Replacing Lamp - B-K lighting BACK BOX Installation Instructions Manual

Installation Instructions

REPLACING LAMP

1. Use 1/8" Allen wrench to loosen #10-24 stainless
faceplate screws to remove faceplate.
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
B-K LIGHTING
2. Remove socket assembly from faceplate
housing. Replace lamp, then reinstall socket
assembly into faceplate. Do not exceed
maximum wattage on label.
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX 559.438.5900
www.bklighting.com • info@bklighting.com
BACK BOX
Low Voltage Halogen
3. Mount faceplate using two (2) #10-24 screws with
1/8" Allen wrench. Tighten to compress gasket.
Do not over tighten.
RELEASED REFERENCE NUMBER
7-13-16 INS-1496
