Appendix A: GPI/O Programming Guide

a a: GPI/o P
PPendIx
GPI/O (General Purpose Input/Output) pins are provided for custom system
design. This appendix provides definitions and its default setting for the ten
GPI/O pins in EBC 357X. The pin definition is shown in the following table:
PowerOn
Pin GPI/O mode
Default
1 VCC -
3 GPO0 Low
5 GPO1 Low
7 GPO2 Low
9 GPO3 Low
Control the GPO 0/1/2/3 level from I/O port A03h bit-6/ A02h bit-5/
A07h bit-0/ A07h bit-1.
The bit is Set/Clear indicated output High/Low.
