- Page 1 DediProg User Manual 11/2018 K110 Engineering ICP Programmer User Manual Version 1.1 © DediProg Technology Co., Ltd 2018 All rights reserved.
-
Page 2: Table Of Contents
DediProg. However, no responsibility is assumed for errors that might appear. DediProg reserves the right to make any changes to the product and/or the specification at any time without notice. No part of this document may be copied or reproduced in any form or by any means without prior written consent of DediProg. -
Page 3: Introduction
ISP adaptor and ISP cable to update the IC through the programmer. Please contact with Dediprog for more information about the socket adaptor. K110 can be used for development and production. It provides USB control, stand- alone/offline programming, and ATE integration for programming control in production. -
Page 4: Product Information
K110 Engineering ICP Programmer User Manual II. Product Information Programmer Models K110 StarProg-ATE Function EEPROM/SPI EEPROM/SPI Supported IC Kinds NOR/SPI NAND NOR/SPI FLASH NAND/MCU/CPLD Mini USB Port √ √ Socket Sites √ √(Use with specific ISP/ICP Port √ adaptor) ATE Port X (note1) √... -
Page 5: System Requirement
*When programming large volume ICs (ex. NAND), please reserve enough space for buffering. IV. Product Descriptions 4.1 Exterior A. Start Button B. Operation Lights C. Power Signal Light D. Programming Adaptor A. Start Button Manually trigger to start in the production mode. B. Operation Lights Red LED (Error): Programming has failed. www.dediprog.com... - Page 6 E. Power Connector F. Mini USB Connector E. Power Connector The power inputs for off-line/standalone mode. (Please use the power adaptor that DediProg provided, 5V/1A) F. Mini USB Connector Mini USB connector is for connecting the computer and the programmer when using Dediware.
-
Page 7: K110 Hardware Specifications
Programming Signal Specifications x8. Supported Voltage: 1.2V~3.6V Dual direction Support various programming protocol Provides ESD proection ATE Control Signals for Integration x4 Output: 0-3.3V Pass/Fail/BusySignal. Input: 0-3.3V Start Signal. Embedded Memory: Use 2Gbit Flash (For Standalone). www.dediprog.com... -
Page 8: Related Accessories
K110 Engineering ICP Programmer User Manual 4.3 Related Accessories 4.3.1 Socket Adaptor K110 supports the IC socket adaptors that are designed by Dediprog, which includes SPI NOR Flash, SPI NAND Flash, and EEPROM. For more information, please contact with Dediprog. 4.3.2 Dedicated ICP Socket Adaptor Dediprog provides corresponding ISP adaptor for different IC kinds. -
Page 9: Dediware Quick Installation Guide
V. Dediware Quick Installation Guide The software is provided with the purchase of K110 programmer. 5.1 Software Installation 1. Execute Dediware 2. Follow the instruction to complete the installation, and then a Dediprog icon will appear on the desktop. www.dediprog.com... -
Page 10: Install K110
3. Start programming after the software is open. 5.3 Dediware Setting 1. Double-Click the icon to run the software. 2. Software interface (Make sure the programmer has been detected by the Dediware, please see the below image for reference) www.dediprog.com... - Page 11 K110 Engineering ICP Programmer User Manual 3. Select the IC brand and the part number www.dediprog.com...
- Page 12 K110 Engineering ICP Programmer User Manual 4. Load the programming file. 5. Single Programming Operation www.dediprog.com...
- Page 13 K110 Engineering ICP Programmer User Manual 6. Batch Setup Step1. Set up the Batch Setting in Config Step2. Click Auto batch to start programming www.dediprog.com...
- Page 14 K110 Engineering ICP Programmer User Manual 7. Save and Load the Project File. SavePrj will save the entire select, load, and config settings into a project file (*.dprj). On the other hand, the Load Prj can import the previous project files. www.dediprog.com...
- Page 15 K110 Engineering ICP Programmer User Manual 8. Production Mode Steps Step 1. Choose a project (SelectPrj) Step 2. Run the Project (RunPrj) Step 3. Click the start button when it is available (as shown), and then click StopPrj to stop. www.dediprog.com...
- Page 16 9. Standalone/Offline programming Setting. Only need to save the project file into the programmer’s embedded memory card through Down Prj, and then the programmer only needs to be connected to the external power in order to start programming. (Please refer to Method C and D in VI. Application) www.dediprog.com...
-
Page 17: Applications
“Start from handler” for start mode in the Config window. Step 2: Connect the CLI (Command line) with your production software and import project file to proceed. Please use the CLI that is provided by DediProg. Method C. Standalone Programming (Use start button) - Page 18 “Start from handler” for start mode in the Config window. And use DownPrj to load the project file to the embedded memory. Step2: Connect the external power to K110 (Not connected to USB), only need to press the Start key on the programmer to execute programming. www.dediprog.com...
- Page 19 And use DownPrj to load the project file to the embedded memory. Step2: Connect the external power to K110 (Not connected to USB), only need to press the Start key on the programmer to execute programming. ※ Detail information, please refer to chapter VII. www.dediprog.com...
-
Page 20: K110 External Control Signals
Step 4. Meanwhile, the programmer will begin to program (Busy light will be on). Step 5. After programming, whether it has passed or failed, the related signal will be Hi, and the signal lights will be on according to the result. www.dediprog.com... -
Page 21: Revision History
209 E Baseline RD, Suite E208 #8, Tempe, AZ, 85283, USA Technical Support: support@dediprog.com Sales Support: sales@dediprog.com Information furnished is believed to be accurate and reliable. However, DediProg assumes no responsibility for the consequences of use of such information or for any infringement of patents or other rights of third parties which may result from its use.
