Operating Instructions

SKC Inc.
863 Valley View Road
Eighty Four, PA 15330 USA
Form 37740 Rev 1707

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIRCHEK 2000 and is the answer not in the manual?

Questions and answers

Summary of Contents for SKC AIRCHEK 2000

  • Page 1: Operating Instructions

    Operating Instructions SKC Inc. 863 Valley View Road Eighty Four, PA 15330 USA Form 37740 Rev 1707...
  • Page 3: Table Of Contents

    Table of Contents Description ..............................1 Performance Profile ............................ 2 Battery Operation Installing the Battery Pack ........................5 Charging the Battery Pack ........................5 Battery Charge Level Indicator ......................6 Replacing the Battery Pack ......................... 6 Battery Eliminator ..........................7 Introduction Pump Display ............................
  • Page 5 AirChek 2000 Quick Guide Operation Star Button  Scrolls through run time data, display options, and sampling parameters during pump setup Up and Down Arrow Buttons  Increase or decrease sampling parameters and toggle between display choices in setup Security Code ...
  • Page 7: Description

    2000 Pump is an advanced programmable sample pump ® that combines lightweight compact design, computer-compatible circuitry, and a patented* isothermal flow sensor. AirChek 2000 can be used with optional DataTrac 2000 Software and your PC to expand pump programmability and ®...
  • Page 8: Performance Profile

    Performance Profile Flow Range: 1000 to 3250 ml/min (5 to 500 ml/min requires low flow accessories. See Accessories.) Flow Control: An internal isothermal flow sensor measures flow directly and continuously. Sensor readings are used in a flow monitoring algorithm to maintain calibrated volumetric flow.
  • Page 9 Performance Profile Sample Time (SГ) AirChek 2000 sample time can be set up to 999 minutes Setting: from the pump keypad or up to 43,200 minutes (30 days) from a PC using DataTrac 2000 Software. During sampling, the pump LCD will display remaining run time (will count time down from a set number of minutes) when sample time is set from the keypad.
  • Page 10 Table 1. AirChek 2000 Run Time in Hours with NiCad Battery Following are typical run times achieved when using a fully charged nickel- cadmium (NiCad) battery pack. Data is sorted by type of sample media. All run times are listed in hours. Results obtained using a new pump and new fully charged battery.
  • Page 11: Battery Operation

    Use only SKC-approved charger designated for this model to ensure reliable performance. Failure to do so voids any warranty. Failure to follow warnings and cautions voids any warranty. The battery pack may be kept on the SKC-approved charger for an indefinite time.
  • Page 12: Battery Charge Level Indicator

    • Replacing the battery pack may erase scheduled runs programmed with DataTrac 2000 Software. After replacing the battery pack, use the software to reprogram the scheduled runs in the AirChek 2000 pump. • Replacing the battery pack will erase sampling time, delayed start, and other settings entered using the pump keypad.
  • Page 13: Battery Eliminator

    Use only an SKC-approved charger and battery pack designed for the AirChek 2000 Sample Pump to ensure reliable performance. Failure to do so voids any warranty and the UL Listing for intrinsic safety. Use of any device other than the approved battery pack to power the pump voids the UL Listing for intrinsic safety and any warranty.
  • Page 14: Introduction

    Introduction Pump Display AirChek 2000 LCD HOLD: Flashes when the pump is in HOLD mode, see page 10 SГ or S: Displayed when a sample time is manually programmed into pump memory, see page 12 VOL: Volume of air pumped...
  • Page 15: Keypad Basics

    Introduction Keypad Basics The AirChek 2000 Pump operates by pressing various button sequences on the keypad located on the front of the pump housing.  Down  Up  arrow arrow Button button button AirChek 2000 Keypad Scrolls through run time data, display options, and sampling ...
  • Page 16: Pump Operating Modes

    Introduction Pump Operating Modes Pump is running; run time data is continuously updated in memory. The LCD shows real-time run time data. Press  to scroll through the parameters. Run time and volume stored in memory will continue to accumulate unless reset.
  • Page 17: Setup

    (see Battery Operation on page 6). A new battery should be fully charged before operation. Entering and Navigating the User Interface The AirChek 2000 User Interface features two levels: Level One—Set Up Flow Rate allows the user to change flow rate, adjust flow rate to a primary standard, and calibrate the pump using the CalChek feature.
  • Page 18: Using User Interface - Level Two

    Setup Used during calibration with calibrator (not for use with CalChek feature). Press  to increase or  to decrease flow adjustment until desired flow is indicated on an attached calibrator. Press  to move to next parameter, or continue to press  until End appears to exit User Interface.
  • Page 19: Resetting Run Time Data

    Setup Time of day The hour will flash. Press  to increase and  to decrease hour. Press  to advance to minutes. Once minutes are flashing, press  to increase or  to decrease minutes. Press  to move to next parameter.
  • Page 20: Setting Sample Time

    Setup Setting Sample Time (S Г) Program the AirChek 2000 from the keypad to run STEL, TWA, or any other run time from 1 to 999 minutes.* AirChek 2000 sampling time may also be programmed from a PC using DataTrac 2000 Software.* To program a sample time using the pump keypad: With the pump running, press [] to place...
  • Page 21: Setting A Delayed Start

    Setup Setting a Delayed Start The Delayed Start feature is available in pump version 2.59 or higher. When setting the pump manually for sampling to begin within a 12-hour timeframe, follow this procedure: With the pump running, press [] to place the pump in HOLD and enter ...
  • Page 22: Deleting A Sample Time

    Setup Deleting a Sample Time (SГ) To delete a sample time, enter User Interface Level Two and press the  button to scroll to . Press  until 00 appears. Press the  button until SГ SГ End appears. Press []. Deleting a DataTrac 2000 Program If a DataTrac 2000 program is in pump memory, the PROG icon will appear in the upper left corner of the display.
  • Page 23: Operation

    Operation Flow Rate and Volume Display Flow rate displayed on the pump LCD is the flow to which the pump has been calibrated. To maintain flow as displayed, the pump automatically adjusts flow during sampling for changes in temperature and atmospheric pressure* that may differ from the temperature and atmospheric pressure present at the time of calibration.
  • Page 24: Set/Calibrate Flow Rate (Calchek Single-Point)

    The CalChek automatic calibration feature is available when calibrating an AirChek 2000 Pump with a Defender Calibrator. A CalChek Communication Cable (Cat. No. 210-502) is required. Optional DataTrac 2000 Software can be used to expand the documentation capabilities of this system. The CalChek feature provides two calibration options: single-point calibration allows setting and verifying a flow rate at a single point before and after sampling.
  • Page 25 Press the right arrow to highlight Preferences; press Enter. d. Press the down arrow to navigate to Data Port. e. Press the left or right arrow to toggle to SKC. f. Press the down arrow to highlight Confirm; press Enter.
  • Page 26: Set Up/Sample (Constant Flow)

    Operation Set Up/Sample (Constant Flow) • Protect sample pump from weather when in use outdoors. • Allow pump to equilibrate after moving it from one temperature extreme to another. • Use of any device other than the approved battery pack to power the pump voids the UL Listing for intrinsic safety and any warranty.
  • Page 27 Operation Pump Flow Rate Ensure that battery is fully charged and that pump has run for 5 minutes before calibrating. Prepare the calibrator (see calibrator instructions). Using flexible tubing, connect the calibrator outlet (suction port) to the pump inlet. With the pump in Hold, set the pump flow rate to 1.5 L/min as follows: a.
  • Page 28: Set Up/Sample With Single Tube

    Operation Set Up/Sample with Single Tube • Allow pump to equilibrate after moving it from one temperature extreme to another. • Charge pump battery completely before calibration and sampling. • Protect sample pump from weather when sampling outdoors. • Calibrate/verify pump flow rate before and after each sampling operation using the tube holder and pump to be used for sampling.
  • Page 29: Set/Calibrate Flow Rate For Multiple Tubes

    Operation Set/Calibrate Flow Rate for Multiple Tubes • Requires Constant Pressure Controller (CPC) and Dual, Tri, or Quad Adjustable Low Flow Tube Holder (see Accessories). The low flow tube holder used with CPC allows up to four tube samples to be taken simultaneously, each at different flow rates if desired.
  • Page 30: Set Up/Sample With Multiple Tubes

    Operation From Hold, press [] to run the pump. Loosen and turn the brass flow adjust screw directly beneath the port holding the first active tube to be calibrated (clockwise to increase, counterclockwise to decrease) until the calibrator indicates the method-specified flow rate. Do not adjust the flow rate on the pump.
  • Page 31: Maintenance

    Full Calibration (CalChek Multiple-point) This type of calibration provides flow correction across the basic operating range of the AirChek 2000 pump (750 to 3000 ml/min) in approximately four minutes. The operation calibrates each flow rate to a calibrator. It can also provide a record of calibration for maintenance and quality purposes if DataTrac 2000 Software is used.
  • Page 32 Maintenance CS1, and a brief flow rate. The pump will continue to display CS2, then a flow rate, CS3, then a flow rate, etc. until calibration is completed at all flow rates between 750 and 3000 ml/min. Full calibration begins at flows lower than 750 ml/min. At these lower flow rates, the calibrator piston will move slowly.
  • Page 33: Troubleshooting

    Pump unable to achieve flow rate of 3000 Check pump’s flow tube to ensure ml/min possibly due to a blocked flow tube it is not blocked, or contact SKC or an air leak inside the pump. Technical Support at skctech@ skcinc.com.
  • Page 34: Replacement Parts

    Interface Control Board P79543 Port Cover P20179 Screw/Gasket Kit P21002 Valve Assembly, bottom P21272 Valve Assembly, top P21322 Use only SKC-approved parts to ensure reliable performance. Failure to do so voids any warranty and the UL Listing for intrinsic safety.
  • Page 35: Accessories

    Calibrator, for manual calibration, 0.75 to 5 L/min, includes 9-volt alkaline battery and NIST-traceable certificate 375-07550N CalChek Communication Cable, required for CalChek feature 210-502 Chargers PowerFlex Charging System for SKC Personal Pumps 5 stations, 100-240 V 223-1000 Single, 100-240 V 223-2000 PowerFlex Pump Cable for AirChek 2000...
  • Page 36 • Create and save an AirChek 2000 program on a PC and upload to the pump for operation in the field. • Program up to ten sampling sequences, each with different flow rates •...
  • Page 37: Warranty

    Warranty SKC Limited Warranty and Return Policy SKC products are subject to the SKC Limited Warranty and Return Policy, which provides SKC’s sole liability and the buyer’s exclusive remedy. To view the complete SKC Limited Warranty and Return Policy, go to http://www.skcinc.
