8.4 Changing the user parameters

Pressing displays the following values in succession:
− manifold delivery temperature T1
− DHW temperature T3
− low temperature circuit delivery temperature T6.
To change the relative setpoints:
− press the "Set/esc" button: the relative value will appear, the two digits on the right will flash
− if the value should not be changed, press "Set/esc" again to return to display mode
− if the value should be changed, press
value. The displayed value stops flashing and the display returns to the display mode
For example's sake here below is a table showing the procedure for changing the setpoint value of the low temp. heating system
from 50 to 40°C.
POS.
1
Press button to enter display mode, press again and go to the first of 6 digits to visualize the set
2
3
4
5
6 After 3 secs. the display will return to the display mode with the new setpoint
If there is no change after pressing "Set/esc" for 10 secs. (the desired value corresponding to the set one) the display returns to
display mode function.
If there is no operation after pressing buttons
value is not memorized.

8.5 Monitor mode

Press "Set/esc" for 5 seconds to access "Monitor" mode. This mode is used to check the operating values for every system unit (ad-
dresses from 1 to 60).
POS.
1
Press "Set/esc" for 5 secs. The displays shows it is possible to read the values or functional status of
2
3 Press
Pressing the first value of the selected unit will appear. Afterwards by pressing the same
4
Press "Set/esc" to exit monitor mode. The display will return to display mode function if it is not
5
and
PROCEDURE
E.g. value read on display for high system 80° C
value (e.g. 50° C)
Press button "Set/esc"
Press to take the setpoint to the desired value (e.g. 40° C)
Press "OK" to memorize the new value
and
OPERATIONS
From current T1 position at 80° C
or to scroll and read the values of the desired unit (e.g. fig., unit 19)
the next values will be visualized.
(e.g. fig., 1st value – flow temperature NTC 70° C).
pressed within 5 minutes or if no operation has been done.
until the required value appears on the display. Press "OK" to save the new
, after one minute the display will return to display mode. The new selected
