CTC Parker Automation PC9 Installation

P C 9 / P 9 D R A M I n s t a ll a t i o n

Introduction

These instructions explain how to install or replace DRAM modules in the
PC9 Industrial PC or the P9 PowerStation. They include steps for disas-
sembling the unit, removing previously installed DRAM module(s),
installing new DRAM, and reassembling the unit.
Warning
Warning
To complete this procedure, you will need the following items:
•
•

Disassembling the Unit

To disassemble the unit, follow these steps:
1. Turn off the unit.
2. Disconnect the unit from the power source.
3. Disconnect all cables attached to the unit.
4. Remove the four screws securing the back cover to the unit, as
shown at the top of the next page.
Note Screws 1 and 2 are located at the sides of the cover; screws 3 and 4 are in the
back of the cover.
CTC Parker Automation
For safety reasons, the unit should be opened only by qualified
service personnel.
Be sure to observe electrostatic discharge (ESD) precautions
while working inside the unit.
The DRAM module(s) that you purchased:
• 32MB SDRAM DIMM (DIM-9032)
• 64MB SDRAM DIMM (DIM-9064
• 128MB SDRAM DIMM (DIM-9128)
• 256MB SDRAM DIMM(DIM-9256)
Phillips-head screwdriver
A3-06025-100
