Operation
™
Pro Pack
- For use with Graco hand-held sprayers (except Fine-Finish sprayers) -
- For portable spray applications of water-based and oil-based (mineral spirit-type)
IMPORTANT SAFETY INSTRUCTIONS
For complete warnings and safety
instructions, see sprayer manual.
Model 24F893
Maximum Working Pressure 12 psi (0.83 bar, 0.083 MPa)
FIRE AND EXPLOSION HAZARD
Use only water-based or oil-based (mineral spirit-type) materials with flash point greater than 100° F
(38° C). Do not use materials which state "FLAMMABLE" on the packaging. For more information about
your material, request MSDS from distributor or retailer.
Use oil-based material outdoors or in a well-ventilated indoor area with a flow of fresh air.
Portable Spray Pack
architectural paints and coatings only -
- Not approved for use in explosive atmosphere locations -
WARNING
WARNING
WARNING
WARNING
3A1292C
ti16502a
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pro Pack 24F893 and is the answer not in the manual?

Questions and answers

Related Manuals for Graco Pro Pack 24F893

Summary of Contents for Graco Pro Pack 24F893

  • Page 1 Pro Pack Portable Spray Pack 3A1292C - For use with Graco hand-held sprayers (except Fine-Finish sprayers) - - For portable spray applications of water-based and oil-based (mineral spirit-type) architectural paints and coatings only - - Not approved for use in explosive atmosphere locations -...
  • Page 2 Component / Replacement Kit Identification Component / Replacement Kit Identification ti16522a Ref. Part Description Ref. Part Description 24J692 Lid with seals 115489 Hose clamp 24H366 Reservoir liners (5) 24H367 Gasket kit 16P667 G2 adapter plate (for use with models 125026 Grommet 16N657, 16M886, 16N664, 16N665, 115099...

  • Page 3: Before You Start

    Before You Start Before You Start 6. Connect battery and place inside air compressor. The ProPack Portable Spray Pack is shipped with a bat- tery inside the air compressor which must be connected before operation. 1. Remove contents from backpack including any packing materials.

  • Page 4: Setup Instructions

    Before You Start Setup Instructions 7. Thread suction hose nut (S) onto lid assembly and hand tighten. Insert drain hose (H) onto lid assembly barb and secure with clamp. 1. Perform Pressure Relief Procedure (see sprayer manual). 2. Remove sprayer battery or unplug sprayer. 3.
  • Page 5 Before You Start 10. Place reservoir into backpack. NOTE: The air com- 13. Place backpack system on operator. You are now pressor always needs to be on while the sprayer is ready to spray! in operation (if the light is on, the air compressor is on).
  • Page 6 Clean-up (Power Flush) Clean-up (Power Flush) NOTE: Be sure to aim the drain hose into a waste container when squeezing trigger to prevent spilling water and material. This procedure is for water-based architectural NOTICE paints and coatings only. If the drain hose is not thoroughly cleaned, it can CAUTION become plugged due to paint buildup.
  • Page 7 Clean-up (Non-Power Flush) Clean-up (Non-Power Flush) 5. Remove drain hose from reservoir lid and aim it into a waste container. This procedure is for water-based and oil-based (mineral spirit-type) paints and coatings only. CAUTION System is pressurized. Failure to properly depressur- ti17159a ize system will result in material discharging from hose and possible injury.
  • Page 8 Clean-up (Non-Power Flush) 9. Remove lid from reservoir. Rinse out reservoir. Dis- Belt Strap assemble lid, suction tube and strainer then rinse. Pull belt straps to tighten around waist. NOTE: Always follow local and state regulations when disposing material. ti16694a 10.

  • Page 9: Troubleshooting

    Troubleshooting Troubleshooting Problem Cause Solution Sprayer loses prime or poor spray pat- Low material level Refill reservoir and re-pressurize. tern Incorrect priming procedure Place back pack on floor, hold sprayer at approximately chest level and prime sprayer until material just begins to fill the drain hose (approximately 1ft).

  • Page 10: Graco Standard Warranty

    With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
