Check It Panel
1 Phase Simplex Demand Dose
Operation, Maintenance & Installation Manual

Introduction

Before proceeding with the installation or operation of the control panel read all instructions thoroughly,
as well as comply with all Federal, State and Local Codes, Regulations and Practices. The control panel
:must be installed by qualified personnel familiar with all applicable local electrical and mechanical
codes.Refer to the National Electrical Code (NFPA 70). Failure to properly install and test this product can
result in personal injury or equipment malfunction. All conduit connected to the panel must be sealed
with conduit sealant to prevent moisture or gases from entering the panel. NEMA 1 enclosures are for
indoor use only while NEMA 4X panel enclosures may be used indoor or outdoor. Refer to panel model
name plate on inside of door for enclosure rating. Note: If options are ordered that affect the number of
floats, refer to the panel schematic for complete information.

Safety Guidelines

1. DO NOT USE WITH FLAMMABLE OR EXPLOSIVE FLUIDS SUCH AS GASOLINE, FUEL OIL, KEROSENE,
ETC. DO NOT USE IN EXPLOSIVE ATMOSPHERES. CONTROL PANEL SHOULD ONLY BE USED IN
WATER AND WASTEWATER APPLICATIONS THAT ARE NOT RATED AS A HAZARDOUS LOCATION.
2. DO NOT WORK ON THE CONTROL PANEL WITH LIVE VOLTAGE APPLIED TO THE CONTROL PANEL
WITH WET HANDS OR WHEN STANDING ON A WET SURFACE.
3. DISCONNECT ALL ELECTRICAL SERVICE BEFORE WORKING ON OR HANDLING THE CONTROL PANEL
4. INCOMING VOLTAGE MUST MATCH THE CONTROL PANEL VOLTAGE. REFER TO THE PANEL SCHE-
MATIC FOR COMPLETE INFORMATION.

Installation of the Control Panel:

1. Determine mounting location for the control panel. Attach the 4 mounting feet to the
control panel enclosure. If splicing is required between the level switches and the panel,
we recommend an Alderon Junction box. CAUTION! Use conduit sealant and waterproof
wire nuts for connections. Make sure all connections are water tight.
2. Determine conduit entrance locations on control panel and install per local codes. Check
schematic and determine number of power sources required. Use conduit sealant on all conduits
to prevent moisture and gases from entering control panel.
3. Connect control/alarm and pump power conductors to the proper terminals. The sche
matic and terminal blocks will be labeled for proper connection.
4. Verify correct panel operation after installation of panel, power and level switches are
complete.
