The Original ScrapBox Ultimate Sewing Box Assembly Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
C nr tl o s
You have received The Ultimate Sewing Box!
We've been working hard to bring you a more customer friendly build in 2018
and we need your feedback. After assembling your Ultimate Sewing Box, please
email us about your experience at ashleyp@theoriginalscrapbox.com.
For this build, there is no companion video tutorial.
We have also partnered with Sew Steady to improve the functionality of our product.
For your free Center Desk Acrylic Table Insert, please complete the online form
found here (case sensitive):
https://www.theoriginalscrapbox.com/pages/sewsteady-link
If you have questions regarding your Ultimate Sewing Box, please contact us.
customerservice@theoriginalscrapbox.com
www.theoriginalscrapbox.com
USA/CAN
(801) 226-2686, M-F 9am-5pm MST (Utah)
GER #: 49-40-57-00-39-98
AUS #: 61-4-1-4441-8022
Thank you for your continued interest in our products.
We hope The Ultimate Sewing Box will provide a place to organize and create.
- The Original ScrapBox Team

Advertisement

loading

Summary of Contents for The Original ScrapBox Ultimate Sewing Box

  • Page 1 (801) 226-2686, M-F 9am-5pm MST (Utah) GER #: 49-40-57-00-39-98 AUS #: 61-4-1-4441-8022 Thank you for your continued interest in our products. We hope The Ultimate Sewing Box will provide a place to organize and create. - The Original ScrapBox Team...
  • Page 2 IMPORTANT PLEASE READ BEFORE ASSEMBLY All bases, lids, and shelves must be installed and kept at a right angle (90 ) with side panels. Once all pieces are fully connected the design is very strong and will last many years! All panels must be kept at a 90 (Right Angle) All panels must be installed at a right angle.

  • Page 3: Tools Needed

    The Ultimate Sewing Box: Assembly Instructions Last Updated: 07/25/2018 MADE IN THE USA TOOLS NEEDED: 10mm wrench Rubber Mallet (or socket wrench with extension) (included) Allen Wrench Phillips Screw Driver Hammer (included) Our furniture is designed to be built with two people.
  • Page 4 CENTER BOX HARDWARE: Small Base Posts Support Pins Angle Brackets Metal Shelf Holders 14mm Locking Washer Screws 1 1/2” Cams Screws for divider panels Bolts Nuts 13mm Euro Screws For Hinges Hinges Wheels 25mm Euro Screws For Back Panel WORK TABLES HARDWARE: CENTER SLIDING TABLE HARDWARE 3/4”...

  • Page 5: Accessories Included

    LEFT SWING BOX HARDWARE: SHELVES INCLUDED 12- 13 x 13 (8 in center box, 4 in right box Offset Hinges 2- 13 x 7 1/2 (Center box) 4 - 3 x 13 Shelves (Right box) Left box: 5 - Thick Shelves (13” x 16.5”) - upper 13mm Euro Screws Metal Hooks 2- Thick Shelves (15.75”...
  • Page 6 LEFT BOX Build on a blanket for best results Bottom View Left Box Pre-drilled wheel screw holes Left Box Unfinished edge 16 Bolts Base Post hole Pre-drilled 16 Nuts Green dowels angle bracket holes Locking Cam hole Post hole Hammer (16) bolts into top of base. Install (4) wheels onto bolts.
  • Page 7 LEFT BOX TOP VIEW Recessed hinge pockets Left Box Left Box Shelf Left Box Left Box Side 1 Shelf With finished edges of Base & Lid facing down, match up posts on Side 1 with post holes. Use mallet to tap Base and Lid into Side 1. Repeat for the Left Box Shelf.
  • Page 8 LEFT BOX Left Box: Side 2 Posts BOTTOM Small base support pins Install (2) small base support pins and posts into bottom of Side 2 as shown. Insert (6) posts into post holes in top, bottom and center of Side 2 as shown. CENTER Use mallet to carefully tap Side 2 Left Box...
  • Page 9 LEFT BOX Posts Head Insert 9 Posts HEAD DOWN into Post Holes on the edge of Sides 1 & 2. Left Box Side 1 Left Box Base CAREFULLY Set door over 8 posts. *Make sure door knob hole is over Side 1. DO NOT FORCE onto posts.
  • Page 10 LEFT BOX Locking Cams Insert 8 Cams along both sides of the interior of the box and turn with Allen Wrench until locked in place. 13mm Euro Screws Install (3) offset hinges to Left Box Side 1 using (12) 13mm Euro Screws. Do not tighten until attaching swing door.
  • Page 11 RIGHTBOX Build on a blanket for best results Bottom View Right Box Right Box Pre-drilled wheel screw Base holes Unfinished edge 16 Bolts Post hole Pre-drilled 16 Nuts Green dowels angle bracket holes Locking Cam hole Post hole Hammer (16) bolts into top of base. Install (4) wheels onto bolts.
  • Page 12 RIGHT BOX TOP VIEW Right Box Recessed hinge pockets Right Box Right Box Shelf 1 Shelf 2 Right Box Right Box Side 1 Shelf 1 With finished edges of Base & Lid facing down, match up posts on Side 1 with post holes. Use mallet to tap Base and Lid into Side 1.
  • Page 13 RIGHT BOX Locking Cams Use mallet to carefully tap Side 2 into the post holes on Base, Lid and Shelves. Insert and lock (8) more Cams. *Note that 2 cams will insert into top side of Lid (outside of the box) and the other four will insert into the undersides of Shelves and Base.
  • Page 14 RIGHT BOX CAREFULLY Set door over 8 posts. DO NOT FORCE onto posts. *Make sure door knob hole is over Side 1. Be certain each post is secure. Next, carefully turn box over so that DOOR is facing down. Be sure that door does not slide off posts. Locking Cams Insert 8 Cams along both sides of the interior of...
  • Page 15 RIGHT BOX Shelf Pegs Insert Shelf Pegs in holes on Side 2. We recommend placing pegs as shown. Shelf Pegs Right Box Divider Side 1 Insert Shelf Pegs in holes on Side 1 of Right Box Divider to match peg placement from step 9 Next, you will use shelves as spacers to properly align and install the Right Box Divider.
  • Page 16 RIGHT BOX Slide divider in and align with pilot holes on lid and top shelf. Add shelves as shown 1 1/2” Screws Once divider and shelves are in place make sure they fit tightly. Use a Phillips screw driver to MANUALLY insert (4) 1 1/4”...
  • Page 17 RIGHT BOX Remove shelf spacers and set aside. Carefully turn box onto Side 2. Attaches to Right Box Side 1 Attaches to Right Swing door 13mm Right Box Side 1 13mm Euro Screws Install (3) offset hinges to Right Box Side 1 using (12) 13mm Euro Screws.

  • Page 18: Center Box

    CENTER BOX Build on a blanket for best results Center Box Divider Finished Edge Align green dowels on Dividers with dowel holes on lid. Center Box Use Rubber Mallet to carefully tap Center Box Bottom Side Dividers into place until secure. Divider 1 1/2”...
  • Page 19 CENTER BOX 1 1/2” Screws for divider panels Center Box Divider Use Phillips Screw Driver to MANUALLY insert (4) 1 1/2” screws into pre-drilled Center Box screw holes on bottom side of Shelf 2 Center Box to secure Dividers. Bottom Divider Side Center Box...
  • Page 20 CENTER BOX Posts Insert (16) Posts into Side 2 corresponding post holes on Sides 1 & 2. Base Support Pins Side 1 Also add (4) Base Support pins to corresponding Holes in Side 1 & 2. Stand Side 1 on its edge and be sure posts, dowels &...
  • Page 21 CENTER BOX Bottom View Nuts Bolts Wheels Center Box Base Pre-drilled wheel screw Center Box holes Base Top View Post hole Green dowel Hammer (16) bolts into top of base. Install (4) wheels onto bolts. Post Post hole hole Tighten with (16) nuts using a wrench or socket wrench.
  • Page 22 CENTER BOX 3 x 7” Shelves 3 x 13” Shelves Slide (2) more stacks of (3) Notions Shelves under the unattached corders of Base & Shelf 1 to stablize. 3 x 13” Shelves 3 x 13” Shelves 3 x 7” Shelves Locking Cams Insert and lock (2) Cams into Base on the left side, corresponding with Side 1.
  • Page 23 CENTER BOX Stand Side 2 on its edge with back groove at the bottom and be sure posts, dowels & pins are aligned. Use Mallet to tap Side 2 CAREFULLY into built section. Side 1 Side 2 Locking Cams Install (8) more Cams into holes on Base, Shelves &...
  • Page 24 CENTER BOX Next, with TWO PEOPLE , carefully turn Ultimate SewingBox onto Side 1. **To avoid injury or damage to your SewingBox, please do not attempt this step alone.** Remove shelves and set aside. Carefully slide Back Panels into back grooves. Be sure that holes are aligned with corresponding pilot holes.
  • Page 25 LEFT, RIGHT & CENTER BOXES With TWO PEOPLE , carefully turn SewingBox over onto its back. Center Angle Brackets 14mm Washer Screws Rotate Left & Right boxes doors down. Use 24 washers screws to attach 6 angle brackets to the base of each box. Proprietary, patented product and assembly instructions.
  • Page 26 CENTER BOX 13mm Hinges Euro Screws Use (15) 13mm Euro Screws to attach (5) Hinges to Center Box Side 1. Repeat for Side 2 using (15) more 13mm Euro Screws and (5) more Hinges. With TWO PEOPLE carefully lift the Center Box and place against wall. Lift and attach Left and Right Box one at a time.
  • Page 27 CENTER BOX 13mm Hinges Euro Screws Use (15) 13mm Euro Screws per side to attach Left Box and Right Box to Center Box hinges. for attaching ScrapBox Security Kit included in your hardware CENTER BOX LEFT BOX RIGHT BOX 1” Screw (or x2 for Ergo White) Door Knob (or x1 door handle...
  • Page 28 SWING TABLES Bottom Barrel Lock 13mm Lever locks downward LONG TABLE LEGS Fold down Work Table Fold down Work Table Install 2 hinges per table. Use Install 2 barrel locks with 8 the hinges that are recessed on 14 mm screws. Install LONG opposite side of barrel.
  • Page 29 CENTER BOX SLIDING TABLE 13mm Euro Screws For attaching rails: 1. Slide rail open, exposing 3 sections of rail. 2. Look for black lever on smallest section. 3. Push lever up or down while removing smallest section from the rail. 4.

  • Page 30: Important Note

    IMPORTANT NOTE! To collapse table legs, pull joint in towards the middle. Proprietary, patented product and assembly instructions. Do not copy or distribute.
  • Page 31 This will enable it to lock into place and function smoothly. Close Ultimate Sewing Box and turn around to back view Proprietary, patented product and assembly instructions. Do not copy or distribute.
  • Page 32 CENTER BOX SLIDING TABLE Install 3 remaining hinges with Back view of Ultimate Sewing Box barrel facing down with 9 Euro screws. Do not tighten. Leave loose until attached to center box sliding table. 13mm Euro Screws Center Box Back Fold out...
  • Page 33 SWING DOOR HARDWARE & SHELVES Left Box Shelving: Left Box Shelving: - 5 Thick Shelves (13” x 16.5”) - 5 Thick Shelves (13” x 16.5”) Acrylic Guards with metal shelf pegs above table. with metal shelf pegs above table. - 2 Thick Shelves (15.75” x 16.5”) - 2 Thick Shelves (15.75”...
  • Page 34 You’re finished building your Ultimate SewingBox! Now you can customize your shelves and totes to fit your organization needs. The instructions that follow will help you install your 1/4 inch adjustable shelves correctly. Fit the wide, flat part of the shelf peg into the corre- sponding hole in the included shelf peg tool.
  • Page 35 CR O W N INS TA LLA T I ON 1. Remove sash lock from the top of box. 2. Make sure both Left and Right Boxes are level with the Center Box. If not level, you may need to adust some of the hinges. *It is critical that Left, Right and Center box be level with one another to avoid scraping the crown when opening and closing the box.
