Summary of Contents for NODOR D 7051 Series
-
Page 3: Product Safety
PRODUCT SAFETY These instructions are for your safety. Please read the following instructions carefully before proceeding with the installation and use of this applicnce. Keep the instruction manuals for future reference. Warning: All installation work must be carried out by a suitably qualified person, strictly following local building regulations and these instructions. - Page 4 PRODUCT SAFETY The oven must be installed in accordance with installation instructions and all dimensions must be followed. Before connecting the appliance to the power supply, check that the power supply voltage and current rating correspondings with the power supply details shown on the appliance rating label. ...
-
Page 5: Product Installation
PRODUCT INSTALLATION INSTALLATION All installation must be carried out by a competent person or qualified electrician. Before connecting the mains supply ensure that the mains voltage corresponds to the voltage on the rating plate. DIRECT CONNECTION This appliance must be connected directly to the mains using an omnipolar circuit breaker with a minimum opening of 3mm between contacts. - Page 6 PRODUCT AND BUILT-IN DIMENSION...
-
Page 7: Handling With Care
PRODUCT AND BUILT-IN DIMENSION 550 Min 85 Min 580 Mín. 560 Min HANDLING WITH CARE... -
Page 8: Fixing & Assembly
ASSEMBLY FIXING & ASSEMBLY... -
Page 9: Before You Start
BEFORE YOU START Switch on the appliance at the switched fused connection unit. The appliance is ready for use. WARNING: Read the instructions before using the appliance. Check the package and make sure you have all of the parts listed. Decide on the appropriate location for your product. This product contains glass, please take care when fitting or handling to prevent personal injury or damage to the product. -
Page 10: Function & Settings
FUNCTION & SETTINGS ICON T °C FUNCTION DESCRIPTION Automatic when selecting the cooking mode for all models. The oven light OVEN LIGHT remains on when using the oven. 160°C CONVECTION MODE Provides traditional cooking with heat from the upper and lower element. 160°C UPPER ELEMENT MODE For gentle cooking, browning or keeping cooked dishes warm. - Page 11 FOOD PROGRAMME AND TEMPERATURE TIME POSITION PREHEAT ACCESSORIES 50 ~ 60 Beef 1.5kg 190°C 210°C 85 ~ 95 Pork 1.5kg 150°C 180°C 40 ~ 50 Lamb 1.5kg 200°C 220°C 115 ~ 125 Turkey 1.5kg 170°C 190°C 50 ~ 60 Chicken 1.5kg 210°C 230°C Roasted red...
-
Page 12: Switching On/Off
SWITCHING ON/OFF Control panel with LCD Full Touch & Display Power Oven function display Function selection Time zone Decreasing / increasing Temperature zone Display Zone Safety child lock symbol Timer selection Alarm symbol Cooking duration time Cancel (countdown) Confirmation End time of clock Lamp symbol Setting the clock When turnning on the oven (and also after any possible power cut) the number “12:00”... - Page 13 seconds, during which time we can select the required time by press or press to start the countdown. The countdown will start immediately. At the end of the time, the indicator will flash and an intermittent sound signal will be triggered, which can be interrupted by press the button. If it is not stopped, it will do automatically after 30 seconds.
- Page 14 Control panel with Push pull knobs and LED Display 10 Cooking mode knob 11 Temperature knob 12 Temperature indicator 13 LED Display Cooking Selection 1. Rotate the cooking mode knob to a desired cooking mode 2. Rotate the temperature knob to a desired cooking temperature 3.
- Page 15 Setting the cooking end time By press three times, set the chosen cooking end time by press or . The cooking will start immediately and appear on the indicator. When the cooking time ends, the cooking will stop and the intermittent sound signal will be heard.
-
Page 16: Oven Accessories
Control panel with 3 knobs automatic stop 10 Cooking mode knob 11 Temperature knob 12 Temperature indicator 13 Timer Cooking Selection 1. Rotate the cooking mode knob to a desired cooking mode 2. Rotate the temperature knob to a desired cooking temperature 3. -
Page 17: Care And Maintenance
CARE & MAINTENANCE CLEANING Before cleaning or performing maintenance, disconnect the oven from the power supply. To extend the life of your oven, it must be cleaned frequently, keep in mind that : Do not use abrasive powders or corrosive substances which could ruin the surfaces. ... - Page 18 CARE & MAINTENANCE OVEN CLEANING SYSTEM EQUIPPED WITH THE AQUACLEAN SYSTEM 1. Take out the internal components: tray, screen, side screens 2. Pour 200ml of soapy water on the bottom of the oven 3. Pressing together for 3 seconds and “AQUA” will be displayed. Pressing to start AQUACLEAN SYSTEM, “AQUA”...
-
Page 19: Replacing The Oven Light Bulb
CARE & MAINTENANCE REPLACING THE OVEN LIGHT BULB Remove all pans and grills from inside the oven to easily access the lamp cover. Unscrew the glass cover and remove the old lamp. Dispose of it safely and ecologically. ... - Page 20 CARE & MAINTENANCE REMOVE THE REAR GLASS FOR CLEANING To simplify cleaning, the rear glass panel can be removed. After loosening 2 screws fixing the side supports of the glass, remove the supports and then the glass panel. (Handle with care!) OR, Press on the indicated points for the extraction of the upper part, and easy access to the internal glasses.
-
Page 21: Troubleshooting
FAQS TROUBLE SHOOTING FAQS SOLUTION What should I do if the oven does not heat Check to see if one of the following actions resolves the issue : The oven may not be switched on. Switch on the oven. ( Switching On/Off). Check to see if the required settings have been applied. - Page 22 Trade Air System Limited 1301-03, Lu Plaza, 2 Wing Yip Street, Kwun Tong, Kowloon, Hong Kong Tel : (852) 2341 4118 | Fax : (852) 3743 5594 | Email : cs@cnagroup.hk WhatsApp or WeChat : (852) 6933 5180 www.nodor.kitchen...
