- Page 1 INLINE MIXED-FLOW FANS TT PRO User’s manual www.ventilation-system.com...
-
Page 2: Table Of Contents
CONTENTS Delivery set ..........................................6 Brief description ........................................6 Operation guidelines ......................................7 Designation key ........................................8 Installation ..........................................9 Electronics operation algorithm ..................................10 Technical maintenance ......................................12 Storage and transportation regulations ..............................12 Manufacturer’s warranty ....................................13... - Page 3 This user’s manual is a main operating document intended for technical, maintenance, and operating staff. The manual contains information about the purpose, technical details, operating principle, design, and installation of the TT PRO unit (-s) and all of its (their) modifications. Technical and maintenance staff must have theoretical and practical training in the field of ventilation systems and should be able to work in accordance with workplace safety rules as well as construction norms and standards applicable in the territory of the country.
- Page 4 FOLLOW THE USER’S MANUAL REQUIREMENTS TO ENSURE DURABLE AND TROUBLE-FREE OPERATION OF THE UNIT. Disconnect the unit from power supply prior to any connection, servicing, maintenance, and repair operations. Only qualified electricians with a work permit for electrical units up to 1000 V are allowed for installation and maintenance.
- Page 5 • Do not use the unit in a hazardous or explosive environment containing spirits, gasoline, insecticides, etc. • Do not close or block the intake or extract vents in order to ensure the efficient air flow. • Do not sit on the unit and do not put objects on it.
-
Page 6: Delivery Set
– modification with a speed controller with an electronic thermostat, a built-in temperature sensor and a power cord with an IEC C14 connector (Fig. 32). VENTS TT PRO XXX Un (U1 n) – modification with a speed controller with an electronic thermostat, external temperature sensor (4 m long) and a power cord with an IEC C14 connector (Fig. -
Page 7: Operation Guidelines
VENTS TT PRO XXX R1 – modification with a power cord with a plug. – spigot diameter. OPERATION GUIDELINES The fan is rated for connection to single-phase AC 220-240 V/50 (60) Hz power mains. The fan is rated for continuous operation. -
Page 8: Designation Key
DESIGNATION KEY TT PRO Options: timer electronic module with temperature-based operation logic and a temperature sensor integrated into the air duct. Equipped with a power cord with an IEC C14 connector. electronic module with temperature-based operation logic and an external temperature sensor equipped with a power cord with an IEC C14 connector. -
Page 9: Installation
INSTALLATION The fan is suitable both for horizontal or vertical mounting on the floor, on the wall or on the ceiling (Fig. 1). The fan can be installed independently or as part of a set with parallel or in-series connection (Fig. 2). Install minimum 1 m long air duct on the intake spigot side in case of horizontal fan mounting or a hood in case of vertical fan mounting. -
Page 10: Electronics Operation Algorithm
ELECTRONICS OPERATION ALGORITHM TT PRO T fan activates upon control voltage application to an input terminal by an external switch (e.g. indoor light switch). After the control voltage is off, the fan continues to operate within the set time period adjustable from 2 to 30 min by the timer. To adjust the fan turn-off delay time, turn the control knob clockwise to increase and counter-clockwise to decrease the turn-off delay time respectively (Fig. - Page 11 controller set point. The fan runs with the speed set by the speed controller if the temperature drops 2 °C below the set point or if the initial temperature is below the set point. (TT PRO U1) is used for exact air temperature control (the fan changes its speed Timer-based operating logic more frequent as compared to temperature-based logic, but one speed interval continues at least 5 minutes).
-
Page 12: Technical Maintenance
TECHNICAL MAINTENANCE The fan surfaces must be regularly cleaned (once in 6 months) from dirt and dust (Fig. 34-41). Disconnect the fan from power mains prior to any maintenance operations. To clean the fan, use a soft cloth or a brush wetted in a mild detergent solution. -
Page 13: Manufacturer's Warranty
MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Council Directive 2014/30/EU, Low Voltage Directive 2014/35/EU and CE-marking Directive 93/68/EEC. This certificate is issued following test carried out on samples of the product referred to above. - Page 14 • Redesign or engineering changes to the unit. • Replacement and use of any assemblies, parts and components not approved by the manufacturer. • Unit misuse. • Violation of the unit installation regulations by the user. • Violation of the unit control regulations by the user. •...
- Page 15 min 1 m...
- Page 18 TT PRO 100/125 MAX / MIN TT PRO 150/160/200/250/315 MAX / MIN...
- Page 19 TT PRO XXX T TERMINAL BLOCK FOR 5 CONTACTS TERMINAL BLOCK FOR 4 CONTACTS TERMINAL BLOCK FOR 5 CONTACTS TERMINAL BLOCK FOR 4 CONTACTS MAX / MIN TERMINAL BLOCK FOR 5 CONTACTS TERMINAL BLOCK FOR 4 CONTACTS...
- Page 21 STOP...
- Page 22 Speed control knob TT PRO U (U1) TT PRO UN (U1N) Thermostat control knob TT PRO P Speed control knob...
- Page 27 Quality Inspector’s Stamp Sold by (name and stamp of the seller) Manufacture Date Purchase Date...
- Page 28 Certificate of acceptance TT PRO The fan is recognized as serviceable V77EN-03...
