Keysight V8486A Power Sensor User’s Guide...
Page 2
Declarations of Conformity for this product ceed beyond a CAUTION notice until the indi- the DFARS and are set forth specifically in and for other Keysight products may be down- cated conditions are fully understood and met. writing elsewhere in the EULA. Keysight shall loaded from the Web.
This Keysight Technologies instrument product is warranted against defects in material and workmanship for a period of 3 years from date of shipment. During the warranty period, Keysight Technologies will at its option, either repair or replace products which prove to be defective. For warranty service or repair, this product must be returned to a service facility designated by Keysight Technologies.
Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards for design, manufacture, and intended use of the instrument. Keysight Technologies assumes no liability for the customer’s failure to comply with these requirements.
Environmental Conditions The V8486A is designed for indoor use and in an area with low condensation. The table below shows the general environmental requirements for this instrument. Environmental cond ition Requirement Operating condition – 0 °C to 55 °C Temperature Storage condition –...
To return this unwanted instrument, contact your nearest Keysight Service Center, or visit http:// about.keysight.com/en/companyinfo/environment/takeback.shtml for more information. Sales and Technical Support To contact Keysight for sales and technical support, refer to the support links on the following Keysight websites: – www.keysight.com/find/waveguidepowersensors (product-specific information and support, software and documentation updates) –...
Page 8
List of Figures Figure 1-1 Keysight V8486A power sensor with accessories and hardware ..10 Figure 2-1 Precision V-band interface on the front of the power sensor ..17 Figure 2-2...
Page 9
Keysight V8486A Power Sensor User’s Guide Introduction General Information Installation Storage and Shipment This chapter provides an overview of the V8486A power sensor and its general information.
Any attempt to disassemble the power sensor will void warranty. Description The Keysight V8486A is a diode-based power sensor. It measures power levels in a range from –30 dBm to +20 dBm. (Specifications for the power sensor are in Table 3-1.) The Keysight V8486A...
The firmware revision required is A1.03.00 (or above) for the Keysight E4418A and A2.03.00 (or above) for the Keysight E4419A. Contact your local Keysight Technologies Sales and Service Office for more information.
Keysight Technologies representative. Interconnections and calibration The Keysight V8486A power sensor has two inputs: a Type-N connector and a waveguide flange. During calibration, the Type-N connector is connected to the calibration port of the power meter.
Containers and materials identical to those used in factory packaging are available through Keysight Technologies offices. If the instrument is being returned to Keysight Technologies for servicing, attach a tag indicating the type of service required, return address, model number, and serial number.
Page 14
Introduction THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK. Keysight V8486A User’s Guide...
Page 15
Keysight V8486A Power Sensor User’s Guide General Operation Operation This chapter provides the V8486A general operation information on how to check and prepare your instrument for operation.
SWR and change the Cal Factor. The Type-N connector plastic bead deteriorates when contacted by any chlorinated or aromatic hydrocarbons such as acetone, trichlorethylene, carbon tetrachloride, benzene, etc. Clean the connector face with a cotton swab saturated in isopropyl alcohol. Keysight V8486A User’s Guide...
If you are using a Keysight 435B or Keysight 436A, the minimum cal factor setting is 85% and the maximum is 100%. If the cal factor setting for your frequency of interest is below the meter's minimum or above the meter's maximum, set the cal factor control to 100%, and divide the reading in watts units by the decimal equivalent of the cal factor.
When measuring microwave sources that are modulated at the chopper frequency (nominally 220 Hz for the Keysight 43X family and 217 Hz for the Keysight E4418A/B and Keysight E4419A/B), or at the first or second harmonic or submultiples of the chopper frequency, beat notes will occur.
Page 20
Keysight E4419B Press [System Inputs], Tables, A Linearity ATyp DTyp or B Linearity ATyp DTyp. For use with the Keysight E4418A and Keysight E4419A power meters, a firmware upgrade will NOTE be required. Refer to your Keysight E4418A and Keysight E4419A power meter’s user’s guide for instructions on how to obtain the revision of the firmware currently installed in the unit.
Page 21
Keysight V8486A Power Sensor User’s Guide Specifications and Characteristics Specifications and Characteristics Calibration Factor (CF)
Specifications and Characteristics Specifications and Characteristics For the characteristics and specifications of the V8486A Power Sensor, refer to the datasheet at https://literature.cdn.keysight.com/litweb/pdf/5991-3676EN.pdf. Keysight V8486A User’s Guide...
Calibration factor uncertainty at 1 mW (0 dBm) ISO expanded uncertainty % Frequency (GHz) (coverage factor k=2) [a] Refer to Application Note 64-1A: Keysight literature number 5965-6630E, “Fundamentals of RF and Microwave Power Measurements” for more information regarding ISO expanded uncertainty. Keysight V8486A User’s Guide...
Page 24
Specifications and Characteristics THIS PAGE HAS BEEN INTENTIONALLY LEFT BLANK. Keysight V8486A User’s Guide...
Keysight V8486A Power Sensor User’s Guide Service Performance Tests Replaceable Parts This chapter provides information on the V8486A performance tests and service.
Keysight V752C/D. The detector should have greater than 0.4 mV/μW sensitivity and should be calibrated with a rotary vane attenuator with an accuracy of 2%. Incident power should be less than +20 dBm. A convenient source is a frequency multiplier driven by a Keysight 8360 B-Series swept signal generator.
Service 2 Warm up the DUT for approximately 30 minutes. 3 Launch the Interactive IO on the Keysight IO Libraries Suite to send SCPI commands to the DUT. 4 Reset the power meter to a known state by sending "*RST" command, followed by "SYST:PRES"...
Page 29
The RSS error specification calculation is computed by using following equation. System linearity error specification DUT error Ref sensor error Example for the DUT measured at 50 Mhz, 20 dBm: – DUT used is V8486A – Reference sensor used is N8481A System linearity error specification (2%) (0.8%) ±...
Do not attempt to repair or adjust the power sensor. Due to the extreme static sensitivity of the power sensor, customer repair is not recommended. If your power sensor should fail or need calibration, return it to Keysight Technologies. Do not disassemble the power sensor. The power sensor is extremely static sensitive and CAUTION can be easily damaged.
