Hobie MAX RACE Assembly Manual page 3

List of the parts
7
8
1
ROPES :
All ropes are labelled with ref.
number and name. Please check
carefully before using.
1. Mainsheet
2. Righting lline
3. Cunningham line (red)
4. Jib halyard
5. Jib line
6. Rotation line
2
3
1
3
6
2
5
8
7
6
10
4
3
4
5
9
2
3
1
Trumpet spi kit
9
1. Spinnaker sheet
2. Spinnaker halyard
3. Tack line
4. Pole fixation line
5. Trampoline rig
6. Trumpet screw
7. Single block for spi head
8. Sister block
9. Shackle 4 mm
10.& 11 2 pole blocks + 2 plastic springs + 2
11
shackles 6 mm.
WIRES :
1. Shrouds
2. Bridles
3. Forestay + pigtail
4. Trapeze cable crew
5. Trapeze cable skipper
6. Rigid forestay
7. Kit trapeze handles skipper
8. Kit trapeze handles crew
9. Spreader wires
5
4
6
