Hull Assembly - Hobie MAX RACE Assembly Manual

Hull Assembly

1
Position the hulls in parallel with the
inner sides fa-cing the ground.Lift
the right hull. One person straddles
the hull tohold it in place. The other
person applies the siliconesealant
(for waterproofing) around the screw
holes.
3
Fasten loosely.
Apply silicone sealant around the screw holes at
theback of the hulls. Place the rear crossbar on the
rightside. Insert the bolts, washers and nuts as
shownfor the front crossbar. Do the same thing for
the leftside.Once the frame has been mounted,
tighten all thebolts fully and then install the lock nuts.
4
Fix the pole to the middle of the front crossbar
5
2
Take the front crossbar (with
dolphin striker). Place itin its
support so that the trampoline
track faces therear of the boat.
Insert the two bolts. Pass
yourhand through the inspection
port to position the nutsand
washers onto the screws photo).
and place the
ground.
It is advisable to check the fastening of the
Do not forget to put the plugs before sailing. On
land take the plugs off to drain the water.
other end on the
