900 D6451 46451 1932 R.TM D6402 46402 1901 D6452 46452 1933 D6403 46403 1902 D6453 46453 1934 D6404 46404 1903...
  • Page 533: Function Setting (D5001 To D5100)

    10.4 UM33A D Registers Function Setting (D5001 to D5100) Register Description Range and meaning of value D5001 to D5008 ALNO._L1 D5009 Number of alarms 1 to 8 D5010 to D5018 0: 50 (50 ms) D5019 Input sampling period (control period) 1: 100 (100 ms) 2: 200 (200 ms) D5019 to D5100...
  • Page 534 10.4 UM33A D Registers Input Setting (D5101 to D5300) Register Description Range and meaning of value 0: OFF (Disable) 1: K1 (-270.0 to 1370.0°C / -450.0 to 2500.0 F) 2: K2 (-270.0 to 1000.0°C / -450.0 to 2300.0 F) 3: K3 (-200.0 to 500.0°C / -200.0 to 1000.0 F) 4: J (-200.0 to 1200.0°C / -300.0 to 2300.0 F) 5: T1 (-270.0 to 400.0°C / -450.0 to 750.0 F) 6: T2 (0.0 to 400.0°C / -200.0 to 750.0 F)
  • Page 535 10.4 UM33A D Registers Register Description Range and meaning of value 0, 2, 3, 4: - (No unit) D5201 P.UNI_L1 Control PV input unit 1: C (Degree Celsius) 5: F (Degree Fahrenheit) 0: No decimal place 1: One decimal place D5202 P.DP_L1 Control PV input decimal point position...
  • Page 536 10.4 UM33A D Registers Communication Setting (D5501 to D5700) Register Description Range and meaning of value 0: PCL (PC link communication) 1: PCLSM (PC link communication (with checksum)) 2: LADR (Ladder communication) 3: CO-M (Coordinated master station) 4: CO-S (Coordinated slave station) D5501 PSL_E1 Protocol selection...
  • Page 537 10.4 UM33A D Registers Key Operation Setting, Display Function Setting, and SELECT Display Setting (D5701 to D5800) Register Description Range and meaning of value D5701 to D5702 0: OFF (Disable) 18: LTUP (LCD brightness UP) 19: LTDN (LCD brightness DOWN) 20: BRI (Adjust LCD brightness) D5703 User function key-n action setting...
  • Page 538 10.4 UM33A D Registers Register Description Range and meaning of value 0: Valve Position Display 18: CS1 (SELECT Display 1) 19: CS2 (SELECT Display 2) D5744 HOME Home Operation Display setting 20: CS3 (SELECT Display 3) 21: CS4 (SELECT Display 4) 22: CS5 (SELECT Display 5) 0: OFF (Disable) 1: Economy mode ON (All indications except PV display OFF)
  • Page 539 10.4 UM33A D Registers Lock Setting (Key Lock/Menu Lock) (D5801 to D5900) Register Description Range and meaning of value D5801 to D5817 0: OFF (Enable) COM.W D5818 Communication write enable/disable 1: ON (Disable) 0: OFF (Unlock) D5819 DATA-L Front panel parameter data key lock 1: ON (Lock) D5820 0: OFF (Display)
  • Page 540 10.4 UM33A D Registers DI Function Setting (D5901 to D6200) Register Description Range and meaning of value D5901 to D5918 D5919 RST-D Latch release D5920 LAT-D Set an I relay number of contact input. LCD backlight ON/OFF switch D5921 LCD-D Message display interruption 1 D5922 MG1-D...
  • Page 541: Do Function Setting (D6201 To D6300)

    10.4 UM33A D Registers Register Description Range and meaning of value D6061 MSG4 D6062 MSG4 D6063 MSG4 20-digit value of alphanumeric characters can be D6064 MSG4 set. Arrangement: D6065 MSG4 D6061, D6062, D6063, D6064, D6065, D6066, D6066 MSG4 Message-4 *2 D6067, D6068, D6069, D6070, D6071 D6067 MSG4...
  • Page 542: O Display (D6301 To D6400)

    10.4 UM33A D Registers I/O Display (D6301 to D6400)  Bit Configuration of D6301: KEY-IO*1 (Key status) Symbol Event PARA_KEY PARAMETER (PARA) key (0: OFF 1: ON) DISP_KEY DISPLAY (DISP) key (0: OFF 1: ON) RIGHT_KEY RIGHT key (0: OFF 1: ON) DOWN_KEY DOWN key (0: OFF 1: ON) SET_KEY...
  • Page 543: Input / Output Terminal Status Register (D7601 To D7700)

    10.4 UM33A D Registers 10.4.5 Input / Output Terminal Status Register (D7601 to D7700) Terminal status registers Input / output terminal status register D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UM33A UM33A D7601 47601 1DB0 D7651 47651 1DE2...
  • Page 544 10.4 UM33A D Registers  Bit Configuration of D7601: DI (DI1-DI2 terminal status: equipped as standard) Symbol Event DI1 terminal status (0: OFF 1: ON) DI2 terminal status (0: OFF 1: ON) 2 to 15  Bit Configuration of D7611: OUT_AL (AL1-AL3 terminal status: equipped as standard) Symbol Event OUT_AL1 AL1 terminal status (0: OFF 1: ON) OUT_AL2...
  • Page 545 10.5 Writing via Communication  Setting Target Setpoint In LCL (local) mode (1) Write the setpoint in the Alarm-1 setpoint to Alarm-8 setpoint. Register No. Register symbol Description D2351 A1_L1 Alarm-1 setpoint D2352 A2_L1 Alarm-2 setpoint D2353 A3_L1 Alarm-3 setpoint D2354 A4_L1 Alarm-4 setpoint...
  • Page 546: Compatibility With Green Series Controllers

    10.6 GREEN Series Compatible D Registers 10.6.1 Compatibility with GREEN Series Controllers The D register map configuration of the UTAdvanced is the same as that of the GREEN Series (UM300 Series) controllers that perform access in the 2-byte integer data format. When GREEN Series devices are replaced with the UTAdvanced, communication programs created in the GREEN Series controllers can be used by just carrying out wiring.
  • Page 547 10.6 GREEN Series Compatible D Registers  D register symbols • With regards to some D register symbols, the loop number, terminal area, and group number are indicated by adding the underline (_) to the end of the parameter symbols. If both the loop number and group number are added to the parameter symbols, they are added in the order of _loop number and _group number.
  • Page 548 10.6 GREEN Series Compatible D Registers 10.6.3 Process Data and User Area (D0001 to D0100) Configuration map for GREEN Series Process data User area Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0001 40001 0000 ADERROR AD1.E_G D0051 40051 0032 USER USER1...
  • Page 549 10.6 GREEN Series Compatible D Registers Configuration map for GREEN Series Can not be used Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0101 40101 0064 D0151 40151 0096 D0102 40102 0065 D0152 40152 0097 D0103 40103 0066...
  • Page 550: Operation-Related Parameters (D0201 To D0300)

    10.6 GREEN Series Compatible D Registers 10.6.4 Operation-related Parameters (D0201 to D0300) Configuration map for GREEN Series Operation-related parameters Register Register Register D-Reg Ref. Register symbol D-Reg Ref. H No. symbol for H No. symbol for symbol for for UTAdvanced GREEN GREEN UTAdvanced D0201 40201 00C8 D0251 40251 00FA ORH D0202 40202 00C9 D0252 40252 00FB ORL D0203 40203 00CA...
  • Page 551: Alarm Function Parameters (D0901 To D1000)

    10.6 GREEN Series Compatible D Registers 10.6.5 Alarm Function Parameters (D0901 to D1000) Configuration map for GREEN Series Alarm function parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0901 40901 0384 D0951 40951 03B6 D0902 40902 0385 D0952 40952 03B7 D0903 40903 0386...
  • Page 552: Common Function Parameters (D1001 To D1100)

    10.6 GREEN Series Compatible D Registers 10.6.6 Common Function Parameters (D1001 to D1100) Configuration map for GREEN Series Common function parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D1001 41001 03E8 D1051 41051 041A D1002 41002 03E9 D1052 41052 041B D1003 41003 03EA...
  • Page 553: Select Display Setting Parameters (D1101 To D1200)

    10.6 GREEN Series Compatible D Registers 10.6.7 SELECT Display Setting Parameters (D1101 to D1200) Configuration map for GREEN Series SELECT display setting parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D1101 41101 044C C.S1 D1151 41151 047E D1102 41102 044D C.S2 D1152 41152...
  • Page 554: Pv Input, And Communication Parameters (D1201 To D1300)

    10.6 GREEN Series Compatible D Registers 10.6.8 PV Input, and Communication Parameters (D1201 to D1300) Configuration map for GREEN Series PV input, and Communication parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D1201 41201 04B0 IN IN (D5101) R/W D1251 41251 04E2 DLN DLN_E1 (D5505) D1202 41202 04B1 UNI...
  • Page 555: Registers Converted For Green Series

    10.6 GREEN Series Compatible D Registers 10.6.9 D Registers Converted for GREEN Series  Bit Configuration of D0001: AD1.E_G (A/D converter error status for GREEN Series) Symbol Event GREEN Series UTAdvanced ADERR.st ADERR (I4065) PV input A/D converter error 1 to 15  Bit Configuration of D0002: PV1.E_L1_G (PV input error status for GREEN Series) Symbol Event GREEN Series UTAdvanced PVBO.st PVBO_L1 (I4097) PV input burnout error RJCERR.st RJCERR (I4070)
  • Page 556: Registers Differring In Content From Green Series

    10.6 GREEN Series Compatible D Registers 10.6.10 D Registers Differring in Content from GREEN Series  D0915 to D0917: Alarm-1 type to alarm-4 type UTAdvanced Register Description Range and meaning of value 0: Disable D0915 AL1.T_L1 Alarm-1 type 01: PV high limit D0916 AL2.T_L1 Alarm-2 type 02: PV low limit 29: PV velocity D0917 AL3.T_L1...
  • Page 557 Blank Page...
  • Page 558: Overview

    Chapter 11 Functions and Applications of I Relays (for UM33A) 11.1 Overview This chapter describes the functions and applications of the I relays. I relays are used in Modbus communication, PC link communication, and contact input / output functions. I relays contain status information of errors, operation, and alarms. Contents of I relays can be read only by means of communication using a host computer.
  • Page 559: Classification Of I Relays

    11.2 Classification of I Relays I relays are classified as shown below. Classification of I Relay Map Area and data I relay No. Description categories Each bit information is the same as that of 1 to 192 Status GREEN series D register.
  • Page 560 11.2 Classification of I Relays CAUTION • Check the model and suffix codes and parameter settings before writing to or read from the registers to be used. • In the area for I relay numbers 4001 to 6560, it is prohibited to write data to I relays with blank cells in I relay map tables.
  • Page 561: Um33A I Relays

    11.3 UM33A I Relays 11.3.1 Function Status (4001 to 5024) Note When specifying an I relay number for communication, begin the number with the character “I.” Example: Set “I4065” to specify the ADERR (I relay No.: 4065). 11-4 IM 05P07A01-01EN...
  • Page 562 11.3 UM33A I Relays System error Input error Free area I relay symbol I relay symbol I relay symbol 4001 SYSTEM_ERR 4065 ADERR 4129 4002 CALB_ERR 4066 4130 4003 UPARA_ERR 4067 4131 4004 4068 4132 4005 SETPA_ERR 4069 4133 4006 OPEPA_ERR 4070 RJCERR 4134 4007...
  • Page 563 11.3 UM33A I Relays FAIL alarm Free area I relay symbol I relay symbol 4193 4257 4194 4258 4195 4259 4196 4260 4197 4261 4198 4262 4199 4263 4200 4264 4201 4265 4202 4266 4203 4267 4204 4268 4205 4269 4206 4270 4207...
  • Page 564 11.3 UM33A I Relays Alarm Alarm latch Alarm latch I relay symbol I relay symbol I relay symbol 4321 ALM1_L1 4385 ALO1LA1_L1 4449 ALO1LA3_L1 4322 ALM2_L1 4386 ALO2LA1_L1 4450 ALO2LA3_L1 4323 ALM3_L1 4387 ALO3LA1_L1 4451 ALO3LA3_L1 4324 4388 4452 4325 ALM4_L1 4389 ALO4LA1_L1 4453 ALO4LA3_L1 4326 ALM5_L1...
  • Page 565 11.3 UM33A I Relays Alarm latch Free area Free area I relay symbol I relay symbol I relay symbol 4513 ALOLA_RLS 4577 4641 4514 ALM_WAIT 4578 4642 4515 4579 4643 4516 4580 4644 4517 4581 4645 4518 4582 4646 4519 4583 4647 4520...
  • Page 566 11.3 UM33A I Relays Display I relay symbol I relay symbol 4705 PARA_KEY 4769 MG1.B 4706 DISP_KEY 4770 MG2.B 4707 RIGHT_KEY 4771 MG3.B 4708 DOWN_KEY 4772 4709 SET_KEY 4773 MG4.B 4710 UP_KEY 4774 4711 LEFT_KEY 4775 4712 4776 4713 4777 4714 4778 4715...
  • Page 567: System Error, Input Error, And Operation Mode (4001 To 4320)

    11.3 UM33A I Relays System Error, Input Error, and Operation Mode (4001 to 4320) I relay No. Symbol Event SYSTEM_ERR to 4001 to 4016 Parameter error status (Same as D2068) CTLPA_ERR 4017 to 4032 E1_ERR to 4033 to 4048 Option error status (Same as D2070) COM_E1_ERR 4049 to 4064 4065 to 4080...
  • Page 568: Input / Output Status (5025 To 5472)

    11.3 UM33A I Relays 11.3.2 Input / Output Status (5025 to 5472) Note When specifying an I relay number for communication, begin the number with the character “I.” Example: Set “I5025” to specify the X_DI1 (I relay No.: 5025). 11-11 IM 05P07A01-01EN...
  • Page 569 11.3 UM33A I Relays Input (status) relay Input (status) relay I relay symbol I relay symbol X_DI1 5089 5025 X_DI2 5090 5026 5091 5027 5092 5028 5093 5029 5094 5030 5095 5031 5096 5032 5097 5033 5098 5034 5099 5035 5100 5036 5101...
  • Page 570 11.3 UM33A I Relays Output (status) relay Output (status) relay I relay symbol I relay symbol 5153 Y_AL1 5217 5154 Y_AL2 5218 5155 Y_AL3 5219 5156 5220 5157 5221 5158 5222 5159 5223 5160 5224 5161 5225 5162 5226 5163 5227 5164 5228...
  • Page 571: Input (Status) Relay And Output (Status) Relay (5025 To 5280)

    11.3 UM33A I Relays Input (Status) Relay and Output (Status) Relay (5025 to 5280) I relay No. Symbol Description 5025 to 5040 X_DI1 to X_DI2 DI1-DI2 status (Same as D7011) 5041 to 5152 5153 to 5168 Y_AL1 to Y_AL3 AL1-AL3 status (Same as D7161) Y_DO11 to 5169 to 5184 DO11-DO15 status (Same sa D7162)
  • Page 572: Special Relay (5537 To 5792)

    11.3 UM33A I Relays 11.3.3 Special Relay (5537 to 5792) Note When specifying an I relay number for communication, begin the number with the character “I.” Example: Set “I5537” to specify the DI1 (I relay No.: 5537). 11-15 IM 05P07A01-01EN...
  • Page 573 11.3 UM33A I Relays Special relay Special relay I relay symbol I relay symbol 5537 5601 5538 5602 5539 5603 5540 5604 5541 5605 5542 5606 5543 5607 5544 5608 5545 5609 5546 5610 5547 5611 5548 5612 5549 5613 5550 5614 5551...
  • Page 574 11.3 UM33A I Relays Special relay Special relay I relay symbol I relay symbol 5665 M01_B 5729 5666 M02_B 5730 5667 M03_B 5731 5668 M04_B 5732 5669 M05_B 5733 5670 M06_B 5734 5671 M07_B 5735 5672 M08_B 5736 5673 M09_B 5737 5674 M10_B...
  • Page 575 11.3 UM33A I Relays Special relay (5537 to 5792) I relay No. Symbol Description You can read/write data from/to the area via communication. (Same as D7201 to D7208) 5537 to 5552 M01 to M16 That is, you can use the area freely without affecting the control function of the UTAdvanced 5553 to 5664 You can read/write data from/to the area via communication.
  • Page 576 11.3 UM33A I Relays 11.3.4 Input / Output Terminal Status (6305 to 6560) Note When specifying an I relay number for communication, begin the number with the character “I.” Example: Set “I6305” to specify the DI1 (I relay No.: 6305). 11-19 IM 05P07A01-01EN...
  • Page 577 11.3 UM33A I Relays DI terminals DI terminals I relay symbol I relay symbol 6305 6369 6306 6370 6307 6371 6308 6372 6309 6373 6310 6374 6311 6375 6312 6376 6313 6377 6314 6378 6315 6379 6316 6380 6317 6381 6318 6382 6319...
  • Page 578 11.3 UM33A I Relays DO terminals DO terminals I relay symbol I relay symbol 6433 6497 OUT_AL1 6434 6498 OUT_AL2 6435 OUT_AL3 6499 6436 6500 6437 6501 6438 6502 6439 6503 6440 6504 6441 6505 6442 6506 6443 6507 6444 6508 6445 6509...
  • Page 579: Di Terminals And Do Terminals (6305 To 6560)

    11.3 UM33A I Relays DI Terminals and DO Terminals (6305 to 6560) I relay No. Symbol Description 6305 to 6320 DI1 to DI2 DI1-DI2 status (Same as D7601) 6321 to 6336 DI11 to DI15 DI11-DI15 status (Same as D7602) 6337 to 6432 OUT_AL1 to 6433 to 6448 AL1-AL3 status (Same as D7611)
  • Page 580: Reading Via Communication

    11.4 Reading via Communication  When reading the alarm status Read I relay numbers 4321 to 4336 for alarm-1 to alarm-8 status. I relay No. Symbol Event 4321 to 4336 ALM1_L1~ALM8_L1 Alarm-1 to alarm-8 status (Same as D2011) * • •...
  • Page 581 11.5 GREEN Series Compatible I Relays 11.5.1 Compatibility with GREEN Series Controllers The map configuration from 1 to 2048 of the I relay map is the same as that of the GREEN Series (UT300 Series) controllers. If existing programs created in the GREEN Series controllers are used, communication is performed using the area from 0001 to 0784.
  • Page 582 11.5 I Relays Corresponding to GREEN Series 11.5.3 Status (0001 to 0192) Status I relay symbol I relay symbol I relay symbol GREEN UTAdvanced GREEN UTAdvanced GREEN UTAdvanced ADERROR.st ADERR (4065) PVBO.st PVBO_L1 (4097) RJCERR.st RJCERR (4070) PV+over.st PVPOVER_L1 (4101) PV-over.st PVMOVER_L1 (4102) ALM1.st...
  • Page 583: User Area (0721 To 784)

    11.5 I Relays Corresponding to GREEN Series I relay No. Symbol Description 1 to 16 ADERR A/D converter error status for GREEN Series (Same as 0001) PVBO_L1 to PV input error status for GREEN Series 17 to 32 ATERR_L1 (Same as 0002) 33 to 48 CALB_ERR to 49 to 64...
  • Page 584: Overview

    Chapter 12 Functions and Applications of D Registers (for UT35A-L) 12.1 Overview This chapter describes the functions and applications of the D registers. D registers are used in Modbus, PC link, ladder, or Ethernet communications and are used for storing UTAdvanced parameter data, flag data, process data, and other data and values.
  • Page 585: Conventions Used In D Register Tables

    12.2 Conventions Used in D Register Tables This section describes the conventions used in the D register map tables. The numerical values arranged vertically in the leftmost column of the table represent (1) D register numbers. 5-digit numbers in the column next to it show (2) reference numbers for Modbus communication.
  • Page 586 12.3 Classification of D Registers  Classification of D Register Map Tables The table on next page outlines how the D registers are classified by their numbers in the D register map tables. When you newly perform communication with the UTAdvanced, the D registers after D2001 are used.
  • Page 587 12.3 Classification of D Registers Classification of D Registers Register No. Area and data categories Description Reference D0001 to D0049 Process data Sections 12.6.3 D0050 to D0100 User area Sections 12.6.3 D0101 to D0200 Free area Sections 12.6.3 D0201 to D0230 Operation mode parameter Sections 12.6.4 D0231 to D0300...
  • Page 588: Ut35A-L D Registers

    12.4 UT35A-L D Registers 12.4.1 Process Monitoring (D2001 to D2300) Process monitoring area Process data D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UT35A-L UT35A-L AD1.E D2001 42001 07D0 D2051 42051 0802 PV1.E_L1 D2002 42002 07D1 D2052 42052 0803 PV_L1 D2003 42003 07D2 D2053 42053 0804...
  • Page 589 12.4 UT35A-L D Registers Process monitoring area Current SP group D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UT35A-L UT35A-L SP_L1 D2101 42101 0834 D2151 42151 0866 D2102 42102 0835 D2152 42152 0867 D2103 42103 0836 D2153 42153 0868 D2104 42104 0837 A1_L1...
  • Page 590 12.4 UT35A-L D Registers Process Data Area Some of the D registers represent multiple events such as errors and status depending on combinations of bits in the register. In the following tables, if an event indicated by a specific bit occurs, the state of that bit changes to “1.”...
  • Page 591 12.4 UT35A-L D Registers  Bit Configuration of D2011: ALM_L1 (Alarm-1 to alarm-3 status) Symbol Event ALM1_L1 ‘1’ when Alarm 1 is ON; ‘0’ when OFF ALM2_L1 ‘1’ when Alarm 2 is ON; ‘0’ when OFF ALM3_L1 ‘1’ when Alarm 3 is ON; ‘0’ when OFF 3 to 15  Bit Configuration of D2037: ALO_L1 (Alarm-1 to alarm-3 output status) Symbol Event...
  • Page 592 12.4 UT35A-L D Registers (Option error status)  Bit Configuration of D2070: OP.ER Symbol Event E3_ERR Nonresponding hardware of E3 terminal area 3 to 9 COM_E3_ERR Communication error E3 terminal area 11 to 15  Bit Configuration of D2071: ALOLA1_L1 (Alarm-1 to alarm-3 latch output status) Symbol Event ALO1LA1_L1 Alarm-1 latch-1 output status ALO2LA1_L1 Alarm-2 latch-1 output status ALO3LA1_L1 Alarm-3 latch-1 output status 4 to 15...
  • Page 593: Current Sp Group (D2101 To D2200)

    12.4 UT35A-L D Registers Current SP Group (D2101 to D2200) Register Description Range and meaning of value 0.0 to 100.0% of PV input range (EU) (Setting D2101 SP_L1_1 Target setpoint range: SPL to SPH) D2102 D2103 Set a display value of setpoint of PV alarm, SP D2104 A1_L1_1 Alarm-1 setpoint...
  • Page 594 12.4 UT35A-L D Registers 12.4.2 Operation Parameter (D2501 to D4700) Operation parameter SP and alarm setpoint setting (Menu: SP) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UT35A-L UT35A-L SP_L1_1 D2501 42501 09C4 D2551 42551 09F6 D2502 42502 09C5 D2552 42552 09F7 D2503 42503 09C6 D2553 42553 09F8 A1_L1_1 D2504...
  • Page 595 12.4 UT35A-L D Registers Operation parameter SP-related setting (Menu: SPS) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UT35A-L UT35A-L 42701 0A8C 42751 0ABE D2701 D2751 42702 0A8D 42751 0ABF D2702 D2752 42703 0A8E 42751 0AC0 D2703 D2753 42704 0A8F 42751 0AC1...
  • Page 596 12.4 UT35A-L D Registers Operation parameter Alarm function setting (Menu: ALRM) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UT35A-L UT35A-L DYN3_L1 D2801 42801 0AF0 AL1.T_L1 D2851 42851 0B22 D2802 42802 0AF1 AL1.W_L1 D2852 42852 0B23 D2803 42803 0AF2 AL1.D_L1 D2853 42853 0B24...
  • Page 597 12.4 UT35A-L D Registers Operation parameter PV-related setting (Menu: PVS) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UT35A-L UT35A-L BS_L1 D2901 42901 0B54 D2951 42951 0B86 FL_L1 D2902 42902 0B55 D2952 42952 0B87 D2903 42903 0B56 D2953 42953 0B88 D2904 42904...
  • Page 598: Sp And Alarm Setpoint Setting (D2501 To D2700)

    12.4 UT35A-L D Registers SP and Alarm Setpoint Setting (D2501 to D2700) Register Description Range and meaning of value 0.0 to 100.0% of PV input range (EU) (Setting D2501 SP_L1_1 Target setpoint of group 1 range: SPL to SPH) D2502 D2503 Set a display value of setpoint of PV alarm, SP D2504 A1_L1_1 Alarm-1 setpoint of group 1...
  • Page 599: Alarm Function Setting (D2801 To D2900)

    12.4 UT35A-L D Registers Alarm Function Setting (D2801 to D2900) Register Description Range and meaning of value D2801 AL1.T_L1 Alarm-1 type AL1.T_L1 to AL3.T_L1 0: Disable 1: PV high limit D2802 AL1.W_L1 Alarm-1 stand-by action 2: PV low limit 3: SP high limit 4: SP low limit D2803 AL1.D_L1...
  • Page 600: Pv-Related Setting (D2901 To D3000)

    12.4 UT35A-L D Registers Register Description Range and meaning of value Set a display value of setpoint of hysteresis. D2841 HY1_L1 Alarm-1 hysteresis -19999 to 30000 (Set a value within the input D2842 HY2_L1 Alarm-2 hysteresis range.) D2843 HY3_L1 Alarm-3 hysteresis Decimal point position depends on the input type.
  • Page 601 12.4 UT35A-L D Registers 12.4.3 Setup Parameters (D5001 to D7000) Setup parameter Control function setting (Menu: CTL) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UT35A-L UT35A-L D5001 45001 1388 D5051 45051 13BA D5002 45002 1389 D5052 45052 13BB D5003 45003 138A D5053 45053 13BC D5004 45004...
  • Page 602 12.4 UT35A-L D Registers Setup parameter Input setting (PV input setting menu: PV) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UT35A-L UT35A-L D5101 45101 13EC D5151 45151 141E D5102 45102 13ED UNIT D5152 45152 141F D5103 45103 13EE D5153 45153 1420 D5104 45104 13EF...
  • Page 603 12.4 UT35A-L D Registers Setup parameter Input setting (Input range·SP limiter setting parameters menu: MPV) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UT35A-L UT35A-L P.UNI_L1 D5201 45201 1450 D5251 45251 1482 P.DP_L1 D5202 45202 1451 D5252 45252 1483 D5203 45203 1452 P.RH_L1 D5253 45253 1484 P.RL_L1...
  • Page 604 12.4 UT35A-L D Registers Setup parameter Output setting (Menu: OUT) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UT35A-L UT35A-L D5301 45301 14B4 D5351 45351 14E6 D5302 45302 14B5 D5352 45352 14E7 D5303 45303 14B6 D5353 45353 14E8 D5304 45304 14B7 D5354...
  • Page 605 12.4 UT35A-L D Registers Setup parameter Communication setting (RS-485 communication setting menu: R485) (Ethernet communication setting menu: ETHR) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UT35A-L UT35A-L SM4_E3 D5501 45501 157C D5551 45551 15AE DG1_E3 D5502 45502 157D D5552 45552 15AF DG2_E3 D5503 45503 157E D5553 45553 15B0 D5504...
  • Page 606 12.4 UT35A-L D Registers Setup parameter Key operation setting (Menu: KEY), Display function setting (Menu: DISP) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UT35A-L UT35A-L F1-K B.STS D5701 45701 1644 D5751 45751 1676 F2-K D5702 45702 1645 D5752 45752 1677 Fn-K D.CYC D5703 45703 1646 D5753 45753...
  • Page 607 12.4 UT35A-L D Registers Setup parameter Lock setting (Key lock setting menu: KLOC) (Menu lock setting menu: MLOC) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UT35A-L UT35A-L D5801 45801 16A8 D5851 45851 16DA DI.SL-L D5802 45802 16A9 D5852 45852 16DB D5803 45803 16AA D5853 45853 16DC D5804 45804 16AB...
  • Page 608 12.4 UT35A-L D Registers Setup parameter DI function setting (DI function registration menu: DI.SL) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UT35A-L UT35A-L D5901 45901 170C D5951 45951 173E D5902 45902 170D D5952 45952 173F D5903 45903 170E D5953 45953 1740 D5904 45904 170F D5954...
  • Page 609 12.4 UT35A-L D Registers Setup parameter DI function setting (Message) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UT35A-L UT35A-L D6001 46001 1770 MSG1 D6051 46051 17A2 MSG3 D6002 46002 1771 MSG1 D6052 46052 17A3 D6003 46003 1772 MSG1...
  • Page 610 12.4 UT35A-L D Registers Setup parameter I/O display (Menu: I/O) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UT35A-L UT35A-L KEY-IO D6301 46301 189C D6351 46351 18CE D6302 46302 189D D6352 46352 18CF D6303 46303 189E D6353 46353 18D0 D6304 46304 189F...
  • Page 611 12.4 UT35A-L D Registers Setup parameter System setting (Menu: SYS) D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UT35A-L UT35A-L D6401 46401 1900 D6451 46451 1932 D6402 46402 1901 D6452 46452 1933 R.MD D6403 46403 1902 D6453 46453 1934 D6404 46404 1903...
  • Page 612 12.4 UT35A-L D Registers Control Function Setting (D5001 to D5100) Register Description Range and meaning of value D5001 to D5020 0: LOW (Low limit control) D5021 HI.LO Limit control type 1: HIGH (High limit control) 0: KEY (By key operation) D5022 The way of confirming operation 1: DI (By DI)
  • Page 613 12.4 UT35A-L D Registers Input Setting (D5101 to D5300) Register Description Range and meaning of value 0: OFF (Disable) 1: K1 (-270.0 to 1370.0°C / -450.0 to 2500.0 F) 2: K2 (-270.0 to 1000.0°C / -450.0 to 2300.0 F) 3: K3 (-200.0 to 500.0°C / -200.0 to 1000.0 F) 4: J (-200.0 to 1200.0°C / -300.0 to 2300.0 F) 5: T1 (-270.0 to 400.0°C / -450.0 to 750.0 F) 6: T2 (0.0 to 400.0°C / -200.0 to 750.0 F)
  • Page 614: Output Setting (D5301 To D5400)

    12.4 UT35A-L D Registers Register Description Range and meaning of value 0, 2, 3, 4: - (No unit) D5201 P.UNI_L1 Control PV input unit 1: C (Degree Celsius) 5: F (Degree Fahrenheit) 0: No decimal place 1: One decimal place D5202 P.DP_L1 Control PV input decimal point position...
  • Page 615 12.4 UT35A-L D Registers Communication Setting (D5501 to D5700) Register Description Range and meaning of value D5501 ro D5520 0: PCL (PC link communication) 1: PCLSM (PC link communication (with checksum)) PSL_E3 D5521 Protocol selection 2: LADR (Ladder communication) 7: MBASC (Modbus (ASCII)) 8: MBRTU (Modbus (RTU)) 0: 600 (600 bps) 1: 1200 (1200 bps)
  • Page 616 12.4 UT35A-L D Registers Register Description Range and meaning of value DG1_E3 D5552 Default gateway 1 0 to 255 DG2_E3 D5553 Default gateway 2 DG3_E3 D5554 Default gateway 3 Address : D5550.D5551.D5552.D5553 DG4_E3 D5555 Default gateway 4 502, 1024 to 65535 D5556 PRT_E3 Port number...
  • Page 617 12.4 UT35A-L D Registers Key Operation Setting, Display Function Setting, and SELECT Display Setting (D5701 to D5800) Register Description Range and meaning of value 0: OFF (Disable) F1-K D5701 User function key-1 action setting 18: LTUP (LCD brightness UP) 19: LTDN (LCD brightness DOWN) D5702 F2-K User function key-2 action setting...
  • Page 618 12.4 UT35A-L D Registers Lock Setting (Key Lock/Menu Lock) (D5801 to D5900) Register Description Range and meaning of value D5801 to D5817 0: OFF (Enable) COM.W D5818 Communication write enable/disable 1: ON (Disable) 0: OFF (Unlock) D5819 DATA-L Front panel parameter data key lock 1: ON (Lock) D5820 to D5830 D5831...
  • Page 619 12.4 UT35A-L D Registers DI Function Setting (D5901 to D6200) Register Description Range and meaning of value D5901 to D5939 0: OFF (No function) 1: LAT (Latch release) 2: LCD (LCD backlight ON/OFF switch) 3: PVPW (PV red/white switch) D5940 DI2.S DI2 function selection 4: MG1 (Message display interruption 1)
  • Page 620 12.4 UT35A-L D Registers Register Description Range and meaning of value D6061 MSG4 D6062 MSG4 D6063 MSG4 20-digit value of alphanumeric characters can be D6064 MSG4 set. Arrangement: D6065 MSG4 D6061, D6062, D6063, D6064, D6065, D6066, Message-4 *2 D6066 MSG4 D6067, D6068, D6069, D6070, D6071 D6067 MSG4...
  • Page 621: O Display (D6301 To D6400)

    12.4 UT35A-L D Registers I/O Display (D6301 to D6400)  Bit Configuration of D6301: KEY-IO*1 (Key status) Symbol Event PARA_KEY PARAMETER (PARA) key (0: OFF 1: ON) DISP_KEY DISPLAY (DISP) key (0: OFF 1: ON) RIGHT_KEY RIGHT key (0: OFF 1: ON) DOWN_KEY DOWN key (0: OFF 1: ON) SET_KEY...
  • Page 622: System Setting (D6401 To D6500)

    12.4 UT35A-L D Registers System Setting (D6401 to D6500) Register Description Range and meaning of value D6401 to D6408 0: Limit output is ON at power on in any cases D6403 R.MD Restart mode 1: Limit output is OFF at power on when PV doesn't exceed SP 0: OFF (Works as UT35A-L in communication of device information response or broadcasting.)
  • Page 623: Input / Output Terminal Status Register (D7601 To D7700)

    12.4 UT35A-L D Registers 12.4.4 Input / Output Terminal Status Register (D7601 to D7700) Terminal status registers Input / output terminal status register D-Reg Ref. D-Reg Ref. H No. Register symbol H No. Register symbol UT35A-L UT35A-L D7601 47601 1DB0 D7651 47651 1DE2...
  • Page 624: Free Area (D7701 To D9000)

    12.4 UT35A-L D Registers  Bit Configuration of D7601: DI (DI1-DI2 terminal status: equipped as standard) Symbol Event DI1 terminal status (0: OFF 1: ON) DI2 terminal status (0: OFF 1: ON) 2 to 15  Bit Configuration of D7611: OUT_AL (AL1-AL3 terminal status: equipped as standard) Symbol Event OUT_AL1 AL1 terminal status (0: OFF 1: ON) OUT_AL2...
  • Page 625: Green Series Compatible D Registers

    12.5 GREEN Series Compatible D Registers 12.5.1 Compatibility with GREEN Series Controllers The D register map configuration of the UTAdvanced is the same as that of the GREEN Series (UT300 Series) controllers that perform access in the 2-byte integer data format. When GREEN Series devices are replaced with the UTAdvanced, communication programs created in the GREEN Series controllers can be used by just carrying out wiring.
  • Page 626 12.5 UT35A-L D Registers  D register symbols • With regards to some D register symbols, the loop number, terminal area, and group number are indicated by adding the underline (_) to the end of the parameter symbols. If both the loop number and group number are added to the parameter symbols, they are added in the order of _loop number and _group number.
  • Page 627: Process Data And User Area (D0001 To D0100)

    12.5 UT35A-L D Registers 12.5.3 Process Data and User Area (D0001 to D0100) Configuration map for GREEN Series Process data User area Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UT35A-L GREEN UT35A-L D0001 40001 0000 ADERROR AD1.E_G D0051 40051 0032 USER USER1 D0002 40002 0001 ERROR PV1.E_L1_G...
  • Page 628 12.5 UT35A-L D Registers 12.5.4 Operation Mode and Operation-related Parameters (D0201 to D0300) Configuration map for GREEN Series Operation mode / Operation-related parameters Register Register Register D-Reg Ref. Register symbol D-Reg Ref. H No. symbol for H No. symbol for symbol for for UTAdvanced GREEN GREEN UTAdvanced D0201 40201 00C8 D0251 40251 00FA D0202 40202 00C9 D0252 40252 00FB D0203 40203 00CA...
  • Page 629 12.5 UT35A-L D Registers 12.5.5 SP Parameters (D0301 to D0500) Configuration map for GREEN Series SP parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0301 40301 012C SP SP_L1 (D2501) R/W D0351 40351 015E D0302 40302 012D D0352 40352 015F D0303 40303 012E...
  • Page 630: Control Action Parameters (D0901 To D1000)

    12.5 UT35A-L D Registers 12.5.6 Control Action Parameters (D0901 to D1000) Configuration map for GREEN Series Control action parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0901 40901 0384 D0951 40951 03B6 D0902 40902 0385 D0952 40952 03B7 D0903 40903 0386...
  • Page 631 12.5 UT35A-L D Registers 12.5.7 Common Function Parameters (D1001 to D1100) Configuration map for GREEN Series Common function parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D1001 41001 03E8 D1051 41051 041A D1002 41002 03E9 D1052 41052 041B D1003 41003 03EA...
  • Page 632 12.5 UT35A-L D Registers 12.5.8 PV Input, and Limit Control Output Parameters (D1201 to D1300) Configuration map for GREEN Series PV input, and Control output parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D1201 41201 04B0 IN IN (D5101) R/W D1251 41251 04E2 DLN DLN_E3 (D5525) R/W D1202 41202 04B1 UNI UNI (D5102)
  • Page 633: Registers Converted For Green Series

    12.5 UT35A-L D Registers 12.5.9 D Registers Converted for GREEN Series  Bit Configuration of D0001: AD1.E_G (A/D converter error status for GREEN Series) Symbol Event GREEN Series UTAdvanced ADERR.st ADERR (I4065) PV input A/D converter error 1 to 15  Bit Configuration of D0002: PV1.E_L1_G (PV input error status for GREEN Series) Symbol Event GREEN Series UTAdvanced PVBO.st PVBO_L1 (I4097) PV input burnout error RJCERR.st RJCERR (I4070) PV input RJC error...
  • Page 634 12.5 UT35A-L D Registers  Bit Configuration of D0035: PA.ER_G (Parameter error status for GREEN Series) Symbol Event GREEN Series UTAdvanced CALB.E.st CALB_ERR (I4002) Calibration value error 1 to 5 SETUP.st SETPA_ERR (I4005) Setup parameter error PARA.E.st OPEPA_ERR (I4006) Operation parameter error 9 to 11 EEP.E.st FRAM_ERR (I4009) Faulty FRAM SYSTEM.E.st SYSTEM_ERR (I4001) System data error  D0231: A1_G (Alarm-1 setpoint for GREEN Series)
  • Page 635: Registers Differring In Content From Green Series

    12.5 UT35A-L D Registers 12.5.10 D Registers Differring in Content from GREEN Series  D0915 to D0917: Alarm-1 type to alarm-3 type UTAdvanced Register Description Range and meaning of value 0: Disable D0915 AL1.T_L1 Alarm-1 type 01: PV high limit 02: PV low limit 05: Deviation high limit 06: Deviation low limit D0916 AL2.T_L1...
  • Page 636: Overview

    Chapter 13 Functions and Applications of I Relays (for UT35A-L) 13.1 Overview This chapter describes the functions and applications of the I relays. I relays are used in Modbus communication, PC link communication, and contact input / output functions. I relays contain status information of errors, operation, and alarms. Contents of I relays can be read only by means of communication using a host computer.
  • Page 637 13.2 Classification of I Relays I relays are classified as shown below. Classification of I Relay Map Area and data I relay No. Description categories Each bit information is the same as that of 1 to 192 Status GREEN series D register.
  • Page 638 13.2 Classification of I Relays CAUTION • Check the model and suffix codes and parameter settings before writing to or read from the registers to be used. • In the area for I relay numbers 4001 to 6560, it is prohibited to write data to I relays with blank cells in I relay map tables.
  • Page 639 13.3 UT35A-L I Relays 13.3.1 Function Status (4001 to 5024) Note When specifying an I relay number for communication, begin the number with the character “I.” Example: Set “I4065” to specify the ADERR (I relay No.: 4065). 13-4 IM 05P07A01-01EN...
  • Page 640 13.3 UT35A-L I Relays System error Input error I relay symbol I relay symbol UT35A-L UT35A-L 4001 SYSTEM_ERR 4065 ADERR 4002 CALB_ERR 4066 4003 UPARA_ERR 4067 4068 4004 4005 SETPA_ERR 4069 4006 OPEPA_ERR 4070 RJCERR 4071 4007 4072 4008 4009 FRAM_ERR 4073 ADBO 4074 4010...
  • Page 641 13.3 UT35A-L I Relays Operation mode Operation mode Operation mode I relay symbol I relay symbol I relay symbol UT35A-L UT35A-L UT35A-L 4129 4193 4257 4130 4194 4258 4131 4195 4259 4132 4196 4260 4133 4197 4261 4134 4198 4262 4135 4199 4263...
  • Page 642 13.3 UT35A-L I Relays Alarm Alarm latch Alarm latch I relay symbol I relay symbol I relay symbol UT35A-L UT35A-L UT35A-L 4321 ALM1_L1 4385 ALO1LA1_L1 4449 ALO1LA3_L1 4322 ALM2_L1 4386 ALO2LA1_L1 4450 ALO2LA3_L1 4323 ALM3_L1 4387 ALO3LA1_L1 4451 ALO3LA3_L1 4324 4388 4452 4325...
  • Page 643 13.3 UT35A-L I Relays Alarm latch and Heater break alarm SP number and PID number Pattern number and Segment number I relay symbol I relay symbol I relay symbol UT35A-L UT35A-L UT35A-L 4513 ALOLA_RLS 4577 4641 4514 ALM_WAIT 4578 4642 4515 4579 4643 4516 4580 4644 4517 4581 4645 4518 4582...
  • Page 644 13.3 UT35A-L I Relays Display, PV event status I relay symbol I relay symbol UT35A-L UT35A-L 4705 PARA_KEY 4769 MG1.B 4706 DISP_KEY 4770 MG2.B 4707 RIGHT_KEY 4771 MG3.B 4708 DOWN_KEY 4772 4709 SET_KEY 4773 MG4.B 4710 UP_KEY 4774 4711 LEFT_KEY 4775 4712 F2_KEY 4776 4713 F1_KEY...
  • Page 645: System Error, Input Error, And Operation Mode (4001 To 4320)

    13.3 UT35A-L I Relays System Error, Input Error, and Operation Mode (4001 to 4320) I relay No. Symbol Event SYSTEM_ERR to 4001 to 4016 Parameter error status (Same as D2068) CTLPA_ERR 4017 to 4032 E3_ERR to 4033 to 4048 Option error status (Same as D2070) COM_E3_ERR 4049 to 4064 ADERR to ADBO...
  • Page 646 13.3 UT35A-L I Relays 13.3.2 Status for Input/Output Relay Note When specifying an I relay number for communication, begin the number with the character “I.” Example: Set “I5025” to specify the X_DI1 (I relay No.: 5025). 13-11 IM 05P07A01-01EN...
  • Page 647 13.3 UT35A-L I Relays Input (status) relay Input (status) relay I relay symbol I relay symbol UT35A-L UT35A-L X_DI1 5089 5025 X_DI2 5090 5026 5091 5027 5092 5028 5093 5029 5094 5030 5095 5031 5096 5032 5097 5033 5098 5034 5099 5035 5100...
  • Page 648 13.3 UT35A-L I Relays Output (status) relay Output (status) relay I relay symbol I relay symbol UT35A/UT32A UT35A/UT32A 5153 Y_AL1 5217 5154 Y_AL2 5218 5155 Y_AL3 5219 5156 5220 5157 5221 5158 5222 5159 5223 5160 5224 5161 5225 5162 5226 5163 5227...
  • Page 649: Input (Status) Relay And Output (Status) Relay (5025 To 5280)

    13.3 UT35A-L I Relays Input (Status) Relay and Output (Status) Relay (5025 to 5280) I relay No. Symbol Description 5025 to 5040 X_DI1 to X_DI2 DI1-DI2 status (Same as D7011) 5041 to 5056 5057 to 5072 5073 to 5088 5089 to 5104 5105 to 5152 5153 to 5168 Y_AL1 to Y_AL3...
  • Page 650 13.3 UT35A-L I Relays 13.3.3 Input / Output Terminal Status (6305 to 6560) Note When specifying an I relay number for communication, begin the number with the character “I.” Example: Set “I6305” to specify the DI1 (I relay No.: 6305). 13-15 IM 05P07A01-01EN...
  • Page 651 13.3 UT35A-L I Relays DI terminals DI terminals I relay symbol I relay symbol UT35A-L UT35A-L 6305 6369 6306 6370 6307 6371 6308 6372 6309 6373 6310 6374 6311 6375 6312 6376 6313 6377 6314 6378 6315 6379 6316 6380 6317 6381 6318...
  • Page 652 13.3 UT35A-L I Relays DO terminals DO terminals I relay symbol I relay symbol UT35A-L UT35A-L OUT_AL1 6433 6497 OUT_AL2 6434 6498 OUT_AL3 6435 6499 6436 6500 6437 6501 6438 6502 6439 6503 6440 6504 6441 6505 6442 6506 6443 6507 6444 6508...
  • Page 653: Di Terminals And Do Terminals (6305 To 6560)

    13.3 UT35A-L I Relays DI Terminals and DO Terminals (6305 to 6560) I relay No. Symbol Description 6305 to 6320 DI1 to DI2 DI1-DI2 status (Same as D7601) 6321 to 6336 6337 to 6352 6353 to 6368 6369 to 6384 6385 to 6432 OUT_AL1 to 6433 to 6448...
  • Page 654: Reading Via Communication

    13.4 Reading via Communication  When reading the alarm status Read I relay numbers 4321 to 4336 for alarm-1 to alarm-3 status. I relay No. Symbol Event 4321 to 4336 ALM1_L1~ALM3_L1 Alarm-1 to alarm-3 status (Same as D2011) * • •...
  • Page 655: Compatibility With Green Series Controllers

    13.5 GREEN Series Compatible I Relays 13.5.1 Compatibility with GREEN Series Controllers The map configuration from 1 to 2048 of the I relay map is the same as that of the GREEN Series (UT300 Series) controllers. If existing programs created in the GREEN Series controllers are used, communication is performed using the area from 0001 to 0784.
  • Page 656: Status (0001 To 0192)

    13.5 GREEN Series Compatible I Relays 13.5.3 Status (0001 to 0192) Status I relay symbol I relay symbol I relay symbol GREEN UTAdvanced GREEN UTAdvanced GREEN UTAdvanced ADERROR ADERR (4065) EXD (4205) OUT (4206) PVBO PVBO_L1 (4097) RJCERR RJCERR (4070) PV+over PVPOVER_L1 (4101) PV-over...
  • Page 657 13.5 GREEN Series Compatible I Relays I relay No. Symbol Description 1 to 16 ADERR A/D converter error status for GREEN Series (Same as 0001) PVBO_L1 to PV input error status for GREEN Series 17 to 32 ATERR_L1 (Same as 0002) 33 to 48 CALB_ERR to 49 to 64...
  • Page 658: Overview

    Chapter 14 Functions and Applications of D Registers (for UT75A) 14.1 Overview This chapter describes the functions and applications of the D registers. D registers are used in Modbus, PC link, ladder, Ethernet communications, or Open Network communication (network profile creating function of LL50A) and are used for storing UTAdvanced parameter data, flag data, process data, and other data and values.
  • Page 659 14.2 Conventions Used in D Register Tables This section describes the conventions used in the D register map tables. The numerical values arranged vertically in the leftmost column of the table represent (1) D register numbers. 5-digit numbers in the column next to it show (2) reference numbers for Modbus communication.
  • Page 660 14.3 Classification of D Registers  Classification of D Register Map Tables The table on next page outlines how the D registers are classified by their numbers in the D register map tables. When you newly perform communication with the UTAdvanced, the D registers after D2001 are used.
  • Page 661 14.3 Classification of D Registers Classification of D Registers Register No. Area and data categories Description Reference D0001 to D0049 Process data Sections 14.6.3 D0050 to D0100 User area Sections 14.6.3 D0101 to D0200 Free area D0201 to D0230 Operation mode parameter Sections 14.6.4 D0231 to D0300 Operation-related parameter...
  • Page 662 14.3 Classification of D Registers Note 1: Data in the process values, operation parameters, and setup parameters is stored in the format (data excluding the decimal point of PV input range, PV input range span, %, or ABS) described in “Lists of Operation Parameters” and “Lists of Setup Parameters” in the UTAdvanced Operation Guide or User’s Manual.
  • Page 663: Process Monitoring (D2001 To D2200)

    14.4 UT75A D Registers 14.4.1 Process Monitoring (D2001 to D2200) Process monitoring area Process data D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A AD1.E D2001 42001 07D0 D2051 42051 0802 PV1.E_L1 D2002 42002 07D1 D2052 42052 0803 PV_L1 D2003 42003 07D2 D2053 42053 0804...
  • Page 664 14.4 UT75A D Registers Process monitoring area Current SP group and PID group D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A SP_L1_* SP_L2_* D2101 42101 0834 D2151 42151 0866 SUB_* D2102 42102 0835 D2152 42152 0867 PIDN_L1_* PIDN_L2_* D2103 42103 0836 D2153 42153 0868...
  • Page 665 14.4 UT75A D Registers The group number to be displayed varies depending on the currently used SP number selection (D2312) and PID number (D2009, D2025). 1 to 20 is written in D2101 to D2112 and D2151 to D2163. 1 to 16, or R (currently used group number) is written in D2114 to D2135 and D2164 to D2185.
  • Page 666: Process Data Area

    14.4 UT75A D Registers Process Data Area Some of the D registers represent multiple events such as errors and status depending on combinations of bits in the register. In the following tables, if an event indicated by a specific bit occurs, the state of that bit changes to “1.”...
  • Page 667 14.4 UT75A D Registers  Bit Configuration of D2008: MOD_L1 (Loop-1 operation mode status) Symbol Event A.M_L1 0: AUTO, 1: MAN R.L_L1 0: Local, 1: Remote S.R_L1 0: Run, 1: Stop CAS_ON 1: CAS AUTO_ON 1: AUTO *2 MAN_ON 1: MAN TRK_ON_L1 1: Output tracking 10 to 13 AT_L1_ON 0: Auto-tuning is OFF, 1: Auto-tuning is ON *1: Effective for the control modes except for cascade control and cascade secondary-loop control.
  • Page 668 14.4 UT75A D Registers LA.ER (Ladder error status)  Bit Configuration of D2012: Symbol Event LAD_ERR Corrupted ladder program LAD_OVER Ladder calculation overflow LAD_P_ERR Ladder program error LD100_OVER Load factor over 100% LD200_OVER Load factor over 200% (Forced end) 6 to 15  Bit Configuration of D2013: ALM_L2 (Loop-2 alarm-1 to alarm-8 status) Symbol Event ALM1_L2 ‘1’...
  • Page 669 14.4 UT75A D Registers  Bit Configuration of D2025: PID_L2 (Current PID number for Loop 2 ) Symbol Event PIDN.B0_L2 Loop-2 bit-0 of the PID number PIDN.B1_L2 Loop-2 bit-1 of the PID number PIDN.B2_L2 Loop-2 bit-2 of the PID number PIDN.B3_L2 Loop-2 bit-3 of the PID number PIDN.B4_L2 Loop-2 bit-4 of the PID number 5 to 15 ...
  • Page 670 14.4 UT75A D Registers  Bit Configuration of D2038: ALO_L2 (Loop-2 alarm-1 to alarm-8 output status) Symbol Event Output status where Loop-2 alarm output 1 is assighed. 0: When the alarm is turned off (alarm type: energized), or the alarm is turned on (alarm type: de-energized). (The ALO1_L2 relay contact is open.) 1: When the alarm is turned on (alarm type: energized), or the alarm is turned off (alarm type: de-energized).
  • Page 671 14.4 UT75A D Registers  Bit Configuration of D2068: PA.ER (Parameter error status) Symbol Event SYSTEM_ERR System data error CALB_ERR Calibration value error UPARA_ERR User (parameter) default value error SETPA_ERR Setup parameter error OPEPA_ERR Operation parameter error FRAM_ERR Faulty FRAM CTLPA_ERR Control parameter error 11 to 15 (Option error status)  Bit Configuration of D2070: OP.ER Symbol Event...
  • Page 672 14.4 UT75A D Registers  Bit Configuration of D2073: ALOLA2_L1 (Loop-1 alarm-1 to alarm-8 latch-2 output status) Symbol Event ALO1LA2_L1 Alarm-1 latch-2 output status ALO2LA2_L1 Alarm-2 latch-2 output status ALO3LA2_L1 Alarm-3 latch-2 output status ALO4LA2_L1 Alarm-4 latch-2 output status ALO5LA2_L1 Alarm-5 latch-2 output status ALO6LA2_L1 Alarm-6 latch-2 output status ALO7LA2_L1 Alarm-7 latch-2 output status ALO8LA2_L1 Alarm-8 latch-2 output status...
  • Page 673 14.4 UT75A D Registers  Bit Configuration of D2076: ALOLA3_L2 (Loop-2 alarm-1 to alarm-8 latch-3 output status) Symbol Event ALO1LA3_L2 Alarm-1 latch-3 output status ALO2LA3_L2 Alarm-2 latch-3 output status ALO3LA3_L2 Alarm-3 latch-3 output status ALO4LA3_L2 Alarm-4 latch-3 output status ALO5LA3_L2 Alarm-5 latch-3 output status ALO6LA3_L2 Alarm-6 latch-3 output status ALO7LA3_L2 Alarm-7 latch-3 output status ALO8LA3_L2 Alarm-8 latch-3 output status...
  • Page 674 14.4 UT75A D Registers Current SP Group and PID Group (D2101 to D2200) Register Description Range and meaning of value 0.0 to 100.0% of PV input range (EU) (Setting D2101 SP_L1_* Loop-1 target setpoint range: SPL to SPH) Loop-1 sub-target setpoint (in Two- Set the offset from SP. D2102 SUB_* position two-level control)
  • Page 675 14.4 UT75A D Registers Register Description Range and meaning of value D2130 OLc_L1_* Cooling-side control output low limit 0.0 to 104.9%, (OLc<OHc) Cooling-side ON/OFF control D2131 HYSc_L1_* 0.0 to 100.0% hysteresis Output dead band (in Heating/cooling In Heating/cooling control: -100.0 to 50.0% D2132 DB_L1_* control or Position proportional control)
  • Page 676 14.4 UT75A D Registers 14.4.2 Loop-1 / Loop-2 Operation Mode Parameter (D2301 to D2500) Operation mode parameters Loop-1 / Loop-2 operation mode (Menu: MODE) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A A.M_L1 D2301 42301 08FC D2351 42351 092E A.M_L2 D2302 42302 08FD D2352 42352 092F C.A.M D2303 42303 08FE D2353 42353...
  • Page 677: Loop-1 / Loop-2 Operation Mode (D2301 To D2400)

    14.4 UT75A D Registers Loop-1 / Loop-2 Operation Mode (D2301 to D2400) Register Description Range and meaning of value 0: AUTO (Automatic mode) 1: MAN (Manual mode) D2301 A.M_L1 Loop-1 AUTO/MAN switch Effective for the control modes except for cascade control and cascade secondary-loop control.
  • Page 678 14.4 UT75A D Registers 14.4.3 Loop-1 Operation Parameter (D2501 to D3600) Loop-1 operation parameter SP and alarm setpoint setting (Menu: SP) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A SP_L1_1 A8_L1_3 D2501 42501 09C4 D2551 42551 09F6 SUB_1 UPR_L1_3 D2502 42502 09C5 D2552 42552 09F7 PIDN_L1_1 UPR_L1_3 D2503 42503...
  • Page 679 14.4 UT75A D Registers Loop-1 operation parameter SP and alarm setpoint setting (Menu: SP) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A SP_L1_6 A8_L1_8 D2601 42601 0A28 D2651 42651 0A5A SUB_6 UPR_L1_8 D2602 42602 0A29 D2652 42652 0A5B PIDN_L1_6 DNR_L1_8 D2603 42603 0A2A...
  • Page 680 14.4 UT75A D Registers Loop-1 operation parameter SP-related setting (Menu: SPS) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A RMS_L1 D2701 42701 0A8C D2751 42751 0ABE RFL_L1 D2702 42702 0A8D D2752 42752 0ABF RT_L1 D2703 42703 0A8E D2753 42753 0AC0...
  • Page 681 14.4 UT75A D Registers Loop-1 operation parameter Alarm function setting (Menu: ALRM) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D2801 42801 0AF0 D2851 42851 0B22 DYN3_L1 AL1.T_L1 D2802 42802 0AF1 D2852 42852 0B23 DYN4_L1 AL1.W_L1 D2803 42803 0AF2 D2853 42853...
  • Page 682 14.4 UT75A D Registers Loop-1 operation parameter PV-related setting (Menu: PVS) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A BS_L1 D2901 42901 0B54 D2951 42951 0B86 FL_L1 D2902 42902 0B55 D2952 42952 0B87 D2903 42903 0B56 D2953 42953 0B88 D2904...
  • Page 683 14.4 UT75A D Registers Loop-1 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A P_L1_1 P_L1_2 D3001 43001 0BB8 D3051 43051 0BEA I_L1_1 I_L1_2 D3002 43002 0BB9 D3052 43052 0BEB D_L1_1 D_L1_2 D3003 43003 0BBA...
  • Page 684 14.4 UT75A D Registers Loop-1 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A P_L1_3 P_L1_4 D3101 43101 0C1C D3151 43151 0C4E D3102 43102 0C1D I_L1_3 D3152 43152 0C4F I_L1_4 D3103 43103 0C1E D_L1_3 D3153...
  • Page 685 14.4 UT75A D Registers Loop-1 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D3201 43201 0C80 P_L1_5 D3251 43251 0CB2 P_L1_6 I_L1_5 I_L1_6 D3202 43202 0C81 D3252 43252 0CB3 D3203 43203 0C82 D_L1_5 D3253...
  • Page 686 14.4 UT75A D Registers Loop-1 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D3301 43301 0CE4 P_L1_7 D3351 43351 0D16 P_L1_8 D3302 43302 0CE5 I_L1_7 D3352 43352 0D17 I_L1_8 D3303 43303 0CE6 D_L1_7 D3353...
  • Page 687 14.4 UT75A D Registers Loop-1 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D3401 43401 0D48 P_L1_R D3451 43451 0D7A D3402 43402 0D49 I_L1_R D3452 43452 0D7B D3403 43403 0D4A D_L1_R D3453 43453 0D7C...
  • Page 688 14.4 UT75A D Registers Loop-1 operation parameter Control action-related setting (Tuning menu: TUNE) (Zone control menu: ZONE) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D3501 43501 0DAC SC_L1 D3551 43551 0DDE RP1_L1 D3502 43502 0DAD D3552 43552 0DDF RP2_L1 AT.TY_L1 RP3_L1 D3503 43503 0DAE D3553...
  • Page 689 14.4 UT75A D Registers Loop-1 SP and Alarm Setpoint Setting of Groups 1 to 8 (D2501 to D2700) Register Description Range and meaning of value 0.0 to 100.0% of PV input range (EU) (Setting D2501 SP_L1_1 Target setpoint of group 1 range: SPL to SPH) Sub-target setpoint (in Two-position Set the offset from SP. D2502 SUB_1 two-level control) of group 1...
  • Page 690 14.4 UT75A D Registers Loop-1 SP-related Setting (D2701 to D2800) Register Description Range and meaning of value 0: RSP (Via remote (aux. analog) input) 1: COM (Via communication) RSP is not displayed if the remote (auxiliary analog) input is not specified. D2701 RMS_L1 Remote input method COM is not displayed if the communication function is not specified.
  • Page 691: Loop-1 Alarm Function Setting (D2801 To D2900)

    14.4 UT75A D Registers Loop-1 Alarm Function Setting (D2801 to D2900) Register Description Range and meaning of value AL1.T_L1 to AL8.T_L1 D2801 AL1.T_L1 Alarm-1 type 0: Disable D2802 AL1.W_L1 Alarm-1 stand-by action 1: PV high limit D2803 AL1.D_L1 Alarm-1 energized/de-energized 2: PV low limit 3: SP high limit D2804 AL1.L_L1...
  • Page 692 14.4 UT75A D Registers Register Description Range and meaning of value VT1_L1 D2833 PV velocity alarm time setpoint 1 D2834 VT2_L1 PV velocity alarm time setpoint 2 D2835 VT3_L1 PV velocity alarm time setpoint 3 D2836 VT4_L1 PV velocity alarm time setpoint 4 1 to 5999 (second) D2837 VT5_L1...
  • Page 693: Loop-1 Pid Setting Of Groups 1 To 8 And R (D3001 To D3500)

    14.4 UT75A D Registers Loop-1 PID Setting of Groups 1 to 8 and R (D3001 to D3500) Register Description Range and meaning of value 0.0 to 999.9% Proportional band of group 1 When 0.0% is set, it operates as 0.1%. D3001 P_L1_1 Heating-side proportional band (in Heating-side ON/OFF control applies when 0.0% in Heating/cooling control) of group 1 Heating/cooling control Integral time of group 1...
  • Page 694 14.4 UT75A D Registers Register Description Range and meaning of value Proportional band of group 2 D3051 to Heating-side proportional band (in P_L1_2 to POc_L1_2 Same as D3001 to D3022 D3072 Heating/cooling control) of group 2 to Cooling-side preset output of group 2 D3073 to D3100 Proportional band of group 3 D3101 to...
  • Page 695 14.4 UT75A D Registers Loop-1 Control Action-related Setting (D3501 to D3600) Register Description Range and meaning of value 0: OFF (Disable) 1: Overshoot suppressing function (normal mode) 2: Hunting suppressing function (stable mode) Enables to answer the wider characteristic changes compared with response mode. 3: Hunting suppressing function (response mode) Enables quick follow-up and short converging time of PV for the changed SP.
  • Page 696 14.4 UT75A D Registers Register Description Range and meaning of value D3551 RP1_L1 Reference point 1 Set reference points at which switching is carried D3552 RP2_L1 Reference point 2 out between groups D3553 RP3_L1 Reference point 3 of PID constants according to the given temperature D3554 RP4_L1 Reference point 4...
  • Page 697 14.4 UT75A D Registers 14.4.4 Loop-2 Operation Parameter/Custom Display Register (D3601 to D4700) Loop-2 operation parameter SP and alarm setpoint setting (Menu: SP) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A SP_L2_1 A8_L2_3 D3601 43601 0E10 D3651 43651 0E42 UPR_L2_3 D3602 43602 0E11 D3652 43652 0E43 PIDN_L2_1 DNR_L2_3 D3603 43603...
  • Page 698 14.4 UT75A D Registers Loop-2 operation parameter SP and alarm setpoint setting (Menu: SP) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D3701 43701 0E74 SP_L2_6 D3751 43751 0EA6 A8_L2_8 D3702 43702 0E75 D3752 43752 0EA7 UPR_L2_8 PIDN_L2_6 DNR_L2_8 D3703 43703 0E76 D3753...
  • Page 699 14.4 UT75A D Registers Loop-2 operation parameter SP-related setting (Menu: SPS) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D3801 43801 0ED8 RMS_L2 D3851 43851 RFL_L2 D3802 43802 0ED9 D3852 43852 D3803 43803 0EDA RT_L2 D3853 43853 RBS_L2 D3804 43804...
  • Page 700 14.4 UT75A D Registers Loop-2 operation parameter Alarm function setting (Menu: ALRM) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D3901 43901 0F3C AL1.T_L2 D3951 43951 0F6E DYN3_L2 D3902 43902 0F3D AL1.W_L2 D3952 43952 0F6F DYN4_L2 DYN5_L2 D3903 43903 0F3E AL1.D_L2...
  • Page 701 14.4 UT75A D Registers Loop-2 operation parameter PV-related setting (Menu: PVS) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A BS_L2 D4001 44001 0FA0 D4051 44051 0FD2 FL_L2 D4002 44002 0FA1 D4052 44052 0FD3 D4003 44003 0FA2 D4053 44053 0FD4 D4004...
  • Page 702 14.4 UT75A D Registers Loop-2 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D4101 44101 1004 P_L2_1 D4151 44151 1036 P_L2_2 D4102 44102 1005 I_L2_1 D4152 44152 1037 I_L2_2 D_L2_1 D_L2_2 D4103 44103 1006...
  • Page 703 14.4 UT75A D Registers Loop-2 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D4201 44201 1068 P_L2_3 D4251 44251 109A P_L2_4 I_L2_3 I_L2_4 D4202 44202 1069 D4252 44252 109B D4203 44203 106A D_L2_3 D4253...
  • Page 704 14.4 UT75A D Registers Loop-2 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D4301 44301 10CC P_L2_5 D4351 44351 10FE P_L2_6 D4302 44302 10CD I_L2_5 D4352 44352 10FF I_L2_6 D_L2_5 D_L2_6 D4303 44303 10CE...
  • Page 705 14.4 UT75A D Registers Loop-2 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A P_L2_7 P_L2_8 D4401 44401 1130 D4451 44451 1162 I_L2_7 I_L2_8 D4402 44402 1131 D4452 44452 1163 D_L2_7 D_L2_8 D4403 44403 1132...
  • Page 706 14.4 UT75A D Registers Loop-2 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A P_L2_R D4501 44501 1194 D4551 44551 11C6 I_L2_R D4502 44502 1195 D4552 44552 11C7 D_L2_R D4503 44503 1196 D4553 44553 11C8...
  • Page 707 14.4 UT75A D Registers Loop-2 operation parameter Control action-related setting (Tuning menu: TUNE) (Zone control menu: ZONE) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A SC_L2 D4601 44601 11F8 D4651 44651 122A D4602 44602 11F9 D4652 44652 122B AT.TY_L2 RP1_L2 D4603 44603 11FA D4653 44653 122C...
  • Page 708: Loop-2 Sp And Alarm Setpoint Setting Of Groups 1 To 8 (D3601 To D3800)

    14.4 UT75A D Registers Loop-2 SP and Alarm Setpoint Setting of Groups 1 to 8 (D3601 to D3800) Register Description Range and meaning of value 0.0 to 100.0% of PV input range (EU) (Setting D3601 SP_L2_1 Target setpoint of group 1 range: SPL to SPH) D3602 Set a PID group number to use. D3603 PIDN_L2_1 PID number selection of group 1...
  • Page 709 14.4 UT75A D Registers Loop-2 SP-related Setting (D3801 to D3900) Register Description Range and meaning of value 0: RSP (Via remote (aux. analog) input) 1: COM (Via communication) RSP is not displayed if the remote (auxiliary analog) input is not specified. D3801 RMS_L2 Remote input method COM is not displayed if the communication function is not specified.
  • Page 710 14.4 UT75A D Registers Loop-2 Alarm Function Setting (D3901 to D4000) Register Description Range and meaning of value AL1.T_L1 to AL8.T_L1 D3901 AL1.T_L2 Alarm-1 type 00: Disable D3902 AL1.W_L2 Alarm-1 stand-by action 01: PV high limit 02: PV low limit D3903 AL1.D_L2 Alarm-1 energized/de-energized 03: SP high limit D3904...
  • Page 711: Loop-2 Pv-Related Setting (D4001 To D4100)

    14.4 UT75A D Registers Register Description Range and meaning of value D3941 HY1_L2 Alarm-1 hysteresis D3942 HY2_L2 Alarm-2 hysteresis HY3_L2 D3943 Alarm-3 hysteresis Set a display value of setpoint of hysteresis. D3944 HY4_L2 Alarm-4 hysteresis -19999 to 30000 (Set a value within the input range.) D3945 HY5_L2...
  • Page 712 14.4 UT75A D Registers Loop-2 PID Setting of Groups 1 to 8 and R (D4101 to D4600) Register Description Range and meaning of value 0.0 to 999.9% Proportional band of group 1 When 0.0% is set, it operates as 0.1%. D4101 P_L2_1 Heating-side proportional band (in Heating-side ON/OFF control applies when 0.0% in Heating/cooling control) of group 1 Heating/cooling control Integral time of group 1...
  • Page 713 14.4 UT75A D Registers Register Description Range and meaning of value Proportional band of group 2 D4151 to Heating-side proportional band (in P_L2_2 to POc_L2_2 Same as D4101 to D4122 D4172 Heating/cooling control) of group 2 to Cooling-side preset output of group 2 D4173 to D4200 Proportional band of group 3 D4201 to...
  • Page 714: Loop-2 Control Action-Related Setting (D4601 To D4690)

    14.4 UT75A D Registers Loop-2 Control Action-related Setting (D4601 to D4690) Register Description Range and meaning of value 0: OFF (Disable) 1: Overshoot suppressing function (normal mode) 2: Hunting suppressing function (stable mode) Enables to answer the wider characteristic changes compared with response mode. 3: Hunting suppressing function (response mode) Enables quick follow-up and short converging time of PV for the changed SP.
  • Page 715 14.4 UT75A D Registers 14.4.5 P Parameter (D4701 to D4800) P parameter P parameter (Menu: PPAR) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D4701 44701 125C P01D D4751 44751 128E P02D D4702 44702 125D D4752 44752 128F D4703 44703 125E P03D D4753 44753 1290...
  • Page 716: Parameter (D4701 To D4770)

    14.4 UT75A D Registers P parameter (D4701 to D4770) Register Description Range and meaning of value P01D D4701 P01 decimal point position P02D D4702 P02 decimal point position P03D D4703 P03 decimal point position 0: No decimal place P04D D4704 P04 decimal point position 1: One decimal place P05D D4705...
  • Page 717 14.4 UT75A D Registers P parameter (D4771 to D4800) Register Description Range and meaning of value D4771 P21 parameter D4772 P22 parameter D4773 P23 parameter D4774 P24 parameter D4775 P25 parameter -19999 to 30000 (Set a decimal point position using LL50A Parameter Setting Software.) D4776 P26 parameter D4777...
  • Page 718 14.4 UT75A D Registers 14.4.6 10-segment Linearizer Setting Parameter (D4801 to D5000) 10-segment linearizer setting parameter 10-segment inearizer setting (Menu: PYS1, PYS2, PYS3) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A PYS_1 B10_2 D4801 44801 12C0 D4851 44851 12F2 A1_1 A11_2 D4802 44802 12C1 D4852 44852 12F3 B1_1 B11_2 D4803 44803 12C2...
  • Page 719 14.4 UT75A D Registers 10-segment linearizer setting parameter 10-segment linearizer setting (Menu: PYS4) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A PYS_4 D4901 44901 1324 D4951 44951 1356 D4902 44902 1325 A1_4 D4952 44952 1357 B1_4 D4903 44903 1326 D4953 44953 1358 D4904 44904...
  • Page 720: Segment Linearizer Setting (D4801 To D5000)

    14.4 UT75A D Registers 10-segment Linearizer Setting (D4801 to D5000) Register Description Range and meaning of value 0: OFF (Disable) 1: PV (PV analog input) 2: PV2 (PV2 analog input) 3: AIN2 (AIN2 analog input) 4: AIN4 (AIN4 analog input) 5: PVIN (PV input) 6: OUT (OUT analog output) 10-segment linearizer selection of 7: OUT2 (OUT2 analog output) D4801...
  • Page 721: Setup Parameters (D5001 To D7000)

    14.4 UT75A D Registers 14.4.7 Setup Parameters (D5001 to D7000) Setup parameter Control function setting (Menu: CTL) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A CTLM D5001 45001 1388 D5051 45051 13BA D5002 45002 1389 D5052 45052 13BB D5003 45003 138A CNT_L1 D5053 45053 13BC...
  • Page 722 14.4 UT75A D Registers Setup parameter Input setting (PV input setting menu: PV) (PV2 input setting menu: PV2) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D5101 45101 13EC D5151 45151 141E D5102 45102 13ED UNIT D5152 45152 141F A.BS_E2 D5103 45103 13EE D5153 45153 1420 A.FL_E2 A.SR_E2...
  • Page 723 14.4 UT75A D Registers Setup parameter Input setting (Input range·SP limiter/input switch/input auto-selector setting parameters menu: MPV) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A P.UNI_L1 D5201 45201 1450 D5251 45251 1482 P.DP_L1 D5202 45202 1451 D5252 45252 1483 P.RH_L1 D5203 45203 1452 D5253 45253 1484 D5204...
  • Page 724 14.4 UT75A D Registers Setup parameter Output setting (Menu: OUT) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A OT.H MAN.T D5301 45301 14B4 D5351 45351 14E6 OT.C D5302 45302 14B5 D5352 45352 14E7 D5303 45303 14B6 D5353 45353 14E8 D5304...
  • Page 725 14.4 UT75A D Registers Setup parameter Communication setting (RS-485 communication setting menu: R485) (Ethernet communication setting menu: ETHR) (Error and version confirmation menu: VER) (CC-Link communication setting menu: CC-L) (DeviceNet communication setting menu: DNET) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A SM4_E3 D5501 45501 157C D5551 45551 15AE D5502 45502 157D D5552 45552 15AF DG1_E3 DG2_E3 D5503 45503 157E D5553 45553...
  • Page 726 14.4 UT75A D Registers Setup parameter Communication setting (PROFIBUS-DP communication setting menu: PROF) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A BR_E3-P D5601 45601 15E0 D5651 45651 1612 ADR_E3-P D5602 45602 15E1 D5652 45652 1613 D5603 45603 15E2 BPS_E3-P D5653 45653 1614 D5604...
  • Page 727 14.4 UT75A D Registers Setup parameter Key operation setting (Menu: KEY), Display function setting (Menu: DISP), SELECT Display setting (Menu: CSEL) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A F1-K B.STS D5701 45701 1644 D5751 45751 1676 F2-K CTRS D5702 45702 1645 D5752 45752 1677 Fn-K D.CYC D5703 45703 1646 D5753...
  • Page 728 14.4 UT75A D Registers Setup parameter Lock setting (Key lock setting menu: KLOC) (Menu lock setting menu: MLOC) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A DI.SL-L D5801 45801 16A8 U.SP_L1 D5851 45851 16DA DI.NU-L D5802 45802 16A9 U.SP_L2 D5852 45852 16DB DI.D-L D5803 45803 16AA U.OUT_L1 D5853...
  • Page 729 14.4 UT75A D Registers Setup parameter DI function setting (DI function registration menu: DI.SL) (DI function numbering menu: DI.NU) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A A/M-D PN.B3 D5901 45901 170C D5951 45951 173E R/L_L1-D D5902 45902 170D D5952 45952 173F PN.B4 R/L_L2-D D5903 45903 170E D5953 45953...
  • Page 730 14.4 UT75A D Registers Setup parameter DI function setting (Message) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D6001 46001 1770 MSG1 D6051 46051 17A2 MSG3 D6002 46002 1771 MSG1 D6052 46052 17A3 D6003 46003 1772 MSG1...
  • Page 731 14.4 UT75A D Registers Setup parameter DI function setting (DI1-DI3 contact type setting menu: DI.D) (DI setting menu (E3, E4): DI.D) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A DI1.D D6101 46101 17D4 D6151 46151 1806 D6102 46102 17D5 DI2.D D6152 46152 1807 DI3.D D6103 46103 17D6 D6153 46153 1808 D6104...
  • Page 732 14.4 UT75A D Registers Setup parameter DO function setting (AL1-AL3 function registration menu: ALM) (DO setting menu (E2): DO) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A AL1.S D6201 46201 1838 D6251 46251 186A AL2.S D6202 46202 1839 D6252 46252 186B AL3.S D6203 46203 183A D6253 46253 186C OR.S...
  • Page 733 14.4 UT75A D Registers Setup parameter I/O display (Menu: I/O) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A KEY-IO D6301 46301 189C D6351 46351 18CE D6302 46302 189D D6352 46352 18CF D6303 46303 189E D6353 46353 18D0 D6304 46304 189F...
  • Page 734 14.4 UT75A D Registers Setup parameter System setting (Menu: SYS) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A R.MD D6401 46401 1900 D6451 46451 1932 R.TM D6402 46402 1901 D6452 46452 1933 D6403 46403 1902 D6453 46453 1934 D6404 46404...
  • Page 735 14.4 UT75A D Registers Custom display registers Custom display D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A USE_CD1 PVST_CD2 D6601 46601 1964 D6651 46651 1996 PVST_CD2 D6602 46602 1965 USE_CD2 D6652 46652 1997 USE_CD3 PVST_CD2 D6603 46603...
  • Page 736: Control Function Setting (D5001 To D5100)

    14.4 UT75A D Registers Control Function Setting (D5001 to D5100) Register Description Range and meaning of value 1: SGL (Single-loop control) 2: CAS1 (Cascade primary-loop control) 3: CAS2 (Cascade secondary-loop control) 4: CAS (Cascade control) 5: BUM (Loop control for backup) D5001 CTLM Control mode...
  • Page 737: Input Setting (D5101 To D5300)

    14.4 UT75A D Registers Input Setting (D5101 to D5300) Register Description Range and meaning of value 0: OFF (Disable) 1: K1 (-270.0 to 1370.0°C / -450.0 to 2500.0 F) 2: K2 (-270.0 to 1000.0°C / -450.0 to 2300.0 F) 3: K3 (-200.0 to 500.0°C / -200.0 to 1000.0 F) 4: J (-200.0 to 1200.0°C / -300.0 to 2300.0 F) 5: T1 (-270.0 to 400.0°C / -450.0 to 750.0 F) 6: T2 (0.0 to 400.0°C / -200.0 to 750.0 F)
  • Page 738 14.4 UT75A D Registers Register Description Range and meaning of value D5115 A.LC PV analog input low signal cutoff 0.0 to 5.0% D5116 to D5120 40: 0.4-2V (0.400 to 2.000 V) 41: 1-5V (1.000 to 5.000 V) D5121 IN_E1 PV2 input type 50: 0-2V (0.000 to 2.000 V) 51: 0-10V (0.00 to 10.00 V) 57: 0-125 (0.000 to 1.250 V)
  • Page 739 14.4 UT75A D Registers Register Description Range and meaning of value D5181 IN_E4 AIN4 remote (aux. analog) input type Same as D5121 D5182 UNIT_E4 AIN4 remote (aux. analog) input unit Same as D5102 Maximum value of AIN4 remote (aux. D5183 DP_E4 Same as D5103 analog) input position...
  • Page 740: Output Setting (D5301 To D5400)

    14.4 UT75A D Registers Output Setting (D5301 to D5400) Register Description Range and meaning of value 0: OFF 1: OUT terminals (voltage pulse) D5301 OT.H Heating-side control output selection 2: OUT terminals (current) 3: OUT terminals (relay) 4: OUT2 terminals (voltage pulse) 5: OUT2 terminals (current) 6: OUT2 terminals (relay) 7: RET terminals (voltage pulse)
  • Page 741 14.4 UT75A D Registers Register Description Range and meaning of value 0: OFF (Disable) 1: PV1 (PV) 2: SP1 (SP) 3: OUT1 (OUT (Valve opening: 0 to 100 % in Position proportional control)) 4: LPS (15 V DC loop power supply) 5: PV2 (Loop-2 PV) 6: SP2 (Loop-2 SP) 7: OUT2 (Loop-2 OUT)
  • Page 742 14.4 UT75A D Registers Register Description Range and meaning of value When O1RS=1 (PV1), 2 (SP1), 5 (PV2), 6 (SP2), 8 (TSP1), 12 (TSP2), 16 (PV), 17 (A.PV2), 18 (AIN2), or 19 (AIN4), O1RL+1digit to 30000 Decimal point position: O1RS=1 (PV1), 2 (SP1), 8 (TSP1): decimal point position is same as that of PV input.
  • Page 743 14.4 UT75A D Registers Register Description Range and meaning of value 100% segmental point of OUT D5331 OU.H current output 0% segmental point of OUT current D5332 OU.L output OU2.H 100% segmental point of OUT2 D5333 current output -100.0 to 200.0% OU2.L 0% segmental point of OUT2 D5334...
  • Page 744: Communication Setting (D5501 To D5700)

    14.4 UT75A D Registers Communication Setting (D5501 to D5700) Register Description Range and meaning of value D5501 ro D5520 0: PCL (PC link communication) 1: PCLSM (PC link communication (with checksum)) 2: LADR (Ladder communication) 3: CO-M (Coordinated master station) 4: CO-S (Coordinated slave station) D5521 PSL_E3...
  • Page 745 14.4 UT75A D Registers Register Description Range and meaning of value D5541 HSR_E3 High-speed response mode 0: OFF, 1 to 8 4: 9600 (9600 bps) D5542 BPS_E3 Baud rate 5: 19200 (19.2k bps) 6: 38400 (38.4k bps) 0: NONE (None) D5543 PRI_E3 Parity...
  • Page 746 14.4 UT75A D Registers Register Description Range and meaning of value 0: 125K (125k bps) Baud rate D5591 BR_E3-D *1 1: 250K (250k bps) (for DeviceNet communication) 2: 500K (500k bps) Address ADR_E3-D *1 D5592 0 to 63 (for DeviceNet communication) Baud rate D5593 BPS_E3-D *1 Same as D5583...
  • Page 747 14.4 UT75A D Registers Key Operation Setting, Display Function Setting, and SELECT Display Setting (D5701 to D5800) Register Description Range and meaning of value 0: OFF (Disable) 1: A/M (AUTO/MAN switch) 2: C/A/M (CAS/AUTO/MAN switch) 3: R/L1 (REM/LCL switch) D5701 User function key-1 action setting 4: R/L2 (Loop-2 REM/LCL switch) 5: S/R (STOP/RUN switch)
  • Page 748 14.4 UT75A D Registers Register Description Range and meaning of value 0: Fixed in white 1: Fixed in red 2: Link to alarm 1 (Alarm OFF: white, Alarm ON: red) 3: Link to alarm 1 (Alarm OFF: red, Alarm ON: white) 4: Link to alarm 1 or 2 (Alarm OFF: white, Alarm ON: red) 5: Link to alarm 1 or 2 (Alarm OFF: red, Alarm ON: white) D5713...
  • Page 749 14.4 UT75A D Registers Register Description Range and meaning of value EV1_L1 D5723 Loop-1 EV1 display condition registration Setting range: 4001 to 6304 EV2_L1 D5724 Loop-1 EV2 display condition registration OFF: Disable EV3_L1 D5725 Loop-1 EV3 display condition registration 4321: Link to alarm 1 (Lit when the alarm occurs) 4322: Link to alarm 2 (Lit when the alarm occurs) 4323: Link to alarm 3 (Lit when the alarm occurs) D5726...
  • Page 750 14.4 UT75A D Registers Register Description Range and meaning of value D5739 PV.D PV display area ON/OFF 0: OFF (Nondisplay) D5740 SP.D Setpoint display area ON/OFF 1: ON (Display) D5741 STS.D Status display area ON/OFF D5742 Scroll speed (Slow) 1 to 8 (Quick) 0: OFF (Nondisplay) D5743 GUID...
  • Page 751 14.4 UT75A D Registers Register Description Range and meaning of value D5757 to D5760 D5761 SELECT Display-1 registration Register the operation parameter (except the Operation Mode) that is frequently modified to display it in the D5762 SELECT Display-2 registration Operation Display. D5763 SELECT Display-3 registration (Register the register number of the parameter)
  • Page 752: Lock Setting (Key Lock/Menu Lock) (D5801 To D5900)

    14.4 UT75A D Registers Lock Setting (Key Lock/Menu Lock) (D5801 to D5900) Register Description Range and meaning of value U.SP_L1 D5801 Loop-1 SP Display lock D5802 U.SP_L2 Loop-2 SP Display lock D5803 U.OUT_L1 Loop-1 OUT Display lock D5804 U.OUT_L2 Loop-2 OUT Display lock D5805 U.HCO Heating/cooling OUT Display lock...
  • Page 753 14.4 UT75A D Registers Register Description Range and meaning of value D5853 to D5855 D5856 DI.D_E3-L [DI.D] menu lock (E3-terminal area) DI.D_E4-L [DI.D] menu lock (E4-terminal area) D5857 [ALM] menu lock D5858 ALM-L D5859 [DO] menu lock (E2-terminal area) D5860 DO_E2-L D5861 to D5862 I/O-L...
  • Page 754: Di Function Setting (D5901 To D6200)

    14.4 UT75A D Registers DI Function Setting (D5901 to D6200) Register Description Range and meaning of value AUTO/MAN switch D5901 A/M-D REMOTE/LOCAL switch D5902 R/L_L1-D *1 REMOTE/LOCAL switch D5903 R/L_L2-D *1 STOP/RUN switch D5904 S/R-D Switch to CAS D5905 CAS-D Switch to AUTO D5906 AUTO-D Switch to MAN...
  • Page 755 14.4 UT75A D Registers Register Description Range and meaning of value D5947 PN.BC Bit changing method of PID number Same as D5941 D5948 PN.B0 Bit-0 of PID number PN.B1 D5949 Bit-1 of PID number Same as D5942 D5950 PN.B2 Bit-2 of PID number D5951 PN.B3 Bit-3 of PID number...
  • Page 756: Do Function Setting (D6201 To D6300)

    14.4 UT75A D Registers DO Function Setting (D6201 to D6300) Register Description Range and meaning of value D6021 MSG2 D6022 MSG2 D6023 MSG2 20-digit value of alphanumeric characters can be D6024 MSG2 set. Arrangement: D6025 MSG2 D6021, D6022, D6023, D6024, D6025, D6026, D6026 MSG2 Messege-2 *2...
  • Page 757 14.4 UT75A D Registers Register Description Range and meaning of value Set an I relay number (Setting range: 4001 to 6000, D6201 AL1.S AL1 function selection UP55A: 4001 to 6304). Ex.) Set the number 4353 for AL1.S to use the alarm 1. 0: OFF (No function) D6202 AL2.S...
  • Page 758: O Display (D6301 To D6400)

    14.4 UT75A D Registers I/O Display (D6301 to D6400)  Bit Configuration of D6301: KEY-IO*1 (Key status) Symbol Event PARA_KEY PARAMETER (PARA) key (0: OFF 1: ON) DISP_KEY DISPLAY (DISP) key (0: OFF 1: ON) RIGHT_KEY RIGHT key (0: OFF 1: ON) DOWN_KEY DOWN key (0: OFF 1: ON) SET_KEY...
  • Page 759: System Setting (D6401 To D6500)

    14.4 UT75A D Registers System Setting (D6401 to D6500) Register Description Range and meaning of value Set how the controller should recover from a power failure of 5 seconds or more. 0: CONT (Continue action set before power failure.) D6401 R.MD Restart mode 1: MAN (Start from MAN.)
  • Page 760: Custom Display Register (D6501 To D6686)

    14.4 UT75A D Registers Custom Display Register (D6501 to D6686) Register Description Range and meaning of value D6501 to D6600 Free area D6601 to D6603 Custom display USE_CD1, USE_CD2, USE_CD3 1: use D6604 to D6610 Free area D6611 to D6626 Custom display-1 characters PVST_CD1 30-digit value of alphanumeric characters can be...
  • Page 761: Parameter (D6701 To D6800)

    14.4 UT75A D Registers 14.4.7 T Parameter (D6701 to D6800) T parameter T Parameter D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D6701 46701 1A2C D6751 46751 1A5E D6702 46702 1A2D D6752 46752 1A5F D6703 46703 1A2E D6753 46753 1A60 D6704 46704...
  • Page 762 14.4 UT75A D Registers T Parameter (D6701 to D6800) Register Description Range and meaning of value This is used to display the value of the ladder of D6701 T1 register the timer or counter. D6702 T2 register D6703 T3 register 0 to 65535 D6704 T4 register D6705 T5 register...
  • Page 763: Registers For Ladder Program (D7001 To D7600)

    14.4 UT75A D Registers 14.4.9 Registers for Ladder Program (D7001 to D7600) Registers for ladder program For input ladder calculation D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D7001 47001 1B58 X_PV D7051 47051 1B8A PVIN_CTL D7002 47002 1B59 X_PV2 D7052 47052 1B8B...
  • Page 764 14.4 UT75A D Registers Registers for ladder program For output ladder calculation D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D7101 47101 1BBC OUT_CTL D7151 47151 1BEE Y_OUT D7102 47102 1BBD OUT2_CTL D7152 47152 1BEF Y_OUT2 D7103...
  • Page 765 14.4 UT75A D Registers Registers for ladder program Status register D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D7201 47201 1C20 M1_16 D7251 47251 1C52 D7202 47202 1C21 M17_32 D7252 47252 1C53 D7203 47203 1C22 M33_48 D7253...
  • Page 766 14.4 UT75A D Registers Registers for ladder program Constant register D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D7301 47301 1C84 D7351 47351 1CB6 D7302 47302 1C85 D7352 47352 1CB7 D7303 47303 1C86 D7353 47353 1CB8 D7304...
  • Page 767 14.4 UT75A D Registers Registers for ladder program Constant register D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D7401 47401 1CE8 D7451 47451 1D1A D7402 47402 1CE9 D7452 47452 1D1B D7403 47403 1CEA D7453 47453 1D1C D7404...
  • Page 768 14.4 UT75A D Registers Registers for ladder program Input range / scale D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D7501 47501 1D4C DP_R D7551 47551 1D7E D7502 47502 1D4D RH_R D7552 47552 1D7F D7503 47503 1D4E...
  • Page 769: For Input Ladder Calculation (D7001 To D7100)

    14.4 UT75A D Registers For Input Ladder Calculation (D7001 to D7100)  D7001 to D7010 Register Description Range and meaning of value D7001 X_PV PV analog input -5.0 to 105.0% D7002 X_PV2 PV2 analog input -5.0 to 105.0% D7003 X_AIN2 AIN2 aux.
  • Page 770: For Output Ladder Calculation (D7101 To D7200)

    14.4 UT75A D Registers For Output Ladder Calculation (D7101 to D7200)  D7101 to D7110 Register Description Range and meaning of value D7101 OUT_CTL Control OUT output -5.0 to 105.0% of control OUT output range D7102 OUT2_CTL Control OUT2 output -5.0 to 105.0% of control OUT2 output range D7103 RET_CTL...
  • Page 771: Status Registers (D7201 To D7300)

    14.4 UT75A D Registers  Bit Configuration of D7163: Y200_E2 (DO21-DO25 status: E2-terminal area) Symbol Event Y_DO21 DO11 status (0: OFF 1: ON) Y_DO22 DO12 status (0: OFF 1: ON) Y_DO23 DO13 status (0: OFF 1: ON) Y_DO24 DO14 status (0: OFF 1: ON) Y_DO25 DO15 status (0: OFF 1: ON) 5 to 15 Status Registers (D7201 to D7300)
  • Page 772 14.4 UT75A D Registers  Bit Configuration of D7213 to D7218: M33_48_B to M113_128_B (Status register (M33_B-M48_B to M113_B-M128_B, Holding type) Symbol Event M33_B M49_B M65_B M81_B M97_B M113_B Internal relay (Holding type) * (0: OFF 1: ON) M34_B M50_B M66_B M82_B M98_B M114_B Internal relay (Holding type) * (0: OFF 1: ON) M35_B M51_B M67_B M83_B M99_B...
  • Page 773: Constant Register (D7301 To D7500)

    14.4 UT75A D Registers Constant Register (D7301 to D7500) Register Description Range and meaning of value D7301 K01 data register to K50 data K01 to K20, K31 to K50: -32768 to 32767 K01 to K50 register K21 to K30: 0 to 65535 D7330 D7331 to D7409 D7410...
  • Page 774 14.4 UT75A D Registers Register Description Range and meaning of value Maximum value of AIN4 remote (aux. D7525 DP_E4_R Same as D5183 (DP_E4) analog) input position Maximum value of AIN4 remote (aux. D7526 RH_E4_R Same as D5184 (RH_E4) analog) input range Minimum value of AIN4 remote (aux.
  • Page 775: Input / Output Terminal Status Register (D7601 To D7700)

    14.4 UT75A D Registers 14.4.10 Input / Output Terminal Status Register (D7601 to D7700) Terminal status registers Input / output terminal status register D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D7601 47601 1DB0 D7651 47651 1DE2...
  • Page 776 14.4 UT75A D Registers  Bit Configuration of D7601: DI (DI1-DI3 terminal status: equipped as standard) Symbol Event DI1 terminal status (0: OFF 1: ON) DI2 terminal status (0: OFF 1: ON) DI3 terminal status (0: OFF 1: ON) 3 to 15  Bit Configuration of D7604: DI_E3 (DI31- DI35 terminal status: E3-terminal area) Symbol Event DI31 DI31 terminal status (0: OFF 1: ON) DI32 DI32 terminal status...
  • Page 777 14.4 UT75A D Registers  D7616 to D7700 Register Description Range and meaning of value D7616 to D7620 D7621 OUT_OUT OUT terminal -1500 to 31500 Cooling-side control output: OUT2 terminal (Relay) 0: OFF D7622 OUT_OUT2H Position proportional control output: 30000: ON VALV (HIGH) terminal Cooling-side control output in Heating/ -1500 to 31500...
  • Page 778: Program Pattern Parameters (D7701 To D7900)

    14.4 UT75A D Registers 14.4.11 Program Pattern Parameters (D7701 to D7900) Program pattern parameters Program pattern setting (Menu: PROG) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D7701 47701 1E14 SSP_L1 D7751 47751 1E46 D7702 47702 1E15 SSP_L2 D7752 47752 1E47 D7703 47703 1E16 D7753 47753 1E48 D7704 47704...
  • Page 779 14.4 UT75A D Registers Program pattern parameters Program pattern setting (Menu: PROG) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A D7801 47801 1E78 TSP_L1_1 D7851 47851 1EAA TSP_L1_11 D7802 47802 1E79 TSP_L2_1 D7852 47852 1EAB TSP_L2_11 D7803 47803 1E7A TIME_1 D7853 47853 1EAC...
  • Page 780: Program Pattern Setting (D7701 To D7900)

    14.4 UT75A D Registers Program Pattern Setting (D7701 to D7900) Register Description Range and meaning of value D7701 SSP_L1 Loop-1 Starting target setpoint 0.0 to 100.0% of PV input range (EU) (Setting range: P.RL to P.RH) D7702 SSP_L2 Loop-2 Starting target setpoint 0: SSP (Program operation begins with the starting target setpoint.
  • Page 781 14.4 UT75A D Registers Register Description Range and meaning of value Loop-1, segment-8 final target D7806 to TSP_L1_8 to setpoint to Loop-2, segment-8 Same as D7801 to D7805. D7810 S.PID_L2_8 segment PID number selection Loop-1, segment-9 final target D7806 to TSP_L1_9 to setpoint to Loop-2, segment-9 Same as D7801 to D7805.
  • Page 782: Loop-1/Loop-2 Operation Parameter (D9001 To D10000) Group 9 To 20

    14.4 UT75A D Registers 14.4.12 Loop-1/Loop-2 Operation Parameter (D9001 to D10000) Group 9 to 20 Loop-1 operation parameter SP and alarm setpoint setting (Menu: SP) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A SP_L1_9 PIDN_L1_12 D9001 49001 2328 D9051 49051 235A SUB_9 A1_L1_12 D9002 49002 2329 D9052...
  • Page 783 14.4 UT75A D Registers Loop-1 operation parameter SP and alarm setpoint setting (Menu: SP) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A SP_L1_15 PIDN_L1_18 D9101 49101 238C D9151 49151 23BE SUB_15 A1_L1_18 D9102 49102 238D D9152 49152 23BF PIDN_L1_15 A2_L1_18 D9103 49103 238E...
  • Page 784 14.4 UT75A D Registers Loop-1 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A P_L1_9 SU.PO_L1_10 D9201 49201 23F0 D9251 49251 2422 I_L1_9 POc_L1_10 D9202 49202 23F1 D9252 49252 2423 D_L1_9 D9203 49203 23F2 D9253...
  • Page 785 14.4 UT75A D Registers Loop-1 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A P_L1_12 SU.PO_L1_13 D9301 49301 2454 D9351 49351 2486 I_L1_12 POc_L1_13 D9302 49302 2455 D9352 49352 2487 D_L1_12 D9303 49303 2456 D9353...
  • Page 786 14.4 UT75A D Registers Loop-1 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A P_L1_15 SU.PO_L1_16 D9401 49401 24B8 D9451 49451 24EA I_L1_15 POc_L1_16 D9402 49402 24B9 D9452 49452 24EB D_L1_15 D9403 49403 24BA D9453...
  • Page 787 14.4 UT75A D Registers Loop-2 operation parameter SP and alarm setpoint setting (Menu: SP) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A SP_L2_9 PIDN_L2_12 D9501 49501 251C D9551 49551 254E A1_L2_12 D9502 49502 251D D9552 49552 254F PIDN_L2_9 A2_L2_12 D9503 49503 251E D9553...
  • Page 788 14.4 UT75A D Registers Loop-2 operation parameter SP and alarm setpoint setting (Menu: SP) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A SP_L2_15 PIDN_L2_18 D9601 49601 2580 D9651 49651 25B2 A1_L2_18 D9602 49602 2581 D9652 49652 25B3 PIDN_L2_15 A2_L2_18 D9603 49603 2582 D9653...
  • Page 789 14.4 UT75A D Registers Loop-2 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A P_L2_9 D9701 49701 25E4 D9751 49751 2616 I_L2_9 POc_L2_10 D9702 49702 25E5 D9752 49752 2617 D_L2_9 D9703 49703 25E6 D9753 49753...
  • Page 790 14.4 UT75A D Registers Loop-2 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A P_L2_12 D9801 49801 2648 D9851 49851 267A I_L2_12 POc_L2_13 D9802 49802 2649 D9852 49852 267B D_L2_12 D9803 49803 264A D9853 49853...
  • Page 791 14.4 UT75A D Registers Loop-2 operation parameter PID setting (Menu: PID) D-Reg Ref. Register D-Reg Ref. Register H No. H No. symbol symbol UT75A UT75A P_L2_15 D9901 49901 26AC D9951 49951 26DE I_L2_15 POc_L2_16 D9902 49902 26AD D9952 49952 26DF D_L2_15 D9903 49903 26AE D9953 49953...
  • Page 792: Loop-1 Sp And Alarm Setpoint Setting, Group 9 To 20 (D9001 To D9200)

    14.4 UT75A D Registers Loop-1 SP and Alarm Setpoint Setting, Group 9 to 20 (D9001 to D9200) Register Description Range and meaning of value D9001 to Target setpoint of group 9 to SP ramp- SP_L1_9 to DNR_L1_9 Same as D2501 to D2513. D9013 down rate of group 9 D9014 to D9016 D9017 to Target setpoint of group 10 to SP SP_L1_10 to DNR_L1_10 Same as D2501 to D2513.
  • Page 793: Loop-1 Pid Setting, Group 9 To 20 (D9201 To D9500)

    14.4 UT75A D Registers Loop-1 PID Setting, Group 9 to 20 (D9201 to D9500) Register Description Range and meaning of value D9201 to Proportional band of group 9 to Cooling- P_L1_9 to POc_L1_9 Same as D3002 to D3022. D9222 side preset output of group 9 D9223 to D9230 D9231 to Proportional band of group 10 to Cooling- P_L1_10 to POc_L1_10 Same as D3002 to D3022.
  • Page 794: Loop-2 Sp And Alarm Setpoint Setting, Group 9 To 20 (D9501 To D9700)

    14.4 UT75A D Registers Loop-2 SP and Alarm Setpoint Setting, Group 9 to 20 (D9501 to D9700) Register Description Range and meaning of value D9501 to Target setpoint of group 9 to SP ramp- SP_L2_9 to DNR_L2_9 Same as D2501to D2513. D9513 down rate of group 9 D9514 to D9516 D9517 to Target setpoint of group 10 to SP SP_L2_10 to DNR_L2_10 Same as D2501 to D2513.
  • Page 795: Loop-2 Pid Setting, Group 9 To 20 (D9701 To D10000)

    14.4 UT75A D Registers Loop-2 PID Setting, Group 9 to 20 (D9701 to D10000) Register Description Range and meaning of value D9701 to Proportional band of group 9 to Cooling- P_L2_9 to POc_L2_9 Same as D3002 to D3022. D9722 side preset output of group 9 D9723 to D9730 D9731 to Proportional band of group 10 to Cooling- P_L2_10 to POc_L2_10 Same as D3002 to D3022.
  • Page 796: Writing Via Communication

    14.5 Writing via Communication  Setting Target Setpoint In LCL (local) mode (1) Set the Loop-1 and Loop-2 target setpoints of groups 1 to 8 parameters (SP_L1_1 to SP_L1_8 or SP_L2_1 to SP_L2_8). (2) Write the setpoint (1 to 8) in the SPNO. (SP number selection) (depends on the setup parameter SPGR.
  • Page 797 14.5 Writing via Communication  Setting PID Number (D2503: PIDN_L1_1 to D2643: PIDN_L1_8, D3603: PIDN_L2_1 to D3743: PIDN_L2_8) PID number can be selected via communication only when the zone PID selection parameter (ZON) is set to 1, 2, or 4. D2503 to D2643 = 1 to 8, D3603 to D3743 = 1 to 8 (depends on the setup parameter SPGR.
  • Page 798: Green Series Compatible D Registers

    14.6 GREEN Series Compatible D Registers 14.6.1 Compatibility with GREEN Series Controllers The D register map configuration of the UTAdvanced is the same as that of the GREEN Series (UT700 Series) controllers that perform access in the 2-byte integer data format. When GREEN Series devices are replaced with the UTAdvanced, communication programs created in the GREEN Series controllers can be used by just carrying out wiring.
  • Page 799 14.6 GREEN Series Compatible D Registers  D register symbols • With regards to some D register symbols, the loop number, terminal area, and group number are indicated by adding the underline (_) to the end of the parameter symbols. If both the loop number and group number are added to the parameter symbols, they are added in the order of _loop number and _group number.
  • Page 800: Process Data And User Area (D0001 To D0100)

    14.6 GREEN Series Compatible D Registers 14.6.3 Process Data and User Area (D0001 to D0100) Configuration map for GREEN Series Process data User area Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0001 40001 0000 ADERROR AD1.E_G D0051 40051 0032 USER USER1...
  • Page 801: Operation Mode And Operation-Related Parameters (D0201 To D0300)

    14.6 GREEN Series Compatible D Registers 14.6.4 Operation Mode and Operation-related Parameters (D0201 to D0300) Configuration map for GREEN Series Operation mode / Operation-related parameters Register Register Register D-Reg Ref. Register symbol D-Reg Ref. H No. symbol for H No. symbol for symbol for for UTAdvanced GREEN GREEN UTAdvanced D0201 40201 00C8 A/M1 A.M (D2301) R/W D0251 40251 00FA ORH.1 D0202 40202 00C9 A/M2...
  • Page 802: Loop-1 Pid Parameters (D0301 To D0500)

    14.6 GREEN Series Compatible D Registers 6.6.5 Loop-1 PID Parameters (D0301 to D0500) Configuration map for GREEN Series Loop-1 SP / AL / PID parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0301 40301 012C 1.SP SP_L1_1 (D2501) R/W D0351 40351 015E 3.SP SP_L1_3 (D2541) R/W D0302 40302 012D 1.A1 A1_L1_1 (D2504) R/W D0352 40352 015F 3.A1...
  • Page 803 14.6 GREEN Series Compatible D Registers Configuration map for GREEN Series Loop-1 SP / AL / PID parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0401 40401 0190 5.SP SP_L1_5 (D2581) R/W D0451 40451 01C2 7.SP SP_L1_7 (D2621) R/W D0402 40402 0191 5.A1 A1_L1_5 (D2584) R/W D0452 40452 01C3 7.A1...
  • Page 804: Loop-2 Pid Parameters (D0501 To D0700)

    14.6 GREEN Series Compatible D Registers 14.6.6 Loop-2 PID Parameters (D0501 to D0700) Configuration map for GREEN Series Loop-2 SP / AL / PID parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0501 40501 01F4 1.SP SP_L2_1 (D3601) R/W D0551 40551 0226 3.SP SP_L2_3 (D3641) R/W D0502 40502 01F5 1.A1 A1_L2_1 (D3604) R/W D0552 40552 0227 3.A1...
  • Page 805 14.6 GREEN Series Compatible D Registers Configuration map for GREEN Series Loop-2 SP / AL / PID parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0601 40601 0258 5.SP SP_L2_5 (D3681) R/W D0651 40651 028A 7.SP SP_L2_7 (D3721) R/W A1_L2_5 (D3684) R/W D0652 40652 028B 7.A1 A1_L2_7 (D3724) R/W...
  • Page 806: User Parameters And 10-Segment Linearizer Parameters (D0701 To D0800)

    14.6 GREEN Series Compatible D Registers 14.6.7 User Parameters and 10-segment Linearizer Parameters (D0701 to D0800) Configuration map for GREEN Series User parameters / 10-segment linearizer parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0701 40701 02BC U1 Depends on the conditions (Note1) R/W D0751 40751 02EE 2.A1 A1_2 (D4832) B1_2 (D4833) D0702 40702 02BD U2...
  • Page 807: Message (D0801 To D0900)

    14.6 GREEN Series Compatible D Registers 6.6.8 Message (D0801 to D0900) Configuration map for GREEN Series Message Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0801 40801 0320 MG10 D0851 40851 0352 D0802 40802 0321 MG11 D0852 40852 0353...
  • Page 808: Control Action Parameters (D0901 To D1000)

    14.6 GREEN Series Compatible D Registers 14.6.9 Control Action Parameters (D0901 to D1000) Configuration map for GREEN Series Control action parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D0901 40901 0384 RMS.1 RMS_L1 (D2701) R/W D0951 40951 03B6 D0902 40902 0385 SPT.1 SPT_L1 (D2710)
  • Page 809: Common Function Parameters (D1001 To D1100)

    14.6 GREEN Series Compatible D Registers 14.6.10 Common Function Parameters (D1001 to D1100) Configuration map for GREEN Series Common function parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D1001 41001 03E8 A.BS1 A.BS (D5112) R/W D1051 41051 041A D1002 41002 03E9 A.FL1 A.FL (D5113)
  • Page 810: Display And Input / Output Parameters (D1101 To D1200)

    14.6 GREEN Series Compatible D Registers 14.6.11 Display and Input / Output Parameters (D1101 to D1200) Configuration map for GREEN Series Display and input / Output parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D1101 41101 044C C.S1 D1151 41151 047E D1102 41102 044D C.S2 D1152 41152...
  • Page 811: Control Mode, Pv Input, And Control Output Parameters (D1201 To D1300)

    14.6 GREEN Series Compatible D Registers 14.6.12 Control Mode, PV Input, and Control Output Parameters (D1201 to D1300) Configuration map for GREEN Series Control mmode, PV input, and Control output parameters Register Register Register Register D-Reg Ref. D-Reg Ref. H No. symbol for symbol for H No. symbol for symbol for GREEN UTAdvanced GREEN UTAdvanced D1201 41201 04B0 IN1 IN (D5101) R/W D1251 41251 04E2 DLN1 Depends on the conditions (Note1) R/W D1202 41202 04B1 UNI1 UNI (D5102)
  • Page 812: Registers Converted For Green Series

    14.6 GREEN Series Compatible D Registers 14.6.13 D Registers Converted for GREEN Series  Bit Configuration of D0001: AD1.E_G (A/D converter error status for GREEN Series) Symbol Event GREEN Series UTAdvanced AD1ERR.st ADERR (I4065) PV input A/D converter error AD2ERR.st (Not used) AD3ERR.st ADERR_E1 (I4069) AIN4 input (E4-terminal area) A/D converter error AD1BO.st ADBO (I4073) PV input burnout error...
  • Page 813 14.6 GREEN Series Compatible D Registers  Bit Configuration of D0008: MOD_L1_G (Loop-1 operation mode status for GREEN Series) Symbol Event GREEN Series UTAdvanced A/M1.st A.M (I4193) 0: AUTO, 1: MAN R/L1.st R.L_L1 (I4194) 0: Local, 1: Remote R/S1.st S.R (I4195) 0: Run, 1: Stop CAS.st CAS_ON (I4197) 1: CAS AUT.st AUTO_ON (I4198) 1: AUTO *2...
  • Page 814 14.6 GREEN Series Compatible D Registers  Bit Configuration of D0018: PV1.E_L2_G (Loop-2 PV input error status for GREEN Series) Symbol Event GREEN Series UTAdvanced PV2ADC.st (Not used) PV2BO.st PVBO_L2 (I4113) Loop-2 PV input burnout error RJC2ERR.st (Not used) PV2+over.st PVPOV_L2 (I4117) Loop-2 PV input over-scale PV2-over.st PVMOV_L2 (I4118) Loop-2 PV input under-scale 6 to 7 RSP2ADC.st (Not used)
  • Page 815 14.6 GREEN Series Compatible D Registers  Bit Configuration of D0036: ALO_G (Alarm-1 to alarm-4 output status for GREEN Series) Symbol Event GREEN Series UTAdvanced Output status where Loop-1 alarm output 1 is assighed. 0: When the alarm is turned off (alarm type: energized), or the alarm is turned on (alarm type: de-energized). (The relay ALO11 ALO1_L1 (I4353) contact is open.)
  • Page 816: Registers Differring In Content From Green Series

    14.6 GREEN Series Compatible D Registers 14.6.14 D Registers Differring in Content from GREEN Series  Bit Configuration of D0033: DI00 (DI1 to DI3 terminal status) Symbol Event GREEN Series UTAdvanced DI1.st 0: OFF 1: ON DI2.st 0: OFF 1: ON DI3.st 0: OFF 1: ON DI4.st (Not used) DI5.st (Not used) DI6.st (Not used)
  • Page 817 14.6 GREEN Series Compatible D Registers Loop-1 Alarm-1 setpoint to Alarm-8 setpoint of Groups 3 When D0917 (AL3.1) = 4, 6, 14, 16 Symbol Event GREEN Series UTAdvanced D0304 1.A3 A3_L1_1 (D2506) D0329 2.A3 A3_L1_2 (D2526) D0354 3.A3 A3_L1_3 (D2546) D0379 4.A3 A3_L1_4 (D2566)
  • Page 818 14.6 GREEN Series Compatible D Registers Loop-2 Alarm-1 setpoint to Alarm-8 setpoint of Groups 3 When D0957 (AL3.2) = 4, 6, 14, 16 Symbol Event GREEN Series UTAdvanced D0504 1.A3 A3_L2_1 (D3606) D0529 2.A3 A3_L2_2 (D3626) D0554 3.A3 A3_L2_3 (D3646) D0579 4.A3 A3_L2_4 (D3666)
  • Page 819 14.6 GREEN Series Compatible D Registers GREEN Series Register Description Range and meaning of value OFF (0), 1 to 31 1: PV high limit (energized, no stand-by action) 2: PV low limit (energized, no stand-by action) 3: Deviation high limit (energized, no stand-by action) D0915 AL1.1 Loop-1 alarm-1 type...
  • Page 820 14.6 GREEN Series Compatible D Registers  D0955 to D0958: Loop-2 alarm-1 type to alarm-4 type UTAdvanced Register Description Range and meaning of value 00: Disable 01: PV high limit 02: PV low limit 03: SP high limit D0955 AL1.T_L2 Loop-2 alarm-1 type 04: SP low limit 05: Deviation high limit 06: Deviation low limit 07: Deviation high and low limits 08: Deviation within high and low limits...
  • Page 821 14.6 GREEN Series Compatible D Registers  D1240, D1241: D1242, D1243: UTAdvanced Register Description Range and meaning of value Control output cycle time D1240 Heating-side control output cycle time (in Heating/cooling control) Loop-1 Control output cycle time D1241 CT_L2 Heating-side control output cycle 0.5 to 1000.0 s time (in Heating/cooling control) Cooling-side control output cycle...
  • Page 822 14.6 GREEN Series Compatible D Registers GREEN Series Register Description Range and meaning of value 1: Single-loop control 2: Cascade primary-loop control 3: Cascade secondary-loop control 4: Cascade control 5: Loop control for backup 6: Loop control with PV switching D1280 Controller mode (UT mode) 7: Loop control with PV auto-selector...
  • Page 823: Registers Differring Depending On Conditions

    14.6 GREEN Series Compatible D Registers 14.6.15 D Registers Differring Depending on Conditions  D registers differring depending on the setting of the control type (CNT_L1) Example: When CNT_L1 = 0, 1, 2, 5, 6, or 7, D0310 is D3005 (OL_L1_1) data. When CNT_L1 = 3 or 4, D0310 is D3016 (OHc_L1_1) data. ONOF ONOF2 2P2L...
  • Page 824 14.6 GREEN Series Compatible D Registers  D registers differring depending on the model Example: D1247 is PSL_E4. Register Name of UT75A GREEN D1247 PSL1 D5521 (PSL_E3) D1248 BPS1 D5522 (BPS_E3) D1249 PRI1 D5523 (PRI_E3) D1250 STP1 D5524 (STP_E3) D1251 DLN1 D5525 (DLN_E3) D1252...
  • Page 825 Blank Page...
  • Page 826 Chapter 15 Functions and Applications of I Relays (for UT75A) 15.1 Overview This chapter describes the functions and applications of the I relays. I relays are used in ladder program, Modbus communication, PC link communication, and contact input / output functions. I relays contain status information of errors, operation, and alarms.
  • Page 827 15.2 Classification of I Relays I relays are classified as shown below. Classification of I Relay Map Area and data I relay No. Description categories Each bit information is the same as that of 1 to 192 Status D register. 193 to 576 Free area GREEN series...
  • Page 828 15.2 Classification of I Relays CAUTION • Check the model and suffix codes and parameter settings before writing to or read from the registers to be used. • In the area for I relay numbers 4001 to 6560, it is prohibited to write data to I relays with blank cells in I relay map tables.
  • Page 829 15.3 UT75A I Relays 15.3.1 Function Status (4001 to 5024) Note When specifying an I relay number for communication, begin the number with the character “I.” Example: Set “I4065” to specify the ADERR (I relay No.: 4065). 15-4 IM 05P07A01-01EN...
  • Page 830 15.3 UT75A I Relays System error Input error I relay symbol I relay symbol UT75A UT75A SYSTEM_ERR 4001 4065 ADERR CALB_ERR 4066 4002 ADERR_E1 UPARA_ERR 4003 4067 ADERR_E2 4004 4068 4005 SETPA_ERR 4069 ADERR_E4 OPEPA_ERR 4006 4070 RJCERR 4007 4071 RJCERR_E1 4008 4072...
  • Page 831 15.3 UT75A I Relays Operation mode Operation mode Operation mode I relay symbol I relay symbol I relay symbol UT75A UT75A UT75A 4129 4193 A.M 4257 4130 4194 R.L_L1 4258 4131 4195 S.R 4259 4132 4196 4260 4133 4197 CAS_ON 4261 4134 4198 AUTO_ON *2...
  • Page 832 15.3 UT75A I Relays Alarm Alarm latch Alarm latch I relay symbol I relay symbol I relay symbol UT75A UT75A UT75A 4321 ALM1_L1 4385 ALO1LA1_L1 4449 ALO1LA3_L1 4322 ALM2_L1 4386 ALO2LA1_L1 4450 ALO2LA3_L1 4323 ALM3_L1 4387 ALO3LA1_L1 4451 ALO3LA3_L1 4324 4388 4452 4325 ALM4_L1...
  • Page 833 15.3 UT75A I Relays Alarm latch SP number and PID number Segment number, Operation status I relay symbol I relay symbol I relay symbol UT75A UT75A UT75A 4513 ALOLA_RLS 4577 CSPN.B0 4641 4514 ALM_WAIT 4578 CSPN.B1 4642 4579 CSPN.B2 4515 4643 4580 CSPN.B3 4516 4644 4581 CSPN.B4 4517...
  • Page 834 15.3 UT75A I Relays Display I relay symbol I relay symbol UT75A UT75A PARA_KEY MG1.B 4705 4769 DISP_KEY MG2.B 4706 4770 RIGHT_KEY MG3.B 4707 4771 DOWN_KEY 4708 4772 4709 SET_KEY 4773 MG4.B UP_KEY 4710 4774 LEFT_KEY 4711 4775 F2_KEY 4712 4776 F1_KEY 4713...
  • Page 835 15.3 UT75A I Relays Free area Segment number status I relay symbol I relay symbol UT75A UT75A 4833 4897 SEG1 4834 4898 SEG2 4835 4899 SEG3 4836 4900 SEG4 4837 4901 SEG5 4838 4902 SEG6 4839 4903 SEG7 4840 4904 SEG8 4841 4905 SEG9 4842...
  • Page 836 15.3 UT75A I Relays System Error, Input Error, and Operation Mode (4001 to 4320) I relay No. Symbol Event SYSTEM_ERR to 4001 to 4016 Parameter error status (Same as D2068) CTLPA_ERR LAD_ERR to 4017 to 4032 Ladder error status (Same as D2012) LD200_OVER E1_ERR to 4033 to 4048...
  • Page 837 15.3 UT75A I Relays Alarm and Alarm Latch (4321 to 4576) I relay No. Symbol Event 4321 to 4336 ALM1_L1~ALM8_L1 Loop-1 alarm-1 to alarm-8 status (Same as D2011) 4337 to 4352 ALM1_L2~ALM8_L2 Loop-2 alarm-1 to alarm-8 status (Same as D2013) 4353 to 4368 ALO1_L1 to ALO8_L1 Loop-1 alarm-1 to alarm-8 output status (Same as D2037)
  • Page 838 15.3 UT75A I Relays SP Number, PID Number, Segment Number, and Program Operation Status (4577 to 4704) I relay No. Symbol Event CSPN.B0 to 4577 to 4592 *1 SP number (Same as D2010) CSPN.B4 4593 to 4608 PIDN.B0_L1 to 4609 to 4624 *1 Loop-1 PID number (Same as D2009) PIDN.B4_L1 PIDN.B0_L2 to 4625 to 4640 *1 Loop-2 PID number (Same as D2025) PIDN.B4_L2...
  • Page 839 15.3 UT75A I Relays Display and Program Segment (4769 to 5024) I relay No. Symbol Event 4769 to 4773 MG1.B to MG4.B Message display interruption status (Same as D2066) 4779 PVRW1 Loop-1 PV red/white switch 0: White color 1: Red color 4780 PVRW2 Loop-2 PV red/white switch 4781 Operation display interruption 1 1: Displaying...
  • Page 840 15.3 UT75A I Relays 15.3.2 Status for Ladder Program (5025 to 5664) Note When specifying an I relay number for communication, begin the number with the character “I.” Example: Set “I5025” to specify the X_DI1 (I relay No.: 5025). 15-15 IM 05P07A01-01EN...
  • Page 841 15.3 UT75A I Relays Input (status) relay Input (status) relay I relay symbol I relay symbol UT75A UT75A 5025 X_DI1 5089 X_DI2 5090 5026 X_DI3 5091 5027 5092 5028 5093 5029 5094 X_DI46 5030 5095 5031 5096 5032 5033 5097 5098 5034 5099...
  • Page 842 15.3 UT75A I Relays Output (status) relay Output (status) relay I relay symbol I relay symbol UT75A UT75A 5153 Y_AL1 5217 5154 Y_AL2 5218 5155 Y_AL3 5219 5156 5220 5157 5221 5158 5222 5159 5223 5160 5224 5161 5225 5162 5226 5163 5227...
  • Page 843 15.3 UT75A I Relays Control (status) relay Control (status) relay I relay symbol I relay symbol UT75A UT75A 5281 AL1_CTL 5345 5282 AL2_CTL 5346 5283 AL3_CTL 5347 5284 5348 5285 5349 5286 5350 5287 5351 5288 5352 5289 5353 5290 5354 5291 5355...
  • Page 844 15.3 UT75A I Relays Special relay Free area I relay symbol I relay symbol UT75A UT75A 5409 TIM1 5473 5410 TIM2 5474 5411 TIM3 5475 5412 TIM4 5476 5413 5477 5414 5478 5415 5479 5416 5480 5417 TIM1_B 5481 5418 TIM2_B 5482 5419...
  • Page 845 15.3 UT75A I Relays Internal relay Internal relay I relay symbol I relay symbol 5537 5601 5538 5602 5539 5603 5540 5604 5541 5605 5542 5606 5543 5607 5544 5608 5545 5609 5546 5610 5547 5611 5548 5612 5549 5613 5550 5614 5551...
  • Page 846 15.3 UT75A I Relays Internal relay Internal relay I relay symbol I relay symbol UT75A UT75A 5665 M01_B 5729 M65_B 5666 M02_B 5730 M66_B 5667 M03_B 5731 M67_B 5668 M04_B 5732 M68_B 5669 M05_B 5733 M69_B 5670 M06_B 5734 M70_B 5671 M07_B 5735...
  • Page 847 15.3 UT75A I Relays Peer-to-peer communication register Peer-to-peer communication register I relay symbol I relay symbol UT75A UT75A 6049 CF01 6113 CI01 6050 CF02 6114 CI02 6051 CF03 6115 CI03 6052 CF04 6116 CI04 6053 6117 CI05 6054 6118 CI06 6055 6119 CI07 6056 6120 CI08 6057...
  • Page 848 15.3 UT75A I Relays Peer-to-peer communication register Free area I relay symbol I relay symbol UT75A UT75A 6177 CO01 6241 6178 CO02 6242 6179 CO03 6243 6180 CO04 6244 6181 CO05 6245 6182 CO06 6246 6183 CO07 6247 6184 CO08 6248 6185 CO09 6249 6186...
  • Page 849 15.3 UT75A I Relays Input (Status) Relay and Output (Status) Relay (5025 to 5280) I relay No. Symbol Description 5025 to 5040 X_DI1 to X_DI3 DI1-DI3 status (Same as D7011) 5057 to 5072 X_DI26 DI26 status (Same as D7013) 5073 to 5088 X_DI31 to X_DI35 DI31-DI35 status (Same as D7014) 5089 to 5104 X_DI46...
  • Page 850 15.3 UT75A I Relays Internal Relay (5537 to 5792) I relay No. Symbol Description You can read/write data from/to the area via communication. (Same as D7201 to D7208) 5537 to 5664 M01 to M128 That is, you can use the area freely without affecting the control function of the UTAdvanced You can read/write data from/to the area via communication.
  • Page 851 15.3 UT75A I Relays 15.3.3 Input / Output Terminal Status (6305 to 6560) Note When specifying an I relay number for communication, begin the number with the character “I.” Example: Set “I6305” to specify the DI1 (I relay No.: 6305). 15-26 IM 05P07A01-01EN...
  • Page 852 15.3 UT75A I Relays DI terminals DI terminals I relay symbol I relay symbol UT75A UT75A 6305 6369 6306 6370 6307 6371 6308 6372 6309 6373 6310 6374 DI46 6311 6375 6312 6376 6313 6377 6314 6378 6315 6379 6316 6380 6317 6381...
  • Page 853 15.3 UT75A I Relays DO terminals DO terminals I relay symbol I relay symbol UT75A UT75A 6433 OUT_AL1 6497 6434 OUT_AL2 6498 6435 OUT_AL3 6499 6436 6500 6437 6501 6438 6502 6439 6503 6440 6504 6441 6505 6442 6506 6443 6507 6444 6508...
  • Page 854 15.3 UT75A I Relays DI Terminals and DO Terminals (6305 to 6560) I relay No. Symbol Description 6305 to 6320 DI1 to DI3 DI1-DI3 status (Same as D7601) 6321 to 6352 6353 to 6368 DI31 to DI35 DI31-DI35 status (Same as D7604) 6369 to 6384 DI46 DI46 status (Same as D7605)
  • Page 855 15.4 Reading via Communication  When reading the alarm status Read I relay numbers 4321 to 4336 for Loop-1 alarm-1 to alarm-8 status. I relay No. Symbol Event 4321 to 4336 ALM1_L1~ALM8_L1 Loop-1 alarm-1 to alarm-8 status (Same as D2011) * 4337 to 4352 ALM1_L2~ALM8_L2 Loop-2 alarm-1 to alarm-8 status (Same as D2013)
  • Page 856 15.5 GREEN Series Compatible I Relays 15.5.1 Compatibility with GREEN Series Controllers The map configuration from 1 to 2048 of the I relay map is the same as that of the GREEN Series (UT700 Series) controllers. If existing programs created in the GREEN Series controllers are used, communication is performed using the area from 0001 to 2048.
  • Page 857 15.5 I Relays Corresponding to GREEN Series 15.5.3 Status (0001 to 0192) UT55A/UT52A Status I relay symbol I relay symbol I relay symbol GREEN UTAdvanced GREEN UTAdvanced GREEN UTAdvanced AD1 ERR ADERR (4065) A/M1 A.M (4193) AD2 ERR R/L1 R.L_L1 (4194) AD3 ERR ADERR_E1 (4066) R/S1...
  • Page 858 15.5 I Relays Corresponding to GREEN Series *1: Effective for the control modes except for cascade control and cascade secondary-loop control. *2: Effective for cascade control mode and cascade secondary-loop control mode. I relay No. Symbol Description ADERR to 1 to 16 A/D converter error status for GREEN Series (Same as D0001) VALVBO PVBO_L1 to...
  • Page 859 15.5 I Relays Corresponding to GREEN Series 15.5.4 SP Number, PID Number, and Status (0577 to 0720) UT55A/UP55A SP number, PID number, and status I relay symbol I relay symbol GREEN UTAdvanced GREEN UTAdvanced 577 CSPNO.0 CSPN.B0 (4577) 578 CSPNO.1 CSPN.B1 (4578) 579 CSPNO.2 CSPN.B2 (4579) 580 CSPNO.3 CSPN.B3 (4580) 593 PIDNO1.0 PIDN.B0_L1 (4609) 657 TIM.1S 594 PIDNO1.1 PIDN.B1_L1 (4610)
  • Page 860 15.5 I Relays Corresponding to GREEN Series I relay No. Symbol Description CSPN.B0 to 577 to 592 SPnumber (Same as 2010) CSPN.B3 PIDN.B0_L1 to 593 to 608 Loop-1 PID number (Same as 2009) PIDN.B3_L1 PIDN.B0_L2 to 609 to 624 Loop-2 PID number (Same as 2025) PIDN.B3_L2 625 to 664 0: Operation by feedback...
  • Page 861 Blank Page...
  • Page 862 Appendix ASCII Code Table Hex. Dec. Symbol Hex. Dec. Symbol Hex. Dec. Symbol Hex. Dec. Symbol ^@ NUL ^A SOH ^B STX " ^C ETX ^D EOT ^E ENQ ^F ACK & ^G BEL ^H BS ^I HT ^J LF ^K VT ^L FF ^M CR...
  • Page 863 Blank Page...
  • Page 864 Revision Information Title : UTAdvanced Series Communication Interface (RS-485, Ethernet)  User’s Manual Manual No. : IM 05P07A01-01EN  May 2009/1st Edition Newly published Sep. 2009/2nd Edition Error correction Jan. 2010/3rd Edition Addition of UT35A/UT32A June 2010/4th Edition Addition of CC-Link communication Aug.
  • Page 865 Blank Page...
  • Page 866 3F Tower D Cartelo Crocodile Building, No.568 West Tianshan Road, Shanghai 200335, CHINA Phone : 86-21-62396262 Fax : 86-21-62387866 YOKOGAWA ELECTRIC KOREA CO., LTD. (Yokogawa B/D, Yangpyeong-dong 4-Ga), 21, Seonyu-ro 45-gil, Yeongdeungpo-gu, Seoul, 07209, KOREA Phone : 82-2-2628-6000 Fax : 82-2-2628-6400 YOKOGAWA ENGINEERING ASIA PTE. LTD.

Table of Contents
