Neopost IM280 iMeter Replacement Part Manual

Scale, Power Adapter & Power Cable, Internet Adapter & Internet Cable,
The following steps will guide you through the removal and installation of the Scale, Power Adapter &
Power Cable, Internet Adapter & Internet Cable, Phone Modem & Phone Cable, and Base Door.
1. Disconnect the power cable from the wall outlet.
2. Remove the old scale from the base.
3. Disconnect the old scale's cable from the port of the
IS / IM280 iMeter™.
4. Remove the new scale from the shipping package.
5. Connect the new scale's cable to the port of the
IS / IM280 iMeter™.
6. Tuck the new scale's cable into the component cavity.
7. Place the new scale onto the system aligning the
scale's feet with the base's indentations.
8. Connect the power cable to the wall outlet.
1. Disconnect the old power cable from the wall outlet.
2. Disconnect the old power adapter from the
IS / IM280 iMeter™.
3. Remove the new power adapter and power cable
from the shipping package.
4. Connect the new power cable to the new power
adapter as shown.
5. Connect the new power adapter to the IS / IM280
iMeter™.
6. Insert the plug of the new power cable into the wall
outlet. This will turn on the IS / IM280 iMeter™.
© 2011 Neopost USA Inc. All rights reserved. No part of this document may be reproduced or distributed in any form or by any means.
IS / IM280 iMeter™ Postage Meter
Replacement Part Guide
Phone Modem & Phone Cable, and Base Door
For interactive step by step instructions, visit:
www.neopostinc.com/280helpdesk
www.haslerinc.com/280helpdesk

Scale Replacement

Power Adapter & Power Cable Replacement
(For Neopost Customers)
(For Hasler Customers)
Power Cable
IS / IM280 iMeter™
Postage Meter
(Back View)
Scale
IS / IM280 iMeter™
Postage Meter
(Back View)
Power
Adapter
