Page 1: User Manual
DediProg User Manual 09/2019 NuProg-F8 eMMC and UFS Gang Programmer and Duplicator User Manual Version 2.0 © DediProg Technology Co., Ltd. 2019 All rights reserved. -
Page 2: Table Of Contents
However, no responsibility is assumed for errors that might appear. DediProg reserves the rights to make any changes to the product and/or the specification at any time without notice. No part of this document may be copied or reproduced in any form or by any means without prior written consent of DediProg. -
Page 3: Introduction
Flag settings. As for eMMC, it supports User Area, Boot1/2 and RPMB read and write, also provides ExtCsd settings, as well as GPP1~4 divisions and Enhance setting. With USB3.0 high speed transmission, Nuprog-F8 is the finest programmer and duplicator for research and development. -
Page 4: System Requirement
NuProg-F8 User Manual III. System Requirement CPU: Intel i5 or Above Windows 7/Windows 8/Windows 8.1/ Windows 10 USB Port: USB 2.0 and USB 3.0 At least double of the programming Free Dish Space: memory. CD ROM: It is necessary for installing the software. -
Page 5: Product Descriptions
NuProg-F8 User Manual IV. Product Descriptions Exterior B. Master Socket Site A. LCD Keypad Panel C. Master Site Operation LED E. Slave Socket Sites D. Duplication Start Button G. Power LED F. Slave Operation LED Fig. 4-1 www.dediprog.com... - Page 6 NuProg-F8 User Manual H. SATA Output Fig. 4-2 I. USB3.0 Port J. Power Connector K. Power Button Fig. 4-3 www.dediprog.com...
- Page 7 The status operation lights for duplication. G. Power LED LED will turn on when NuProg-F8 is powered on. H. SATA Output For daisy chain NuProg-F8 (Please contact DediProg for further information). I. USB3.0 Port For connect the programmer with the computer. J. Power Button K.
-
Page 8: Socket Adaptor Installation
NuProg-F8 User Manual 4.2 Socket Adaptor Installation Insert an IC into a socket adaptor, and then attach to the socket site. Fig. 4-4 www.dediprog.com... -
Page 9: Dediware Quick Installation
NuProg-F8 User Manual V. Dediware Quick Installation The software is provided with the purchase of NuProg-F8. The latest version is available on our website. www.dediprog.com 5.1 Software Installation 5.1.1 Run Dediware Fig. 5-1 www.dediprog.com... - Page 10 NuProg-F8 User Manual 5.1.2 When it is the first time to install NuProg-F8 software, please install the USB Driver. Otherwise, the computer will not be able to recognize the programmer. Fig. 5-2 Fig. 5-3 www.dediprog.com...
- Page 11 NuProg-F8 User Manual 5.1.3 After installation, Dediware and NuProg icons will appear on the desktop. The Dediware icon is for StarProg and ProgMaster series programmer; NuProg is for NuProg-E programmer. StarProg/ProgMaster NuProg-E Fig. 5-4 There is another icon called DediWare_CLI; it is the Command Line software for StarProg Series programmers, and it does not support NuProg series.
-
Page 12: Install Nuprog-F8 Programmer
5.2 Install NuProg-F8 Programmer 5.2.1 Place an IC into a socket adaptor and attach it to the socket site. 5.2.2 Connect NuProg-F8 to the computer (USB 3.0 is recommended). 5.2.3 Once start running the Dediware, it will detect programmer automatically and available for programming. - Page 13 Programmer Information: It shows whether the programmer and the Dediware are connected. NuProg-F8 has master device and slave devices, but when the NuProg-F8 is connected to the PC (USB mode), it can only operate the Master Chip, since the Copy function only works in Standalone mode.
- Page 14 NuProg-F8 User Manual Fig. 5-8 IC Information: Shows the IC manufacturer, model name, memory size, and the number of the corresponding socket adaptor Batch Config Setting: It shows the settings of the copy function CheckSum Data: It shows the project data that were loaded in the Engineering mode.
-
Page 15: Stand Alone Mode
Please follow the below steps: Step 1. After turn on NuProg-F8, the main screen will show the Firmware version and the FPGA version of the master device. When the NuProg Software is not connected to the programmer, user can use the LCD keypad to enter the standalone mode on NuProg-F8. - Page 16 In the Check socket counter, the LCD will display each connected socket counter. Step 3. After select Copy UFS or Copy eMMC, please set up the Batch Setting according to user’s need, press enter to continue, and NuProg-F8 will detect the master IC. www.dediprog.com...
- Page 17 (byte), but the master IC has not, then it might occur copy failure. Step 5. Click enter to the next page, NuProg-F8 will initialize the master chip, after finishing the process, the result will appear on the LCD. It shows details information of the master IC;...
- Page 18 If users do not want to re-scan the master IC, they can select [No] to reduce scanning time, but please note that NuProg-F8 only saves one default config, so if re-scan the master IC, F8 will create another new config file and also cover the old one.
- Page 19 NuProg-F8 User Manual After reviewing the master IC info, press Enter to start initializing and the copy process. Step 6-2-1. If choosing Yes at Step 6, then it will ask for the size range for scan limit setting. www.dediprog.com...
- Page 20 NuProg-F8 User Manual Step 6-2-2. Start scanning the master IC and it will display its result. Step 6-2-3. Next, after reviewing the master IC info, press Enter to start initializing and the copy process. Please also remember that F8 has already saved a new config.
- Page 21 NuProg-F8 User Manual P/N: IC master’s IC part number. Batch: programming operations. Checksum: chip checksum. Total: total counter in this production process. Pass: total pass and each site pass counter in this production process. ...
-
Page 22: Trouble Shooting And Other Questions
Download default vector table: Download a new vector file from NuProg software. There is a standard procedure to upgrade the firmware, please see the following to upgrade: Slave FPGA Master FPGA Slave Firmware Master Firmware Please remember to restart the NuProg-F8 once it has finished updating. www.dediprog.com... - Page 23 NuProg-F8 User Manual Q2. If eMMC IC is not recognizable on the NuProg-F8 when the user has pressed the Detect button, what to do next? Ans. First, please check if the IC model is supported. If it is not supported yet, please contact DediProg, so we can add the new IC model name to the software database.
-
Page 24: Revision
