- Page 1 OpenWay® Riva Routing Node ERT Gateway Installation Guide Technical knowledge to shape your future Communications...
- Page 2 Suggestions For more information about Itron or Itron products, see www.itron.com. If you have questions or comments about the software or hardware product, contact Itron Technical Support Services. Contact •...
-
Page 3: Table Of Contents
Mounting the ERT Gateway on a davit arm..................... 16 Connecting the ground wire........................17 Connecting the ERT Gateway power.......................17 Connecting the power cable......................18 ERT Gateway wiring diagram........................18 Chapter 5 OpenWay Riva Routing Node Communications Software...20 Appendix A ERT Gateway Specifications............21 Dimensions and weight............................21 Antenna specifications............................21 Environmental specifications..........................22 ERT Gateway power operating range.........................22... -
Page 4: Chapter 1 Important Safety And Compliance Information
To ensure system performance, this device and antenna shall not be changed or modified without the express approval of Itron. Per FCC rules, unapproved modifications or operation beyond or in conflict with these instructions for use could void the user's authority to operate the equipment. -
Page 5: Canada, Ised Compliance
Important Safety and Compliance Information Canada, ISED compliance Compliance Statement Canada Déclaration de Conformité This device complies with Innovation, Science Le présent appareil est conforme aux CNR and Economic Development Canada (ISED) d'Industrie Canada applicables aux appareils license-exempt RSS standard(s). Operation is radio exempts de licence. -
Page 6: Chapter 2 Getting Started: Openway
The OpenWay Riva Routing Node-ERT Gateway provides a unified means of reading Itron 100G series and 100W series devices over an IPv6 network. The OpenWay Riva Routing Node ERT Gateway can be deployed in one of two network configurations designated in the firmware. -
Page 7: Installation Location Information
Warning: In accordance with FCC rules, unapproved modifications or operation beyond or in conflict with these use instructions could void the user's authority to operate the equipment. Only authorized Itron personnel may open the ERT Gateway. Unauthorized access or modifications to the ERT Gateway will void the warranty. -
Page 8: Ert Gateway Housing
Description ERT Gateway The ERT Gateway processes data received through the antennas and relays it to the OpenWay Operations Center (OWOC). Only authorized Itron personnel may open this product housing. ERT antenna A 915MHz antenna that receives messages from the 100 series ERT modules in the network. -
Page 9: Ert Gateway Antennas
(EIRP) is not more than that permitted for successful communication. Antennas not approved by Itron are strictly prohibited for use with this device. Installing the OpenWay Riva Routing Node ERT Gateway with an unapproved antenna will void the product warranty and can void the user's authority to operate this equipment. -
Page 10: Chapter 3 Planning An Ert Gateway Installation
• On a structure on in a location that can physically support the weight of the ERT Gateway (and its mounting hardware). Caution: Always get permission to install the ERT Gateway at the selected site prior to installation. If you have questions or need help, contact Itron Support. ERT Gateway Installation Guide TDC-1744-000 Proprietary and Confidential... -
Page 11: Propagation Study For The Ert Gateway Installation Site
National Electrical Code, ANSI/NFPA 70, and where applicable, the Canadian Electrical Code, Part 1 CSA C22.1 or the prevailing local code. Power wiring on the Itron- supplied power cable follows conventional color coding for AC wiring: green (ground), white (neutral), and black (hot). -
Page 12: Mounting Hardware Requirements
ERT Gateway. Reference Appendix A: Dimensions and weight on page 21 for the dimensions and weight specifications of the ERT Gateway. Itron recommends that you consult a qualified engineer to verify load requirements and safety issues. Installers must comply with local codes when the ERT Gateway is installed. -
Page 13: Chapter 4 Installing The Ert Gateway
Use the ERT Gateway shipping packaging to transport the device to protect the equipment. This chapter provides the Itron-approved instructions to install an ERT Gateway in the field. The ERT Gateway can be installed in a variety of locations. This installation profile uses an AC mains power. - Page 14 Installing the ERT Gateway 2. Slide the black rubber boot onto the base of the antenna with the widest portion of the boot oriented as shown in the illustration. 3. Thread the antenna onto the top of the ERT Gateway. Do not over-tighten. Caution: Do not cross-thread the connection.
-
Page 15: Attaching The Snic Antenna
Installing the ERT Gateway Attaching the SNIC antenna This information provides the instructions to install the SNIC antenna. 1. Remove the SNIC antenna from the shipping box. 2. Remove the red connector protector. 3. Thread the antenna onto the N-connector (labeled WAN) on the bottom of the ERT Gateway. -
Page 16: Mounting Hardware
• Four bolts • The set screw • (optional) Metal bands (not provided by Itron) Note: If the vertical pipe or pole exceeds 6.75" in diameter, you may use metal bands instead of the mounting brackets to secure the mounting plate to the pipe or pole. Two 1.5"... -
Page 17: Mounting The Ert Gateway On A Pipe
Installing the ERT Gateway Component Image Description Brackets for pipe or pole mounting (bracket dimensions are shown) Mounting bolts Bracket mounting bolts Miscellaneous Mounting nuts, set screw, washers, split washers, and anti-seize lubricant The integrated mounting support on the back of the ERT Gateway housing slides into the slot in the center of the mounting bracket. -
Page 18: Mounting The Ert Gateway On A Pole
Installing the ERT Gateway 2. Place the gateway on the mounting plate with the antenna in an upright position. Insert the mounting plate disc into the mounting plate's disc opening. 3. Secure the ERT Gateway to the mounting plate using the set screw and washers. Caution: There are four possible locations for the set screw. -
Page 19: Mounting The Ert Gateway On A Davit Arm
Installing the ERT Gateway Mounting the ERT Gateway on a davit arm These instructions describe a typical utility or street light pole installation. The ERT Gateway is mounted on a davit or street light arm. Power is supplied on a davit or street light arm installation using a photocell adapter cable. The cable plugs into the photocell sensor of the street light. -
Page 20: Connecting The Ground Wire
Connect the ground wire to the grounding lug on the ERT Gateway. Note: Due to variable requirements for cable length, cables are not provided by Itron. Attach the grounding wire to earth ground. Follow local codes if earth ground is not provided through the AC power cable. -
Page 21: Connecting The Power Cable
Installing the ERT Gateway Warning: Securely mount the ERT Gateway before the dedicated AC mains power source is connected. The ERT Gateway must be grounded by the ground wire in the three-wire AC mains cable or through the grounding lug on the bottom of the gateway. - Page 22 Installing the ERT Gateway Connection Description AC power source Ground ERT Gateway Installation Guide TDC-1744-000 Proprietary and Confidential...
-
Page 23: Chapter 5 Openway Riva Routing Node Communications Software
Chapter 5 OpenWay Riva Routing Node Communications Software The OpenWay Riva Routing Node ERT Gateway Star communicates using the OpenWay Operations Center Collection Manager. The OpenWay Operations Center Collection Manager sends a request to the ERT Gateway Star requesting the data from the previous 8 hours. -
Page 24: Appendix A Ert Gateway Specifications
Radome diameter 1" OD 1" OD 0.84" OD 1" OD *See the OpenWay Riva Routing Node Ordering Guide (PUB-1306-001) for the full list of part numbers and availability or contact your Itron representative. ERT Gateway Installation Guide TDC-1744-000 Proprietary and Confidential... -
Page 25: Environmental Specifications
ERT Gateway Specifications To reduce potential radio interference to other users, select an antenna type with gain such that the equivalent isotropically radiated power (e.i.r.p.) is not more than that permitted for successful communication. Innovation, Science, and Economic Development Canada (ISED) Conformity This radio transmitter (IC: 864A-ORRNA) has Le présent émetteur radio (IC: 864A-ORRNA) est been approved by Innovation, Science and...
