Nilfisk-Advance SW900 Quick Start Manual

Use and Maintenance
- SW900
ATTENTION! Do not use the machine before you have read and understood the Instructions for User Manual
1. Disconnect the battery charger cable
from the electrical main.
6. Drive the machine straight forward.
Adjuting speed depending working
conditions/quantity of debris.
11. Check the main and side broom and
remove any debris like straps, rope
etc..
If the machine has been used until the Red light illuminates on the battery level indicator on the machine, a full recharge of the batteries (10-12 hours) will be required. Failure to carry out this this
procedure may cause damage to the batteries. Charging the batteries after every use is recommended.
PLEASE ENSURE GREY SOCKET IS LEFT DISCONNECTED AFTER RECHARGE IF THE MACHINE IS NOT TO BE USED ON A DAILY BASIS
Nilfisk A/S Tel.: +45 43 23 40 50
Kornmarksvej 1 Fax: +45 43 43 77 00
DK-2605 Brøndby mail.com@nilfisk.com
Denmark www.nilfisk.com
2. Adjust the handlebar by using the
lever
7. Activate the filter shaker switch every
10 min.
12. Remove and clean the dust filter as
indicated into the manual.
3. Turn the ignition key to "I" without
pulling the drive control lever.
8. When operating on wet floors, open
the "wet by-pass" port to avoid
damaging the dust filter. Close the
"wet by-pass" port to restore proper
vacuuming.
13. Clean the machine by using a damp
cloth and where needed use a neutral
cleaning product.
4. Lower the side broom by pulling the
lever backwards.
9. Release the traction lever, lift the side
broom by and turn off the machine
with the ignition key "0".
14. Connect the battery charger cable
to the electrical main
5. Activate the traction by pulling the
lever.
10. Remove the hopper by pulling the
handle and drive it to the area of
disposal and empty it and put the
hopper back on the machine
15. Park the machine into dry and
clean storage area.
