CONNECTORS
WATCHPAX 60 model A:
1
1
1
2
DESCRIPTION
CONNECTOR
1
Kensington lock
2
Power inlet IEC 60320 C14 1
3
Power inlet IEC 60320 C14 2
4
USB 3.0 port 1
5
USB 3.0 port 2
6
RJ45 10GbE Ethernet 1
7
RJ45 10GbE Ethernet 2
Currently disabled; reserved for future use.
8
DisplayPort v1.4 - 4
9
DisplayPort v1.4 - 3
10
DisplayPort v1.4 - 2
11
DisplayPort v1.4 - 1
12
Audio input/output VHDCI (to XLR by
break-out cable)
13
Capture card SDI 3G
14
Capture card HDMI 1.4
WATCHPAX 60 MODEL A
1
1
1
3
4
5
Keep clear for ventilation
1
1
1
1
1
1
6
7
8
9
10
11
1
12
Connect the audio cable to the
analog connector on the right
(as indicated by blue here).
1
1
1
12
13
14
25
