Clas Ohlson IW001 Quick Manual

Internet Weather Station
Quick guide
Art.no: 36-3552
Please read the entire instruction manual
before using and save it for future use. We
apologise for any text or photo errors and
any changes of technical data. If you have
any questions concerning technical problems
please contact our Customer Services.
1. Inserting the batteries
Weather station (for battery backup)
Open the battery cover on the backside of
the device and insert 3xAA/LR6 batteries
(not included).
- Make sure to insert the batteries according
to the markings in the battery compartment.
Outdoor sensor
Open the battery cover on the back and insert
2xAA/LR6 batteries (not included).
- Make sure to insert the batteries according
to the markings in the battery compartment.

2. Installing the software

The following installation instructions apply to
Windows XP with Service Pack 2 installed.
1. First, make sure that the computer to be
used is connected to the Internet and that
the weather station is turned on.
2. Connect the USB transmitter to a vacant
USB port on the computer. Position the
aerial in the upright position for the best
possible range.
3. Insert the supplied CD into the computer's
CD-ROM drive.
4. Installation starts automatically.
5. After installation you will be asked if you wish
to search for an updated version from the
Internet. Select Yes to search for updates.
6. After updating you will be requested to
restart your computer. Select OK to restart.
7. The programme will start automatically
when the computer restarts.
GREAT BRITAIN For consumer contact, please visit www.clasohlson.
co.uk and click on customer service.
ENGLISH
Model: IW001
3. Synchronising the outdoor
sensor to the weather station
The weather station and outdoor sensor are
already pre-synchronised, but after a possible
resetting re-synchronisation may be required.
1. Press and hold OUT TEMP on the weather
station until the
2. Then press RESET on the outdoor sensor.
3. The weather station will then automatically
synchronise with the outdoor sensor.
Re-synchronising the weather station to
the wireless USB transmitter
If the weather station loses the connection to
the USB transmitter it must be re-synchronised.
1. Right click the weather programme's icon
on the task bar and select Device and then
Device Register.
2. Press and hold RESET on top of the
weather station to restart and reset it.
3. When the weather station starts weather
information is transferred and displayed
after a short while.
4. Selecting the nearest
meteorological station
via the Internet
1. When you have started the programme,
right click on the weather programme's icon
on the taskbar and select City select....
2. Select the country and then the nearest
metrological station.
3. Click OK. Weather information is then
retrieved from the metrological station and
transmitted to the weather station. (Can
take a few minutes in certain cases.)
symbol begins flashing.
