Connecting Rs232 - Automation Direct DL305 Instruction

Wiring Diagram: Outputs
PLC DL 405 Type D4-450CPU

Connecting RS232

B3
A2 A3 A4 A5
DN25TB
DIP SWITCH CONFIGURATION
PORT 1 DL 305 D3-350
PORT 1 DL 405 D4-450
PORT 1 DL 405 D4-430
PORT 1 DL 405 D4-440
Pg. 2
TERMINAL BLOCK
DN25TB
RS 232 Configuration
1 2 3 4
On
Off
Cable ZL-DN25TB-CBL
Terminal
DSub 25-P
Block 25-P
1 A1
A2
2
3 A3
4 A4
5 A5
6 A6
7 B3
A7
8
B4
9
10 B1
11 C5
12 A8
A9
13
B5
14
B6
15
16 B2
17 B7
18 C1
19 C4
20 B8
21 B9
22 C6
C2
23
C7
24
C8
25
RS 232
REV 1.2
