Configuring Alarms - ADC Campus-REX RS Interface Card User Manual

C
ONFIGURING
You can configure four different alarm options:
•
HDSL ES Alarm Threshold determines the number of errored seconds
that must occur to trigger an alarm
• HDSL Margin Alarm Threshold determines the margin, in dB, that
triggers an alarm
•
Alarm on Local I/F LOS lets you enable or disable the local Loss of
Signal alarm
•
Alarm on Remote I/F LOS lets you enable or disable the remote Loss of
Signal alarm
To configure the alarm options:
1 From the Main Menu, type
Menu displays.
May 3, 1999
Local Unit ID:
Remote Unit ID: Campus-REX Unit #12
Circuit ID:
1) SYSTEM PARAMETERS
2) HDSL PARAMETERS
ENTER CHOICE>
2 Type 1
Campus-REX RS Interface Card User Manual
A
LARMS
ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx
Campus-REX Unit #34
Network Extension Circuit 5001
SYSTEM SETTINGS MENU
then press ENTER
Configuring with an ASCII Terminal
3 ENTER
then press
Local I/F:
Remote I/F: REX
(R)eturn
. The System Parameters menu displays.
. The System Settings
13:18:41
REX
5-15
