Xylem Lowara Presfix Beta MK2 Operating And Maintenance Instructions Manual

Dual System Pressurisation set
Operating and Maintenance Instructions
EC Declaration of conformity
Xylem Water Solutions UK Limited declare that the Presfix pressurisation set conforms to the requirements of
the Machinery Safety Directive
Electromagnetic Compatibility (EMC) Directive
Conforming to the UK Health & Safety Requirements
Water supply (Water fittings) regulations
Code of practice for heating and chilled water systems
Signed:
t
Clive Willmot

Introduction

This leaflet contains information to enable the safe installation and operation of the products mentioned above.
The following instructions must be read and understood by all persons responsible for the installation, operation
and maintenance of this product.

Warning Symbols

Safety instructions where noncompliance would affect safety.
Safety instruction where electrical hazard is involved.
Safety instruction where noncompliance could cause damage to the equipment.

Instruction for safe use

This product has been designed for the pressurisation of sealed heating, chilled water and closed-
condenser water systems to the operating conditions shown.
This product should not be installed until this leaflet has been studied carefully.
Handling, transportation and installation of this equipment should only take place with the proper
use of lifting equipment.
This product must be stored in a frost-free dry environment.

Noise Emissions

This equipment operates at a noise level lower than
Protection degree
Ambient temperature
Maximum system operating pressure:
PRESFIX Beta MK2
Position: Engineering manager
2006/42/EC.
2014/30/EU
2008 No.1597
1999
BS7074 (parts 1, 2 & 3)
Date: 20-04-2016 Revision B
70dBA.
IP54
4-30°C
2.8 & 5.5 units (10 bar) 8.0 units (13 bar)
1
