Summary of Contents for ITRON OpenWay Riva
- Page 1 OpenWay Riva Leak Sensor Installation Guide Technical knowledge to shape your future Communications...
- Page 2 Suggestions For more information about Itron or Itron products, see www.itron.com. If you have questions or comments about the software or hardware product, contact Itron Technical Support Services. Contact •...
-
Page 3: Table Of Contents
Installing the OLS..........................10 Connecting the OLS......................... 11 Attaching a security seal ........................12 OpenWay Riva Leak Sensor (OLS) installation with a remote water module...........13 Installing the OLS with the remote Itron module................13 Appendix A Using Gel-cap Connectors............17 OpenWay® Riva Leak Sensor Installation Guide TDC-1691-003... -
Page 4: Chapter 1 Important Safety And Compliance Information
Itron device. Do not drop Warning: While Itron modules are designed to withstand a drop, dropping the module may damage the device and void the warranty. OpenWay® Riva Leak Sensor Installation Guide TDC-1691-003... -
Page 5: Chapter 2 Openway ® Riva Leak Sensor Installation Guide Overview
Audience This installation guide is intended for Itron personnel, third-party installers, and end users who want to understand the installation and use of Itron OpenWay Riva Leak Sensors to monitor their water systems for water leaks. Related documents For more information about compatible OpenWay Riva Water Modules or 100W+ water ERT modules and their ordering and installation, reference the listed documents. -
Page 6: Chapter 3 About The Openway Riva Leak Sensor (Ols)
(pit or remote) to provide leak monitoring information over network communications. The water module stores 40 days of OpenWay Riva Leak Sensor data. On the 41st day, the water module begins to overwrite the stored data in a first in-first out manner. -
Page 7: 1:4 Deployment Ratio
• The parcel width is <175' from center to center. 1:2 deployment ratio In systems with PVC or Transite pipes, Itron recommends a 1:2 deployment ratio. Use the 1:2 ratio for the listed deployment conditions. • The pipe types are PVC or Transite. -
Page 8: Chapter 4 Openway Riva Leak Sensor Compatibility With The 100W+ Ert Module
Chapter 4 OpenWay Riva Leak Sensor compatibility with the 100W+ ERT Module The OpenWay Riva Leak Sensor is compatible with the OpenWay Riva Water Module and the 100W+ Water ERT Module. Note: Compatibility with the 100W+ module requires an FDM > Set Leak Sensor Port Power Level programming update. - Page 9 OpenWay Riva Leak Sensor compatibility with the 100W+ ERT Module Note: The menu item number may be different than that shown in the illustration. Menu items are dependent on the field service technician's permissions. 3. Verify the Endpoint ID. If prompted, enter the Utility ID.
- Page 10 OpenWay Riva Leak Sensor compatibility with the 100W+ ERT Module 7. Verify a Check Endpoint function confirms Peripheral Device displays the Leak Sensor is connected. OpenWay® Riva Leak Sensor Installation Guide TDC-1691-003 Proprietary and Confidential...
-
Page 11: Chapter 5 Openway Riva Leak Sensor Installation
Chapter 5 OpenWay Riva Leak Sensor Installation This section describes installation of the OLS with an Itron OpenWay Riva Water or 100W+ water module. The OLS mounts on a water service pipe or meter insetter (meter horn). These installation instructions show installation and connection with the OpenWay Riva Water module. -
Page 12: Leak Sensor (Ols) Installation With The Pit Water Module
Related documents on page 2. If the OLS 5 foot cable is not long enough to reach the OpenWay Riva Pit Water Module, an extension cable is available from Itron (CFG-0151-404). The maximum cable length between the OpenWay Riva Leak Sensor and the OpenWay Riva Pit Water Module is 30 feet. -
Page 13: Installing The Ols
1. Select a mounting location within 5 feet of the water module. Important: If the OpenWay Riva Leak Sensor mounting location is in a meter box, ensure that there is adequate room for the leak sensor and the pit water module. Mount the leak sensor on the water input side of the meter. -
Page 14: Connecting The Ols
After the pit module is installed in the desired location, connect the pit module to the OLS. Note: These instructions show connection to the OpenWay Riva Water Module. Connection to the 100W+ ERT module is the same. Connect the OLS to the blue 100W+ (2, telemetry) connector. -
Page 15: Attaching A Security Seal
Twisting the connector body could damage the connector's pins. Attaching a security seal After the OpenWay Riva Leak Sensor is connected to the pit water module, attach the Itron security seal. OpenWay® Riva Leak Sensor Installation Guide TDC-1691-003... -
Page 16: Openway Riva Leak Sensor (Ols) Installation With A Remote Water Module
2. Installing the OLS with the remote Itron module The following steps provide the information to install and interface the OpenWay Riva Leak Sensor with the remote Itron water module. For remote module installation, see the installation guide for your remote module. These instructions show installation illustrations with both the remote OpenWay Riva Water Module and 100W-R+/100WP-R+ ERT module. - Page 17 OpenWay Riva Leak Sensor Installation available from Itron (CBA-0067-001). The maximum cable length between the OLS and the OpenWay Riva Remote Water Module is 30 feet. 1. Connect the OLS wires to the remote water module using gel cap connectors to complete...
- Page 18 OpenWay Riva Leak Sensor Installation 8. Place the cable connection into the remote water module housing with the cable ties to the inside. 9. Attach the backplate. 10. Route the register cable and telemetry device cable through the dual-port backplate.
- Page 19 OpenWay Riva Leak Sensor Installation 12. Align the remote module backplate with the mounting screw holes. Verify that the Itron logo is not upside down. 13. Insert a backplate mounting screw in one corner and tighten the screw two or three turns.
-
Page 20: Appendix A Using Gel-Cap Connectors
Appendix A Using Gel-cap Connectors This section describes connecting the Itron device to the water meter register using gel cap connectors. Required Materials ® • E-9R 3M gel cap crimping tool • Gel cap connectors 1. Push two wires as far as possible into the connector. - Page 21 The sealant may cause minor eye and skin irritation. Avoid eye contact. Avoid prolonged or repeated skin contact. Contact Itron Support for Safety Data Sheets (SDS). OpenWay® Riva Leak Sensor Installation Guide TDC-1691-003...
