Characteristics
System Bandwidth
System Risetime (Calculated)
Attenuation Ratio
Input Resistance
(when terminated into 1 M
Input Capacitance
Maximum Input
(pollution degree 2)
Compensation Range
Probe Readout
Operating Temperature
Humidity
Shock
Propagation Delay
Altitude
Keysight 10076C
High Voltage Probe
• 500 MHz when used with 500 MHz bandwidth
• Oscilloscope bandwidth when used with oscilloscope
• < 0.7 n sec when used with 500 MHz oscilloscope
• Oscilloscope risetime when used with oscilloscope
100:1
66.7 M
Ω
)
≈
3 pF
3700 Vpk (2650 V rms ) (mains isolated)
2650 Vdc (mains isolated)
1000 Vpk (dc + ac peak) CAT II (post receptacle mains)
DO NOT connect to a circuit above these maximums.
6 - 18 pF
Yes
0 °C to 50 °C
90% RH Non-condensing
400g 1/2 sine wave on tip end
50g 1/2 sine wave on BNC end
≈
8 ns (1.8 m probe cable length)
3000 m (indoor use only)
oscilloscope
≤
with
150 MHz bandwidth
≤
with
150 MHz bandwidth
Ω
Advertisement
Table of Contents
Related Manuals for Keysight 10076C
Summary of Contents for Keysight 10076C
- Page 1 Keysight 10076C High Voltage Probe Characteristics System Bandwidth • 500 MHz when used with 500 MHz bandwidth oscilloscope • Oscilloscope bandwidth when used with oscilloscope ≤ with 150 MHz bandwidth System Risetime (Calculated) • < 0.7 n sec when used with 500 MHz oscilloscope •...
- Page 2 Mains Isolated Maximum input 3,700 Vpk Mains Isolated: 3700 Vpk CAT II: 1000 Vpk CAT II 1,000 Vpk 100 Vpk 10 Vpk 100 KHz 1 Mhz 10 MHz 100 MHz 1,000 MHz Probe Derating Curve (frequency limits measurable voltage) This yellow part: Adjust C to stabilize gain covering frequency range Included Accessories...
- Page 3 On receiving the shipment, inspect the probe and its accessories. If there is a mechanical damage or a defect, or if the probe does not operate properly or pass calibration tests, notify your Keysight Technologies Sales Office. Verifying the Ground Level The GND level can be confirmed when the probe is connected to the signal line.
- Page 4 WEEE Directive Annex I, this product is classed as a “Monitoring and Control instrumentation” product. Do not dispose in domestic household. To return unwanted products, contact your local Keysight office, or refer to www.keysight.com for more information. © Keysight Technologies 2014, 2018...
