the following sdI interfaces are supported (model C):
VIDEO INTERFACE
sd-sdI
Hd-sdI
3G-sdI Level a
3G-sdI Level B-ds
6G-sdI
12G-sdI
VIDEO PLAYOUT FORMATS

SDI OUTPUT FORMATS (MODEL C)

Note: Quad-Link Quadrant mode divides a uHd image into four Hd quadrants or a dCI 4K image
into four dCI 2K Quadrants. this will create four independent Hd-sdI or 3G-sdI Level a streams
depending on framerate.
RESOLUTION FRAMES PER SECOND
720p 23.98 24
1080p 23.98 24
dCI 2K 23.98 24
2160p 23.98 24
dCI 4K 23.98 24
RESOLUTION FRAMES PER SECOND
1080p –
dCI 2K –
2160p 23.98 24
dCI 4K 23.98 24
RESOLUTION FRAMES PER SECOND
2160p 23.98 24
dCI 4K 23.98 24
RESOLUTION FRAMES PER SECOND
2160p –
dCI 4K –
the following sdI interfaces are supported:
VIDEO INTERFACE
Hd-sdI
dual-Link Hd-sdI
Quad-Link Hd-sdI Quadrant
3G-sdI Level a
dual-Link 3G-sdI
Quad-Link 3G-sdI Interleaved
Quad-Link 3G-sdI Quadrant
6G-sdI
12G-sdI
supported formats
SDI COMPLIANCE
smpte 259m
smpte 292m
smpte 424m, smpte 425-1
smpte 424m, smpte 425-1
smpte 2081-10
smpte 2082-10
25 29.7 30
25 29.7 30
25 29.7 30
25 29.7 30
25 29.7 30
– – – –
– – – –
25 29.7 30
25 29.7 30
25 29.7 30
25 29.7 30
– – – –
– – – –
SDI COMPLIANCE
smpte 292m
smpte 372m
smpte 292m
smpte 424m, smpte 425-1
smpte 425-3
smpte 425-5
smpte 424m
smpte 2081-10
smpte 2082-10
SINGLE LINK
– 50 59.94 60
– 50 59.94 60
48 50 59.94 60
– 50 59.94 60
48 50 59.94 60
DUAL LINK
– 50 59.94 60
48 50 59.94 60
– – – –
– – – –
QUAD LINK QUADRANT
– 50 59.94 60
48 50 59.94 60
QUAD LINK INTERLEAVED
– 50 59.94 60
48 50 59.94 60
