CTC Parker Automation PS SERIES Replacement

PS S

Introduction

If the glass on the 10-inch displays is damaged, the enttire bezel must be replaced in order to maintain
the seal around the glass. The following instructions explain how to replace the bezel.

Before You Start

You will need the following items:
•
Bezel Replacement kit Model BZK-1001
•
Bezel Replacement instructions
•
Screwdriver

Precautions

The following precautions are essential during the installation of sensitive components:
Warning
Warning

Electrostatic Discharge Precautions Preparation

Important Open the Electrostatic Discharge Kit and follow the directions for attaching the wrist strap and
handling sensitive electronic components.
Bezel Replacement

Open the unit

To open the unit, follow these steps:
1. Turn off the unit.
2. Disconnect the unit from the power source.
3. Disconnect all cables attached to the unit.
Caution Before you complete the next step, you must wear an ESD wrist strap connected to a good, known,
earth ground to avoid damaging the unit.
Parker Automation – CTC
10-INCH B
ERIES
For safety reasons, the PowerStation should be opened only by qualified service
personnel.
Be sure to observe electrostatic discharge (ESD) precautions while working inside
the unit.
R
EZEL EPLACEMENT
A3-06421-100
