The Original ScrapBox Ultimate Sewing Box Assembly Instructions Manual page 10

LEFT BOX
9
Insert 8 Cams along both sides of the interior
of the box and turn with Allen Wrench until
locked in place.
10
Install (3) offset hinges to Left Box
Side 1 using (12) 13mm Euro Screws.
Do not tighten until attaching swing door.
Attach Left Swing Door with Shelves
to Left Box using (9) 13 mm Euro Screws.
Tighten all screws.
CAUTION: Leave the Left Box laying on its side for a future step
10
Proprietary, patented product and assembly instructions. Do not copy or distribute.
x8
Locking
Cams
x21
13mm Euro Screws
and until attaching the Center Box.
Attaches to Left Swing door
Attaches to Left Box Side 1
Left Box
Side 1
13mm
