B-K lighting BACK BOX Installation Instructions Manual page 8

Installation Instructions
Phase 1 - Rough In
Installation of Back box
1. Install Conduit (By Others) to be used with
this product.
Phase 2 - Finish Installation of Fixture with Remote Transformer
1. Remove #10-24 Phillips screws from mounted back
box. Install universal mounting ring (supplied with
faceplate) using #10-24 screws onto back box.
Align faceplate mounting holes to final mounting
position.
5 To install lamp (if needed), remove socket assembly
from faceplate housing by loosening thumbscrew.
Do not exceed wattage on label.
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
B-K LIGHTING
Low Voltage Halogen - Thermal Protector & Adjustable Bracket
Additional Info
• Please follow National and Local electrical codes for your area.
• 4" round cast box
• Suitable for through wire.
• Suitable for installation into combustible materials.
• Rated for 90° C.
2. Install junction box so that front face is flush
with finished wall or ceiling.
THERMAL
PROTECTOR
Yellow
Red Black
REMOTE
TRANSFORMER
Red
WIRING DIAGRAM
Low Voltage - For use with 12VAC remote
transformer.
2. Make watertight connections from remote
transformer to thermal protector using
waterproof wire connectors. (By Others) See
wiring diagram.
6. Insert tab from socket into notch on adjustable
lamp bracket, then tighten thumbscrew.
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX 559.438.5900
www.bklighting.com • info@bklighting.com
3. Connect box to conduit and pull wires for
connections (See Wiring diagram).
White
QUICK
DISCONNECT
White
LAMP
3. Connect quick disconnect from thermal protector
to lamp leads.
4. Re-insert socket assembly into faceplate.
7. Mount faceplate using two (2) #10-24 screws
with 1/8" Allen wrench. Tighten to compress
gasket. Do not over tighten.
RELEASED
7-13-16
BACK BOX
REFERENCE NUMBER
INS-1496-AJ-TP
