Lattice iCEblink40-HX1K Quick Start

This document provides a brief introduction and instructions to install and run the
iCEblink 40-HX1K Evaluation Kit on Windows 7/Vista/XP. Please refer to the complete
™
documentation at www.latticesemi.com/iceblink40-hx1k.

Check Kit Contents

The iCEblink40-HX1K Evaluation Kit includes the following items:
• iCEblink40-HX1K Evaluation Board preloaded with capacitive-sense touch-button
demonstration design and USB virtual I/O demonstration
• USB cable
• QuickSTART Guide
Detailed information is provided in the iCEblink40-HX1K Evaluation Kit User's Guide at
www.latticesemi.com/iceblink40-hx1k.
USB Programming,
Debug and Power
Note: Static electricity can shorten the lifespan of electronic components. Please handle
the kit components appropriately.

Download and Install iCEcube2 Development Software

Download and install the iCEcube2
Board and the hardware drivers for Windows at www.latticesemi.com/iCEcube2.
Low Power iCE40 68 User I/O Pins
™
FPGA
design software for the iCEblink40 Evaluation
™
iCEblink40-HX1K
Evaluation Kit
(3.3V)
Capacitive Touch
Buttons
User LEDs
