- Page 1 Installation and Maintenance Micro 10 Polyethylene packaged pumping station for lifting waste water...
-
Page 2: Table Of Contents
FOREWORD This manual must remain available close to the machine/installation. All work carried out must be undertaken by professional personnel. Current national regulations and local safety and hygiene requirements must be complied with. Disclaimer Design modifications may have been carried out on technical characteristics. -
Page 3: Safety
SAFETY This manual contains essential information Security instructions to be followed by on installation, operation and maintenance. the operator / user These instructions must be meticulously fol- Current national regulations and local safety lowed. Installation and maintenance person- and hygiene requirements must be complied nel must read these instructions carefully with. - Page 4 SAFETY Safety instructions DANGER (Gas, dust, fumes, smoke) The rules set out below must be scrupu- lously adhered to in order to reduce accident Before any work on the risks during servicing, installation and main- equipment, authorisation tenance. must be obtained. Gases may form within the - Ensure that electrical equipment is discon pumping station and...
-
Page 5: Guarantee
GUARANTEE Lowara undertakes to remedy any defect This guarantee does not therefore apply to which may be presented by the products defects resulting from lack of maintenance, sold by their intermediary subject to: inappropriate installation, repairs incorrectly carried out or normal wear and tear. - The defect resulting from a design, materials or manufacturing fault Lowara moreover declines any responsibility... -
Page 6: Technical Characteristics
TECHNICAL CHARACTERISTICS Applications Weight The Micro 10 is delivered completely assem- Micro 10 1300 mm 130 Kg bled and ready to be put into service. Micro 10 2000 mm DN 50 150 Kg This pumping station is intended for pumping Micro 10 2000 mm DN 65 210 Kg raw sewage, black water with or without par- Riser 350 mm 23 Kg... - Page 7 TECHNICAL CHARACTERISTICS The pumping station is not intended for use in an explosive environment or for inflammable liquids PUMPS ø DISCHARGE REFERENCE DXGM 25-11 58 60 670 DXVM 50-11 58 60 210 DXVM 50-7 58 60 900 DXM 50-7 58 60 240 MICRO DP 3045 MT 234 58 60 170...
- Page 8 TECHNICAL CHARACTERISTICS Figure 1. Dimensions (Dimensions in mm) Opening Ø 800 Opening Ø 800 TRANSPORT, UNLOADING AND STORAGE Transport: Checks: 1. Ensure the tank never comes into contact Before installation or storage, check that the with sharp edges. Polyethylene tank and internal pipework are 2.
-
Page 9: Installation
INSTALLATION Installation of the pumping station is always Filling: under the entire responsibility of the firm in Important: during filling, ensure that the tank charge of the installation. General informa- is vertical. tion and instructions in accordance with EN 976-2:1997 Fill material must have a granulosity of be- tween 2 and 36 mm. - Page 10 INSTALLATION Connection of inlet pipe (fig 2) Fig 2 • Fix the self-adhesive drill former on the drill Gasket area (flat piece shown) Tank • Drill the tank with a jigsaw or similar • Fit gasket Ø160 • Chamfer exterior of tube Ø160 •...
- Page 11 INSTALLATION Ventilation Ventilation This can be mounted on the upper part of one Fig. 6 of the two flat pieces 1. Drill a hole of the same dimensions as your ventilation pipe. 2. Connect the ventilation duct using a gasket (equipment not provided) (fig 6) Note: Ventilation duct and electrical connections...
-
Page 12: Cam Locking Mechanism Option
CAM LOCKING MECHANISM OPTION • Take the cover and drill a Ø 21 mm hole in the centre of the hollow cylindrical shape provided for the locking mechanism • Insert the upper part of the barrel (1) in the hole which has been drilled (the triangular shape of the barrel should be outside the cover) as indicated in the diagram below. -
Page 13: Electrical Connection
ELECTRICAL CONNECTIONS All electrical work is to be Information for the electrician connecting the carried out under the Micro 10 pumpstation. supervision of an autho rised electrician. When making connections inside the station, Strictly comply with local do not forget that this is a humid environ- codes and regulations. -
Page 14: General Arrangement
GENERAL ARRANGEMENT 23 24 22 24... -
Page 15: List Of Spare Parts
GENERAL ARRANGEMENT Inlet drilling for pvc tube Ø 150 with gasket Discharge 2 pvc LIST OF PARTS Figure DESIGNATION REMARKS Tank polyethylene Cover polyethylene Cover gasket epdm Cover locking system cam type Plug polyethylene Keyed joint Ø 160 ext. epdm Dn50 pump (material according to type) Dn50 mounting base... -
Page 16: Declaration Of Conformity
DECLARATION OF CONFORMITY... - Page 17 Xylem is headquartered in White Plains, N.Y., with 2011 revenues of $3.8 billion and 12,500 employees worldwide. The name Xylem is derived from classical Greek and is the tissue that transports water in plants, highlighting the engineering efficiency of our water-centric business by linking it with the best water transportation of all -- that which occurs in nature.
