Lattice ECP5 Quick Start

QuickSTART
This document provides a brief introduction to ECP5 Evaluation Board.
Mini USB
Programming
(J2)
JTAG
Interface (J1)
ECP5-5G
Device (U3)
GPIO
Headers
(J5, J8)
Prototype
Area

Check Kit Contents

1
The ECP5 Evaluation Board kit contains the following items
ECP5 Evaluation Board
„
12V AC/DC Adapter & International Plug Adapters
„
USB Cable for Programming via PC (USB-A to Mini-B)
„
Limited license with unique serial number for Lattice Diamond development software
„
(optional to use).
Quick Start Guide
„

Using the ECP5 Evaluation Board

2
The ECP5 Evaluation Board as shipped supports Master-SPI based configuration.
The external SPI Flash Configuration Memory is pre-loaded with a demonstration
program described below.
SERDES Test
SMA
Connectors
(J9-J26)
Microphone PMOD/
Board/ GPIO
GPIO Header Header
(J30) (J31)
ECP5 Evaluation Board
Parallel Versa
Config Expansion
Header Connectors
(J38) (J39, J40)
GPIO
Headers
(J32, J33)
SPI Flash
Configuration
Memory (U4)
CFG Switches
(SW1)
Input Switches
(SW5)
Output LEDs
(D5-D12)
Input Push
Buttons
(SW2, SW3,
SW4)
12 V DC
Power
Input (J37)
