Included Accessories - Keysight 10076C Manual

Mains Isolated
3,700 Vpk
CAT II
1,000 Vpk
100 Vpk
10 Vpk
100 KHz
Probe Derating Curve (frequency limits measurable voltage)
6
1
4

Included Accessories

Item Description
1 Retractable Hook Tip Adapter
2 Ground Lead
3 Insulation Cap
4 Measuring Pin
5 Identification Tags
6 Spring Ground Tip (order N2789A)
NOTE: Items 1-5 are included in the 10077A replacement accessory kit. Order N2789A
for a replacement spring ground tip (qty 1).
When using any accessory, the probe assembly-accessory combination is only rated for
measurements on mains isolated circuits, not CAT II, III, or IV circuits.
1 Mhz
5
3
Maximum input
Mains Isolated: 3700 Vpk
CAT II: 1000 Vpk
10 MHz 100 MHz
2
1,000 MHz
This yellow part:
Adjust C to stabilize gain
covering frequency range
Qty
1
1
1
2
8
1
