Set Up the Campus-REX System
1 From the HDSL Parameters menu, type
HDSL Operating Mode options changes from Standard Mode to

Extended Mode.

Dec 9, 1999
Local Unit ID:
Remote Unit ID: Campus-REX Unit #12
Circuit ID:
1) HDSL OPERATING MODE:
2) TRANSCEIVER MODE:
3) HDSL LOOP MODE:
4) HDSL RATE:
*Note:
Changes will not be effective until this menu is exited!
ENTER CHOICE>
2 To change the HDSL Loop Mode, type
step until the desired HDSL Loop Mode setting displays.
3 Type 4
3-14
ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx
Campus-REX Unit #34
Network Extension Circuit 5001
EXTENDED MODE HDSL PARAMETERS
Extended
Auto
2 Loops
256
1 Loop = single loop, full duplex
2 Loops = two loops, full duplex
(R)eturn
then press ENTER
1
then press
Local I/F:
Remote I/F: REX
(Standard, Extended)
(Master, Slave, Auto)
(1 Loop, 2 Loops)
(M)ain Menu
3 then press
. The Select HDSL Rate menu displays.
Campus-REX RS Interface Card User Manual
ENTER
. The
13:19:32
REX
ENTER . Repeat this
