Hobie GETAWAY Owner's Manual

Hobie getaway
Hide thumbs Also See for GETAWAY:
Table of Contents

Advertisement

Quick Links

HOBIE GETAWAY
OWNER'S MANUAL
HOBIE GETAWAY
1

Advertisement

Table of Contents
loading

Related Manuals for Hobie GETAWAY

Summary of Contents for Hobie GETAWAY

  • Page 1 HOBIE GETAWAY OWNER’S MANUAL HOBIE GETAWAY...
  • Page 2 Report any such power lines to your local power authority and sail elsewhere. We take pride in presenting the Getaway to you and hope that you'll take as much pride in ow- ning her.

  • Page 3: Table Of Contents

    HOBIE GETAWAY TABLE OF CONTENT Description of the boat ....................4 Assembling the boat..................... 5 List of the parts ....................5 Hull assembly....................... 6 Main trampoline and front trampolin (option) ............7-8 Mast assembly ..................... 9 Stepping the mast ....................10 Rudder assembly ....................

  • Page 4: Description Of The Boat

    83078 Toulon cedex 9 France Tel +33 (0)494 08 78 78 Fax +33 (0)494 08 13 99 E-mail : info@hobie-cat.net http://www.hobie-cat.net The manufacturing of Hobie Cats conforms to the following ISO norms : ISO 12215-1:2000 Hull construction and scantlings ISO 12217:2000 Stability and buoyancy...

  • Page 5: Assembling The Boat

    LIST OF THE PARTS HOBIE GETAWAY Hulls with hardware (2) Front Crossbar Rear Crossbar Spreader bar (bow) Trampoline + rod Rudder assemblies (right & left) Tiller crossbar Tiller extension Main sail Jib sail Main batten set Mast Rope bag Wire bag...

  • Page 6: Hull Assembly

    HULL ASSEMBLY HOBIE GETAWAY Lay the hulls on the ground, on their sides with bottoms to the center (graphics down), as shown above. A tarpoline or pads under the hull may be desirable if the ground surface is rough. Place the hulls about seven feet apart.

  • Page 7: Main Trampoline And Front Trampolin (Option)

    TRAMPOLINE HOBIE GETAWAY Slide the main trampoline bolt ropes into the hull trampoline tracks. Soapy water can be used as a lubricant (Do not use an oil or silicon lubricant on the trampoline track or the bolt rope). Sliding the bolt rope into the track is a 2 person job.
  • Page 8 LACING THE TRAMPOLINE HOBIE GETAWAY Once the aft lace is tight, begin cinching the center lace tight from forward to aft. You will notice that as you get the trampoline tight you will have more lace line aft to com- plete the lacing.

  • Page 9: Mast Assembly

    MAST SET UP HOBIE GETAWAY WARNING : ALUMINIUM MAST - MAST CONTACT WITH POWER LINE COULD BE FATAL - Watch for overhead power lines. Never rig, trailer or sail the boat near overhead power lines. To step the mast upright, position the mast base next to the mast step ball.

  • Page 10: Stepping The Mast

    STEPPING THE MAST HOBIE GETAWAY WARNING : ALUMINIUM MAST - MAST CONTACT WITH POWER LINE COULD BE FATAL - Watch for overhead power lines. Never rig, trailer or sail the boat near overhead power lines. Ensure that the wires fixed on the mast are well positionned and not twisted.

  • Page 11: Rudder Assembly

    RUDDER ASSEMBLY HOBIE GETAWAY Insert the retainer pins to lock the rud- ders in place. The pins will prevent the rudders from falling off the boat in the event of a capsize. Locate the left rudder (red tap) and the right one (green tap). As shown, line up the rudder pintles (metal pegs on the hulls) with the rudder castings (holes with plastic bushings).

  • Page 12: Mainsail

    MAINSAIL HOBIE GETAWAY Unfold the sail on the trampoline. Insert the battens into the batten pockets. Fasten each batten as shown on the photos above. To tension the battens, pull tension on the line forcing the batten into the pocket and cleat it. Tension each batten so that the wrinkles in the batten pockets are removed, but not excessively otherwise the sail may be more difficult to handle.

  • Page 13: Mainsheet System

    MAINSHEET SYSTEM HOBIE GETAWAY Connect the main sheet block to the traveler car. Attach the shackle that is part of the block through the clevis pin on the traveler car. Hook the mainsheet to the clew grommet at the rear of the main sail.

  • Page 14: Jib

    HOBIE GETAWAY Thread the jib sheet line starting from the eye next to the starboard (right side) swivel cleat. Pass the line through the stainless eye and tie a figure 8 knot. Thread the other end through one of the jib clew blocks and then through the swivel cleat.

  • Page 15: Tips And Safety

    Ambrozijnberg 161 NL-4707 MP Roosendaal, NED Phone : + 31 165 570 223 Fax : + 31 165 570 225 Email: geert.schouten@haveahobieday.com Visit the EHCA web site : http://www.haveahobieday.com to find the location of the Hobie Class association in your country.
  • Page 16 It is essential that for each sold boat, the warranty card be contractor’s charge. completely filled in, signed by the dealer and the customer, and that the copy for Hobie Cat Europe be returned to the fac- What is not covered? tory within 8 days of boat delivery .

  • Page 17: Warranty Conditions

    Owner of the Hobie Cat : HIN : Sail number : I am aware of the warranty conditions of this Hobie catamaran and of all safety tips and warnings contained in this manual. The warranty begins on ........(date) Signature :..........
  • Page 18 HOBIE GETAWAY Manuel written by : HOBIE CAT EUROPE ZI Toulon Est, BP 250, 83078 Toulon cedex 9, France Tel : +33 (0)494 08 78 78 Fax : +33 (0)494 08 13 99 E-mail : hobiecat@hobie-cat.net http://www.hobie-cat.net...
