Page 3: Product Safety
PRODUCT SAFETY These instructions are for your safety. Please read the following instructions carefully before proceeding with the installation and use of this applicnce. Keep the instruction manuals for future reference. Warning: All installation work must be carried out by a suitably qualified person, strictly following local building regulations and these instructions. - Page 4 PRODUCT SAFETY ! The oven must be installed in accordance with installation instructions and all dimensions must be followed. ! Before connecting the appliance to the power supply, check that the power supply voltage and current rating correspondings with the power supply details shown on the appliance rating label. ! Never use a damaged appliance! Disconnect the appliance from the electrical outlet and contact your retailer if it is damaged.
-
Page 5: Product Installation
PRODUCT INSTALLATION INSTALLATION All installation must be carried out by a competent person or qualified electrician. Before connecting the mains supply ensure that the mains voltage corresponds to the voltage on the rating plate. DIRECT CONNECTION This appliance must be connected directly to the mains using an omnipolar circuit breaker with a minimum opening of 3mm between contacts. - Page 6 STEAM OVEN AND BUILT-IN DIMENSION See below for full dimensional drawings of the steam oven to help with installation. For a built-in steam oven to work well, the cabinet must be of the right type. The panels of the adjoining furniture should be heat resistant. Particularly when the adjoining furniture is made of veneered wood, the adhesives should be able to withstand a temperature of 120°C.
- Page 7 STEAM OVEN AND BUILT-IN DIMENSION...
-
Page 8: Handling With Care
STEAM OVEN AND BUILT-IN DIMENSION HANDLING WITH CARE... -
Page 9: Fixing & Assembly
ASSEMBLY FIXING & ASSEMBLY... -
Page 10: Before You Start
BEFORE YOU START Switch on the appliance at the switched fused connection unit. The appliance is ready for use. WARNING: Read the instructions before using the appliance. Check the package and make sure you have all of the parts listed. Decide on the appropriate location for your product. This product contains glass, please take care when fitting or handling to prevent personal injury or damage to the product. -
Page 11: Function & Settings
FUNCTION & SETTINGS ADJUSTABLE T°C FUNCTION T°C POWER RANGE OVEN LIGHT DEFROST 20°C ~ 60°C FAN HEAT 200°C 50°C ~ 225°C 1680W FULL GRILL 200°C 50°C ~ 225°C 1450W TURBO GRILL 200°C 50°C ~ 225°C 1480W TURBO GRILL AN STEAM COOKING 120°C 120°C ~ 220°C 2520W... -
Page 12: Suggested Steaming Times
SUGGESTED STEAMING TIMES FOOD TYPE WEIGHT TIME FOOD TYPE WEIGHT TIME Fish 650g 15 min Soup 450g 15 min Crab 500g 25 min 650g (~ 10pcs) 15 min Shrimp 500g 12 min Pumpkin 850g 20 min Chicken leg 650g (~ 5pcs) 30 min Tomato 550g... -
Page 13: Switching On/Off
SWITCHING ON/OFF ON/OFF Power Increase Program Decrease Oven light Temperature (°C) Quick start Timer selection Start / stop Display Zone QUICK START 1) Activate the steam function STEP 1 : Press “ON/OFF” STEP 2: Press “Timer” twice for cooking time STEP 3 : Press “+/-“... - Page 14 HOW TO USE Date / Cooking time / finish time setting • The sequence of cooking time modes will be displayed in the screen as below: • Clock : Pressing “Timer Selection” for 3 seconds, press “+” or “-“ to adjust the time, press “OK” to confirm.
- Page 15 Cooking Functions • Press “Program” to start operating, pressing continuously to select the function that you desire. • The current function will be stopped and cooking time must be reset if new function is selected. • The sequence of the function selection as below. Descaling Function •...
- Page 16 DEMO MODE (For shop use only) To Turn-On Demo Mode: Press “On/Off Power” to turn the oven on (In standby mode). Pressing “Start/stop” during 5 seconds in order the alarm will give a short “beep” for 3 times and will be shown on the top right of the display to confirm the system has entered into the demo mode.
-
Page 17: Oven Accessories
OVEN ACCESSORIES The deep pan and wired shelf have a side edge, these edges can match with the sliding rack on the sides of the cavity. It can prevent the rack or tray from slipping out from the oven. Insert the deep pan and oven sheet on the lateral guides (position 1 – 4 marked) fitted to the oven wall. -
Page 18: Care And Maintenance
CARE & MAINTENANCE CARE • There will be water droplets form on the appliance when it is in use, please wipe. • Only fill water into water tank, and fill up the water tank between “_MIN_” and “_MAX_”. At “_MAX_” fill up level, the steaming can be lasted up to 1 hour and 45 mins. •... -
Page 19: Replacing The Oven Light Bulb
CARE & MAINTENANCE REPLACING THE OVEN LIGHT BULB • Remove all pans and grills from inside the oven to easily access the Iight cover. • Unscrew the glass cover attached to the lamp holder. • Unscrew and remove the old light lamp. Dispose of it safely and ecologically. •... -
Page 20: Troubleshooting
FAQS TROUBLE SHOOTING FAQS SOLUTION What should I do if the oven does not heat Check to see if one of the following actions resolves the issue : The oven may not be switched on. Switch on the oven. ( Switching On/Off). Check to see if the required settings have been applied. - Page 21 WARMING DRAWER D1050BKHK EXCLUSIVE WITH STEAM OVEN D3050BKHK • This appliance is exclusively for home use for heating dishes mainly. • This appliance is equipped with a hot air system. A fan creates excellent distribution of warmth from the drawer heating element. Air circulation heats the dishes evenly and quickly.
- Page 22 WARMING DRAWER D1050BKHK INSTALLATION Make sure that the electrical outlet is easily accessible even after the appliance has been inserted. The warming drawer can only be inserted with other appliances with a maximum weight of 40kg that are provided with adequate cooling ventilation.
-
Page 23: Appliance Controls
WARMING DRAWER D1050BKHK BEFORE THE FIRST TIME USE • When using the appliance for the first time. Clean it as follows: • Clean the surface with a soft cloth and then dry it. • Pre-heat the empty drawer for at least two hours. Turn the temperature knob to the maximum setting, in order to eliminate any residual grease, oil, or manufacturing resins which may cause unpleasant odours during heating. -
Page 24: Temperature Selection
WARMING DRAWER D1050BKHK TEMPERATURE SELECTION The temperature knob lets you select a temperature between approximately 30°C and 75°C. Turn the temperature knob clockwise only, until it reaches it’s stop position (MAX). Do not force it beyond this point, otherwise the thermostat will be damaged. -
Page 25: Care And Cleaning
WARMING DRAWER D1050BKHK CARE AND CLEANING Cleaning operations are to be undertaken only when the machine is disconnected from the electrical mains. The appliance is disconnected from the electrical mains in the following cases: • The main switch of the electrical system is off. - Page 26 WARMING DRAWER D1050BKHK TROUBLE SHOOTING Various factors affect heating time, for example: Material and thickness of dishes, size of load, arrangement of load, temperature setting. Optimal heating times for dishes are subjective. Therefore, it is advisable to determine them on a trial and error basis according to your own perferences.
- Page 27 WARMING DRAWER D1050BKHK NOTES...
- Page 28 Trade Air System Limited 1301-03, Lu Plaza, 2 Wing Yip Street, Kwun Tong, Kowloon, Hong Kong Tel : (852) 2341 4118 | Fax : (852) 3743 5594 | Email : cs@cnagroup.hk WhatsApp or WeChat : (852) 6933 5180 www.nodor.kitchen...
