ADC SL20 Gen II Parts Manual

Phase 7
Hide thumbs Also See for SL20 Gen II:
Table of Contents

Advertisement

Quick Links

Download this manual
SL20 Gen II
Parts Manual
Phase 7
American Dryer Corporation
88 Currant Road
Fall River, MA 02720-4781
Telephone: (508) 678-9000 / Fax: (508) 678-9447
E-mail: techsupport@amdry.com
www.amdry.com
ADC Part No. 450599 - 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL20 Gen II and is the answer not in the manual?

Questions and answers

Related Manuals for ADC SL20 Gen II

Summary of Contents for ADC SL20 Gen II

  • Page 1 SL20 Gen II Parts Manual Phase 7 American Dryer Corporation 88 Currant Road Fall River, MA 02720-4781 Telephone: (508) 678-9000 / Fax: (508) 678-9447 E-mail: techsupport@amdry.com www.amdry.com ADC Part No. 450599 - 2...
  • Page 2 We have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the right to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change or discontinue models.

  • Page 3: Table Of Contents

    Table of Contents Phase 7.3 Non-Coin Top Panel Assembly for Top Control Models ... 4 Phase 7.5 Non-Coin Top Panel Assembly for Top Control Models ... 5 Front Panel Assemblies ... 6 Phase 7.5 Non-Coin Bottom Panel Assembly for Bottom Control Models ... 7 Phase 7.3 Non-Coin Bottom Panel Assembly for Bottom Control Models ...

  • Page 4: Phase 7.3 Non-Coin Top Panel Assembly For Top Control Models

    Phase 7.3 Non-Coin Top Panel Assembly For Top Control Models Illus. No. Part No. Qty. Description 112579 Phase 7 Keypad 137250 Phase 7 Ribbon Cable 137270 Large Character Display 150005 #6-32 x 1/4” Phillips Round Head Machine Screw 153010 #6 Star Washer 887012 Phase 7.3.2 Board with a Fire Suppression System (for models mfd.

  • Page 5: Phase 7.5 Non-Coin Top Panel Assembly For Top Control Models

    Illus. No. Part No. Qty. Description 112580 Phase 7.5 Non-Coin Keypad 153010 #6 Star Washer 150005 #6-32 x 1/4” Phillips Round Head Machine Screw 887020 Phase 7.5 Non-Coin Board with a Fire Suppression System 818463 Non-Coin Top Control Panel 818206 Magnetic Switch 450599 - 2 Phase 7.5 Non-Coin Top Panel Assembly...

  • Page 6: Front Panel Assemblies

    Front Panel Assemblies Illus. No. Part No. Qty. Description 818478 Top Control Panel for Bottom Controls ––––––* – Logo ONLY 818466 Front Bottom Panel Assembly for Top Controls * Contact reseller for logo. American Dryer Corporation 450599 - 2...

  • Page 7: Phase 7.5 Non-Coin Bottom Panel Assembly For Bottom Control Models

    Illus. No. Part No. Qty. Description 112580 Phase 7.5 Non-Coin Keypad 887020 Phase 7.5 Non-Coin Board with a Fire Suppression System 153010 #6 Star Washer 150005 #6-32 x 1/4” Phillips Round Head Machine Screw 818465 Phase 7.5 Non-Coin Bottom Control Panel 450599 - 2 Phase 7.5 Non-Coin Bottom Panel Assembly www.amdry.com...

  • Page 8: Phase 7.3 Non-Coin Bottom Panel Assembly For Bottom Control Models

    Phase 7.3 Non-Coin Bottom Panel Assembly For Bottom Control Models Illus. No. Part No. Qty. Description 112579 Phase 7.3 Keypad 137270 Large Character Display 818436 Non-Coin Bottom Control Panel 150005 #6-32 x 1/4” Phillips Round Head Machine Screw 153010 #6 Star Washer 887012 Phase 7.3.2 Board with a Fire Suppression System (for models mfd.

  • Page 9: Phase 7.3 Coin Top Panel Assembly For Top Control Models

    Illus. No. Part No. Qty. Description 137270 Large Character Display 883774 Optic Switch 153010 #6 Star Washer 150005 #6-32 x 1/4” Phillips Round Head Machine Screw 112579 Phase 7.3 Coin Keypad 137250 Phase 7.3 Ribbon Cable 887011 Phase 7.3.2 Board without a Fire Suppression System (for models mfd.

  • Page 10: Phase 7.3 Coin Bottom Panel Assembly For Bottom Control Models

    Phase 7.3 Coin Bottom Panel Assembly For Bottom Control Models Illus. No. Part No. Qty. Description 137270 Large Character Display 883774 Optic Switch 153010 #6 Star Washer 150005 #6-32 x 1/4” Phillips Round Head Machine Screw 112579 Phase 7.3 Coin Keypad 137250 Phase 7.3 Ribbon Cable 887011...

  • Page 11: Main Door Assemblies

    Illus. No. Part No. Qty. Description 883824 Door Pan with Glass 818832 Door Assembly Complete (right hinge) Stainless Steel (for models mfd. as of October 25, 2004) (includes illus. nos. 1 through 13) 818830 Door Assembly Complete (right hinge) White (for models mfd.

  • Page 12: Middle Front Panel Assembly

    Middle Front Panel Assembly Illus. No. Part No. Qty. Description 102004 Door Magnet 152224 #10-32 x 1/2” Flat Head Spanner Machine Screw 103067 Door Hinge (for models mfd. as of November 20, 2003) 884134 Door Hinge (for models mfd. prior to November 20, 2003) 150321 #10-32 x 1/2”...

  • Page 13: Lint Drawer Assembly For Models Mfd. As Of July 29, 2005

    Illus. No. Part No. Qty. Description 183129 #10-32 x 1/2” TORX 170168 Brush 818801 Lint Drawer 819345* Lint Drawer Assembly Complete (includes illus. nos. 1 through 7) 819344* Cold Rolled Steel Lint Drawer Handle 819287 Lint Drawer Handle Fastening Plate Assembly 185226 Black Lint Screen Handle Molded 150334...

  • Page 14: Lint Drawer Assembly For Models Mfd. Prior To July 29, 2005

    Lint Drawer Assembly For Models Mfd. prior to July 29, 2005 Illus. No. Part No. Qty. Description 883751 Stainless Steel Lint Drawer Handle (includes illus. nos. 1 through 5 and 8) 883859 Black Cold Rolled Steel Lint Drawer Handle (includes illus. nos. 1 through 5 and 8) 818166 Lint Drawer Complete with Stainless Steel Handle (includes illus.

  • Page 15: Tumbler Assembly For Models Mfd. As Of May 2004

    Illus. No. Part No. Qty. Description 115906 Tumbler Felt 401010 Adhesive for Felt Collar (5 oz. tube) … Not Illustrated 102004 Rotational Sensor Magnet 884363 Tumbler Assembly Complete 154217 1/8” x 1/2” Pop Rivet 150123 1/4-20 x 1/4” Socket Button Head Cap Screw 318784 Tumbler Shaft 153048...

  • Page 16: Tumbler Assembly For Models Mfd. Prior To May 2004

    Tumbler Assembly For Models Mfd. prior to May 2004 Illus. No. Part No. Qty. Description 884359 Tumbler Assembly (includes illus. nos. 1 through 6) 318242 5” Tapered Rib 150313 #10-16 x 1/2” TORX PLUS 154217 1/8” x 1/2” Pop Rivet 102102 Rotational Sensor Magnet 115906...

  • Page 17: Rear Support Panel Assembly

    Illus. No. Part No. Qty. Description 818608 Rear Felt Pad with Shims and Pop Rivets 318695 Junction Box (for models mfd. as of August 21, 2003) 318628 Junction Box (for models mfd. prior to August 21, 2003) 318629 Electric Cover 150300 #10-16 x 1/2”...

  • Page 18: Front Tumbler Wheel Assemblies

    Front Tumbler Wheel Assemblies Illus. No. Part No. Qty. Description 150510 1/4-20 x 3/4” Hex Head Machine Bolt 154264 M10 x 25mm Shoulder Screw 153007 1/4” Lock Washer 153002 5/16” Lock Washer 154013 M8 Hex Nut 154284 Tumbler Wheel Spacer 818183 Front Right Wheel Assembly Complete (includes illus.

  • Page 19: Rear Tumbler Wheel Assemblies

    Illus. No. Part No. Qty. Description 150510 1/4-20 x 3/4” Hex Head Machine Bolt 154264 M10 x 25mm Shoulder Screw 153007 1/4” Lock Washer 153002 5/16” Lock Washer 154013 M8 Hex Nut 154284 Tumbler Wheel Spacer 818110 Rear Left Wheel Assembly Complete (includes illus.

  • Page 20: Fire Suppression System Piping Assembly

    Fire Suppression System Piping Assembly Illus. No. Part No. Qty. Description 143581 3/8” N.P.T. Spray Nozzle 143303 3/8” N.P.T. Brass Locknut 136987 Pressure Switch 143025 3/4”-11.5 NH x 3/8” N.P.T. Hose Adaptor 143155 3/8” Brass Street Elbow 165114 Solenoid Valve 24V 50/60 Hz 143315 3/8”...

  • Page 21: Temperature Sensor Assemblies

    Illus. No. Part No. Qty. Description 818207 Tumbler Temperature Sensor Probe (includes illus. nos. 1 through 3) 122646 2-Pin Plug 122691 Socket Terminal 883821 Fire Suppression System Temperature Sensor Probe Assembly Complete (includes illus. nos. 4 through 8) 122646 2-Pin Plug 122691 Socket Terminal 318525...

  • Page 22: Motor Drive Assembly

    Motor Drive Assembly Illus. No. Part No. Qty. Description 818200 Motor Base Plate (with studs) 153002 5/16” Lock Washer 154321 5/16” x 3/8” Allen Setscrew 152004 5/16-18 Hex Nut 153001 5/16” Flat Washer 887091 Motor with Sheave (60 Hz models) 887090 Motor with Sheave (50 Hz models) 318247...

  • Page 23: Hot Surface Ignition Burner Assembly

    Illus. No. Part No. Qty. Description 130500 Radiant Sensor 142631 3/8” x 2” Bi-Pipe Nipple 142633 3/8” Street Elbow 142635 3/8” 45° Street Elbow 154356 U-Bolt for 3/8” Pipe 183139 Hot Surface Ignition Igniter Bracket 183140 3/8” N.P.T. Male 90° Pipe 183141 Hot Surface Ignition Burner Base 183143...

  • Page 24: Direct Spark Ignition Burner Assembly

    Direct Spark Ignition Burner Assembly American Dryer Corporation 450599 - 2...
  • Page 25 Illus. No. Part No. Qty. Description 143226 1/2” Brass Street Elbow 141317 1/2” Bronze Union Elbow 128927 Gas Valve 128933 (CE) Gas Valve 140868 #31 Burner Orifice (natural gas) 40K Btu Burner 140869 #49 Burner Orifice (liquid propane gas) 40K Btu Burner 883610 Liquid Propane Conversion Kit (includes orifice) 40K Burner 140870...

  • Page 26: Lint Box / Blower Motor Assembly

    Lint Box / Blower Motor Assembly American Dryer Corporation 450599 - 2...
  • Page 27 Illus. No. Part No. Qty. Description 818207 Temperature Sensor Probe Assembly (refer to Temperature Sensor Assemblies on page 21) 100623 25 M.F.D. 440V Capacitor (for use with 120V blower) 100633 6 M.F.D. 440V Capacitor (for use with 220V blower) 318230 Capacitor Bracket (for use with 25 M.F.D.

  • Page 28: Electric Oven Assembly

    Electric Oven Assembly Illus. No. Part No. Qty. Description 131368 25A 25V Contactor with Lugs 153022 #10 Flat Washer 153024 #10 Split Lock Washer 318543 Electric Oven Housing 120086 Element Bank 130400 290° Thermostat 150300 #10-16 x 1/2” Hex Washer Screw 152008 #10-32 Hex Nut 818525...

  • Page 29: Blower Assembly

    Illus. No. Part No. Qty. Description 883826 Motorized Impellor 120V ONLY (refer to Blower Motor Assembly on page 30) 883827 Motorized Impellor 240V ONLY (refer to Blower Motor Assembly on page 30) 318446 Blower Housing Mount 150300 #10-16 x 1/2” Hex Washer Screw 154338 M4 x 6mm Phillips Head Slotted Machine Screw 152008...

  • Page 30: Blower Motor Assembly

    Blower Motor Assembly Illus. No. Part No. Qty. Description 883826 120V Motorized Impellor with Plug (includes illus. nos. 1 through 4) 883827 240V Motorized Impellor with Plug (includes illus. nos. 1 through 4) 121000 1/4” x 0.032 Uninsulated Terminal 122622 4-Pin Plug 122705 Socket Terminal...

  • Page 31: Front Electrical Panel Assembly

    Illus. No. Part No. Qty. Description 131932 24V SPST Relay 818347 Front Electrical Panel Complete (120V) (includes illus. nos. 1 through 12) 818348 Front Electrical Panel Complete (240V) (includes illus. nos. 1 through 12) 818284 Universal Transformer Assembly (120V or 240V) 114506 Fuse Rating Label 318620...

  • Page 32: Sail Switch Assembly

    Sail Switch Assembly Illus. No. Part No. Qty. Description 154002 1/8” Push-On Fastener 318490 Sail Switch Damper (flat) 3-1/4” Diameter (for models mfd. as of January 21, 2004) 332689 Sail Switch Damper (flat) 2-1/2” Diameter (for models mfd. prior to January 21, 2004) 150309 #10-16 x 1/2”...

  • Page 33: Base / Top / Sides / Back Guard Assemblies

    Illus. No. Part No. Qty. Description 318643 Back Guard 318634 Gas Pipe Pocket 150300 #10-16 x 1/2” Hex Washer TEK Screw 318629 Junction Box Cover 103501 Leveling Leg 152014 1/4-20 Free Spin Wash Nut 818564 Hooked Base (for models mfd. as of January 31, 2004) 818479 Slide Base (for models mfd.

  • Page 34: Pedestal Box Option

    Pedestal Box Option Illus. No. Part No. Qty. Description 818169 Dryer Pedestal American Dryer Corporation 450599 - 2...

  • Page 35: Additional Parts Available

    Part No. Description 112014 “Warning – High Voltage” Label 112046 Computer Ground 112057 24 Volt Controls 112075 1/2” Diameter Ground Symbol 112093 Motor Rotation (red) 112280 “Clean Lint Screen” Label 112704 Phase 7.3.2 Program Location Summary Label 114001 “Caution – Combustible Lint” Label 114004 Rotating Parts 114005...
  • Page 36 ADC Part No. 450599 2 - 10/23/08 - 0...
