Summary of Contents for Clarke PLS135AH
- Page 1 POWER WASHER MODEL NO: PLS135AH/PLS200AH/ DLS200AL/PLS165AH OPERATION & MAINTENANCE INSTRUCTIONS LS0818 - ISS 10...
- Page 2 Under the Terms of this Warranty, any repair or replacement can only be carried out by Clarke International Limited, or one of our authorised dealers. Where possible any machine requiring attention should be returned to the dealer from whom it was purchased.
-
Page 3: General Safety Precautions
• When using the chemical injection facility, use only the chemical cleaning agents (detergents) that are approved for power washers. CLARKE Traffic Film Remover or CLARKE Wash and WAX (available from your dealer), is recommended. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 4 ASSEMBLY AND PREPERATION FOR USE • A - Pressure Regulator Knob • B - Low Pressure Water Inlet • C - High Pressure Water Outlet • D - Pressure Guage • E - Unloader Valve • F - Detergent Hose 1.
-
Page 5: Operation
OPERATION 1. Turn the water supply fully ON at the mains. 2. Refer to the engine handbook, and start the engine. Move the speed lever to MAX. 3. To set the lance at high pressure, turn the hand grip of the lance clockwise (i.e. screwed 'IN'). - Page 6 NOTE: ONLY use detergents designed for use with power washers. We recommend the use of CLARKE Traffic Film Remover. When detergent injection is required, screw the lance hand grip out (anticlockwise), to the low pressure setting, and the detergent will automatically be drawn into the water supply.
-
Page 7: Maintenance
Change the oil after the first 50 hours of service and every 500 hours thereafter. DO NOT attempt to carry out any mechanical repairs yourself. Please contact your CLARKE dealer for servicing and repairs. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 8 PARTS LIST ( PLS200AH & DLS200AL) Description Part No. Description Part No. Engine (200AH) 11HP 8000081 Washer M8 3044582 Engine (200AL) 11HP 8000818 Washer M8 3044582 Pump AR20001 Screw M8 3044506 Frame 8050490 Engine Bracket 8050700 Screw 3040526 Anti Vibration Mount 8950357 Washer 3040583...
-
Page 9: Parts Diagram
PARTS DIAGRAM ( PLS200AH & DLS200AL) Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 10 PARTS LIST (PLS135AH & PLS165AH) Description Part No. Description Part No. Engine (135AH) 8000002 Chemical Filter (165AH) AR15509 Engine (165AH) 8000004 Anti Vibration Mount 8950357 Pump (135AH) AR13001 Plastic Foot 2100302 Pump (165AH) AR16001 Knob M8x50 3044531 Frame 8050480 Washer...
- Page 11 PARTS DIAGRAM (PLS135AH & PLS165AH) Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 12: Specifications
SPECIFICATIONS PLS135AH PLS165AH PLS200AH DLS200AL Engine Type Honda Honda Honda Honda Engine Rating 5.5 HP 6.5 HP 11 HP 8.5 HP Engine Speed 3400 RPM 3400 RPM 3400 RPM 3400 RPM Max. Pressure 120 Bar 150 Bar 200 Bar 200 Bar Max. -
Page 13: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 14 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
- Page 15 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
