P C 9 / P 9 B e z e l R e p l a c e m e n t

Introduction

These instructions explain how to replace the bezel in the PC9 Industrial
PC or P9 PowerStation. The bezel is the front part of the unit that encloses
the display screen. This documentation includes instructions for replacing
touchscreen and non-touchscreen bezels. The instructions explain how to
disassemble the unit, remove the old bezel, install a new bezel, and reas-
semble the unit.
Warning
Warning
To complete this procedure, you will need the following items:
•
•

Disassembling the Unit

To disassemble the unit, follow these steps:
1. Turn off the unit.
2. Disconnect the unit from the power source.
3. Disconnect all cables attached to the unit.
4. Remove the unit from its enclosure, and place it on a static dissi-
pative mat in a location free from dirt and moisture and protected
against static discharge.
CTC Parker Automation
For safety reasons, the unit should be opened only by qualified
service personnel.
Be sure to observe electrostatic discharge (ESD) precautions
while working inside the unit.
Bezel kit that you purchased:
• P9/PC9 Non-touchscreen Bezel Kit for use with 12" display
units (BZK-1200)
• P9/PC9 Non-touchscreen Bezel Kit for use with 15" display
units (BZK-1500)
• P9/PC9 Touchscreen Bezel Kit for use with 12" display
units (BZK-1201)
• P9/PC9 Touchscreen Bezel Kit for use with 15" display
units (BZK-1501)
Phillips-head screwdriver
A3-06055-100
