P C 9 / P 9 B e z e l R e p l a c e m e n t

Introduction

These instructions explain how to replace the bezel in the PC9 Industrial
PC or the P9 PowerStation. The bezel is the front part of the unit that
encloses the display screen. This documentation includes instructions for
replacing touchscreen and non-touchscreen bezels. The instructions
explain how to disassemble the unit, remove the old bezel, install a new
bezel, and reassemble the unit.
Warning
Warning
To complete this procedure, you will need the following items:
•
•

Disassembling the Unit

To disassemble the unit, follow these steps:
1. Turn off the unit.
2. Disconnect the unit from the power source.
3. Disconnect all cables attached to the unit.
4. Remove the unit from its enclosure, and place it on a static dissi-
pative mat, in a location free from dirt and moisture and protected
against static discharge.
CTC Parker Automation
For safety reasons, the unit should be opened only by qualified
service personnel.
Be sure to observe electrostatic discharge (ESD) precautions
while working inside the unit.
Bezel kit that you purchased:
• P9/PC9 Non-touchscreen Bezel Kit for use with 12" display
units (BZK-1200)
• P9/PC9 Non-touchscreen Bezel Kit for use with 15" display
units (BZK-1500)
• P9/PC9 Touchscreen Bezel Kit for use with 12" display
units (BZK-1201)
• P9/PC9 Touchscreen Bezel Kit for use with 15" display
units (BZK-1501)
Phillips-head screwdriver
A3-06055-102

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PC9 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CTC Parker Automation PC9

Summary of Contents for CTC Parker Automation PC9

  • Page 1 P C 9 / P 9 B e z e l R e p l a c e m e n t Introduction These instructions explain how to replace the bezel in the PC9 Industrial PC or the P9 PowerStation. The bezel is the front part of the unit that encloses the display screen.
  • Page 2 6. Swing the backshell away from the faceplate. 7. If you have a PC9, detach the two cables connecting the faceplate assembly and backshell, as shown in Figure 2. Then go to step 9. Figure 2: Disconnecting PC9 Cables...
  • Page 3 PC9/P9 Bezel Replacement 8. If you have a P9, detach the three cables connecting the faceplate assembly and backshell, as shown in Figure 3. Figure 3: Disconnecting P9 Cables Detach the Monitor card Detach the monitor cable backlight cable here...

  • Page 4: Replacing The Bezel

    P9 or PC9. Follow the instructions carefully. To replace the bezel, follow these steps: 1. Remove the 10 retaining screws (P9), or 3 retaining screws (PC9) around the outer monitor frame. 2. Lift the outer monitor frame off the bezel, and set it to one side.
  • Page 5 This cable is absent in non-touchscreen bezels. 6. Fasten the outer monitor frame in place with the 10 screws (P9), or 3 screws (PC9) that you removed in step 1 on page 4. Reassembling the Unit To reassemble the unit, follow these steps: 1.
  • Page 6 PC9/P9 Bezel Replacement CTC Parker Automation...
