You manage loopbacks through the DIAGNOSTICS menu:
1 Press Escape until CAMPUS RS I/F: REX displays.
2 Press Next four times. DIAGNOSTICS displays.
3 Press Enter. LOOPBACK MODE displays.
The following sections describe how to initiate and clear loopbacks, and to
set a loopback timeout.

Initiating a Loopback

To initiate a loopback condition:
1 From the LOOPBACK MODE display, press Enter.
2 Press Next to scroll through the loopback options until the desired
loopback condition displays.
3 Press Enter to initiate the loopback. LOOPBACK MODE displays.

Clearing a Loopback

To clear a loopback condition:
1 From the LOOPBACK MODE display, press Enter.
2 Press Next to scroll through the loopback options until NONE displays.
3 Press Enter to clear the loopback. LOOPBACK MODE displays.
