Chapter 2: Jumpers and Connectors

GPIO Connector

Connector type: 2x5 10-pin header, 2.0mm pitch
Connector location: JP5
2 10
1 9
Pin Definition
1 +5V_IO
3 ICH_GPO0_OUT
5 ICH_GPO1_OUT
7 ICH_GPO2_OUT
9 ICH_GPO3_OUT
Copyright © 2016 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 GND
4 ICH_GPI0_IN
6 ICH_GPI1_IN
8 ICH_GPI2_IN
10 ICH_GPI3_IN

COM Port 1 (RS232)

Connector type: 1x10 10-pin header, 1.0mm pitch
Connector location: J6
10 1
Pin Definition
1 SP1_DCD
3 SP1_TXD
5 GND
7 SP1_RTS
9 SP1_RI
16
Pin Definition
2 SP1_RXD
4 SP1_DTR
6 SP1_DSR
8 SP1_CTS
10 GND
