Configuring with an ASCII Terminal
Dec 9, 1999
Local Unit ID: Campus REX Unit #34
Remote Unit ID: Campus REX Unit #12
Circuit ID:
1) HDSL Operating Mode:
2) Transceiver Mode:
3) HDSL Rate:
Changes will not be effective until this menu is exited!
ENTER CHOICE>
3 Type 2
new Transceiver Mode setting. Repeat this step until the desired setting
displays.
5-14
ADC DSL SYSTEMS INC., CAMPUS RS, Version x.xx
STANDARD MODE HDSL PARAMETERS
Standard
Auto
T1
(R)eturn
then press ENTER
Local I/F:
Remote I/F: REX
(Standard, Extended)
(Master, Slave, Auto)
(768, T1, E1)
(M)ain Menu
. The HDSL Parameters menu displays the
Campus-REX RS Interface Card User Manual
00:27:03
REX
