P C 9 / P 9 H a r d D r i v e I n s t a l l a t i o n
Introduction
These instructions explain how to install or replace a hard drive in the PC9
Industrial PC or the P9 PowerStation. They include steps for disassem-
bling the unit, removing a previously installed hard drive, installing a new
hard drive, and reassembling the unit.
Warning
Warning
To complete this procedure, you will need the following items:
•
•
Disassembling the Unit
To disassemble the unit, follow these steps:
1. Turn off the unit.
2. Disconnect the unit from the power source.
3. Disconnect all cables attached to the unit.
4. Remove the two screws securing the backshell to the faceplate as-
sembly, as shown at the top of the next page.
CTC Parker Automation
For safety reasons, the unit should be opened only by qualified
service personnel.
Be sure to observe electrostatic discharge (ESD) precautions
while working inside the unit.
The hard drive replacement kit that you purchased:
• 3.2GB Hard Drive Replacement/Upgrade Kit for PC9/P9
(HDV-9003)
• 6.4GB Hard Drive Replacement/Upgrade Kit for PC9/P9
(HDV-9006)
Phillips-head screwdriver
A3-06023-100
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CTC Parker Automation PC9
Summary of Contents for CTC Parker Automation PC9
- Page 1 P C 9 / P 9 H a r d D r i v e I n s t a l l a t i o n Introduction These instructions explain how to install or replace a hard drive in the PC9 Industrial PC or the P9 PowerStation. They include steps for disassem- bling the unit, removing a previously installed hard drive, installing a new hard drive, and reassembling the unit.
- Page 2 PC9/P9 Hard Drive Installation Remove these screws 5. Swing the backshell away from the faceplate. 6. Detach the three cables connecting the faceplate assembly and backshell. These cables are shown below. Detach the Monitor card Detach the monitor cable backlight cable...
- Page 3 PC9/P9 Hard Drive Installation c. Detach the backlight cable from its connection on the monitor card (press down on the small tab on the lower half of the con- nector, and pull the cable out). 7. Remove the safety bracket below the upper hinge of the backshell by removing the screw that holds the bracket in place.
-
Page 4: Removing A Hard Drive
PC9/P9 Hard Drive Installation Removing a Hard Drive To remove a previously installed hard drive, follow these steps: 1. Locate the hard drive assembly in the upper right side of the main- tenance compartment, as shown below. Note The hard drive assembly consists of the hard drive and a metal bracket, into which the hard drive is fastened with four screws. -
Page 5: Installing A Hard Drive
PC9/P9 Hard Drive Installation Loosen these screws Loosen these screws Slide the hard drive assembly up and out of the unit 4. Slide the entire hard drive assembly up, and lift it over the retain- ing screws and out of the unit. - Page 6 PC9/P9 Hard Drive Installation To prepare for first installation of a hard drive, follow these steps: 1. Locate the power supply in the lower right portion of the mainte- nance compartment. The power supply is shown in the illustration on page 4.
- Page 7 PC9/P9 Hard Drive Installation BOTTOM OF THE PC9/P9 Remove screws 1, 2, 3, and 4 5. Disconnect any cables that might hinder installation of the new hard drive. These cables are shown in the illustration below. Monitor card Detach the video and...
-
Page 8: Installing The Hard Drive
PC9/P9 Hard Drive Installation 6. Insert, but do not tighten, the four retaining screws in the space provided for the hard drive in the upper right side of the service compartment. These screws will be provided in your Hard Drive Replacement/Upgrade Kit. -
Page 9: Reassembling The Unit
PC9/P9 Hard Drive Installation c. Replace the four screws that secure the power supply in place and that you removed in step 4 on page 6. Be sure to replace the nuts with screws 1 and 2. d. Re-attach the two sets of cables that you disconnected from the power supply in step 2 on page 6. - Page 10 PC9/P9 Hard Drive Installation CTC Parker Automation...
