Operating, Installation and Maintenance Instructions
EC Declaration of conformity
Xylem Water solutions UK Ltd declare that the Micro Presfix pressurisation set conforms to the:
Requirements of the Machinery Safety Directive
Electromagnetic compatibility (EMC) Directive
Conforming to the UK Health & Safety Requirements
Water supply (Water fittings) regulations
Code of practice for heating and chilled water systems
Signed:
t
Clive Willmot
Introduction
This leaflet contains information to enable the safe installation and operation of the products mentioned above.
The following instructions must be read and understood by all persons responsible for the installation, operation
and maintenance of this product.
Warning Symbols
Safety instructions where noncompliance would affect safety.
Safety instructions where electrical hazard is involved.
Safety instructions where noncompliance could cause damage to the equipment.
Instruction for safe use
This product has been designed for the pressurisation of sealed heating, chilled water and
closed-condenser water systems to the operating conditions shown.
This product should not be installed until this leaflet has been studied carefully.
Handling, transportation and installation of this equipment should only take place with the proper use
of lifting equipment.
This product must be stored in a frost-free dry environment.
Micro PRESFIX
Pressurisation Set
2006/42/EC.
2014/30/EU
2008 No.1597
1999
BS7074 (parts 1, 2 & 3)
Position: Engineering manager
Date: 13-01-2017
