The Original ScrapBox Ultimate Sewing Box Assembly Instructions Manual page 32

CENTER BOX SLIDING TABLE
Center Box
Back Fold out
Table
Left Pivot
Bracket
Back Fold
Out Table
7
Place rubber caps onto
pivot brackets.
8
Fold up the Back Fold Out Table as shown. Place the right
Pivot Bracket with metal dowel inside groove. Slide Back
Fold Out Table gently back up to the end of the groove.
Attach right Pivot Bracket to table with 2 washer screws.
Repeat with left Pivot Bracket and 2 washer screws.
32
Proprietary, patented product and assembly instructions. Do not copy or distribute.
Install 3 remaining hinges with
barrel facing down with 9
5
Euro screws. Do not tighten.
Leave loose until attached to
center box sliding table.
6
WITH TWO PEOPLE:
Hold Back Fold Out Table in
place while attaching hinges to
Center Box Sliding Table with barrel
facing down using 9 Euro screws.
Tighten all 18 Euro scews.
Right Pivot Bracket
3/4" washer screws
Back view of Ultimate Sewing Box
13mm Euro Screws
