Hobie 18 Assembly Manual

HOBIE 18 / 18 SX
SCREW
8030601
boW TANg
CASTiNg 60120000
61120001
NUT 8050111
gASKET
61382020
PoP iN
CovER
61380001
fLANgE
61370000
NEWER
ENd SToP
SCREW iN CovER
20260000
WHiTE v1145
SCREW
bLACK v1146
8031501
Jib TRACK
20250000
TRAMP TRACK
LEfT 61320001
RigHT 61330001
dAggERboARd
60300001
HANdLE
RM716 X 2' 6"
SHoCK CoRd
gUdgEoN 50101401
RS014bLK X 4'
dRAiN HoUSiNg
10092000
H18 tRAmpOlInE
CoMPLETE TRAMPoLiNE 6097XXXX
(XXXX = Color / See parts list for available options)
(does not include lace line)
CENTER LACiNg LiNE RH014WHT X 19'
LACiNg STRiP 6378XXXX
56 HOBIE 18 / 18sX
H18 HUll/dECk
EyESTRAP 61510000
original fairlead fastener rivet
no longer available. Latest
production used #10-32 x1/2"
PH screw 8030150. This may
fAiRLEAd
not be a suitable replacement
60270000
for the original rivet due to
hole wear.
TRAPEZE
SHoCK CoRd
ANCHoR PiN
60730001
20100000
dAggER WELL
NUT 8050321
NEoPRENE KiT
60309001
AnCHOR plAtE kIt
64100001
SCREW
8030211
NUT
8050111
WASHER
8080571
EyESTRAP
61510000
LoCK WASHER 8080021
SCREW 8030401
SCREW 8031731
dRAiN PLUg WiTH
gASKET
10091000
AfT LACiNg LiNE RH014WHT X 15' (2)
H18 FWd CROssBAR
CROssBAR WItH stEp CAstInG
BlACk 60132010
LEfT fRoNT CoRNER
CASTiNg bLACK
60150011
NyLoN SCREW
8031031 RigHT fRoNT CoRNER
CASTiNg bLACK
60160011
FROnt InBOARd
sUppORt
CAstInG kIt 61010001
(requires 1 per side)
SQUARE NUT,
CUSToM 61020001
LoCK WASHER
8080581
CHANNEL
61110000
boLT 8040561
H18 REAR CROssBAR
REAR CRoSSbAR - EXTRUSioN oNLy
bLACK 60191211
boLT
8040501
NUT
8050521
CHANNEL
61110000
LEfT REAR CASTiNg
bLACK 60210011
H18 mAIn tRAVElER CAR
TRAvELER
61800001
mAst stEp AssY.
SCREW
BlACk 60180011
8030211
(includes all parts listed within
this box)
WASHER
8080521
(Complete assy required for
older boats with threaded
bEARiNg
posts / casting)
60110000
MAST STEP CASTiNg
bLACK 60170011
CLEAT
10261000
PoST
60140001
Rod 61170001
SLEEvE
61140000
REAR InBOARd
sUppORt
CAstInG kIt 61040001
(requires 1 per side)
LoCK WASHER
SWivEL JAM CLEAT
8080581
50007 SEE PAgE 22
boLT
PAd foR CAM CLEAT
8040521
1162 SEE PAgE 22
RigHT REAR CASTiNg
bLACK 60200011
dEAdEyE 61060001
boLT 8040301
dECK PLATE 61870000
SPACER 61880000
SHEAvE 61890000
NUT 8050311
CAR body SUb ASSy. 61842000
CoTTER PiN 8060121
RoLLER SKid 61810000
bUSHiNg SHAfT 61830000
bEARiNg SET 61852000
CLEviS PiN 8020431
NUT
8050511
boLT
8040501
NUT
8050521
CHANNEL
61110000
