VAXft Systems
Model 810

Service Information

Order Number: EK-VXFTA-SI.A01
June 1993
This manual is intended for use by trained personnel responsible for
maintaining VAXft Model 810 systems.
Digital Equipment Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VAXft Systems 810 and is the answer not in the manual?

Questions and answers

Related Manuals for Digital Equipment VAXft Systems 810

Summary of Contents for Digital Equipment VAXft Systems 810

  • Page 1: Service Information

    VAXft Systems Model 810 Service Information Order Number: EK-VXFTA-SI.A01 June 1993 This manual is intended for use by trained personnel responsible for maintaining VAXft Model 810 systems. Digital Equipment Corporation...
  • Page 2 June 1993 The information in this document is subject to change without notice and should not be construed as a commitment by Digital Equipment Corporation. Digital Equipment Corporation assumes no responsibility for any errors that may appear in this document.
  • Page 3 Documentation Map Hardware Information (VAXft Systems) Overview Software Models Model Information Operating System Information (VAXft Systems) 110, 410, 610, 612 (VMS) (VAXft System Services) Cover Software Product Before You Configuring Configuration Letter Description Install Letter the Model 810 Guide Release Notes Site Prep and Release Notes Installation...

  • Page 5: Table Of Contents

    Contents 1 Cabinet and Component Descriptions In This Chapter ..........1–1 CPU and Expansion Cabinets .
  • Page 6 3 System Maintenance In This Chapter ..........3–1 Maintenance Strategy .
  • Page 7 FTSS Event Reporting Interface ....... . 4–40 4.6.1 Event Reporting Interface Routines ......4–40 4.6.2 Error Event Messages .
  • Page 8 6 Managing Integrated Storage Elements In This Chapter ..........6–1 Loading the DUP Driver .
  • Page 9 3–1 Module Fault LEDs ........3–6 Power System Block Diagram (1 of 2) .
  • Page 10 5–22 SF73 Disk Drive, Front View ....... . 5–33 SF73 Disk Drive Enclosure Removal ......5–23 5–34 5–24...
  • Page 11 3–1 Before Stopping a Zone ........3–2 After a Zone is Repaired .
  • Page 12 4–19 System Register Entry Descriptions ......4–28 End Actions Register Descriptions ......4–20 4–29 4–21...
  • Page 13 6–5 Disabling the MSCP ........6–11 Processor Halt Code Definitions .

  • Page 15: 1.1 In This Chapter

    Cabinet and Component Descriptions 1.1 In This Chapter This chapter includes descriptions of the: • CPU and expansion cabinets • Zone control panel • Power modules • Domestic power distribution box • International power distribution box 1.2 CPU and Expansion Cabinets Figure 1–1 shows the front layout of an expanded system.

  • Page 16: Cabinet Layout, Front View

    Figure 1–1 Cabinet Layout, Front View Front Expansion Cabinet CPU Cabinet MR−0406−92RAGS 1–2 Cabinet and Component Descriptions...

  • Page 17: Key To Figure 1-1, Cabinet Layout, Front View

    Table 1–1 Key to Figure 1–1, Cabinet Layout, Front View Item Component Description Zone A Complete computer with enough elements to run an operating system. Zone B Complete computer with enough elements to run an operating system. Fan assembly Cooling device. Disk drawer Optional SF35 disk drive(s).

  • Page 18: Cabinet Layout, Rear View

    Figure 1–2 Cabinet Layout, Rear View Rear 8 9 10 16 17 Expansion Cabinet CPU Cabinet Expansion Cabinet Option MR−0407−92RAGS 1–4 Cabinet and Component Descriptions...

  • Page 19: Key To Figure 1-2, Cabinet Layout, Rear View

    Table 1–2 Key to Figure 1–2, Cabinet Layout, Rear View Item Component Description Zone A Complete computer with enough elements to run an operating system. Zone B Complete computer with enough elements to run an operating system. Fan assembly Cooling device. Blank panel Not used.

  • Page 20: Zone Control Panel

    1.3 Zone Control Panel Figure 1–3 shows the layout of the zone control panel. Table 1–3 describes the functions of the zone control panel controls and indicators. Figure 1–3 Zone Control Panel MR−0514−92RAGS 1–6 Cabinet and Component Descriptions...

  • Page 21: Key To Figure 1-3, Zone Control Panel

    Table 1–3 Key to Figure 1–3, Zone Control Panel Item Control/Indicator Function Logic Power - OFF Two switches with amber indicators. Pressing the two switches removes 48 V power and disables the zone. Pressing one switch has no effect on the operation of the zone. (CPU cabinet disk power is not affected when logic power is removed by pressing these switches.) Logic Power - ON...

  • Page 22: Power Module Controls And Indicators

    1.4 Power Modules Figure 1–4 shows the location of the power module controls and indicators. Table 1–4 describes their functions. Figure 1–4 Power Module Controls and Indicators CAMP MR−0483−92RAGS 1–8 Cabinet and Component Descriptions...

  • Page 23: Key To Figure 1-4, Power Module Controls And Indicators

    Table 1–4 Key to Figure 1–4, Power Module Controls and Indicators Item Control/Indicator Function AC Circuit Breaker FEU Failure When on, indicates the dc output voltages for the FEU are below the specified minimum. FEU OK When on, indicates the dc output voltages for the FEU are above the specified minimum.

  • Page 24: Domestic Power Distribution Box

    Figure 1–5 Domestic Power Distribution Box M R - 0 4 9 8 - 9 2 D G Table 1–5 Key to Figure 1–5, Domestic Power Distribution Box Item Component Description Three-phase power cord Connects the power distribution box to ac power. The power cord may be repositioned by moving the locking arm.

  • Page 25: International Power Distribution Box

    Figure 1–6 International Power Distribution Box M R - 0 4 9 9 - 9 2 D G Table 1–6 Key to Figure 1–6, International Power Distribution Box Item Component Description Single-phase power cord Connects the power distribution box to ac power. Circuit breaker When set to on, ac power is applied to the distribution box.

  • Page 27: In This Chapter

    Console Operations 2.1 In This Chapter This chapter describes the console, console operating modes and commands, and booting information. This chapter includes: • Console description • Console operating modes • Console control characters • Console command language syntax • Bootstrap procedures •...

  • Page 28: System Components

    Figure 2–1 System Components MR−0486−92RAGS Table 2–1 Key to Figure 2–1, System Components Number Component CPU cabinet Zone (A or B) CPU module To memory Primary NCIO module Cross-link cable Local console terminal Remote console terminal (optional) 2–2 Cabinet and Component Descriptions...

  • Page 29: Function Of The Console Components

    Table 2–2 describes the function of each console component. Table 2–2 Function of the Console Components Part Function Local console terminal Terminal located with the system that is used for console input and display output. Remote console port One remote port is available in each zone. The port may be connected to a remote console terminal through a modem.

  • Page 30: Console Operating Modes

    2.3.1 Entering CIO Mode The CIO mode is entered when you turn on system power if: • The Zone Halt Enable switch is pressed • A STOP/ZONE instruction is executed • A severe processor condition occurs • An external halt is detected Once entered, the console prompt >>>...

  • Page 31: Console Control Characters And Function Keys

    2.4 Console Control Characters The ASCII control characters and function keys listed in Table 2–3 have special meanings when typed on a console terminal. Table 2–3 Console Control Characters and Function Keys Character/Key Function In CIO mode, acts like . In PIO mode, causes the processor to Break Ctrl/C halt and begin running the console program.

  • Page 32: 2.5 Console Command Language Syntax

    2.5 Console Command Language Syntax The console commands accept qualifiers. Qualifiers specify a numerical value or select an option from a list of options. Command elements may be abbreviated and any extra tabs or spaces are ignored. Unless otherwise noted, numerical values must be given in hexadecimal notation.

  • Page 33: Boot Procedure

    2.6 Bootstrap Procedures The BOOT command initializes the system and then loads and starts the virtual memory bootstrap (VMB) program from read-only memory (ROM). The VMB program, in turn, loads and starts the operating system from the specified boot device. Figure 2–3 shows the steps in the boot procedure. Figure 2–3 Boot Procedure Enter BOOT command at the >>>...
  • Page 34 2.7 Entering CIO Mode To recognize and process CIO commands: • The System Halt Enable switch on both zone control panels must be pressed • The operating software must be halted • The processor must be running the console firmware The example below shows how to use the key to enter CIO mode from PIO Break...

  • Page 35: Qualifiers For Boot

    2.8 CIO Mode Console Commands This section describes the CIO mode console commands. The console commands are listed below with command abbreviations shown in bold capital letters. Boot HElp SHow CLEAR Initialize Start Continue Move Test Deposit MATCH_ZONES X(transfer) Repeat Examine !(comment) Find...

  • Page 36: Vmb Program /R5: Values

    Table 2–6 VMB Program /R5:<flag> Values Hex Value Function Action Conversational Returns to the SYSBOOT> prompt. boot Debug Maps the XDELTA program into the system page table. Initial Operating system issues a breakpoint after breakpoint turning on memory management. Secondary boot Boots from boot block specified in /R4:n.

  • Page 37: Qualifiers For Deposit

    2.8.3 CONTINUE CONTINUE exits the CIO mode and returns operation to the PIO mode. Caution Use CONTINUE to continue from a system halt. Use START/ZONE to continue from a zone halt. The CONTINUE syntax is: CONTINUE 2.8.4 DEPOSIT DEPOSIT stores the specified data in the specified address. When the system is initialized or when any transition from a running to a halted state occurs, the defaults are physical address space 0 and data size longword.

  • Page 38: Indirect Addressing

    Table 2–9 Address-Spec Symbolic Addresses Symbolic Address Description R<n> General purpose register number n, where n is a decimal number 0 to 15. Frame pointer. Argument pointer. Stack pointer. Program counter. Program status longword. A location following the last location accessed by an EXAMINE or DEPOSIT.

  • Page 39: Qualifiers For Dup

    2.8.5 DUP DUP connects to the DSSI DUP service on a selected node. DUP is used to examine and modify the parameters of a DSSI device. DUP syntax is: DUP[/PATH:<path-number>] node-id /[TASK:task] The node-spec identifies the node number (0 to 7) of a DSSI device attached to the console.

  • Page 40: Qualifiers For Examine

    Table 2–11 Qualifiers for EXAMINE Qualifier Function Sets the data size to byte. Sets the data size to word. Sets the data size to longword. Sets the data size to quadword. Sets general purpose register address space R0 through PC. Sets internal processor register (IPR) address space accessed by the MTPR and MFPR instructions.

  • Page 41: Qualifiers For Find

    2.8.7 FIND FIND searches the main memory beginning at physical address space 0 for either a page-aligned 512-Kbyte segment of memory, or a restart parameter block (RPB). When FIND is successful, it saves the address plus the segment of memory (or RPB) in the stack pointer.

  • Page 42: Initialize Steps

    2.8.9 INITIALIZE INITIALIZE performs the steps shown in Table 2–14. Table 2–14 INITIALIZE Steps Step Action Do hard reset of zone (the cross-link state is set to off). Do hard reset of all available ATMs. Initialize hardware. Reconfigure the zone and update the device configuration block (DCB) to reflect the zone status.

  • Page 43: Set Variables And Values

    2.8.12 REPEAT REPEAT continuously executes the specified command. REPEAT applies to the following commands only. • DEPOSIT • EXAMINE REPEAT can be aborted by pressing at the console keyboard. Ctrl/C The REPEAT syntax is: REPEAT command 2.8.13 SET SET modifies the value of the specified variable. The SET syntax is: SET variable value [value] Note...

  • Page 44: Show Variables

    2.8.13.1 SET BOOT SET BOOT saves the values of boot-specs. Space for nine boot-specs is available on the CPU module EEPROM. The first space is reserved for the default boot- spec. The other eight spaces are available to the user. The SET BOOT syntax is: SET BOOT DEFAULT value SET BOOT boot-spec value...

  • Page 45: Start

    Table 2–16 (Cont.) SHOW Variables Variable Description Acceptable Values DSSI/PATH=path- Specifies the zone and number slot number of an adapter connecting to a DSSI device. The path-number format is zss, where: z is the zone ID (A or B). ss is the slot number (10 to 17, 20 to 27) of an adapter connecting to a DSSI device.

  • Page 46: Test

    2.8.16 TEST TEST enables the user to test: • The system • A zone • The CPU and memory Use TEST only when the cross-link state is set to off. The TEST syntax is: TEST [qualifier(s)] Tables 2–17 and 2–18 describe the TEST selection and control qualifiers. Table 2–17 Qualifiers for TEST Selection Qualifier Function...

  • Page 47: Transfer)

    Table 2–18 Qualifiers for TEST Control Qualifier Function /PASSCOUNT:n n is a decimal number from 0 to MAXINT. When n is 0, the passcount is infinite. /NOTRACE Disables the test traces. /COE Continues on error. /NOCONFIRM Disables the test confirmation on destructive tests. /EXTENDED Enables extended error reports.

  • Page 48: Qualifier For Z

    2.8.18 Z Z connects to the firmware of another module in the system. The Z syntax is: Z[/PATH=path-number] Table 2–19 describes the qualifier. Table 2–19 Qualifier for Z Qualifier Function /PATH=path-number Specifies the zone and slot number of a module. The path- number format is zss, where: z is the zone ID (A or B).

  • Page 49: In This Chapter

    System Maintenance 3.1 In This Chapter This chapter includes: • Maintenance strategy • Operating rules and cautions • General troubleshooting procedure • Module fault LEDs • Power system overview • Power system maintenance • Device status and fault indicators • ROM-based diagnostics 3.2 Maintenance Strategy When a hardware component fails, the Model 810 system uses self-diagnosis...

  • Page 50: Before Stopping A Zone

    3.3 Operating Rules and Cautions Table 3–1, Table 3–2, and Table 3–3 contain operating rules for use during a service call. Table 3–4 provides cautions. Table 3–1 Before Stopping a Zone Step Action Do not depend on the accuracy of a zone ID label. Issue SHOW ZONE before STOP/ZONE to check the states of both zones.

  • Page 51: Before Leaving The Site

    Table 3–3 Before Leaving the Site Step Action Issue SHOW DEVICE D to make sure that all disks are either shadow set members or in the process of being copied. Issue SHOW DEVICE E to make sure that all EP/EF drivers are on line. Use FTSS$FSM to show the failover set status: MCR FTSS$FSM Return...

  • Page 52: 3.4 General Troubleshooting Procedure

    Table 3–4 Cautions Do not press ZONE HALT ENABLE and the key to stop a running zone. Break Use STOP/ZONE. If ZONE HALT ENABLE is used, CONTINUE will not resume zone operation. Do not press the Break key or cycle power during the power on or RBD tests. This action may corrupt the EEPROM.
  • Page 53 Table 3–5 (Cont.) General Troubleshooting Procedure Step Action If the replaced FRU did not correct the problem, open the system cabinet front door. Check all module and disk drawer fault LEDs. If any fault LED is on, replace the associated module or device. (See Chapter 5, FRU Removal and Replacement Procedures.) If no module or disk fault LED is on, open the system cabinet rear door.

  • Page 54: Module Fault Leds

    Table 3–5 (Cont.) General Troubleshooting Procedure Step Action If the problem cannot be isolated and repaired, the service call should be escalated to the Customer Service Center for further action. 3.5 Module Fault LEDs Figure 3–1 shows all module fault LED locations. Table 3–6 identifies each module.

  • Page 55: Key To Figure 3-1, Module Fault Leds

    Table 3–6 Key to Figure 3–1, Module Fault LEDs Module CPU module ATM module System Fault (zone control panel) Front end unit DC3 converter DC5 converter Power system controller Console module CAMP module DSSI and Ethernet interface modules 3.6 Power System Overview The following sections describe the power distribution and power components.

  • Page 56: Power System Block Diagram (1 Of 2)

    Figure 3–2 Power System Block Diagram (1 of 2) UTILITY POWER INPUT 120 Vac, 60 Hz Optional Uninterruptible 240 Vac, 50 Hz Power System AC POWER OUTPUT AND DISTRIBUTION With UPS: AC Power Distributed to Power System and Expansion Cabinets Distribution Without UPS: AC Power Distributed Boxes...

  • Page 57: Power System Block Diagram (2 Of 2)

    Figure 3–3 Power System Block Diagram (2 of 2) DC POWER OUTPUT AND DISTRIBUTION DC3 3.3 Vdc/12 Vdc Input DC5 5 Vdc Input Console Extender Module Module −12 Vdc Input DC3 3.3 Vdc/12 Vdc Input DC5 5 Vdc Input IO ATM Module Console Extender Module 12 Vdc...

  • Page 58: Power System Functional Summary

    Table 3–7 Power System Functional Summary Functional Summary Local Disk Converter An LDC is located in each in-zone disk drawer. It provides (LDC) +12 Vdc with fast transit response and tolerance to short-term loading during disk spinup. Also provides +5 Vdc for power logic, and EMI filtering for the 48 V bus.
  • Page 59 Table 3–7 (Cont.) Power System Functional Summary Functional Summary DC5 H7179-AA DC to dc converter which provides +5 Vdc to the CPU, MMB, SIMMs, I/O ATM, interface and console extender modules, as well as +5 Vdc to the I/O ATM internal +5 Vdc to +3.3 Vdc converter for the SOC.

  • Page 60: System Dc Voltage Summary

    Table 3–8 System DC Voltage Summary Component Supplies . . . To . . . DC5 (H7179-AA) +5 Vdc CPU, I/O ATM, console extender, and interface modules DC3 (H7178-AA) +3.3 Vdc CPU, I/O ATM, console extender, and interface modules DC3 (H7178-AA) +12 Vdc CPU, I/O ATM, console extender, and interface modules...

  • Page 61: Power Module Controls And Indicators

    Figure 3–4 Power Module Controls and Indicators CAMP MR−0483−92RAGS Table 3–9 Key to Figure 3–4, Power Module Controls and Indicators Item Control/Indicator Function Repair Action AC Circuit Breaker FEU Failure When on, indicates the Replace the FEU. See dc output voltages for the Chapter 5.
  • Page 62 Table 3–9 (Cont.) Key to Figure 3–4, Power Module Controls and Indicators Item Control/Indicator Function Repair Action DC3 OK When on, indicates that the output voltages are within the specified tolerances. AC Present When on, indicates ac power If ac power is present, is present at the ac input check the power source and connector, regardless of the...

  • Page 63: Fan, Ldc, Temperature Error Codes

    Table 3–9 (Cont.) Key to Figure 3–4, Power Module Controls and Indicators Item Control/Indicator Function Repair Action Fault ID Display Displays the power subsystem fault codes. PSC Reset Button When out, indicates a PSC Press in to reset. fault condition. CAMP Fan Fault When on, indicates that a fan Replace the fan.

  • Page 64: Feu Error Codes

    Table 3–11 FEU Error Codes Error Code Failure Error Description E200 48V_SWITCHED OK before enabling E201 Fan converter operating before enabling E202 HVDC is OK, but POWER is not OK (contradictory status) E203 The ac current is not OK (in idle state/loop) E204 48V_DIRECT is not OK and POWER is OK (IRQ18) E205...
  • Page 65 Table 3–12 (Cont.) PSC Error Codes Error Code Failure Error Description E018 Unimplemented opcode interrupt occurred (invalid instruction) E019 Masked interrupt occurred (HSI FIFO 4th entry) E020 Masked interrupt occurred (Timer 2 capture) E021 Masked interrupt occurred (Timer 2 overflow) E022 PSC bias supply failed (NMI occurred) E023...

  • Page 66: Dc To Dc Converter Error Codes

    Table 3–12 (Cont.) PSC Error Codes Error Code Failure Error Description E098 Unused error condition E099 Unused error condition Table 3–13 12 V DC to DC Converter Error Codes Error Code Fault Fault Fault Fault Error Description E010 — — —...

  • Page 67: Device Status And Fault Indicators

    Table 3–15 3 V DC to DC Converter Error Codes Error Code Fault Error Description E120 Out of regulation low E121 Out of regulation high E122 Undervoltage E123 Overvoltage E124 Voltage present when disabled E125 Did not turn off Table 3–16 5 V DC to DC Converter Error Codes Error Code Fault...

  • Page 68: Rf35 Disk Drawer Controls And Indicators

    Figure 3–5 RF35 Disk Drawer Controls and Indicators D1 D2 FAULT WRITE PROT LINE 0−1 ON/OFF SET UP D4 D5 FAULT WRITE PROT LINE 0−1 ON/OFF SET UP MR−0436−92RAGS Table 3–18 RF35 Disk Drawer Controls and Indicators Control/Indicator Color State Operating Condition Fault Drive is faulty.

  • Page 69: Sf35 Operator Control Panel

    3.8.2 SF35 Storage Array Figure 3–6 shows the operator control panel. Table 3–19 describes their functions. Figure 3–7 shows the rear of the storage array. Table 3–20 describes the functions of the controls and indicator located at the rear of the storage array. Figure 3–6 SF35 Operator Control Panel Operator Control...

  • Page 70: Sf35 Operator Control Panel Description

    Table 3–19 SF35 Operator Control Panel Description Control/Indicator Function Ready Push-to-set switch with green indicator. Brings the integrated storage element (ISE) on-line in about 10 seconds. The indicator remains on while the ISE is on-line. Write Protect Push-to-set switch with amber indicator. Write protects the data on the ISE.

  • Page 71: Sf35 Rear Panel Fault Indicator

    Figure 3–7 SF35 Rear Panel Fault Indicator DSSI Connectors d i g i t a l F A U L T F A U L T F A U L T Power Supply Fault Indicator (Behind Panel) Line Voltage AC Power Selector Switch Switch (Behind Panel)

  • Page 72: Location Of Sf73 Storage Array Leds And Switchpacks

    3.8.3 SF73 Storage Array Figure 3–8 shows the SF73 storage array status and fault indicators. Table 3–21 descibes their functions. Figure 3–9 shows the controls and indicator located at the rear of the storage array. Figure 3–8 Location of SF73 Storage Array LEDs and Switchpacks d i g i t a l Write DSSI...

  • Page 73: Rear Of The Sf73 Storage Array

    Figure 3–9 Rear of the SF73 Storage Array DSSI Connectors F A U L T F A U L T F A U L T Power Supply Fault Indicator (Behind Panel) Line Voltage AC Power Selector Switch Switch (Behind Panel) M R - 0 4 2 2 - 9 2 D G System Maintenance 3–25...

  • Page 74: Tf85C Cartridge Tape Drive

    3.8.4 TF85C Tape Drive Table 3–22 may help you define and correct TF85C tape drive problems. Table 3–22 TF85C Tape Drive Problems Problem Possible Solution Correctable failure If the TF85C drive fails during operation, reset the the drive, then during operation rewind, unload, and remove the cartridge.

  • Page 75: Tf85C Cartridge Tape Drive Indicators

    Table 3–23 TF85C Cartridge Tape Drive Indicators Indicator Color State Operating Condition Write Protected Orange Tape is write-protected. Tape is write-enabled. Tape in Use Yellow Blinking Tape is moving. Tape is loaded; ready for use. Use Cleaning Orange Drive head needs cleaning or tape is bad. Tape If it remains on after Then the cleaning was not completed because the...

  • Page 76: Tf857 Operator Control Panel

    Figure 3–11 TF857 Operator Control Panel Operator Control Panel E j e c t Button L o a d / U n l o a d Indicator Mode Select Key Area S l o t S e l e c t Disabled Automatic OCP Label...

  • Page 77: Rom-Based Diagnostics

    Table 3–24 (Cont.) TF857 OCP Controls and Indicators Control/Indicator Color Function Load/Unload button – Loads the currently selected cartridge into the drive, or unloads the cartridge from the drive to the magazine. If the Loader Fault or Magazine Fault indicators are on, can also be used to reset the subsystem.

  • Page 78: Test

    3.9.1 TEST TEST enables the user to test: • The system • A zone • The CPU and memory Use TEST only when the cross-link state is set to off. The TEST syntax is: TEST [qualifier(s)] Tables 3–25 and 3–26 describe the TEST selection and control qualifiers. Table 3–25 Qualifiers for TEST Selection Qualifier Description...

  • Page 79: Cpu Rom-Based Diagnostic Descriptions

    3.9.2 Z Z connects to the firmware of another module in the system. It is also used to initiate I/O ROM-based diagnostics. The Z syntax is: Z[/PATH=path-number] Table 3–27 describes the qualifier. Table 3–27 Qualifier for Z Qualifier Function /PATH=path-number Specifies the zone and slot number of a module.
  • Page 80 Table 3–28 (Cont.) CPU ROM-Based Diagnostic Descriptions Group Test Subtest Description G: 0 T: 1 S: 0 P-CACHE Register Bit Test G: 0 T: 1 S: 1 P-CACHE Tag Integrity Test G: 0 T: 1 S: 2 P-CACHE Data Integrity Test G: 0 T: 1 S: 3...
  • Page 81 Table 3–28 (Cont.) CPU ROM-Based Diagnostic Descriptions Group Test Subtest Description G: 0 T: 7 S: 5 DMA Sub-Trasfer Length Test G: 0 T: 7 S: 6 DMA I/O Byte Alignment Test G: 0 T: 7 S: 7 DMA Memory Byte Alignment Test G: 0 T: 7 S: 8...

  • Page 82: I/O Rom-Based Diagnostic Descriptions

    Table 3–28 (Cont.) CPU ROM-Based Diagnostic Descriptions Group Test Subtest Description G: 2 T: 2 S: 0 ACCESS I/O Module Path Access Test G: 2 T: 2 S: 1 ACCESS I/O Module SSC Console Uart Test G: 2 T: 2 S: 2 ERROR I/O Crosscheck Test G: 2...
  • Page 83 Table 3–29 (Cont.) I/O ROM-Based Diagnostic Descriptions Group Test Subtest Description G: 0 T: 1 I/O VIC Test G: 0 T: 1 S: 0 VIC Register Test G: 0 T: 1 S: 1 VIC Interrupt Test G: 0 T: 2 I/O Firewall Test G: 0 T: 2...
  • Page 84 The following example shows an I/O RBD error frame. >>> z Connecting to target...Press Ctrl/P to end connection IO1> group: 0 test: 4 subtest:1 ====================================================================== ----------------------- DIAGNOSTIC TEST ERROR ---------------------- GROUP: 00 Test: 04 Sub: 01 Error: 03 Pass: 00000001 Addr: 00000000 Exp: 00000000 Rec: 000000ff...

  • Page 85: In This Chapter

    Error Handling and Analysis 4.1 In This Chapter This chapter includes: • Error handling services overview • Field replaceable units • OpenVMS error log • Module NVRAM status and LED indicators • FTSS error reporting interface • Firmware interfaces • Firmware and OpenVMS interface data structures •...

  • Page 86: Hardware Error Handling Flowchart

    EHS error notification is described in Table 4–1. Table 4–1 EHS Error Notification Step Action Entries are made into the system error log. Status information is written to the module ID NVRAM and the DCB, where applicable. The LED indicator associated with a failed module is set. A call is issued to the error reporting interface (ERI) which reports the event to the FTSS$SERVER.

  • Page 87: Error Handling Flowchart Definitions

    Table 4–2 Error Handling Flowchart Definitions Event Definition Hardware reports error through a high-level interrupt and control is transferred to the EHS. The EHS examines system registers to determine the type of failure which has occurred. The EHS identifies the FRU that is the source of the error. FRU isolation is generally accomplished at the module level.

  • Page 88: Ehs Architectural Position

    Figure 4–2 EHS Architectural Position Error Handling Services Functions System Utilities Error Reporting Interface Error Event Notification System Error Log IZC Routines Serial Interrupts Remote Zone Zone Available Interface Serial Transmit/Receive Resets VAXELN and Diagnostics Firmware Interface Status Console and Diagnostics Registers Hardware Interface System Hardware...

  • Page 89: Error Types

    Table 4–3 (Cont.) System Operating Modes Mode Definition Duplex The memories in both zones are identical and both CPUs are running in lockstep. The I/O subsystems of both zones are available and in use. The cross-link state in both zones is Duplex. The system can be booted in this mode, or can transition to this mode as the result of the synchronization process from either Simplex or Degraded Duplex modes.
  • Page 90 Table 4–4 (Cont.) Error Types Error Type Definition Double-Bit Hardware reports a double-bit error (DBE) when the ECC checkers detect memory this condition on a read from a main memory location. This read can occur errors during a DMA or CPU cycle, with two possible error causes: a memory failure or a programming error.
  • Page 91 Table 4–4 (Cont.) Error Types Error Type Definition Single-Bit Single-Bit Errors (SBEs) can be detected by either the JXD during a DMA memory read cycle which reads from main memory or the CPU during a memory errors read. Software action varies depending upon the system operating mode and where the error detection occurs.
  • Page 92 Table 4–4 (Cont.) Error Types Error Type Definition Power If a zone loses power in a non-Simplex configuration, hardware generates failures an interrupt to report the event to the EHS. In a non-Duplex mode, software will detect this error only when the slave zone loses power. In this case, the slave zone is removed from the configuration and the system continues to run in Simplex mode.
  • Page 93 Table 4–4 (Cont.) Error Types Error Type Definition Halt errors A halt error occurs when the system is operating in Duplex mode, the Zone Halt Enable switch on the zone control panel is pressed, and the Break is pressed on one of the system consoles, or one zone experiences errors on its halt lines.

  • Page 94: Vaxeln Error Handling

    Table 4–4 (Cont.) Error Types Error Type Definition I/O errors The ATM module contains a series of checkers that verify consistency between the dual rails of the system during I/O accesses. When discrepancies are detected, the hardware generates an interrupt, invoking the EHS.

  • Page 95: Vaxeln Error Classes

    Table 4–5 describes the VAXELN error classes and the actions taken by the EHS. Table 4–5 VAXELN Error Classes Error Class Description EHS Actions VAXELN Kernel This error is reported when the The FRU is the I/O expansion Fatal VAXELN kernel detects a fatal module.

  • Page 96: System Frus

    4.3 Field Replaceable Units (FRUs) After analyzing error information and determining the error type, the EHS isolates the source of the error to a FRU. If the error was solid, the system is deconfigured to remove the FRU from service. If the error is transient, it is compared against a threshold for the error type and FRU.

  • Page 97: Atm Deconfiguration Actions

    4.3.2 Deconfiguration This section describes the actions taken by the EHS when a FRU is identified as the source of a solid error or transient errors which exceed the FRU threshold. A table is provided for each FRU that describes the actions taken by the EHS when the FRU is deconfigured.

  • Page 98: Cpu Deconfiguration Actions

    4.3.2.2 CPU Module and Memory When memory is deconfigured from the system, it is done by removing the CPU module on which the memory resides. Table 4–8 describes the OpenVMS operating system actions taken when a CPU module or memory is identified as the FRU and is deconfigured by the EHS. These actions are identical for CPU and memory failures.

  • Page 99: I/O Expansion Module Deconfiguration Actions

    Table 4–9 I/O Expansion Module Deconfiguration Actions Action Taken Description I/O hard reset The I/O expansion module which is being deconfigured is reset through the cross-link I/O hard reset register. Set I/O expansion The module I2C bus is used to turn on the LED for the failed module LED module.

  • Page 100: Zone Deconfiguration Actions

    4.3.2.5 Zone Table 4–11 describes the OpenVMS operating system actions taken when an entire zone is identified as the FRU and is deconfigured by the EHS. Note that some actions are dependent on the system operating mode. Table 4–11 Zone Deconfiguration Actions Action Taken Description Comments...

  • Page 101: Fru Thresholds

    4.3.3 Application of Thresholds Application of thresholds by the EHS is rate based. An FRU exceeds its threshold when it accumulates a certain number of a given error type in a specified time period. Table 4–13 lists the thresholds associated with each FRU and error type. In most cases, more than one type of error can result in the isolation of an FRU.
  • Page 102 Table 4–13 (Cont.) FRU Thresholds Error Error Time Type Limit Period Comments I/O Expansion Module Transient When the threshold is exceeded, the module is NXIO errors deconfigured except in Simplex system. Transient When the threshold is exceeded, the module is I/O errors deconfigured except in Simplex system.

  • Page 103: Openvms Error Log Format

    4.4 OpenVMS Error Log The EHS makes entries in the system error log for all system error interrupts. Figure 4–3 shows the format of the error log. With the exception of the Fault Data block, all blocks have fixed length. Figure 4–3 OpenVMS Error Log Format Number of Longwords Fault Summary...

  • Page 104: Fault Summary Block Entry Descriptions

    4.4.1 Fault Summary The Fault Summary block contains the fault ID, fault flags describing the nature of the fault, the cross-link mode at the time the fault occurred, and the cross-link mode after the error handling was completed. All fields in this block are valid for all error entries.
  • Page 105 Table 4–15 (Cont.) Fault Summary Block Entry Descriptions Entry Contents 23 - Power gone end action (reserved for future use) 24 - Clock error end action 25 - Other zone halted end action (reserved for future use) 26 - Resynch abort error end action (reserved for future use) 27 - CPU-detected single-bit error end action 28 - JXD-detected single-bit error end action (reserved for future use)

  • Page 106: Fru Information

    Table 4–15 (Cont.) Fault Summary Block Entry Descriptions Entry Contents [07:04] - Not used XLINK_MODE_ Cross-link mode at the time of error. The following values are ERROR defined: 0 - Off (Simplex) 1 - Slave 2 - Master 3 - Duplex 4 - Not used 5 - RESYNCH_SLAVE 6 - RESYNCH_MASTER...

  • Page 107: Fru Information Block Entry Descriptions

    Table 4–16 FRU Information Block Entry Descriptions Entry Contents FRU_TYPE The following bits are defined: 01 - The FRU is a module in Zone A (FRU_DATA has slot ID) 02 - The FRU is a module in Zone B (FRU_DATA has slot ID) 03 - Zone A is the FRU 04 - Zone B is the FRU 05 - The cross-link cable is the FRU...

  • Page 108: Deconfiguration Information Block

    4.4.3 Deconfiguration Information This error log block contains information about any system deconfiguration performed by the EHS. Figure 4–6 identifies each entry in the block and the offset from the start of the block. Table 4–17 describes the content of each entry. Note For errors which require no system deconfiguration, only the FT_FLAGS fields will be filled in.
  • Page 109 Table 4–17 (Cont.) Deconfiguration Information Block Entry Descriptions Entry Contents DECONFIG_ This field shows the Zone A modules removed from service as MODULES a result of error handling. For example, if the source of a solid or excessive transient error were an I/O expansion module, all attached interface modules have been removed from service.

  • Page 110: Threshold Information Block Entry Descriptions

    4.4.4 Threshold Information When the Transient Error flag is set in the FAULT_FLAGS field of the Fault Summary block, the isolated FRU error is compared to its error rate threshold. When threshold is exceeded, the FRU will be removed from the system. In addition, the Excessive Transient Errors flag is set in the FAULT_FLAGS field.

  • Page 111: Fault Data

    4.4.5 Fault Data The Fault Data block has a variable length specific to the class of the fault which occurred. The error class can be determined by the high-order four bits of the FAULT_ID field in the Fault Summary block (see Table 4–15). The six Fault Data types based on these fault classes are shown in Figure 4–8 and described in the following subsections.

  • Page 112: System Register Entry Descriptions

    Table 4–19 System Register Entry Descriptions Entry Content Offset SYSFLT JXD System Fault Register SYSADR JXD System Error Address Register DMAADR DMA Error Address Register DMA_IO_ADDR DMA Engine I/O Error Address Register JCSR_A JXD Control and Status Register - Zone A JCSR_B JXD Control and Status Register - Zone B JDIAG_P_A...

  • Page 113: End Actions Register Descriptions

    Table 4–20 End Actions Register Descriptions Entry Content Offset SYSFLT JXD System Fault Register SYSADR JXD System Error Address Register JCSR JXD Control and Status Register JDIAG_P JXD Diagnostic Error Register - primary rail JDIAG_M JXD Diagnostic Error Register - mirror rail MMBERR0 JXD ROM BUS MMB Error Register 0 MMBERR1...

  • Page 114: End Action Timeout Block

    Figure 4–9 shows the format of this Fault Data block entry and its offset. Table 4–21 contains a brief description of the entry. Figure 4–9 End Action Timeout Block TIMEOUT_INT (Timeout Interval) MR−0013−93RAGS Table 4–21 End Action Timeout Block Entry Description Entry Content Offset...
  • Page 115 Table 4–22 (Cont.) VAXELN Detected Error Block Entry Descriptions Entry Contents 5 - VAXELN job fatal error 6 - VAXELN job recoverable error (reserved for future use) ERROR_TYPE VAXELN error type: 1 - Hardware error 2 - Software error 3 - Unknown error JOB_ID VAXELN component job with error: 0 - Interface module 0 driver job...
  • Page 116 Table 4–22 (Cont.) VAXELN Detected Error Block Entry Descriptions Entry Contents 20080 DAL parity error. Read error - normal read 30080 Cache parity error. Read error - normal read 40080 Uncorrectable read data error. Read error - normal read 50080 DMA error.
  • Page 117 Table 4–22 (Cont.) VAXELN Detected Error Block Entry Descriptions Entry Contents Normal successful completion 7C04 Bad parameter count 7C0C Bad job or process creation 7C14 Bad string parameter length 7C1C Bad access mode 7C24 Bad stack 7C2C Bad object state 7C34 Bad object type 7C3C...

  • Page 118: Software Detected Errors

    Table 4–22 (Cont.) VAXELN Detected Error Block Entry Descriptions Entry Contents 7D2C No virtual address space available 7D34 Power recovery signal 7D3C Quit signal 7D44 Remote port value 7D4C Process exit signal 7D54 Remote system currently unreachable 7D5C Interprocess signal 7D64 Remote system rejected username or password 7D6C...

  • Page 119: Software Detected Error Block

    Figure 4–11 Software Detected Error Block MODULE_STATUS RESET_REASON RESET_ACTION MR−0007−93RAGS Table 4–23 Software Detected Error Block Entry Descriptions Entry Contents MODULE_STATUS Hexidecimal module ID NVRAM status code. The following values are defined: Excessive CPU/MEM faults Excessive resynchronization abort errors Double-bit error Excessive single-bit errors Excessive clock phase errors Excessive CPU I/O errors...

  • Page 120: Unsynchable Events

    Table 4–23 (Cont.) Software Detected Error Block Entry Descriptions Entry Contents Fatal memory error has occurred Single-bit error has occurred User command issued to stop a zone Unexpected machine check has occurred Software detected failure has occurred Solid NXIO error has occurred Excessive transient I/O expansion module errors have occurred A solid I/O error has occurred Excessive transient I/O errors have occurred...

  • Page 121: Unsynchable Event Block

    Figure 4–12 shows the format of this Fault Data block and the offset of each field from the start of the block. Table 4–24 contains a brief description of each entry. Figure 4–12 Unsynchable Event Block COMPAT_STS (Test Status) DIAG_STS (Diagnostic Status) MR−0008−93RAGS Table 4–24 Unsynchable Event Block Entry Descriptions Description...

  • Page 122: Module Nvram Status And Led Indicators

    Table 4–24 (Cont.) Unsynchable Event Block Entry Descriptions Description CPU memory configuration mismatches with other zone Cables (cross-link/resynchronization) CPU is in burn-in mode Ethernet EEPROM mismatches with other zone CPU console firmware cannot be run in Duplex [31:28] Not used DIAG_STS System diagnostic status longword.

  • Page 123: Module Id Nvram/Dcb Status Codes

    such cases, diagnostics on the remote zone are relied on to report the failure. Table 4–25 Module ID NVRAM/DCB Status Codes Status Code Description Affected Modules The threshold for CPU/MEM faults for CPU module this module has been exceeded. The threshold for resynch abort errors CPU module for this module has been exceeded.

  • Page 124: Ftss Event Reporting Interface

    4.6 FTSS Event Reporting Interface The EHS externalizes events by reporting them to the event reporting interface (ERI). The ERI, in turn, passes notification of the event to the FTSS$SERVER process. The server reports the event in one of three ways: 1.
  • Page 125 FTSS$_CLOCK_ENDTMO, Clock fault end action timeout on zone [zone_id] Facility: FTSS Explanation: When a clock fault occurs in a non-Simplex system, diagnostics normally run on the failed zone and, upon completion, report status back to the zone running the operating system. If this end action does not occur within a reasonable timeout period, the failure will be treated as solid and the zone will not be automatically resynchronized by FTSS.
  • Page 126 FTSS$_CPUDBE, Double-bit memory fault detected on [module_id] in slot [slot_ id], zone [zone_id] Facility: FTSS Explanation: A double-bit memory error has occurred. This indicates a solid memory failure. This error will only be reported in a Duplex system and a CPU module will be removed from service when it occurs.
  • Page 127 FTSS$_DBE_END, DBE end action complete Facility: FTSS Explanation: Error processing for a double-bit memory error has been completed and the CPU is available to be resynchronized. User Action: The system error log should be examined for entries which correspond to the double-bit error. These error logs will identify an FRU. FTSS$_DBE_ENDTMO, DBE end action timed out on zone [zone_id] Facility: FTSS Explanation: When double-bit memory errors occur in a Duplex system,...
  • Page 128 FTSS$_ELNJOBFATAL, VAXELN job fatal error detected on [module_id] in slot [slot_id], zone [zone_id] Facility: FTSS Explanation: A VAXELN job running on an I/O Expansion module has detected a fatal error and has terminated. This error results in the removal of the associated Interface module from the system. User Action: The system error log should be examined for entries which correspond to the VAXELN job fatal error.
  • Page 129 FTSS$_ELNMASFATAL, VAXELN master job fatal error detected on [module_ id] in slot [slot_id], zone [zone_id] Facility: FTSS Explanation: The VAXELN master job running on an I/O Expansion module has detected a fatal error and has terminated. This error results in the removal of the indicated I/O Expansion module and associated Interface modules from the system configuration.
  • Page 130 FTSS$_POWERGONE, Power gone fault detected on zone [zone_id] Facility: FTSS Explanation: Power has been lost in one of the zones. This error is compared to its error rate threshold. If the threshold is not exceeded, the zone will be automatically resynchronized when power returns. User Action: If power is restored and the zone is automatically resynchronized, no action is required on the part of the user.
  • Page 131 FTSS$_SOLIDNXIO, Solid NXIO fault detected on [module_type] in slot [slot_ id], zone [zone_id] Facility: FTSS Explanation: A fatal nonexistent I/O error has occurred when accessing the indicated I/O module. The module is removed from service by the operating system. User Action: The system error log should be examined for entries which correspond to the nonexistent I/O error.
  • Page 132 FTSS$_TRNSIOMOD, Transient I/O fault detected on [module_type] in slot [slot_id], zone [zone_id] Facility: FTSS Explanation: A transient I/O miscompare error was detected and attributed to the indicated module. These errors are compared to their error rate threshold. If the threshold is exceeded and the system mode is not Simplex, the module is removed from service.

  • Page 133: Deconfiguration Messages

    FTSS$_ZONEHALT, Zone Halt fault detected on zone [zone_id] Facility: FTSS Explanation: A single zone of a Duplex system has been halted. This can be caused by a user command on the system console or by a system error. User Action: If the Halt was caused by a user command on the system console, a START/ZONE command must be executed to restore the zone to service.

  • Page 134: Firmware Interfaces

    FTSS$_DECONFIG_EXMOD, I/O expansion module in slot [slot_id], zone [zone_ id] has been removed from service Facility: FTSS Explanation: Due to one or more system errors, the indicated I/O Expansion module and its associated Interface modules have been removed from service. User Action: The system error log should be examined for entries which correspond to the removal of the I/O expansion module.

  • Page 135: System Reset Action Codes

    4.7.1.1 System Resets When the EHS determines that a zone or CPU should be removed from the configuration, it forces a reset on the CPU. The reset results in the system console being invoked from serial ROM by the hardware. When system console runs, it attempts to determine the reason for the reset, which in turn may determine the actions performed by the console.

  • Page 136: System Reset Reason Codes

    Table 4–27 System Reset Reason Codes Decimal Value Description When the EHS detects zone divergence, it selects one zone to continue the OpenVMS operating system and one zone to stop. Note that the OpenVMS operating system is not indicating an error in this zone; it must stop one of the two.

  • Page 137: Cca Fields

    4.7.1.2 CCA Fields When a CPU or zone completes diagnostics, it enters its halt loop, which reports its status to the OpenVMS operating system in the other zone through the IZC service. The IZC service will in turn call the OpenVMS operating system to report the availability of the other zone.

  • Page 138: Firmware And Openvms Data Structure Memory Map

    Table 4–29 I/O Reset Action Code Description Decimal Value Description This reset code will cause the I/O expansion module console to invoke diagnostics. The diagnostics which run depend upon the mode of the cross-link at the time. After diagnostics, console will enter its halt loop. Table 4–30 I/O Reset Reason Code Descriptions Decimal Value...

  • Page 139: Cca Component Descriptions

    4.8.1 Console Communications Area The console communications area (CCA) is the main data structure used by the console to interface with the OpenVMS operating system. Table 4–31 describes the CCA components. Table 4–31 CCA Component Descriptions Parameter Size Description CCA size 2 bytes Size of the CCA in bytes.
  • Page 140 Table 4–31 (Cont.) CCA Component Descriptions Parameter Size Description Bootability 4 bytes Results of the bootstrap test. Written by the firmware. Field test results breakdown by bit: • 00 = CPU/ATM check. Set when the CPU and ATM are good. •...

  • Page 141: Duplex Compatibility Test

    Table 4–31 (Cont.) CCA Component Descriptions Parameter Size Description Diagnostic 8 bytes Results of the diagnostic tests. Initialized by firmware. status Breakdown of the status fields: • [07:00] = Error number • [15:08] = Subtest number • [23:26] = Test number •...

  • Page 142: Duplex Compatibility Test Failure Codes

    • CPU module ID EEPROM: Valid checksum OpenVMS and firmware status byte is good Module ID and module name compatible with other zone Module hardware revision compatible with other zone (major) Firmware and software revisions compatible with other zone (major) •...

  • Page 143: Dispatch Block Structure

    Table 4–32 (Cont.) Duplex Compatibility Test Failure Codes Failure Code Bit Number Code Description CPU ID EEPROM software revision (major) mismatches between zones ATM ID EEPROM is bad ATM ID EEPROM OpenVMS status field shows module is bad ATM ID EEPROM firmware status field shows module is bad ATM ID EEPROM module type field mismatches between zones ATM ID EEPROM module name field mismatches between zones ATM ID EEPROM hardware revision (major) mismatches between...

  • Page 144: Dispatch Block Components

    Table 4–33 Dispatch Block Components Block Content Offset Description Dispatch reason Base + 00h Code identifying reset reason. Bytes 03:02 code 4 bytes identify the reason for the reset. Bytes 01:00 identify the end action to be taken by the console as specified below: •...

  • Page 145: Bpb Entry Components

    Table 4–35 BPB Entry Components Component Length Description Unit number 2 bytes Device unit number. Valid numbers are in the 0 to 999 (decimal) range. Device 2 bytes Device name in ASCII (that is, EP and DI). Path identifier 1 byte Path to device.
  • Page 146 Table 4–37 (Cont.) DCB Entry Components Component Length Description Status 1 byte Module status summary. This field is a summary of the summary OpenVMS and firmware status fields. The field should be updated whenever OpenVMS or firmware status fields are updated.

  • Page 147: Sub-Device Configuration Blocks

    Table 4–37 (Cont.) DCB Entry Components Component Length Description Ethernet 32 bytes Module Ethernet address. Follows the DEC STD format. address Valid only for CPU module and LANCE adapter card. Copied from the Ethernet EEPROM by firmware for the CPU. Copied from the LANCE ROM for the LANCE adapter card.

  • Page 148: Subdcb Links To Dcb

    Figure 4–15 SubDCB Links to DCB SubDCB for DCB Entry 1 Number of Entries DCB Entry 1 DCB Entry 2 CCA Base + Offset DCB Entry n−1 Zone A DCB Offset DCB Entry n Zone B DCB Offset Zone A DCB Number of Entries DCB Base + Offset...

  • Page 149: Cpu Subdcb Components

    Table 4–38 CPU SubDCB Components Component Length Description Number of 4 bytes Number of entries in the SubDCB. Initialized by firmware. entries Is 0 if no entries are present. SubDCB 16 bytes An entry describes an MMB found by the firmware. entries per entry Initialized by firmware.

  • Page 150: Fault Summary Block

    4.9 Error Log Analysis 4.9.1 CPU/MEM Fault Error Log Entry V A X / V M S SYSTEM ERROR REPORT COMPILED 3-FEB-1993 09:33:44 PAGE 40. ******************************* ENTRY 686. ******************************* ERROR SEQUENCE 1033. LOGGED ON: SID 17000002 DATE/TIME 2-FEB-1993 18:15:45.55 SYS_TYPE 02010101 SYSTEM UPTIME: 0 DAYS 01:47:45 SCS NODE: SIXSHL VAX/VMS T5.5-D34...
  • Page 151 V A X / V M S SYSTEM ERROR REPORT COMPILED 3-FEB-1993 09:33:44 PAGE 41. THRESHOLD INTER.0000A8C0 THRESHOLD INTER. SECONDS = 43200. THRESHOLD COUNT 00000001 THRESHOLD COUNT = 1. THRESHOLD LIMIT 00000003 THRESHOLD LIMIT = 3. THRESHOLD ZEROED0000190E THRESHOLD ZEROED SECONDS = 6414. THRESHOLD TOTAL 00000001 THRESHOLD TOTAL = 1.
  • Page 152 V A X / V M S SYSTEM ERROR REPORT COMPILED 3-FEB-1993 09:33:44 PAGE 42. MMBERR1_B Register Invalid SERCSR_A REG 00000080 Loopback request Enable query interrupt SERCSR_B Register Invalid SERMODE_A REG 00200912 Master Operating System is running Clock fault enable Clock select 0 = Master, 1 = Slave Halt source 0 = A, 1 = B SERMODE_B Register Invalid...

  • Page 153: Cpu/Mem Fault End Action Error Log Entry

    4.9.2 CPU/MEM Fault End Action Error Log Entry V A X / V M S SYSTEM ERROR REPORT COMPILED 3-FEB-1993 09:33:46 PAGE 56. ******************************* ENTRY 701. ******************************* ERROR SEQUENCE 1048. LOGGED ON: SID 17000002 DATE/TIME 2-FEB-1993 18:16:21.40 SYS_TYPE 02010101 SYSTEM UPTIME: 0 DAYS 01:48:21 SCS NODE: SIXSHL VAX/VMS T5.5-D34 INT60 ERROR KA560 CPU FW REV# 2.
  • Page 154 V A X / V M S SYSTEM ERROR REPORT COMPILED 3-FEB-1993 09:33:46 PAGE 57. Fault Data Block END ACTION SYSFLT 30020020 I/O error, zone B CPU/memory fault, zone B XLINK MODE = Duplex SYSADR 61200034 SYSADR = 61200034(X) CNTRL/STAT REG 00000008 System errors enabled DIAG_P REG CAC08000...
  • Page 155 V A X / V M S SYSTEM ERROR REPORT COMPILED 3-FEB-1993 09:33:46 PAGE 58. BIU CTL DFE0DEF9 Generate/Expect ECC on check_h pins output enable of cache rams direct mapped 2X CPU Cycle IO Map = 1(X) 512 Kbytes BC TAG 07913800 tag_match tag control V...

  • Page 156: Fault Data Block

    4.9.3 CPU or Zone Unsynchable Error Log Entry V A X / V M S SYSTEM ERROR REPORT COMPILED 3-FEB-1993 09:33:46 PAGE 56. ******************************* ENTRY 743. ******************************* ERROR SEQUENCE 1099. LOGGED ON: SID 17000002 DATE/TIME 2-FEB-1993 18:16:21.40 SYS_TYPE 02010101 SYSTEM UPTIME: 0 DAYS 01:48:21 SCS NODE: SIXSHL VAX/VMS T5.5-D34 INT60 ERROR KA560 CPU FW REV# 2.
  • Page 157 V A X / V M S SYSTEM ERROR REPORT COMPILED 3-FEB-1993 09:33:46 PAGE 57. CUP or ZONE UNSYNCHABLE EVENTS COMPAR/STAT REG 02000000 CPU is in burnin mode DIAG STATUS REG FFFFFFFF Diagnostic status is valid DIAG ERR NUM DIAG ERR NUM = 255 DIAG SUBTEST NUM DIAG SUBTEST NUM = 255 DIAG TEST NUM...

  • Page 159: Domestic Power Distribution Box

    FRU Removal and Replacement Procedures 5.1 In This Chapter This chapter includes: • Field replaceable unit list • Before you begin • FRU removal and replacement 5.2 Field Replaceable Unit List A complete list of field replaceable units (FRUs) is given in Table 5–1. Table 5–1 Model 810 FRUs Part Number Modules:...
  • Page 160 Table 5–1 (Cont.) Model 810 FRUs Part Number Control and miscellaneous power module (CAMP) 54-21073-01 Options: Ethernet interface module (EIM) 54-21081-01 DSSI extender module 54-21063-01 DSSI interface module (DIM) 54-21065-01 DSSI disk drawer assembly 70-30569-01 Storage: 18.2 Gbyte magazine tape subsystem TF857-AA/AB 2.6 Gbyte cartridge tape drive TF85C-BA...

  • Page 161: Before You Begin

    5.3 Before You Begin Warning Hazadous voltages exist within the system. Bodily injury or equipment damage can result when service procedures are performed incorrectly. Note FRUs should be handled only by qualified maintenance personnel. You do not need to shut down the entire system to remove and replace a FRU. You can shut down the zone that houses the faulty FRU while the other zone continues to operate.

  • Page 162: Handling Frus

    5.3.1 Handling FRUs Static electricity can damage FRUs. When you handle FRUs, follow the rules in Table 5–2. Table 5–2 Handling FRUs Rule Action Wear an electrostatic discharge (ESD) wrist strap. When possible, use a grounded ESD workmat. Attach both the wrist strap and the workmat to the system chassis. Before you remove the FRU from the antistatic box, be sure you ground the box to the system chassis.

  • Page 163: Verifying Zone Shutdown

    Example 5–1 How to Shut Down a Zone $ SHOW ZONE ! Displays the status of each zone. Zone A is ACTIVE ! Zone A is running. Zone B is PROVIDING I/O ONLY ! Zone B has a faulty component. $ STOP/ZONE B ! Stops zone B.

  • Page 164: Fru Removal And Replacement

    Figure 5–1 Latches Latch Location Expander CPU Cabinet Cabinet Expander CPU Cabinet Cabinet Front View Rear View M R - 0 4 5 7 - 9 2 D G 5.4 FRU Removal and Replacement The following sections contain FRU removal and replacement procedures. Caution Service procedures may be performed only by qualified personnel.

  • Page 165: Cpu Module And Atm Module Locations

    5.4.1 CPU and ATM Modules You use the same steps to remove the CPU and ATM modules. Figure 5–2 shows the locations of the modules. Table 5–3 describes the removal procedure. Figure 5–2 CPU Module and ATM Module Locations Captive Screws Module Release...

  • Page 166: Simm Locations

    5.4.2 SIMMs Figure 5–3 shows the locations of the SIMMs. Table 5–4 describes the removal procedure. Note SIMMs are configured on the MMBs in rows, with a pair of SIMMs (two) in each row. You always replace a pair of SIMMs (a two-SIMM row). Figure 5–3 SIMM Locations Retaining Clip...

  • Page 167: Mmb Locations

    5.4.3 MMBs Figure 5–4 shows the locations of the MMBs. Table 5–5 describes the removal procedure. Figure 5–4 MMB Locations Mounting Bracket Screws Mounting Bracket MMB3 MMB0 Mounting Bracket MMB1 MMB2 CPU Module M R - 0 4 1 4 - 9 2 D G Table 5–5 MMB Removal Procedure Step Action...

  • Page 168: Fan Location

    Table 5–5 (Cont.) MMB Removal Procedure Step Action Remove the three screws that secure each of the mounting brackets on the MMB. Note the configuration of the SIMMs on the MMB. They must be removed from the faulty MMB and installed in the same locations on the replacement MMB. Remove the SIMMs from the MMB using the procedure in Table 5–4.

  • Page 169: Fcsb Location

    Table 5–6 Fan and FCSB Removal Procedure Step Action Ask the operator or system manager to shut down the zone using the procedure in Section 5.3.2. Open the rear door of the cabinet. Set the FEU circuit breaker to the off position. Open the front door of the cabinet.

  • Page 170: Rf35 Disk Drive Location

    5.4.5 RF35 Disk Drive Removal and Replacement Figure 5–7 shows an RF35 disk drive in the DSSI disk drawer. Table 5–7 describes the RF35 disk drive removal procedure. Figure 5–7 RF35 Disk Drive Location Release Lever Bracket Phillips Screws (6) Captive Screws (4) Release...

  • Page 171: Rf35 Disk Drive Removal Procedure

    Table 5–7 RF35 Disk Drive Removal Procedure Step Action Ask the operator or system manager to shut down the zone using the procedure in Section 5.3.2. Open the front door of the cabinet. Turn off the RF35 disk drive. Loosen the four screws that secure the DSSI disk drive rack in the CPU cabinet.

  • Page 172: Dssi Disk Drawer Removal Procedure

    5.4.6 DSSI Disk Drawer Figure 5–7 shows the components in the DSSI disk drawer. Table 5–8 describes the DSSI disk drawer removal procedure. Table 5–8 DSSI Disk Drawer Removal Procedure Step Action Ask the operator or system manager to dismount the drive. Open the rear door of the cabinet.

  • Page 173: Zone Control Panel

    Figure 5–8 Zone Control Panel Captive Screws Zone Control Panel Bracket Signal Cable Controller Module Handle Phillips Screws (6) Captive Screws MR−0023−93RAGS Table 5–9 Zone Control Panel Removal Procedure Step Action Ask the operator or system manager to shut down the zone using the procedure in Section 5.3.2.

  • Page 174: Feu, 3.3V Regulator, 5V Regulator, And Psc Locations

    5.4.8 FEU, 3.3V Regulator, 5V Regulator, PSC Modules You use the same steps to remove these four FRUs. Figure 5–9 shows the locations of the modules. Table 5–10 describes the removal procedure. Figure 5–9 FEU, 3.3V Regulator, 5V Regulator, and PSC Locations +3.3V Regulator +5V Regulator Rear...

  • Page 175: Feu, 3.3V Regulator, 5V Regulator, And Psc Removal Procedure

    Caution Removing/replacing these four modules without shutting down 48V_DRCT may cause damage to the power components. Table 5–10 FEU, 3.3V Regulator, 5V Regulator, and PSC Removal Procedure Step Action Ask the operator or system manager to shut down the zone using the procedure in Section 5.3.2.

  • Page 176: Cross-Link Assembly

    5.4.9 Cross-Link Assembly Figure 5–10 shows the location of the cross-link assembly. Table 5–11 describes the removal procedure. Figure 5–11 shows you how to use the module extraction tool. Figure 5–10 Cross-Link Assembly Rear Upper Retaining Crosslink Module Middle Retaining Crosslink Cable Upper...

  • Page 177: Module Extraction Tool

    Table 5–11 Cross-Link Assembly Removal Procedure Step Action Ask the operator or system manager to shut down the zone using the procedure in Section 5.3.2. Open the rear door of the cabinet. Remove the four screws from the upper retaining bar. Remove the four screws from the middle retaining bar.

  • Page 178: Console Extender Module Location

    5.4.10 Console Extender Module Figure 5–12 shows the location of the console extender module. Figure 5–13 shows the layout of the console extender module. Table 5–12 describes the removal procedure. Figure 5–12 Console Extender Module Location Rear Upper Retaining Console Extender Module Middle...

  • Page 179: Console Extender Module Layout

    Table 5–12 Console Extender Module Removal Procedure Step Action Ask the operator or system manager to shut down the zone using the procedure in Section 5.3.2. Open the rear door of the cabinet. Remove the four screws from the upper retaining bar. Remove the four screws from the middle retaining bar.

  • Page 180: Dssi Extender Module Locations

    5.4.11 DSSI Extender Module Figure 5–14 shows the locations of the DSSI extender modules. Table 5–13 describes the removal procedure. Figure 5–14 DSSI Extender Module Locations Rear Upper Retaining DSSI Extender Modules DIMs Middle Retaining DSSI Cables DSSI Extender Modules DIMs CPU Cabinet MR−0032−93RAGS...

  • Page 181: Dssi Extender Module Removal Procedure

    Table 5–13 DSSI Extender Module Removal Procedure Step Action Ask the operator or system manager to shut down the zone using the procedure in Section 5.3.2. Open the rear door of the cabinet. Remove the four screws from the upper retaining bar. Remove the four screws from the middle retaining bar.

  • Page 182: Camp Module Locations

    5.4.12 CAMP Module Figure 5–15 shows the locations of the CAMP modules. Table 5–14 describes the removal procedure. Caution Removing/replacing the CAMP module without shutting down 48V_DRCT may cause damage to the CAMP module. Figure 5–15 CAMP Module Locations Rear CAMP Module CPU Cabinet...

  • Page 183: Camp Module Removal Procedure

    Table 5–14 CAMP Module Removal Procedure Step Action Ask the operator or system manager to shut down the zone using the procedure in Section 5.3.2. Open the rear door of the cabinet. Set the FEU circuit breaker to the off position. Remove the four screws from the upper retaining bar.

  • Page 184: Dim Location

    5.4.13 DSSI Interface Module (DIM) Figure 5–16 shows the location of the interface logic modules. Figure 5–17 shows how to remove the DIMs. Table 5–15 describes the removal procedure. Figure 5–16 DIM Location Rear Middle Interface Retaining Logic Modules (DIMs and EIMs) Lower Retaining CPU Cabinet...

  • Page 185: Dim Removal

    Figure 5–17 DIM Removal Rear Connector DSSI Cable CPU Cabinet Expansion Cabinet MR−0046−93RAGS Table 5–15 DIM Removal Procedure Step Action Ask the operator or system manager to shut down the zone using the procedure in Section 5.3.2. Open the rear door of the cabinet. Remove the four screws from the middle retaining bar.

  • Page 186: Eim Removal

    5.4.14 Ethernet Interface Module (EIM) Figure 5–16 shows the location of the interface logic modules. Figure 5–18 shows how to remove the EIMs. Table 5–16 describes the removal procedure. Figure 5–18 EIM Removal Rear Ethernet Switch Ethernet Cable Connector Ethernet Cable Terminator CPU Cabinet...

  • Page 187: Eim Removal Procedure

    Table 5–16 EIM Removal Procedure Step Action Ask the operator or system manager to shut down the zone using the procedure in Section 5.3.2. Open the rear door of the cabinet. Remove the four screws from the middle retaining bar. Remove the four screws from the lower retaining bar.

  • Page 188: Tf85C-Ba Tape Drive, Rear View

    5.4.16 TF85C-BA Tape Drive Figure 5–19 and Figure 5–20 show how to remove an TF85C-BA tape drive from the system. Table 5–18 describes the removal procedure. Warning Two people are required to lift and carry the TF85C-BA tape drive enclosure. Figure 5–19 TF85C-BA Tape Drive, Rear View Power Supply Fault Indicator...

  • Page 189: Tf85C-Ba Tape Drive Removal

    Figure 5–20 TF85C-BA Tape Drive Removal Tape Drive Enclosure Release Tab Front Plate Screws (4) Screws (3) TF85 Tape Drive Front Plate M R - 0 0 3 8 - 9 3 D G Table 5–18 TF85C-BA Tape Drive Removal Procedure Step Action Ask the operator or system manager to dismount the tape.

  • Page 190: Sf73 Disk Drive, Rear View

    5.4.17 SF73 Disk Drive Figure 5–21 and Figure 5–22 show how to remove the SF73 disk drives from the system. Figure 5–23 shows how to remove an SF73 disk drive enclosure from the system. Figure 5–24 shows how to remove an SF73 disk ISE from a drive. Table 5–19 describes the removal procedure.

  • Page 191: Sf73 Disk Drive, Front View

    Figure 5–22 SF73 Disk Drive, Front View d i g i t a l Write DSSI DSSI Write Ready Protect Fault Ready Fault Protect C a p t i v e S c r e w s F r o n t C o v e r D o o r C a p t i v e S c r e w s M R - 0 0 3 5 - 9 3 D G...

  • Page 192: Sf73 Disk Drive Enclosure Removal

    Figure 5–23 SF73 Disk Drive Enclosure Removal Retainer Screws Chassis Retainer Mounting Screws Retainer Retainer Screws M R - 0 4 8 4 - 9 2 D G 5–34 Error Handling and Analysis...

  • Page 193: Sf73 Disk Ise Removal

    Figure 5–24 SF73 Disk ISE Removal N O T E T O I L L U S T R A T O R : f r o n t p a n e l f o r t h i s h a r d w a r e i s S H R _ X 1 1 2 7 _ 8 9 I S O L a n d r e d u c e d 1 7 / 6 4 ( .

  • Page 194: Sf35 Storage Array, Rear View

    5.4.18 SF35 Storage Array Figure 5–23 shows how to remove an SF35 storage array from the system. Figure 3–7 and Figure 5–26 show the rear and front views of the SF35 storage array. Figure 5–27 shows how to remove an SF35 disk ISE from the storage array.

  • Page 195: Sf35 Storage Array, Front View

    Figure 5–26 SF35 Storage Array, Front View Operator Control Panel (OCP) F r o n t R e a r F r o n t R e a r R e a d y W r i t e P r o t e c t F a u l t F r o n t R e a r...

  • Page 196: Sf35 Disk Ise Removal

    Figure 5–27 SF35 Disk ISE Removal r i t Carrier Lever Screw Carrier Lever M R - 0 0 3 3 - 9 3 D G Table 5–20 SF35 Storage Array Removal Procedure Step Action Ask the operator or system manager to dismount the disk. Turn off the storage array.

  • Page 197: Tf857-Ca Tape Drive, Rear View

    5.4.19 TF857-CA Tape Drive Figure 5–28 shows how to remove the TF857-CA tape drive from the system. Table 5–21 describes the removal procedure. Warning Two people are required to lift and carry the TF857-CA tape drive enclosure. Figure 5–28 TF857-CA Tape Drive, Rear View DSSI Cable Cable Clip...

  • Page 198: Loosening The Shipping Restraint Screw

    Table 5–21 TF857-CA Tape Drive Removal Procedure Step Action Ask the operator or system manager to shut down the zone using the procedure in Section 5.3.2. Ask the operator or system manager to dismount the tape drive. Unload the tape magazine, if one is present. At the front of the drive, set the power switch to off (0).

  • Page 199: Setting The Tf857 Tape Loader Node Id

    Note If you are replacing the TF857 tape loader, you must set the node ID. Refer to Figure 5–30 for the node ID DIP switch location. Figure 5–30 Setting the TF857 Tape Loader Node ID Node ID DIP Switch Drive Enclosure Controller Module TF857 Tape Drive Assembly...

  • Page 200: Power Distribution Box

    5.4.20 Power Distribution Box Figure 5–31 shows a domestic power distribution box. Figure 5–32 shows an international power distribution box. Table 5–22 describes the removal procedure. Figure 5–31 Domestic Power Distribution Box AC Power Outlets (8) Screws Circuit Breaker AC Power DEC Power Bus Cable Switch...

  • Page 201: Power Distribution Box Removal Procedure

    Figure 5–32 International Power Distribution Box AC Power Outlets (6) Screws AC Power Connector Circuit Breaker DEC Power Bus Switch Access Hole Screws M R - 0 0 4 5 - 9 3 D G Table 5–22 Power Distribution Box Removal Procedure Step Action Turn off any devices connected to the power distribution box.

  • Page 203: Managing Integrated Storage Elements

    Managing Integrated Storage Elements 6.1 In This Chapter This chapter includes: • Loading the DUP driver • Using VMS DUP • Using the server setup switch • Assigning DSSI unit numbers • Warm swapping an ISE 6.2 Loading the DUP Driver If the VMS diagnostic utility protocol (DUP) class driver is not loaded, load it as follows: $ MCR SYSGEN...

  • Page 204: 6.4 Using The Server Setup Switch

    To stop the PARAMS utility, press , or type EXIT at the Ctrl/C Ctrl/Y Ctrl/Z PARAMS prompt. Table 6–1 lists PARAMS commands. Table 6–1 PARAMS Commands Command Description EXIT Stops the PARAMS utility HELP Displays information on how to use PARAMS commands Changes internal ISE parameters SHOW Displays the setting of a parameter or a class of parameters...

  • Page 205: 6.6 Warm Swapping An Ise

    Figure 6–1 VAXft Model 810 Front View Front SF73 Expansion Cabinet SF35 CPU Cabinet MR−0050−93RAGS 6.6 Warm Swapping an ISE Warm swapping is the procedure by which an ISE can be replaced or added to a running system without interrupting system operations. Caution The procedure must be followed carefully.

  • Page 206: Vaxft Model 810 Rear View

    Figure 6–2 VAXft Model 810 Rear View Rear SF73 CPU Cabinet Expansion Cabinet SF35 MR−0051−93RAGS • Replacement in a system that is running • Installation in a system that is running When replacing an ISE or installing a new ISE, determine the parameter values for the ISE before performing the warm swap procedure.

  • Page 207: 6.6.1 Setting Ise Parameters

    6.6.1 Setting ISE Parameters Digital Equipment Corporation recommends maintaining a worksheet of the parameters for all ISEs, as well as the serial number of each ISE. This is especially important at sites that maintain a set of spare drives that may be stored for some time before they are used.
  • Page 208 The node name is shown in parentheses. In the following sample output, the node names are RIRRBA and RICYAA. • ALLCLASS The allocation class is found in the device name between the dollar signs ($). In $1$DIA21, the ISE has an allocation class of 1. If the allocation class was 0, the node name would display as RICYAA$DIA21.

  • Page 209: 6.6.2 Ise Removal

    Owner UIC [000010,000001] Operation count 1116 ORB address 802D6700 00000000 Error count DDB address 804DA680 Alloc. lock ID 00B000E5 Reference count DDT address 80308BD8 Alloc. class 1 Online count VCB address 802E2750 Class/Type 01/38 BOFF 0000 CRB address 8048C250 Def buf. size 512 Byte count 0000 PDT address 802A5F80...

  • Page 210: 6.6.3 Ise Replacement

    Caution You must use an ESD wrist strap, ground clip, and grounded ESD workmat whenever you handle ISEs. Use the static protective service kit (PN 29-262446). Use great care when you handle an ISE; excessive shock can damage the head-disk-assembly (HDA). 1.

  • Page 211: Disabling The Mscp

    1. Disable the MSCP server as described in Table 6–4. Table 6–4 Disabling the MSCP Disks Action RF-series Press and hold the SU switch/button SF72 or SF72- Set the MSCP enable switch series SF35 Press the MSCP/Fault switch (LED is green when enabled) 2.
  • Page 212 For example: $ SET HOST/DUP/SERVER=MSCP$DUP/TASK=PARAMS R1QSAA Return %HSCPAD-I-LOCPROGEXE, Local program executing - type ^\ to exit Copyright (C) 1993 Digital Equipment Corporation PARAMS> SHOW NODENAME Return Parameter Current Default Type Radix ---------- ------------- -------------- ---------- --------- NODENAME R1QSAA RF31 String Ascii PARAMS>...

  • Page 213: 6.6.4 Installing An Ise In A Running System

    Note The SHOW CLUSTER command continues to show the name of the ISE replaced. This does not harm the system. After the next reboot, the replacement ISE name appears. Note also that the following message is displayed if another node is already assigned the same SYSTEMID and NODENAME: %PWA0-REMOTE SYSTEM CONFLICTS WITH KNOWN SYSTEM In this case, shut down the new node and issue a unique SYSTEMID and...
  • Page 214 NODENAME — DISK22 • SYSTEMID — no change • UNITNUM — 22 $ SET HOST/DUP/SERVER=MSCP$DUP/TASK=PARAMS R1QSAA Return %HSCPAD-I-LOCPROGEXE, Local program executing - type ^\ to exit Copyright (C) 1990 Digital Equipment Corporation PARAMS> SHOW NODENAME Return Parameter Current Default Type Radix...
  • Page 215 When initialization is complete, the new ISE and its parameters are made available to the VMS operating system. 8. On SF-series drives, enable the MSCP switch. Note The SHOW CLUSTER command continues to show the name of the ISE you replaced. This does not harm the system. After the next reboot, the new ISE name appears.

  • Page 217: Processor Halt Codes

    Miscellaneous System Information A.1 In This Appendix This appendix includes: • Processor Halt codes • Console Halt codes • Error register descriptions • I/O physical address space • System control block description A.2 Processor Halt Codes Table A–1 provides the processor Halt code definitions. Table A–1 Processor Halt Code Definitions Halt Code Number...

  • Page 218: Processor Halt Reason Code Definitions

    Table A–1 (Cont.) Processor Halt Code Definitions Halt Code Number Definition CPM$K_PSL_EXC7 PSL [26:24] = 111 during interrupt or exception CPM$K_PSL_REI5 PSL [26:24] = 101 during REI CPM$K_PSL_REI6 PSL [26:24] = 110 during REI CPM$K_PSL_REI7 PSL [26:24] = 111 during REI The following example shows a processor Halt code output.

  • Page 219: Console Halt Reason Code Definitions

    Table A–2 (Cont.) Processor Halt Reason Code Definitions Reason Code (Hex) Definition 0016 A VAXELN kernel fatal error has occurred 0017 Initializing VAXELN before starting reconfiguration A.3 Console Halt Codes The following example shows a console Halt code output. Table A–3 defines the Halt Reason fields.

  • Page 220: System Fault Register

    Table A–3 (Cont.) Console Halt Reason Code Definitions Reason Code (Hex) Definition 0015 Unexpected VAXELN error occurred 0016 A VAXELN kernel fatal error has occurred 0017 Initializing VAXELN before starting reconfiguration A.4 Error Register Descriptions A.4.1 System Fault (SYSFLT) Register This register is not rail or zone unique (Figure A–1).
  • Page 221 Table A–4 (Cont.) Xlink Mode Coding Code Mode Resync Slave Resync Master Not Used [27:26]: - Not used. [25]: LCK - Lock. Latched when an error occurs during an interlock I/O access. (Interlock access refers to the special I/O access mode.) [24]: RSA - Resync Abort.
  • Page 222 a two-zone system to diverge. Hardware generates an IPL29 interrupt to both zones within three clock cycles. [12]: MSA - Memory Single-Bit Error (Zone A). Set when a single-bit ECC error is detected in memory during a read and the JXD was not the requester of the data.

  • Page 223: A.4.2 System Error Address (Sysadr) Register

    A.4.2 System Error Address (SYSADR) Register This register latches when any error is detected at the JXD Jet Bus and below (Figure A–2). It contains the address the CPU was accessing at the time the error occurred. The register is read only and cleared by clearing errors. All bits in this register have the following characteristics: default = 0, type = ro, reset = hr.

  • Page 224: A.4.4 Reset Reason 0013 Fault Analysis

    Register Address: CPU = E110 1040 (CCA_BASE+180) [31:30]: DL - DMA data length: 00 - Hexword 01 - Longword 10 - Quadword 11 - Octaword [29:00]: DEA - DMA 30-bit address latched during error. A.4.4 Reset Reason 0013 Fault Analysis The following example shows the content of the SYSFLT and SYSADR registers after a Reset Halt.

  • Page 225: I/O Physical Address Space

    Figure A–4 I/O Physical Address Space E000 0000 CPU Private Space E110 1030 (CCA offset = 15C) SYSADR Register E110 1040 (CCA offset = 160) DMAADR Register 0000 0000 SYSFLT Register E110 1100 (CCA offset = 180) Main Memory EFFF FFFF (512−Mbytes, 30−bit) F000 0000 Reserved for Zone A (M=0)

  • Page 226: System Control Block Base Register

    A.6 System Control Block Description The System Control Block (SCB) contains vectors for servicing interrupts and exceptions. The SCB address should be aligned on a page boundary. The SCB address is contained in the System Control Block Base register (SCBB) (Figure A–5).

  • Page 227: Scb Layout

    Table A–5 (Cont.) Code Field Definition Code Definition The event is to be serviced on the interrupt stack. If the event is an exception, the IPL is raised to 1F (hex). Unimplemented, results in a console error halt. Unimplemented, results in a console error halt. The SCB content is specified in Table A–6.
  • Page 228 Table A–6 (Cont.) SCB Layout Vector Name Type Parameter Notes CHMS Trap Parameter is sign- extended operand word CHMU Trap Parameter is sign- extended operand word Unused — — — Soft error notification Interrupt IPL is 1A (hex) 58 to 5C Unused —...

  • Page 229: B.1 In This Appendix

    ISE Parameter Worksheets B.1 In This Appendix This appendix includes: • Individual ISE parameter worksheets • ISE zone parameter worksheets B.2 Individual ISE Parameter Worksheets Use the following worksheets to record parameters for each ISE. Serial Number: NODENAME: SYSTEMID: ALLCLASS: UNITNUM: FORCEUNI: FORCENUM:...
  • Page 230 Serial Number: NODENAME: SYSTEMID: ALLCLASS: UNITNUM: FORCEUNI: FORCENUM: Serial Number: NODENAME: SYSTEMID: ALLCLASS: UNITNUM: FORCEUNI: FORCENUM: Serial Number: NODENAME: SYSTEMID: ALLCLASS: UNITNUM: FORCEUNI: FORCENUM: MR−0053−93RAGS B–2 ISE Parameter Worksheets...

  • Page 231: B.3 Ise Zone Parameter Worksheets

    B.3 ISE Zone Parameter Worksheets Use the following worksheets to record parameters for each ISE. Serial No: Serial No: NODENAME: NODENAME: UNITNUM: UNITNUM: Serial No: Serial No: NODENAME: NODENAME: UNITNUM: UNITNUM: Serial No: Serial No: NODENAME: NODENAME: UNITNUM: UNITNUM: Serial No: Serial No: NODENAME: NODENAME:...
  • Page 232 Serial No: Serial No: NODENAME: NODENAME: UNITNUM: UNITNUM: Serial No: Serial No: NODENAME: NODENAME: UNITNUM: UNITNUM: Serial No: Serial No: NODENAME: NODENAME: UNITNUM: UNITNUM: Serial No: Serial No: NODENAME: NODENAME: UNITNUM: UNITNUM: Serial No: Serial No: NODENAME: NODENAME: UNITNUM: UNITNUM: Serial No: Serial No: NODENAME:...
  • Page 233 Index Console commands (cont’d) START, 2–19 TEST, 2–20, 3–30 Application of thresholds, 4–17 X, 2–21 ATM module Z, 2–22, 3–31 removal and replacement, 5–7 Console communications area data structures, ATM module deconfiguration actions, 4–13 4–55 Console extender module removal and replacement, 5–20 Controls and indicators Before you begin, 5–3 disk drawer, 3–19...
  • Page 234 Documentation road map, iii FRUs, 4–12 DSSI cable access, 5–5 removal and replacement, 5–29 FTSS event reporting interface, 4–40 DSSI disk drawer removal and replacement, 5–14 DSSI extender module General troubleshooting procedure removal and replacement, 5–22 system maintenance, 3–4 DSSI interface module removal and replacement, 5–26 DUP, 6–1 PARAMS utility, 6–1...
  • Page 235 RF35 disk drive removal and replacement, 5–12 ROM-based diagnostics Page frame number bitmap system diagnostics, 3–29 data structures, 4–65 POST, 3–27 Power distribution box removal and replacement, 5–42 SCB description, A–10 Power distribution boxes Server setup switch, 6–2 system component descriptions, 1–9 Services Power modules, 3–12 error handling, 4–1...
  • Page 236 Threshold information block, 4–26 fault data, 4–30 TK85C-BA cartridge tape drive indicators, 3–27 VAXELN error handling, 4–10 Unit number assignment, 6–2 Warm swapping, 6–3 Unsynchable events fault data, 4–36 Z command system diagnostics, 3–31 5V regulator Zone control panel removal and replacement, 5–16 removal and replacement, 5–14 3.3V regulator system component descriptions, 1–6...

Table of Contents
